Sharp EL-377T Manual de usuario
ELECTRONIC CALCULATOR
电子计算器
EL-377T
OPERATION MANUAL 操作手册
• Do not press too hard against the LCD panel
because it contains glass.
• Never dispose of the battery in a fire.
• Keep battery out of reach of children.
• Please press if you see no indication.
• This product, including accessories, may
change due to upgrading without prior notice.
• Since this product is not waterproof, do not
use it or store it where fluids, for example
water, can splash onto it. Raindrops, water
spray, juice, coffee, steam, perspiration, etc.
will also cause malfunction.
Type: Electronic calculator
Operating capacity: 10 digits
Power supply: Built-in solar cell and
lithium battery (3V ...
(DC) CR2016 × 1)
Automatic Power-off: Approx. 7 min.
Operating temperature: 0°C - 40°C (32°F-104°F)
Dimensions: 70 mm (W) × 117 mm
(D) × 8.4 mm (H) 2-3/4"
(W) × 4-19/32" (D) ×
11/32" (H)
Weight: Approx. 52 g (0.11 lb.)
(battery included)
Accessories: Lithium battery
(installed), Operation
manual
PRINTED IN CHINA / 中国印刷
09BT(TINSZ1473EHZZ)
ENGLISH
BEFORE USE
SPECIFICATIONS
SHARP will not be liable nor responsible for any incidental or consequential economic or property
damage caused by misuse and/or malfunctions of this product and its peripherals, unless such liability
is acknowledged by law.
• LCD 面板内含玻璃，所以请不要用力挤压
LCD。
• 请绝对不要将电池投入火中。
• 请将电池放置在小孩所能接触范围之外。
• 如果没有任何显示，请按 。
• 本产品及其附件会因升级而变化，恕不提前通
知。
• 因为产品不防水，请不要在液体（如水）能溅
到的地方使用或保存。雨滴、喷水、果汁、咖
啡、蒸汽、汗水等也会造成产品故障。
类型： 电子计算器
计算能力： 10 位数字
电源： 内置太阳能电池和锂电池 (3V ...
(DC) CR2016 × 1)
自动关机： 约7 分钟
工作温度： 0°C - 40°C (32°F-104°F)
尺寸： 70 mm (W) × 117 mm (D) × 8.4
mm (H) 2-3/4" (W) × 4-19/32" (D)
× 11/32" (H)
重量： 约52 g (0.11 lb.)
（包括电池）
附件： 锂电池
（已安装），操作手册
中文
使用之前
规格
夏普对本产品和其外设因误用和（或）故障而导致的附带或间接经济或财产损坏不承担义务或责任，除
非法律规定有此义务。
0GS9216180////
OPERATIONS 操作
1. Press twice to clear any residual values and calculation instructions in the calculator.
2. Before starting memory calculations, press twice to clear the memory contents.
3. For expressing calculation examples, only the symbols that are required for explanation are
mentioned.
4. Example procedures are listed in following manner unless otherwise specified.
(1) Example (2) Key operations (3) Display
1. 按两次清除计算器内任何数值和计算指令。
2. 如果开始记忆计算，请按 两次清除内存信息。
3. 对于表达式计算示例，只有对需要解释的符号才会说明。
4. 示例步骤按如下方式列举，除非另有说明。
(1) 示例 (2) 关键运算 (3) 显示
HOW TO PERFORM BASIC CALCULATIONS /
如何执行基本计算
• In these display examples, symbols such as “=”and “+”, “–”, “×”, “÷”which are visible on the actual
display are omitted.
• 在这些显示示例中，在显示屏实际出现的符号（如“=”、“+”、“–”、“×”和“÷”）会被忽
略。
)3()2()1(
0.
(–24+2)÷4=–5.5 24 2 4
–5.5
34+57=91 34 57
91.
45+57=102 45
102.
38–26=12 38 26
12.
35–26=9 35
9.
68×25=1700 68 25
1’700.
68×40=2720 40
2’720.
35÷14=2.5 35 14
2.5
98÷14=7 98
7.
200×10%=20 200 10
20.
(9÷36)×100=25 009 36
25.
200+(200×10%)=220 200 10
220.
4
6
=(4
3
)
2
=4096 4
4’096.
1/8=0.125 8
0.125
25 ×05 = 125 25 15
125.
–) 84 ÷ 03 = 028 84 03
28.
+) 68 + 17 = 085 68 17
85.
182 00
182.
00
182.
2+3 →2+4=6 2 3 4
6.
5×2→5÷2=2.5 5 2
2.5
9876543212÷0.444 9876543212 0.444
2.2244466 69
×555 555
1’234.567901
=1234.567901×10
10
(
1234.567901×10
10
=12345679010000
)
M
M
M
M
E
EL-377T(U1U)-1①
CALCULATING TAX / 计算税率
• To perform a tax calculation, first it is absolutely necessary to set and check the tax rate. (The initial
tax rate is 0.)
A tax rate can be set (or changed) with a number containing up to four digits. (Decimal point is not
regarded as a digit.)
The set tax rate is retained until it is changed. However, the set tax rate may be changed or lost if the
battery is consumed largely.
• 要执行税率计算，首先当然需要设置和检查税率。（初始税率设置为 0）。
税率可以使用最多4位数字设置（或更改）。（小数点不作为数字。）
设置的税率会一直保留到下次更改。但是，如果电池基本耗尽，设置税率也会更改或丢失。
(1) • Confirming the tax rate. (0%)
• 确认税率。（0%）
(1) • Set a 5% tax rate. Calculate the
tax on $800 and calculate the total
Including tax.
• 设置 5% 税率。对 $800 计算税率，
计算连税值。
(1) • Perform two calculations using
$84 and $52.5, both of which
already include tax. (tax rate: 5%)
Calculate the tax on the total and
the total without tax.
• 对$84 和$52.5 执行计算，两者
均已含税。（税率：5%）
计算税费总额和去税总额。
(2) (3)
)3()2(
5
800
)3()2(
84 52.5
EL-377T(U1U)-2①
BATTERY REPLACEMENT
电池更换
For USA only:
This product contains a CR Coin Lithium Battery which contains Perchlorate Material – special
handling may apply, California residents, See www.dtsc.ca.gov/hazardouswaste/perchlorate/
