Why the AR-M355N/M455N …

Targeted for busy mid-volume environments, the

AR-M335N/M445N Digital Multifunctional IMAGERs

offer powerful Multitasking, Advanced Application

Integration and Leading Edge Security. The base

model is comprised of a newly engineered 300 MHz

Multi-tasking Controller, an integrated PCL6

Network Printing System, and 40 GB Hard Disk

Drive that include Sharp’s Document Filing System

combined with a Duplex Single Pass Document

Feeder (DSPF) and on-line paper capacity of up to

3100 sheets.

Each of the host machines is available in three

different configurations:

Package A, AR-M355NA / AR-M455NA

Package B, AR-M355NB / AR-M455NB

Package C, AR-M355NC / AR-M455NC

Base N Model machines include 35/45 PPM engine,

300 MHz multitasking controller, 128 MB memory,

PCL6 printing system, 40 GB hard disk drive (with

document filing), 500-sheet letter size tray, USB2

port, IEEE parallel port, and RJ-45 network

interface.

The AR-M335N/M445N Digital

Multifunctional IMAGER

Features

935/45 ppm print speed

9True multi-tasking engine controller

950-sheet Duplex Single Pass Feeder

9Document filing system

9Permanent Font and Form storage

9Carbon Copy Print mode

9Auto Duplexing on stocks up to 97 lb. index

9IP/MAC Address Filtering (secure NIC card)

9LDAP support with optional Network Scanner

Expansion Kit

9Standard IEEE 1284 and USB 2.0 ports

9New Card Shot feature (copies both sides of

an ID card onto a single sheet of paper)

Scan2 Technology

The new technology enables users to scan both

sides of a 2-sided document in one pass, auto-

duplex documents on paper stocks up to 97 lbs

Index, and offer an array of convenience

features.

Quick Reference Guide: AR-M355N/M455N

Performance, Flexibility,

Productivity, and Security

Powerful Network Connectivity

300 MHz PCL6 Printing System

40 GB Hard Drive

Network Tandem Printing

Flexible Network Scanning

Ability to end to 6 different destinations

allows for a truly digital workflow

¾Send to Desktop

¾Sent to E-mail

¾Send to FTP

¾Send to Group

¾Send to FAX

¾Send to I-FAX

Professional Finishing

Two-Tray Finisher

Saddle-Stitch Finisher

Mail Bin Stacker

Scalable Security Offerings

Confidential Print Feature

User Authentication (E-mail)

IP/MAC Address Filtering

Data Security Kit (128 bit

encryption)

Description: Features & Options

Quick Reference Guide: AR-M355N/M455N

Pre-Setup: Tools, Documentation, & Admonitions

Toolbox Basics

Mechanical

• Screwdriver, Phillips #2

• Screwdriver, Flat #1

• Wrench, 1.5mm Hex head

• Feeler gauges

Electrical

• Voltmeter

• ESD wrist or ankle strap

• Approved surge suppressor

• 30x lighted viewing device

Miscellaneous

• Clean, soft, lint-free cloths

• Alcohol

Special Tools & Service Documentation

Electrical/Electronic Component

Admonitions

WARNING: Electrical hazard.

Employ proper precautions when

working with high-voltage electrical

equipment.

CAUTION: Improper handling of

electronic components can damage

the equipment.

Properly ground and wear an

electro-static device (ESD) on your

wrist or ankle when working with

electronic modules. Similarly, use

anti-static bags to protect electronic

components during storage or

shipping.

Material Safety Data Sheets

(MSDSs)*

* Download MSDSs at http://www.sharp-service.com

Laser Admonition

For your protection, do

not remove protective

covers or bypass safety

interlocks.

SM-AR-FN6*AR-FN7, Saddle Stitch Finisher

SM-AR-MS1*AR-MS1, Mail-bin Stacker

SM-AR-FN7*AR-FN6, Finisher

SM-AR-D28*AR-MU2, Multi-purpose Drawer

SM-AR-D28*AR-D28, Stand/MPD & 2000 Sheet Paper Drawer

SM-AR-D28*AR-D27, Stand/3 x 500 Sheet Paper Drawer

N/A

*AR-TE3, Exit Tray

*AR-TE5, Exit Tray/Cabinet

SM-AR-DU3*AR-DU3/DU4, Duplex Unit

SM-ARC355N/ARM455N

Code: 00ZARM455NA1E

AR-M355N/AR-M455N, Service Manual, Circuit Diagram,

and Parts Guide

Part NumberDescription

* Optional equipment

n/aDrumAR-455DR

F-31331Developer (Black)AR-455MD

F-01331Toner cartridge

(Black)

AR-455MT

MSDS

No.

DescriptionProduct Code

Quick Reference Guide: AR-M355N/M455N

Basic System Configuration

System configuration

Basic system

AR-M355N/AR-M455N

(Copier/Network printer model)

Necessary options:

Any one of the stand/MPD & 2000

sheet paper drawer (AR-D28), the

stand/3x 500 sheet paper drawer (AR-

D27), or the multi-purpose drawer

(AR-MU)*

Any one of the upper exit tray

extensions (AR-TE4 or AR-TE5), the

finisher (AR-FN6), the mail-bin stacker

(AR-MS1)

AR-EF3

AR-RK2

* To install the AR-MU2, the exclusive use desk is required.

Quick Reference Guide: AR-M355N/M455N

Optional Equipment

Option lineup

Major options

AR-

FX12

Fax expansion kit11

AR-MS1Mail-bin stacker10

AR-FN6Finisher9

AR-FN7Saddle stitch finisher8

AR-DU3Duplex module7

AR-DU4Duplex module/bypass tray6

AR-TE3Exit tray5

AR-TE4

AR-TE5

Upper exit tray extension

or Cabinet exit tray

AR-MU2Multi-purpose drawer3

AR-D27Stand/3 x 500 sheet paper drawer2

AR-D28Stand/MPD & 2000 sheet paper drawer1

ModelOption NameNo.

Exit Tray/Cabinet

(AR-TE5)

Quick Reference Guide: AR-M355N/M455N

Adjustment and Simulation

Adjustment Checklist Simulation

Note: For detailed instructions, refer to Section 8

of the AR-M355N/M455N Service Manual.

Entering the Simulation Mode

1. Copy mode key ON →Program key ON →Asterisk (*) key

ON →CLEAR key ON →Asterisk key ON →Ready for

input of a main code of simulation

2. Entering a main code with the 10-key →START key ON

3. Entering a sub-code with the 10-key →START key ON

4. Select an item with the scroll key and the item key.

5. The machine enters the mode corresponding to the

selected item.

a) Press START key or EXECUTE key to start

the simulation operation.

b) To cancel the current simulation mode or to

change the main code or the sub code, press

the user setup key.

*Canceling the simulation mode to return to the

normal mode:

Simulation List

Please refer to the Simulation List (pages 1 through 10) that follows.

6. Press CA key.

Quick Reference Guide: AR-M355N/M455N

Simulation List (Pg. 1 of 10)

Simulation List (Main/Sub)

Used to set the warm-up time display YES/NO.8

Used to set the intermittent aging cycle.6

Used to set the operating conditions of aging.17

Used to check the operations of each fan motor and its control circuit.2

Used to check the operation of the paper transport system loads and the control circuit.16

Used to check the operation of the heater lamp and the control circuit.2

Used to check the operation of the display, LCD in the operation panel and control circuit.15

Used to check the operations of the loads in the paper feed section (desk paper feed/large capacity tray) and the related circuit.3

Used to check the operations of the sensors and detectors in the paper feed section (desk paper feed/large capacity tray) and

the related circuit.

Used to check the operations of the mail bin stacker loads.21

Used to check the mail bin stacker sensor.20

Console finisher (AR-FN7) adjustment.10

Used to adjust the stacking capacity of the finisher. (Used to adjust the alignment plate [jogger] stop position in the finisher

paper width direction. The adjustment is made by changing the alignment plate home position in the paper width direction by

software.)

Used to check the operation of the load in the finisher and the control circuit.3

Used to check the operation of sensor and detector in the finisher and the related circuit.23

Used to check the operations of the loads in the automatic document feeder unit and the control circuits.3

Used to check the operations of the sensors and detectors in the automatic document feeder unit and the related circuits.2

Used to check the operations of the automatic document feeder unit and the control circuit.12

Used to check the operation of sensor and detector in the scanning (read) section and the related circuit.2

Used to check the operations of the scanner (read) unit and its control circuit.11

SubMain

Function (Purpose)Code

Used to check the system configuration (options, internal hardware).10

Used to check the number of use (print quantity) of each paper feed section.9

Used to check the number of use of the finisher, the SPF, and the scan (reading) unit.8

Used to display the key operator code. (This simulation is used when the customer forgets the key operator code.)7

Used to output the list of the setting and adjustment data (simulations, FAX soft switch, counters).6

Used to check the ROM version of each unit (section).5

Used to check the trouble (self-diag) history.4

Used to check misfeed positions and the misfeed count of each position. (if the misfeed count is considerably great, it may be

judged as necessary to repair.)

Used to check the total numbers of misfeed and troubles. (When the number of misfeed is considerably great, it is judged as

necessary for repair. The misfeed rate is obtained by dividing this count value with the total counter value.)

Used to check the print count value in each section an each operation mode. (Used to check the maintenance timing.)122

Used to set the maintenance cycle.121

Used to cancel the PF troubles (when the copy inhibit command from the host computer is received).017

Used to cancel the self-diag U2 troubles.016

Used to cancel the self-diag “U6-01, 02, 03, F3-12, 22” (large capacity paper feed tray, paper feed trays 1, 2) troubles.015

Used to cancel excluding the self-diag U1/LCC/U2/PF troubles.014

Used to cancel the self-diag “U!” trouble. (Only when FAX is installed.)013

Used to check the operations of the toner motor and the related circuit.110

Used to check the operations of the sensors and detectors in the duplex section and its control circuit.2

Used to check and adjust the operation of the load (clutch/solenoid) in the duplex section and the control circuit.19

Used to check and adjust the operation of the transfer voltage and the related circuit. (Transfer belt cleaning mode.)17

Used to check and adjust the operation of the transfer voltage and the control circuit.6

Used to check and adjust the operation of the main charger grid voltage in each printer mode and the control circuit.2

Used to check and adjust the operations of the developing voltage of each color and the control circuit.18

Quick Reference Guide: AR-M355N/M455N

Simulation List (Pg. 2 of 10)

Simulation List (Main/Sub)

Used to make the initial setting of toner concentration when replacing developer.2

Used to check the operations of the developing section (toner concentration, humidity and toner concentration sensor, humidity

sensor, temperature sensor output can be monitored.)

125

Used to clear the counters related to the scan mode and the internet FAX mode.15

Used to reset the OPC drum rotation time, and the DV unit rotation time counter. ; The developer counter in the DV unit installed

Is reset.

Used to clear the FAX counter. (Only when FAX is installed.)10

Used clear the printer mode print counter and the self print mode print counter.9

Used to clear the OPC drum counter. (Perform this simulation when the OPC drum is replaced.)7

Used to reset the copy counter.6

Used to reset the developer counter. (The developer counter of the DV unit which is installed is reset.)5

Used to reset the maintenance counter.4

Used to clear the number of use of the finisher, SPF, and the scan (reading) unit.3

Used to clear the number of use (the number of prints) of each paper feed section.2

Used to clear the misfeed counter, the misfeed history, the trouble counter and the trouble history. The counters are cleared

after completion of maintenance.)

1`24

Used o check the operations of the sensors and detectors in the paper feed and transport sections.80

Used to check the trouble history of paper jam and misfeed. (If the number of misfeed and troubles is considerably great, it may

be judged as necessary to repair.)

223

Used to check the values of the counters related to the scan mode and the internet FAX mode.19

Used to check the operating time of the process section (OPC drum, DV unit, toner bottle).13

Used to check the SPF misfeed positions and the number of misfeed at each position. (When the number of misfeed is

considerably great, it can be used as necessary for repair.)

Used to check the use frequency (send/receive) of FAX. (Only when FAX is installed.)1122

Quick Reference Guide: AR-M355N/M455N

Simulation List (Pg. 3 of 10)

Simulation List (Main/Sub) (cont’d)

Quick Reference Guide: AR-M355N/M455N

Simulation List (Pg. 4 of 10)

Simulation List (Main/Sub) (cont’d)

Used to check the output level of the temperature sensor and the humidity sensor.14

Used to check the data related to the image forming section correction (process correction) result (corrected main charger grid

voltage, the developing bias voltage, and the laser power voltage in each print mode). (This simulation allows to check that

correction is performed normally or not.)

Used to set enable/disable of correction operations in the image forming (process) section.144

Used to set the fusing temperature in each operation mode.143

Used to check the operation of the document size sensor and the related circuit. (The document size sensor output level can be

monitored with the LCD display.)

Used to adjust the document size sensor sensing level.2

Used to check the operation of the document size sensor and the related circuit. (The operation of the document size sensor

can be monitored with the LCD display.)

141

Used to check the multi-purpose tray width detection adjustment value.12

Used to check the multi-purpose tray width detection adjustment value.11

Used to enter the manual paper feed tray paper width adjustment value.7

Used to adjust the manual paper feed tray paper width detector detection level.2

Used to check the operation of the manual feed tray paper size detector and the related circuit. (The operation of the manual

feed tray paper size detector can be monitored with the LCD display.

140

Used to check the operation of sensors and detectors in the paper feed section and the related circuits.2

Used to check the operation of sensors and detectors in other than the paper feed section and the operations of the related

circuits.

130

Used to set YEZ/NO of toner save operation. (This function is valid only in Japan and UK versions. [Depends on the destination

setting of SIM26-6.] For the other destinations, the same setting can be made by the user program P22.)

Used to set the network scanner trial mode.10

Used to set the specifications (paper, document detection, etc.) of the destination.6

Used to set the count mode of the total counter and the maintenance counter.5

Used to set the specification of the auditor. Setting must be made according to the auditor use conditions.326

Used to adjust sharpness of the copy mode.31

Used to adjust the gamma (density gradient) of the network scanner mode.27

Used to adjust the scanner exposure level in the ultra fine text mode.25

Used to adjust the scanner exposure level (in the super fine text mode).24

Used to adjust the scanner exposure level in the fine text mode.23

Used to adjust the scanner exposure level in the normal text mode.22

Unused to adjust the scanner exposure level in all the scanner modes.21

Used to adjust the copy density correction into eh SPF copy mode for the document table copy mode. The adjustment is made

so that the copy density becomes the same as that of the document table copy mode.

Used to set the auto mode operation specifications in ach mode (copy, scan, FAX).19

Used to adjust the gamma (density gradient) in the copy mode.18

Used to set the gain in shading correction.17

Used to adjust the print density in the FAX mode (each ultra fine mode). (Only when FAX is installed.)16

Used to adjust the print density in the FAX mode (each super fine mode). (Only when FAX is installed.)15

Used to adjust the print density in the FAX mode (each fin mode). (Only when FAX is installed.)14

Used to adjust the print density in the FAX mode (each normal mode). (Only when FAX is installed.)13

Used to adjust the print density into eh FAX mode (all models).12

Used to adjust the print density for each density level (display value) in the copy mode (binary-Photo m ode). An optional print

density can be set for each density level (display value).

Used to adjust the print density for each density level (display value) in the copy mode (binary-Text mode). An optional print

density can be set for each density level (display value).

Used to adjust the copy density in all the copy modes (Auto, Text, Text/Photo, and Photo mode.246

Used to check the toner concentration control data.16

Used to check the output level of the temperature sensor and the humidity sensor.1444

Quick Reference Guide: AR-M355N/M455N

Simulation List (Pg. 5 of 10)

Simulation List (Main/Sub) (cont’d)

Otros manuales para AR-M355N

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Impresora todo en uno de Sharp

Sharp

Sharp MX-5000N Manual de usuario

Sharp

Sharp MX-M264U N Manual de usuario

Sharp

Sharp FO-3800M Instrucciones de construcción

Sharp

Sharp AL-2051 Guía

Sharp

Sharp AR-M237 IMAGERs Manual de usuario

Sharp

Sharp Advanced MXM365N Manual de usuario

Sharp

Sharp MX-2314N Manual de usuario

Sharp

Sharp DX-C401 - Color Laser - All-in-One Manual de usuario

Sharp

Sharp FO-4700 Manual de usuario

Sharp

Sharp MX-4500N Manual de usuario

Sharp

Sharp MX-M753U Manual de usuario

Sharp

Sharp AR-168N Manual de usuario

Sharp

Sharp MX-M1100 Manual de usuario

Sharp

Sharp MX-B402 Manual de usuario

Sharp

Sharp AR-C260 Instrucciones de instalación y mantenimiento

Sharp

Sharp MX-4100N Manual de usuario

Sharp

Sharp AR-F15 Manual de usuario

Sharp

Sharp AR-M256 Manual de usuario

Sharp

Sharp MX-M182 Manual de usuario

Sharp

Sharp MX-6240N Manual de usuario

Sharp

Sharp MX-C301 Manual de usuario

Sharp

Sharp MX-M1204 Manual de usuario

Sharp

Sharp AR-203E X Manual de usuario

Sharp

Sharp MX-M314N Manual de usuario

Manuales populares de Impresora todo en uno de otras marcas

Triumph Adler

Triumph Adler DC 2016 Manual

Epson

Epson WorkForce WF-2510 Guía del usuario

Epson

Epson Stylus Scan 2000 Manual de instalación y operación

Epson

Epson PictureMate Snap PM 240 Manual de instrucciones

Konica Minolta

Konica Minolta bizhub C35 Manual de usuario

Brother

Brother MFC-J430w Manual de usuario

Konica Minolta

Konica Minolta BIZHUB 558 Manual de usuario

Lexmark

Lexmark MX710 Series Manual

Brother

Brother MFC-9760 Manual de usuario

Lexmark

Lexmark XC8155 Manual de usuario

Lexmark

Lexmark X642E Manual de usuario

Aficio

Aficio 200 Manual de usuario

Canon

Canon ImageCLASS 2300 Manual

Ricoh

Ricoh Pro C900 Manual de usuario

Lexmark

Lexmark X925 Manual de usuario

Brother

Brother Business Smart MFC-J4510dw Manual de usuario

Epson

Epson Stylus CX8400 Series Manual de usuario

Oce

Oce VarioLink 5022 Manual de usuario
