DIGITAL MULTIFUNCTIONAL

SYSTEM

OPERATION MANUAL

AL-1556

AL-1566

MODEL

The CE mark logo label is affixed on an equipment in case that the directives described in the

above sentence are applicable to the product. (This sentence is not applicable in any country

where the above directives are not required.)

In some areas, the "POWER" switch positions are marked "I" and " " on the copier

instead of "ON" and "OFF".

If your copier is so marked, please read "I" for "ON" and " " for "OFF".

Caution!

For a complete electrical disconnection, pull out the main plug.

The socket-outlet shall be installed near the equipment and shall be easily

accessible.

This equipment complies with the requirements of Directives 89/336/EEC and 73/23/EEC as amended by

93/68/EEC.

Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 89/336/EWG und 73/23/EWG mit Änderung

93/68/EWG.

Ce matériel répond aux exigences contenues dans les directives 89/336/CEE et 73/23/CEE modifiées par la

directive 93/68/CEE.

Dit apparaat voldoet aan de eisen van de richtlijnen 89/336/EEG en 73/23/EEG, gewijzigd door 93/68/EEG.

Dette udstyr overholder kravene i direktiv nr. 89/336/EEC og 73/23/EEC med tillæg nr. 93/68/EEC.

Quest’ apparecchio è conforme ai requisiti delle direttive 89/336/EEC e 73/23/EEC, come emendata dalla

direttiva 93/68/EEC.

Este equipamento obedece às exigências das directivas 89/336/CEE e 73/23/CEE, na sua versão corrigida

pela directiva 93/68/CEE.

Este aparato satisface las exigencias de las Directivas 89/336/CEE y 73/23/CEE, modificadas por medio de

la 93/68/CEE.

Denna utrustning uppfyller kraven enligt riktlinjerna 89/336/EEC och 73/23/EEC så som kompletteras av

93/68/EEC.

Dette produktet oppfyller betingelsene i derektivene 89/336/EEC og 73/23/EEC i endringen 93/68/EEC.

Tämä laite täyttää direktiivien 89/336/EEC ja 73/23/EEC vaatimukset, joita on muutettu direktiivillä

93/68/EEC.

Do not make copies of anything which is prohibited from copying by law. The

following items are normally prohibited from copying by national law. Other

items may be prohibited by local law.

●Checks ●Passports ●Driver's licenses

●Money ●Stamps ●Bonds ●Stocks ●Bank drafts

CAUTIONS................................................................................................................ 3

ENVIRONMENTAL INFORMATION ......................................................................... 5

INTRODUCTION....................................................................................................... 6

MAIN FEATURES ..................................................................................................... 7

1PREPARATIONS

PART NAMES ................................................................................................... 9

CHECKING PACKED COMPONENTS AND ACCESSORIES ....................... 12

PREPARING THE MACHINE FOR INSTALLATION ...................................... 13

INSTALLING THE TD CARTRIDGE ............................................................... 14

POWER ON AND OFF.................................................................................... 16

2LOADING PAPER

PAPER ............................................................................................................ 18

LOADING THE PAPER TRAY ........................................................................ 19

BYPASS FEED (including special paper)........................................................ 21

CHANGING A TRAY'S PAPER SIZE SETTING ............................................. 23

3MAKING COPIES

NORMAL COPYING........................................................................................ 24

SELECTING THE TRAY ................................................................................. 27

MAKING A COPY DARKER OR LIGHTER..................................................... 28

REDUCTION/ENLARGEMENT/ZOOM ........................................................... 29

4CONVENIENT COPY FUNCTIONS

AUTOMATIC TWO-SIDED COPYING ............................................................ 30

SORT COPY ................................................................................................... 33

COPYING MULTIPLE ORIGINALS ONTO A SINGLE SHEET OF PAPER

(2 IN 1 copy) .................................................................................................... 35

CREATING MARGINS WHEN COPYING (Margin shift)................................. 38

5SET UP THE SOFTWARE

SOFTWARE FOR AL-1556/1566 .................................................................... 40

BEFORE INSTALLATION ............................................................................... 41

INSTALLING THE SOFTWARE ...................................................................... 42

SETTING UP BUTTON MANAGER ................................................................ 55

CONTENTS

6PRINTER/SCANNER FUNCTIONS

USING THE PRINTER MODE ........................................................................ 60

BASIC PROCEDURE FOR PRINTING ........................................................... 60

USING THE SCANNER MODE....................................................................... 61

SCANNING USING THE KEYS ON THE MACHINE ...................................... 61

SCANNING FROM YOUR COMPUTER ......................................................... 62

OPERATION IN COPY, PRINTER, AND SCANNER MODES ....................... 62

HOW TO USE THE ONLINE MANUAL........................................................... 63

7USER SETTINGS

USER PROGRAMS......................................................................................... 64

SELECTING A SETTING FOR A USER PROGRAM...................................... 69

8TROUBLESHOOTING AND MAINTENANCE

DISPLAY MESSAGES .................................................................................... 71

TROUBLESHOOTING THE MACHINE........................................................... 73

PROBLEMS DURING SETUP THE SOFTWARE........................................... 77

MISFEED REMOVAL ...................................................................................... 80

TD CARTRIDGE REPLACEMENT.................................................................. 85

DRUM CARTRIDGE REPLACEMENT............................................................ 86

CHECKING THE TOTAL COUNT AND DRUM CARTRIDGE LIFE................ 87

CLEANING THE MACHINE ............................................................................ 88

ABOUT SUPPLIES AND OPTIONS................................................................ 91

9APPENDIX

SPECIFICATIONS........................................................................................... 92

SOFTWARE LICENSE.................................................................................... 96

MATERIAL SAFETY DATA SHEET................................................................ 98

INDEX............................................................................................................ 106

CAUTIONS

Caution label on the machine

The label ( ) in the fusing area of the machine indicates the following:

: Caution, risk of danger

: Caution, hot surface

Cautions on using the machine

Follow the cautions below when using this machine.

Warning:

• The fusing area is hot. Exercise care in this area when removing misfed paper.

• Do not look directly at the light source. Doing so may damage your eyes.

• Do not switch the machine rapidly on and off. After turning the machine off, wait 10

to 15 seconds before turning it back on.

• Machine power must be turned off before installing any supplies.

Caution:

• Place the machine on a firm, level surface.

• Do not install the machine in a humid or dusty location.

• When the machine is not used for a long time, for example for consecutive

holidays, turn the power switch off and remove the power cord from the outlet.

• When moving the machine, be sure to turn the power switch off and remove the

power cord from the outlet.

• Do not cover the machine with a dust cover, cloth or plastic film while the power is

on. Doing so may prevent heat radiation, damaging the machine.

• Use of controls or adjustments or performance of procedures other than those

specified herein may result in hazardous radiation exposure.

• The socket-outlet shall be installed near the machine and shall be easily

accessible.

Important points when selecting an installation site

Do not install your machine in areas that are:

• damp, humid, or very dusty

• exposed to direct sunlight

• poorly ventilated

• subject to extreme temperature or humidity changes, e.g., near an air conditioner

or heater.

Be sure to allow the required space around the

machine for servicing and proper ventilation. 20cm (8")

10cm

(4") 10cm

(4")

Cautions on handling the machine

Be careful in handling the machine as follows to maintain the performance of this

machine.

Do not drop the machine, subject it to shock or strike it against any object.

Do not expose the drum cartridge to direct sunlight.

• Doing so will damage the surface (green portion) of the drum cartridge, causing

smudges on copies.

Store spare supplies such as drum cartridges and TD cartridges in a dark

place without removing from the package before use.

• If they are exposed to direct sunlight, smudges on copies may result.

Do not touch the surface (green portion) of the drum cartridge.

• Doing so will damage the surface of the cartridge, causing smudges on copies.

Cautions on laser

Trademark acknowledgements

•Microsoft

®Windows®operating system is a trademark or copyright of Microsoft

Corporation in the U.S.A. and other countries.

• Windows®95, Windows®98, Windows®Me, Windows NT®4.0, Windows®2000,

and Windows®XP are trademarks or copyrights of Microsoft Corporation in the

U.S.A. and other countries.

• IBM and PC/AT are trademarks of International Business Machines Corporation.

• Acrobat®Reader Copyright

1987- 2002 Adobe Systems Incorporated. All rights

reserved. Adobe, the Adobe logo, Acrobat, and the Acrobat logo are trademarks of

Adobe Systems Incorporated.

• All other trademarks and copyrights are the property of their respective owners.

Wave length 770 nm –795 nm

Pulse times 10.24 µs / 7 mm

Output power 0.17 mW ± 0.01 mW

ENVIRONMENTAL INFORMATION

As an ENERGY STAR®Partner, SHARP has determined that

this product meets the ENERGY STAR®guidelines for energy

efficiency.

A small amount of ozone is produced within the unit during operation. The

emission level is insufficient to cause any health hazard.

Note:

The present recommended long term exposure limit for ozone is 0.1ppm

(0.2mg/m3) calculated as an 8hr. time-weighted average concentration.

However, since the small amount that is emitted may have an objectionable odor, it

is advisable to place the unit in a ventilated area.

USB 2.0 compatible

When connecting the machine by USB 2.0 (Hi-Speed mode),

be sure to read "System requirements for USB 2.0 (Hi-Speed

mode)" (p.59) to verify that your system and the machine

settings are configured appropriately.

INTRODUCTION

Using the manual

This machine has been designed to provide convenient copying features in a

minimum amount of office space and with maximum operational ease. To get full use

of all machine features, be sure to familiarize yourself with this manual and the

machine. For quick reference during machine use, keep this manual in a handy

location.

About the operation manuals

The operation manuals for the machine are as follows:

Operation Manual (this manual)

Explains the machine and how to use it as a copier. Also explains how to install the

software that allows the machine to be used as a printer and scanner for your

computer.

Online Manual (on the accessory CD-ROM)

This manual explains the procedures for using the machine as a printer or a

scanner.

Operation Manual (for facsimile) (for models that have the fax function)

This manual explains the procedures for using the machine as a fax machine.

Conventions used in this manual and online manual

• The illustrations in this manual show the AL-1556. The appearance of your

machine may be different depending on the model and options installed, however,

the basic operations are the same.

• Where "AL-XXXX" appears in this manual, please substitute the name of your

model for "XXXX". For the name of your model, see the operation panel on the

machine.

• Illustrations of driver screens and other computer screens show the screens that

appear in Windows XP Home Edition. Some of the names that appear in these

illustrations may differ slightly from the screens that appear in other operating systems.

• The explanations in this manual assume that the person who will install the product

and the users of the product have a working knowledge of Microsoft Windows.

• This operation manual refers to the Reversing Single Pass Feeder as the "RSPF".

• In this manual, the following icons are used to provide the user with information

pertinent to the use of the machine.

Some model may not be available in some countries.

Warns that injury may result if the contents of the warning are

not properly followed.

Cautions that damage to the machine or one of its components may

result if the contents of the caution are not properly followed.

Notes provide useful information on the specifications, functions,

performance, and operation of the machine.

Note

Warning

Caution

Note

MAIN FEATURES

High-speed laser copying

First-copy time*1at 300 dpi*2is only 9.6 seconds.

Copying speed is 15 copies per minute. This is ideal for business use and provides a

big boost to workplace productivity.

*1First-copy time may vary depending on the power-supply voltage, ambient

temperature, and other operating conditions.

*2"dpi" ("dots per inch") is unit that is used to measure resolution. Resolution

indicates how much detail can be reproduced in a printed or scanned image.

High-quality digital image

• High-quality copying at 600 dpi is performed.

• In addition to automatic exposure adjustment, two original modes can be selected:

"TEXT" for text-only originals, and "PHOTO" for photographs. The exposure can be

adjusted to five levels in each mode.

• The photo mode copying function allows clear copying of delicate halftone original

images such as monochrome photos and color photos.

Enhanced copying features

• Zoom copies can be made from 25% to 400% in increments of 1%. (When the

RSPF is being used, the zoom copy ratio range is 50% to 200%.)

• Continuous copying of up to 99 copies is possible.

• Sets of output can be offset from each other for easy separation (offset function).

• Sorting by sets is possible without the need for a sorter or other special device

(Sort copy).

• Includes convenient features such as margin shift, 2 IN 1 copy, and automatic two-

sided copying.

Scan once/Print many

• The machine is equipped with a memory buffer allowing the machine to scan an

original once and make up to 99 copies of the scanned image. This improves

workflow, reduces operating noise from the machine and reduces wear and tear on

the scanning mechanism, which provides for a higher reliability.

LCD panel displays messages

The LCD panel displays messages that show function settings and the status of the

machine.

Margin shift

Sort copy Offset function 2 IN 1 copy

Laser printer function

• Printer function

The accompanying printer driver can be installed to enable use of the machine as a

printer.

• Network printer function

A LAN connector is provided as a standard feature that allows the machine to be

used as a network printer.

Color scanner function

• The accompanying scanner driver can be installed and the machine connected to

a computer using a USB cable to enable use as a scanner.

Environment and people friendly design

• Preheat mode and auto power shut-off mode are provided to reduce power

consumption when the machine is not in use.

• A universal design has been implemented in the product whereby the height of the

operation panel and shape of the keys are designed to be usable by as many

people as possible.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Impresora todo en uno de Sharp

Sharp

Sharp MX-6201N Series Manual de usuario

Sharp

Sharp MX-B381 Manual de instalación y funcionamiento

Sharp

Sharp MX-2010U Manual de usuario

Sharp

Sharp MX-6240N Manual de usuario

Sharp

Sharp AR-203E X Manual de usuario

Sharp

Sharp MX-2314N Manual de usuario

Sharp

Sharp AL-841 Manual de usuario

Sharp

Sharp MX-2314N Manual de usuario

Sharp

Sharp AR-M256 Manual de usuario

Sharp

Sharp MX-M905 Manual de usuario

Sharp

Sharp MX-3640N Manual

Sharp

Sharp AR-M150 Online Manual de usuario

Sharp

Sharp MX-M350-U Manual de usuario

Sharp

Sharp MX-M182 Manual de usuario

Sharp

Sharp AL-1651CS Manual de usuario

Sharp

Sharp MX-2700N Guide Manual de usuario

Sharp

Sharp MX 5500N - Color Laser - Copier Manual de usuario

Sharp

Sharp AR-M256 Manual de usuario

Sharp

Sharp MX-2300N Guide Manual de usuario

Sharp

Sharp AR-C260 Manual de usuario

Sharp

Sharp MX-M753 Manual de usuario

Sharp

Sharp AR-208S Manual de usuario

Sharp

Sharp FO-2150 Manual de usuario

Sharp

Sharp AL-2030 Manual de usuario

Manuales populares de Impresora todo en uno de otras marcas

Triumph Adler

Triumph Adler DC 2016 Manual

Epson

Epson WorkForce WF-2510 Guía del usuario

Epson

Epson Stylus Scan 2000 Manual de instalación y operación

Epson

Epson PictureMate Snap PM 240 Manual de instrucciones

Konica Minolta

Konica Minolta bizhub C35 Manual de usuario

Brother

Brother MFC-J430w Manual de usuario

Konica Minolta

Konica Minolta BIZHUB 558 Manual de usuario

Lexmark

Lexmark MX710 Series Manual

Brother

Brother MFC-9760 Manual de usuario

Lexmark

Lexmark XC8155 Manual de usuario

Lexmark

Lexmark X642E Manual de usuario

Aficio

Aficio 200 Manual de usuario

Canon

Canon ImageCLASS 2300 Manual

Ricoh

Ricoh Pro C900 Manual de usuario

Lexmark

Lexmark X925 Manual de usuario

Brother

Brother Business Smart MFC-J4510dw Manual de usuario

Epson

Epson Stylus CX8400 Series Manual de usuario

Oce

Oce VarioLink 5022 Manual de usuario
