AH-A07BE-C/09BE-C

AH-A07BE/09BE/12BE

AY-A07BE-C/09BE-C

AY-A07BE/09BE/12BE

INDOOR UNIT

AH-A07BE/A09BE/A12BE

AH-A07BE-C/A09BE-C

AY-A07BE/A09BE/A12BE

AY-A07BE-C/A09BE-C

OUTDOOR UNIT

AU-A07BE/A09BE/A12BE

AU-A07BE-C/A09BE-C

AE-A07BE/A09BE/A12BE

SHARP CORPORATION

TABLE OF CONTENTS Page

SPECIFICATIONS .............................................................................................................................................2

EXTERNAL DIMENSIONS ................................................................................................................................4

WIRING DIAGRAMS .........................................................................................................................................6

ELECTRICAL PARTS........................................................................................................................................9

MICROCOMPUTER CONTROL SYSTEM ......................................................................................................13

FUNCTIONS ....................................................................................................................................................17

TROUBLESHOOTING OF THE CONTROL CIRCUIT ....................................................................................24

REFRIGERATION CYCLE ..............................................................................................................................29

PERFORMANCE CURVE ...............................................................................................................................31

DISASSEMBLING PROCEDURE....................................................................................................................33

REPLACEMENT PARTS LIST ........................................................................................................................41

SERVICE MANUAL

S4216AYA09BE/

SPLIT SYSTEM

ROOM AIR CONDITIONERS

In the interests of user-safety (Required by safety regulations in

some countries) the set should be restored to its original

condition and only parts identical to those specified should be

used.

MODELS

AH-A07BE-C/09BE-C

AH-A07BE/09BE/12BE

AY-A07BE-C/09BE-C

AY-A07BE/09BE/12BE

SPECIFICATIONS

ITEMS

INDOOR UNIT OUTDOOR UNIT INDOOR UNIT OUTDOOR UNIT

AY-A07BE AE-A07BE AY-A07BE-C AE-A07BE-C

Cooling capacity kW 2.1

Heat pump kW 2.4

Heating capacity

Moisture removal Liters/h 0.7

Electrical data

Phase – Single

Rated frequency Hz 50

Rated voltage range V 198 to 264

Rated voltage V 220 - 240

Rated current Cool A 3.1 - 3.0

Heat A 2.9 - 2.8

Rated input Cool W 650 - 690

Heat W 600 - 640

Power factor Cool % 95 - 96

Heat % 94 - 95

Compressor Type Hermetically sealed rotary type

Model QK134PA13A RH135VHST

Oil charge 300cc (SUNISO 4GSI) 300cc (DIAMOND MS56)

Refrigerant system

Evaporator Louver fin and Bare tube type

Condenser Corrugate fin and Grooved tube type

Control Capillary tube

Refrigerant volume 700g 650g

De-Ice system Micro computercontroled reverse systyem

Noise level High dB(A) 33 43 33 43

(at cooling) Med. dB(A) 29 – 29 –

Low dB(A) 27 – 27 –

Fan system

Drive Direct drive

Air flow quantity High m3/min. 7.2 21 7.2 21

Med. m3/min. 6.0 – 6.0 –

Low m3/min. 4.8 – 4.8 –

Fan Cross flow fan Propeller fan Cross flow fan Propeller fan

Connections

Refrigerant coupling Flare type

Refrigerant tube size Gas, Liquid 3/8", 1/4"

Drain piping mm O.D ø 18

Others

Safety device Compressor: Overload protector Compressor: Overload protector

(Internal)

Fan motor: Thermal fuse

Fuse, Micro computer control

Air filters Polypropylene net (Washable)

Net dimensions Width mm 815 720 815 720

Height mm 278 535 278 535

Depth mm 198 236 198 236

Net weight kg 9 30 9 30

Note: The condition of star( ) marked item are 'ISO5151' : 1994(E), condition T1.

AH-A07BE-C/09BE-C

AH-A07BE/09BE/12BE

AY-A07BE-C/09BE-C

AY-A07BE/09BE/12BE

Overload

ITEMS

INDOOR UNIT

OUTDOOR UNIT

INDOOR UNIT

OUTDOOR UNIT

INDOOR UNIT

OUTDOOR UNIT

AY-A09BE AE-A09BE AY-A09BE-C AE-A09BE-C AY-A12BE AE-A12BE

Cooling capacity kW 2.64 3.5

Heat pump kW 3.1 4.0

Heating capacity

Moisture removal Liters/h 0.8 1.2

Electrical data

Phase – Single

Rated frequency Hz 50

Rated voltage range V 198 to 264

Rated voltage V 220 - 240

Rated current Cool A 3.8 - 3.6 5.0 - 4.8

Heat A 3.7 - 3.5 5.0 - 4.8

Rated input Cool W 820 - 850 1090 - 1120

Heat W 810 - 840 1080 - 1120

Power factor Cool % 98 - 98 99 - 97

Heat % 100 - 100 98 - 97

Compressor Type Hermetically sealed rotary type

Model QK164PA13A RH165VHET RH207VHET

Oil charge

300cc (SUNISO 4GSI) 300cc (DIAMOND MS56) 520cc (DIAMOND MS56)

Refrigerant system

Evaporator Louver fin and Grooved tube type

Condenser Corrugate fin and Grooved tube type

Control Capillary tube

Refrigerant volume 740g 690g 970g

De-Ice system Micro computercontroled reverse systyem

Noise level High dB(A) 36 43 36 43 38 48

(at cooling) Med. dB(A) 32 – 32 – 33 –

Low dB(A) 27 – 27 – 29 –

Fan system

Drive Direct drive

Air flow quantity High m3/min. 8.6 28 8.6 28 9.3 30

Med. m3/min. 6.8 – 6.8 – 8.4 –

Low m3/min. 5.3 – 5.3 – 7.4 –

Fan

Cross flow fan Propeller fan Cross flow fan Propeller fan Cross flow fan Propeller fan

Connections

Refrigerant coupling Flare type

Refrigerant tube size Gas, Liquid 3/8", 1/4" 1/2", 1/4"

Drain piping mm O.D ø 18

Others

Safety device Compressor: Compressor: Overload protector (Internal)

Overload protector

Fan motor: Thermal fuse

Fuse, Micro computer control

Air filters Polypropylene net (Washable)

Net dimensions Width mm 815 780 815 780 815 780

Height mm 278 540 278 540 278 540

Depth mm 198 269 198 269 198 269

Net weight kg 9 34 9 34 10 39

Note: The condition of star( ) marked item are 'ISO5151' : 1994(E), condition T1.

AH-A07BE-C/09BE-C

AH-A07BE/09BE/12BE

AY-A07BE-C/09BE-C

AY-A07BE/09BE/12BE

ITEMS

INDOOR UNIT OUTDOOR UNIT INDOOR UNIT OUTDOOR UNIT

AH-A07BE AU-A07BE AH-A07BE-C AU-A07BE-C

Cooling capacity kW 2.1

Moisture removal Liters/h 0.7

Electrical data

Phase – Single

Rated frequency Hz 50

Rated voltage range V 198 to 264

Rated voltage V 220 - 240

Rated current A 3.1 - 3.0

Rated input W 650 - 690

Power factor % 95 - 96

Compressor Type Hermetically sealed rotary type

Model QK134PA13A RH130VHST

Oil charge

300cc (SUNISO 4GSI) 300cc (

DIAMOND MS 56

)

Refrigerant system

Evaporator Louver fin and Bare tube type

Condenser Louver fin and Bare tube type

Control Capillary tube

Refrigerant volume 480g 470g

Noise level High dB(A) 33 43 33 43

(at cooling) Med. dB(A) 29 – 29 –

Low dB(A) 27 – 27 –

Fan system

Drive Direct drive

Air flow quantity High m3/min. 7.2 20 7.2 20

Med. m3/min. 6.0 – 6.0 –

Low m3/min. 4.8 – 4.8 –

Fan Cross flow fan Propeller fan Cross flow fan Propeller fan

Connections

Refrigerant coupling Flare type

Refrigerant tube size Gas, Liquid 3/8", 1/4"

Drain piping mm O.D ø 18

Others

Safety device Compressor: Overload protector Compressor: Overload protector

(Internal)

Fan motor: Thermal fuse

Fuse, Micro computer control

Air filters Polypropylene net (Washable)

Net dimensions Width mm 815 720 815 720

Height mm 278 535 278 535

Depth mm 198 236 198 236

Net weight kg 9 29 9 29

Note: The condition of star( ) marked item are 'ISO5151' : 1994(E), condition T1.

AH-A07BE-C/09BE-C

AH-A07BE/09BE/12BE

AY-A07BE-C/09BE-C

AY-A07BE/09BE/12BE

ITEMS

INDOOR UNIT

OUTDOOR UNIT

INDOOR UNIT

OUTDOOR UNIT

INDOOR UNIT

OUTDOOR UNIT

AH-A09BE AU-A09BE AH-A09BE-C AU-A09BE-C AH-A12BE AU-A12BE

Cooling capacity kW 2.64 3.5

Moisture removal Liters/h 0.8 1.2

Electrical data

Phase – Single

Rated frequency Hz 50

Rated voltage range V 198 to 264

Rated voltage V 220 - 240

Rated current A 3.8 - 3.6 5.0 - 4.8

Rated input W 820 - 850 1090 - 1120

Power factor % 98 - 98 99 - 97

Compressor Type Hermetically sealed rotary type

Model QK164PA13A RH154VHST RH207VHET

Oil charge

300cc (SUNISO 4GSI) 300cc (DIAMOND MS56) 520cc (DIAMOND MS56)

Refrigerant system

Evaporator Louver fin and Grooved tube type

Condenser Louver fin and Grooved tube type

Control Capillary tube

Refrigerant volume 550g 560g 870g

Noise level High dB(A) 36 43 36 43 38 48

(at cooling) Med. dB(A) 32 – 32 – 33 –

Low dB(A) 27 – 27 – 29 –

Fan system

Drive Direct drive

Air flow quantity High m3/min. 8.6 28 8.6 28 9.3 30.0

Med. m3/min. 6.8 – 6.8 – 8.4 –

Low m3/min. 5.3 – 5.3 – 7.4 –

Fan

Cross flow fan Propeller fan Cross flow fan Propeller fan Cross flow fan Propeller fan

Connections

Refrigerant coupling Flare type

Refrigerant tube size Gas, Liquid 3/8", 1/4" 1/2", 1/4"

Drain piping mm O.D ø 18

Others

Safety device

Compressor: Overload protector Compressor: Overload protector

(Internal)

Fan motor: Thermal fuse

Fuse, Micro computer control

Air filters Polypropylene net (Washable)

Net dimensions Width mm 815 780 815 780 815 780

Height mm 278 540 278 540 278 540

Depth mm 198 269 198 269 198 269

Net weight kg 9 33 9 33 10 38

Note: The condition of star( ) marked item are 'ISO5151' : 1994(E), condition T1.

AH-A07BE-C/09BE-C

AH-A07BE/09BE/12BE

AY-A07BE-C/09BE-C

AY-A07BE/09BE/12BE

EXTERNAL DIMENSIONS

Figure E-1. INDOOR UNIT

Figure E-2. OUTDOOR UNIT FOR AE-A07BE/AE-A07BE-C AND AU-A07BE/AU-A07BE-C

Length unit (mm)

815

278

198

1100

Remote controller

18.5

140

INVERTER AIR CONDITIONER

430

720

775

143

245

535

278

236

228

20˚

AH-A07BE-C/09BE-C

AH-A07BE/09BE/12BE

AY-A07BE-C/09BE-C

AY-A07BE/09BE/12BE

Figure E-3. OUTDOOR UNIT FOR AE-A09BE/AE-A09BE-C/A12BE AND AU-A09BE/AU-A09BE-C/A12BE

269

179.5

182.5

136

780

540

310

335

540

37.5

4.5

158

AH-A07BE-C/09BE-C

AH-A07BE/09BE/12BE

AY-A07BE-C/09BE-C

AY-A07BE/09BE/12BE

Figure W-1. Wiring Diagram for AH-A07BE/A07BE-C/A09BE/A09BE-C/A12BE

WIRING DIAGRAMS

Figure W-2. Wiring Diagram for AU-A07BE

Figure W-3. Wiring Diagram for AU-A07BE-C

INTERNAL

THERMOSTAT

TRANSFORMER

CONTROL BOARD UNIT

WPE1

TEMP.FUSE L

SSR

EVAPORATOR

BLBK

CN1

OUTDOOR

UNIT

TERMINAL

BOARD

FAN MOTOR

CAPACITOR

FAN

MOTOR

UNIT TO UNIT CORD

: BLACK

: BLUE

: BROWN

G(Y): RED

: GREEN-YELLOW

THERMISTOR

(PIPE TEMP.)

THERMISTOR

(ROOM TEMP.)

LOWER

LOUVER MOTOR

UPPER

LOUVER MOTOR

CN2

CN5

CN4

BCN2

BCN202

BCN201

RY1

BCN1

DISPLAY

UNIT

RECEIVER

UNIT

CN3

1 3 5

OUT

C1 NR1 3A

250V

INDOOR UNIT

BL BL

G(Y)

TERMINAL BOARD 1

TERMINAL BOARD 2

POWER

SUPPLY

R.P.M SIGNAL

(N)

400(430)V 2µF

INTERNAL

THERMAL

FUSE

MOTOR PROTECTOR

OUTDOOR UNIT

TERMINAL BOARD

RUNNING

CAPACITOR

370V 25µF

FAN MOTOR

CAPACITOR

400(450)V 1.5µF

COMPRESSOR MOTOR

CONTROL BOX

BK BL

UNIT TO UNIT CORD

: BLACK

: BROWN

: RED

: BLUE

G(Y)

: WHITE

: GREEN-

YELLOW

1 1

INDOOR UNIT

TERMINAL BOARD 1

G(Y)

TERMINAL BOARD 2

POWER SUPPLY

INTERNAL

THERMAL

FUSE

INTERNAL

MOTOR

PROTECTOR

OUTDOOR UNIT

TERMINAL BOARD

RUNNING

CAPACITOR

400V 25µF

FAN MOTOR

CAPACITOR

400(450)V 1.5µF

COMPRESSOR MOTOR

CONTROL BOX

BK BL

UNIT TO UNIT CORD

: BLACK

: BROWN

: RED

: BLUE

G(Y): WHITE

: GREEN-

YELLOW

1 1

INDOOR UNIT

TERMINAL BOARD 1

G(Y)

TERMINAL BOARD 2

POWER SUPPLY

AH-A07BE-C/09BE-C

AH-A07BE/09BE/12BE

AY-A07BE-C/09BE-C

AY-A07BE/09BE/12BE

Figure W-4. Wiring Diagram for AU-A09BE

Figure W-5. Wiring Diagram for AU-A09BE-C

Figure W-6. Wiring Diagram for AU-A12BE

INTERNAL

THERMAL

FUSE

MOTOR PROTECTOR

OUTDOOR UNIT

TERMINAL BOARD

RUNNING

CAPACITOR

400V 30µF

FAN MOTOR

CAPACITOR

400(450)V 1.5µF

COMPRESSOR MOTOR

CONTROL BOX

BK BL

UNIT TO UNIT CORD

: BLACK

: BROWN

: RED

: BLUE

G(Y): WHITE

: GREEN-

YELLOW

1 1

INDOOR UNIT

TERMINAL BOARD 1

G(Y)

TERMINAL BOARD 2

POWER SUPPLY

INTERNAL

THERMAL

FUSE

INTERNAL

MOTOR

PROTECTOR

OUTDOOR UNIT

TERMINAL BOARD

RUNNING

CAPACITOR

400V 25µF

FAN MOTOR

CAPACITOR

400(450)V 1.5µF

COMPRESSOR MOTOR

CONTROL BOX

BK BL

UNIT TO UNIT CORD

: BLACK

: BROWN

: RED

: BLUE

G(Y): WHITE

: GREEN-

YELLOW

1 1

INDOOR UNIT

TERMINAL BOARD 1

G(Y)

TERMINAL BOARD 2

POWER SUPPLY

INTERNAL

THERMAL

FUSE

INTERNAL

MOTOR

PROTECTOR

OUTDOOR UNIT

TERMINAL BOARD

RUNNING

CAPACITOR

400V 30µF

FAN MOTOR

CAPACITOR

400(450)V 2µF

COMPRESSOR MOTOR

CONTROL BOX

BK BL

UNIT TO UNIT CORD

: BLACK

: BROWN

: RED

: BLUE

G(Y): WHITE

: GREEN-

YELLOW

1 1

INDOOR UNIT

TERMINAL BOARD 1

G(Y)

TERMINAL BOARD 2

POWER SUPPLY

AH-A07BE-C/09BE-C

AH-A07BE/09BE/12BE

AY-A07BE-C/09BE-C

AY-A07BE/09BE/12BE

Figure W-7. Wiring Diagram for AY-A07BE/A07BE-C/A09BE/A09BE-C/A12BE

Figure W-8. Wiring Diagram for AE-A07BE

Figure W-9. Wiring Diagram for AE-A07BE-C

INTERNAL

THERMOSTAT

TRANSFORMER

CONTROL BOARD UNIT

WPE1

TEMP.FUSE L

SSR

EVAPORATOR

BLBK

CN1

OUTDOOR

UNIT

TERMINAL

BOARD

FAN MOTOR

CAPACITOR

FAN

MOTOR

UNIT TO UNIT CORD

: BLACK

: BLUE

: BROWN

G(Y)

: ORANGE

: PURPLE

: RED

: GREEN-YELLOW

THERMISTOR

(PIPE TEMP.)

THERMISTOR

(ROOM TEMP.)

LOWER

LOUVER MOTOR

UPPER

LOUVER MOTOR

CN2

CN5

CN4

BCN2

BCN202

BCN201

RY2

RY1

RY3

BCN1

DISPLAY

UNIT

RECEIVER

UNIT

CN3

1 3 5

C.T. OUT

C1 NR1 3A

250V

INDOOR UNIT

G(Y)

TERMINAL BOARD 1

TERMINAL BOARD 2

POWER

SUPPLY

R.P.M SIGNAL

(A)

(B)

(N)

400(430)V 2µF

INTERNAL

THERMAL

FUSE

MOTOR PROTECTOR

OUTDOOR UNIT

TERMINAL BOARD

RUNNING

CAPACITOR

370V 25µF

FAN MOTOR VALVE

COIL

FAN MOTOR

CAPACITOR

400(450)V 1.5µF

COMPRESSOR MOTOR

CONTROL BOX

UNIT TO UNIT CORD

: BLACK

: BROWN

: RED

: BLUE

G(Y): WHITE

: GREEN-

YELLOW

INDOOR UNIT

TERMINAL

BOARD 1

POWER SUPPLY

G(Y)G(Y)

G(Y)

TERMINAL BOARD 2

INTERNAL

THERMAL

FUSE

INTERNAL

MOTOR

PROTECTOR

OUTDOOR UNIT

TERMINAL BOARD

RUNNING

CAPACITOR

400V 25µF

FAN MOTOR VALVE

COIL

FAN MOTOR

CAPACITOR

400(450)V 1.5µF

COMPRESSOR MOTOR

CONTROL BOX

UNIT TO UNIT CORD

: BLACK

: BROWN

: RED

: BLUE

G(Y): WHITE

: GREEN-

YELLOW

CB574

INDOOR UNIT

TERMINAL

BOARD 1

POWER SUPPLY

BR BL

G(Y)

TERMINAL BOARD 2

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Acondicionador de aire de Sharp

Sharp

Sharp AY-X36RU Manual de usuario

Sharp

Sharp AY-AP9NRH Manual de usuario

Sharp

Sharp AH-AP9SMD Manual de usuario

Sharp

Sharp AU-PNX11 Manual de usuario

Sharp

Sharp AFS60FX - 6,000 BTU Compact Air Conditioner Manual de usuario

Sharp

Sharp AY-AP9KR Manual de usuario

Sharp

Sharp Plasmacluster AE-A09DJ Manual de usuario

Sharp

Sharp AY-XPM7PHR Manual de instalación

Sharp

Sharp AE-A126J Manual de usuario

Sharp

Sharp UL-C10EA-W Manual de usuario

Sharp

Sharp CV-P09LX Manual de usuario

Sharp

Sharp AH-M098E Manual de usuario

Sharp

Sharp AY-AP7FHR Manual de usuario

Sharp

Sharp AH-X108E Manual de usuario

Sharp

Sharp AF-S125NX Manual de usuario

Sharp

Sharp AE-X3M18JR Manual de usuario

Sharp

Sharp AH-XP18UHD Manual de usuario

Sharp

Sharp AY-AP09DE Manual de usuario

Sharp

Sharp AE-XM30GR Manual de usuario

Sharp

Sharp AF-R140CX Manual de usuario

Sharp

Sharp Plasmacluster AY-XP9LSR Manual de usuario

Sharp

Sharp AE-A189J Manual de usuario

Sharp

Sharp AH-X08CR Manual de usuario

Sharp

Sharp Eco Inverter AH-XP18MV Manual de usuario

Manuales populares de Acondicionador de aire de otras marcas

Spheros

Spheros CC 355 Manual de usuario

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manual de usuario

Panasonic

Panasonic CS-E12HKEW Manual de usuario

nedis

nedis ACMB1WT7 Manual de usuario

Samsung

Samsung AR KV Series Guía

Daikin

Daikin FCFV50A Manual de usuario

Fujitsu

Fujitsu Inverter ASBA30JFC Manual de usuario

Toshiba

Toshiba RAS-M10SMUV-E Manual de usuario

Daikin

Daikin FXLQ20MAVE Manual de usuario

Hitachi

Hitachi RAS-E24CAK Manual de usuario

CIAT

CIAT Magister 2 Series Guía

Bestron

Bestron AAC6000 Manual de usuario

Hisense

Hisense 7K Manual técnico

Frigidaire

Frigidaire FFRE0533S1E0 Manual de usuario

Samsung

Samsung AS09HM3N Manual de usuario

Frigidaire

Frigidaire CRA073PU11 Manual del propietario

Soleus Air

Soleus Air GB-PAC-08E4 Manual de usuario

McQuay

McQuay MCK020A Manual de usuario
