Sharp IG-NX2B Manual de usuario

“Plasmacluster” and “Device of a cluster

of grapes” are trademarks of Sharp

Corporation.

* 1 The number on this technical mark

indicates more than 50,000 ions

supplied into air of 1 cm3, which is

measured near the center of space

(0.5 m height from floor) when the air

volume is “MED” by placing the

product in an appropriate place such

as a cup holder beside the driver's

seat.

IG-NX2B

IG-NX2Y

PLASMACLUSTER ION

GENERATOR OPERATION

MANUAL

ENGLISH

เครื่องพนอนุภาค

พลาสมาคลัสเตอร

คูมือการใชงาน

ภาษาไทย

PETUNJUK

PENGOPERASIAN UNIT

PENGHASIL ION

PLASMACLUSTER

INDONESIA

01_IG-NX2B_IG-NX2Y-EN.indd 101_IG-NX2B_IG-NX2Y-EN.indd 1 2/6/2564 BE 20:522/6/2564 BE 20:52

ENGLISH

CONTENTS

IMPORTANT SAFETY INSTRUCTIONS............................. 1

PART NAMES...................................................................... 4

INSTALLATION GUIDANCE ............................................... 6

OPERATION........................................................................ 8

CLEANING AND MAINTENANCE..................................... 10

REPLACEMENT................................................................ 14

TROUBLESHOOTING ...................................................... 15

SPECIFICATIONS............................................................. 17

Thank you for purchasing this SHARP Plasmacluster Ion Generator.

Please read this manual carefully before using the product.

This manual should be kept in a safe place for handy reference.

• While the product can remove suspended viruses and other

contaminants, it cannot create a completely sterile environment.

SHARP does not guarantee its ability to prevent microbial

infection.

• To enable stable emission of high-density Plasmacluster ions,

the Plasmacluster Ion Generating Unit mounted in the product

will need to be replaced periodically*.

• The product is designed for ordinary passenger cars with DC 12

V batteries. It cannot be used in vehicles with DC 24 V batteries

(buses, trucks, etc.).

* Replacement is required approximately every 6 years (17,500 hours) when

operated 8 hours a day. the product will stop operating after about 6 years

and 6 months (19,000 hours) if the Plasmacluster Ion Generating Unit is

not replaced.

01_IG-NX2B_IG-NX2Y-EN.indd 201_IG-NX2B_IG-NX2Y-EN.indd 2 2/6/2564 BE 20:522/6/2564 BE 20:52

EN-1

ENGLISH

IMPORTANT SAFETY INSTRUCTIONS

Please read these instructions carefully before using this product.

When using electrical appliances, basic safety precautions should

be followed, including the following:

WARNING - To reduce the risk of electric shock, fire or injury :

• Do not operate switches while driving. (Doing so could lead to

accidents.)

• Do not install the product in places where it could hamper visibility

to the front, driving operations, or in places where it could be

dangerous to passengers. (Doing so could lead to accidents or

injury.)

• Do not put in places exposed to direct sunlight. (Doing so could

cause warping or malfunction.)

• This product is designed exclusively for use in vehicles with 12 V

batteries. Do not use it in other vehicles. Do not use the product in

large trucks, buses or other vehicles with 24 V batteries. (Doing so

could lead to fire or electric shock.)

• Do not damage or modify the cord. Also, do not use the cord if it is

damaged. (The damaged section could cause short-circuiting and

the cord could melt, leading to fire.) If the cord is damaged, contact

your store of purchase or SHARP authorized service center.

• Do not pull on the cord when unplugging the Car Adapter or the

Micro USB Plug. (Doing so could damage the cord, leading to fire

or electric shock.)

• Do not plug in or unplug the Car Adapter or the Micro USB Plug

with wet hands. (Doing so could cause electric shock.)

• When transporting, be careful not to drop the product or subject it

to shocks. (Doing so could cause injury or damage.)

If the product should drop or be damaged, contact your store of

purchase or SHARP authorized service center.

Continued usage of damaged product could lead to fire or electric

shock.

01_IG-NX2B_IG-NX2Y-EN.indd EN-101_IG-NX2B_IG-NX2Y-EN.indd EN-1 2/6/2564 BE 20:522/6/2564 BE 20:52

EN-2

• Do not modify the product. Also, no one other than an authorized

repairman should take apart or repair the product. (Doing so could

lead to fire, electric shock or injury.) Contact your store of purchase

or SHARP authorized service center for repairs.

• Do not spill beverages or drop cigarette ashes, metal objects,

easily burnable objects, etc., into the product through the Air Outlet

or Air Inlet. Be particularly careful if there are small children in your

family. If water or foreign substances should get inside the product,

unplug the Car Adapter from the accessory socket. (Continued

usage could lead to fire or electric shock.) Contact your store of

purchase or SHARP authorized service center.

• Do not wipe the product with oils, alcohol, benzine or thinners, or

spray hairspray or insecticides on the product. If such substances

should get on the product, wipe them off immediately. (Such

substances could lead to cracking or electric shock or could catch

fire.)

• Do not place the product in a place where it is exposed to oil

smoke or moisture such as kitchen counter or humidifying device.

(Doing so could lead to electric shock.)

• Do not place the product near heating equipment such as the

outlet of hot-air type heater. (Doing so could cause warping or

malfunction.)

• Use the Car Adapter designed exclusively for this product, and

insert the Car Adapter securely all the way in until it stops. (If the

Car Adapter is not inserted securely until it stops, it could heat up,

deforming the accessory socket, and this could lead to fire.)

• Be sure to unplug the Car Adapter from the accessory socket when

cleaning. (Failure to do so could cause electric shock or injury.)

• Be sure to unplug the Car Adapter from the accessory socket when

not in use for long periods of time. (Failure to do so could lead to

electric shock or fire caused by short-circuiting.)

• If the accessory socket is integrated into the ashtray, be sure that

cigarettes are completely extinguished before using the product.

• When leaving the vehicle, unplug the Car Adapter and close the

ashtray’s lid. (Failure to do so could lead to fire caused by the

smoldering cigarettes.)

01_IG-NX2B_IG-NX2Y-EN.indd EN-201_IG-NX2B_IG-NX2Y-EN.indd EN-2 2/6/2564 BE 20:522/6/2564 BE 20:52

EN-3

ENGLISH

• This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities, or

lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliance by a

person responsible for their safety.

Children should be supervised to ensure that they do not play with

the appliance.

CAUTIONS CONCERNING OPERATION :

• Do not touch the metal parts of the Car Adapter (or of the

accessory socket).

(The metal parts of the Car Adapter could be hot directly after the

car is stopped, and could cause burns if touched.)

• Do not use the product in external cup holders, on shaky or

non-level surfaces or in other unstable places. (The product could

fall, resulting in injury or damage.)

• Move the product out of the car when using room fumigating type

insecticides or deodorizers. If not, the chemicals could get inside

the product and later be ejected from the Air Outlet, possibly

harming your health.

• If the product risks falling out of the cup holder (when driving on

rough roads, over bumps, etc.), either slow down or remove the

product from the cup holder beforehand. (Failure to do so could

cause injury or damage to the product.)

• Do not use silicone-based items* near the product.

The fluororesin or silicone could get stuck inside the product,

preventing it from producing Plasmacluster ions.

If this happens, remove the dust from the electrode section of the

Plasmacluster Ion Generating Unit. (Page 13)

* Hair care items (split end coatings, hair mousses, hair treatments, etc.),

cosmetics, antiperspirants, antistatic agents, waterproofing sprays, polishes,

glass cleaners, chemical-impregnated clothes, wax, etc.

01_IG-NX2B_IG-NX2Y-EN.indd EN-301_IG-NX2B_IG-NX2Y-EN.indd EN-3 2/6/2564 BE 20:522/6/2564 BE 20:52

EN-4

PART NAMES

Note

NOTE

• Please use the official Car Adapter and power cord.

(Failure to do so could lead to fire / electric shock / failure)

01_IG-NX2B_IG-NX2Y-EN.indd EN-401_IG-NX2B_IG-NX2Y-EN.indd EN-4 2/6/2564 BE 20:522/6/2564 BE 20:52

EN-5

ENGLISH

1Main Unit

2Air Outlet

3Operation Button

(Page 8)

4Operation Lamp

(Blue, Purple)

5Unit Replacing Lamp

(Red) (Page 9)

6Power Supply Port

7Unit* Holder

8Plasmacluster Ion

Generating Unit*

9Unit* Cleaning Brush

10 Main Unit Cover

11 PM10 Filter

12 Filter Cover

13 Micro USB Plug

14 Cord (length 1.5 m)

USB Plug

• Do not use with voltages

other than the rated

voltage of DC 5 V.

16 Car Adapter

(with 2 ports)

* The Unit refers to Plasmacluster Ion

Generating Unit. (The same as

below.)

01_IG-NX2B_IG-NX2Y-EN.indd EN-501_IG-NX2B_IG-NX2Y-EN.indd EN-5 2/6/2564 BE 20:532/6/2564 BE 20:53

EN-6

INSTALLATION GUIDANCE

Insert the Car Adapter into the accessory socket and

connect the USB plug to the Car Adapter.

• You can use the product by inserting the

included USB cable into USB connector of

PC, etc.

NOTE

• Be sure to remove any dirt from the accessory socket. Failure to

do so could cause faultily contact or fire.

• The Car Adapter (accessory) for the product has 2 USB ports.

It is possible to connect another equipment of 1.5 A or lower

while the product is connected. However, in this case, the normal

operation of the additional equipment is not guaranteed.

• The Car Adapter and/or connecting section could be hot while in

use and/or right after use.

01_IG-NX2B_IG-NX2Y-EN.indd EN-601_IG-NX2B_IG-NX2Y-EN.indd EN-6 2/6/2564 BE 20:532/6/2564 BE 20:53

EN-7

ENGLISH

Cautions on wiring the Car Adapter

• Do not let the cord touch or get caught in the seat rails, shift lever

or other moving parts.

• Wire in such a way that the cord does not get in the way of the

driver.

• Consider the movement of the seats (forward / backward, swiveling

or reclining) when wiring.

• Do not bend the cord extremely or compress it.

Cautions on installation

• Separate the product from

electronic key of vehicle by 30 cm

or more. Otherwise, it may

interfere with electronic wave of

product and the electronic key may

not be recognized.

• Be sure to place in a stable

location. (Do not put in a external

cup holder or other unstable

place.)

• Do not obstruct the air inlet or outlet.

• Keep the product away from the vehicle’s in-glass antenna. Failure

to do so could cause interference on the radio.

• If there should be interference on a TV or radio located in the same

car, or if an atomic clock in the car should not display the time

properly, move the product away from the TV, radio, atomic clock,

etc.

• If the product is installed directly in front of the car climate control’s

outlets, the product could get hot when the climate control is

operating in the heating mode.

• The product could get scratched by the vibrations of the vehicle,

etc.

• It might be impossible to use for some types of cars.

01_IG-NX2B_IG-NX2Y-EN.indd EN-701_IG-NX2B_IG-NX2Y-EN.indd EN-7 2/6/2564 BE 20:532/6/2564 BE 20:53

EN-8

OPERATION

SELECT MODE

LOW MED TURBO

QUICK CLEANOFF

LOW Release high-density Plasmacluster

ions quietly.

MED Release Plasmacluster ions

approximately 2 times as much as

“LOW” at standard air flow.

TURBO Release Plasmacluster ions

approximately 3.6 times as much as

“LOW” at a strong air flow.

QUICK CLEAN If you want to remove odors quickly.

Releases Plasmacluster ions with

TURBO mode for 25 minutes, After that,

the mode is switches “MED”.

• After smoking

• After eating in a vehicle

• When you are conscious about odor of air

conditioner

01_IG-NX2B_IG-NX2Y-EN.indd EN-801_IG-NX2B_IG-NX2Y-EN.indd EN-8 2/6/2564 BE 20:532/6/2564 BE 20:53

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Purificador de aire de Sharp

Sharp

Sharp FU-S40E Manual de usuario

Sharp

Sharp KI-N51R Manual de usuario

Sharp

Sharp KI-N50TA Manual de usuario

Sharp

Sharp FP-J40E Manual de usuario

Sharp

Sharp Plasmacluster IG-A10EU Manual de usuario

Sharp

Sharp FP-E50TA Manual de usuario

Sharp

Sharp Plasmacluster KC-830U Manual de usuario

Sharp

Sharp KC-A60Y Manual de usuario

Sharp

Sharp FX-J80U Manual de instrucciones

Sharp

Sharp Plasmacluster IG-A20E Manual de usuario

Sharp

Sharp KC-A60J Manual de usuario

Sharp

Sharp IG-DM1Y Manual de usuario

Sharp

Sharp FU-40SE Manual de usuario

Sharp

Sharp FP-A40UW Manual de usuario

Sharp

Sharp IG-BC2A Manual de usuario

Sharp

Sharp FU-W40A Manual de usuario

Sharp

Sharp KC-930EKW Manual de usuario

Sharp

Sharp FP-A60UW Manual de usuario

Sharp

Sharp FZ-28SEF Manual de usuario

Sharp

Sharp FU-551KB Manual de usuario

Sharp

Sharp Plasmacluster FP-A28C Manual de usuario

Sharp

Sharp KC-860EKW Manual de usuario

Sharp

Sharp KC-20TX1 Manual de usuario

Sharp

Sharp KC-G60TA Manual de usuario

Manuales populares de Purificador de aire de otras marcas

IKEA

IKEA UPPÅTVIND Manual de usuario

Nash

Nash AP-1 PureSmart Manual de usuario

LG PH-U450 Series Manual de usuario

DeLonghi

DeLonghi DDSX 220WFA Manual de usuario

Mitsubishi Electric

Mitsubishi Electric MA-E85R-E Manual de usuario

Philips

Philips AC2721 Manual de usuario

Hitachi

Hitachi EP-A3000 Manual de usuario

TruSens

TruSens Z-2000 Manual de usuario

Motorola

Motorola MBP87SN Manual de usuario

Beko

Beko ATP 7100I Manual de usuario

Carrier

Carrier INFINITY 1620 Manual de usuario

AtmosAir

AtmosAir P2002 Manual de usuario

Winix

Winix NK300 Manual de usuario

Friedrich

Friedrich C-90A Instrucciones de funcionamiento e instalación

Surgically Clean Air

Surgically Clean Air JADE2.0 Manual de usuario

Base aire

Base aire 555 Pro Manual de usuario

Champion

Champion CP25 Manual de usuario

vollara

vollara Air & Surface Pro+ Manual de usuario
