Sharp FU-28H-S Manual de usuario

FU-28H-S

S4616FU28HS//

AIR PURIFIER

In the interests of user-safety (Required by safety regulations

in some countries) the set should be restored to its original

condition and only parts identical to those specified should be

used.

SERVICE MANUAL

FU-28H-S

MODEL

SHARP CORPORATION

Page

SAFETY PRECAUTIONS ..................................................................................................................................2

HOW SHARP AIR PURIFIER WORKS .............................................................................................................4

SPECIFICATIONS FOR THIS PRODUCT ........................................................................................................5

NAMES OF PARTS .......................................................................................................................................... 7

INSTLLATION................................................................................................................................................... 8

ABOUT THE FUNCTION................................................................................................................................ 14

ELECTRIC CIRCUIT........................................................................................................................................15

TROUBLESHOOTING GUIDE ........................................................................................................................22

REPLACEMENT OF MAIN PARTS .................................................................................................................24

OPERATION....................................................................................................................................................29

MAINTENANCE...............................................................................................................................................30

CUMULATIVE TIME CHECK FUNCTION (MAINTENANCE MODE)............................................................. 32

USE RESIN TABLE .........................................................................................................................................33

REPLACEMENT PARTS LIST ........................................................................................................................34

TABLE OF CONTENTS

FU-28H-S

SAFETY PRECAUTIONS

When using electrical appliances, basic safety precautions should be followed, including the

following:

WARNING

- To reduce the risk of electrical shock, fire or injury to persons:

• Read all instructions before using the air purifier.

• Use only a 220-240 volt outlet .

• Do not use the air purifier if the power cord or plug is damaged or the connection to the wall

outlet is loose.

•Periodically remove dust from the power plug.

• Do not insert fingers or foreign objects into the intake or air outlet.

When removing the power plug, always hold the plug and never pull the cord.

Electrical shock and/or fire from short circuit may occur as result.

• Do not use this air purifier near gas appliances or fireplaces.

• Remove the power plug from the wall outlet before cleaning the unit and when not using the

unit.

Electrical shock from bad insulation and / or fire from short circuit may occur as a result.

• If the power cord is damaged, it must be replaced by the manufacturer, its service agent, Sharp

authorized service or similarly qualified person in order to avoid a hazard.

•Do not operate when using aerosol insecticides or in rooms where there is oily residue, incense,

sparks from lit cigarettes, chemical fumes in the air or a humidity condition.

•Use care when cleaning the air purifier. Strong corrosive cleansers may damage the exterior.

•Only Sharp Authorized Servicers should service this air purifier. Contact the nearest Servicer for any

problems, adjustments, or repairs.

•The batteries must be removed from the remote control before disposal, and the batteries must be

disposed of safely.

CAUTIONS CONCERNING OPERATION

• Do not block the intake and air outlet.

• Do not use the unit near or on hot objects, such as range or where it may come into contact with

steam.

• Always hold the main unit when moving it.

Holding the front panel when carrying may cause it to detach, thus dropping the unit and resulting in

bodily injury.

• Do not operate the unit without the filter.

• Do not wash the Active Carbon Filter and the HEPA Filter.

Not only it does not improve filter performance, it may cause electric shock or malfunction.

• Clean the exterior with a soft cloth only.

The unit surface may be damaged or cracked.

In addition, the sensor may malfunction as a result.

FU-28H-S

REMOTE CONTROL LIMITATIONS

DO NOT USE THE REMOTE CONTROL IN THE FOLLOWING LOCATIONS:

•Any location where there is inverter lighting equipment or electronic spontaneous lighting

equipment

The remote control may become inoperative. In this case, move away from such lighting equipment or

change direction.

•Location exposed to direct sunlight or fluorescent.

The unit may not receive signals from the remote control.

CAUTIONS WHEN MOUNTING THIS PRODUCT ON A WALL

•Avoid a location where the sensor is exposed to direct wind.

The unit may not operate properly.

•Avoid a location where curtains, etc., come into contact with the intake or air outlet.

Curtains, etc., may become dirty or a malfunction may occur.

•Avoid locations where the unit is exposed to condensation, due to drastic temperature changes.

•Place on a stable surface with sufficient air circulation.

•Install the unit on a wall, wooden pillar, crosspiece, etc. that is flat and strong enough.

•Do not install the unit on a thin wall or on plasterboard. The unit may fall down if installed on an

insufficiently strong wall.

•To install the unit on a wooden wall that is less than 10 mm thick, consult your dealer and have

them confirm the strength of the wall before installation.

•Always hold the main unit when moving it.

Holding the front panel may cause it to become detached, thus dropping the unit and resulting in

bodily injury.

•Do not install when there is generation of lampblack, such as in a kitchen, etc.

The unit surface may crack or the sensor may malfunction as a result.

FILTER GUIDELINES

•Follow the instructions in this manual for correct care and maintenance of the filters.

This equipment complies with the requirements of Directives

89/336/EEC and 73/23/EEC as amended by 93/68/EEC.

FU-28H-S

HOW SHARP AIR PURIFIER WORKS

An air purifier draws in room air from its air intake, lets the air pass through an Active Carbon Filter (Deodorizing

Filter) and a HEPA Filter (dust collection filter) inside of the unit, then discharges the air from its air outlet.

The air purifier unit repeats this process by moving its internal fan.

As air passes through, the HEPA Filter can remove dust particles. The Active Carbon Filter gradually absorbs odour

elements as they repeatedly pass through the filter.

(Odour elements are absorbed by HEPA Filter as well.)

Some odour ingredients absorbed by the filters may become separated and may be discharged through the air outlet

and result in additional odour.

Depending on the usage environment, this odour may become strong in a shorter period than expected.

In this case, purchase the optional replacement filter kit FZ-28SEF.

NOTE

The air purifier is designed to remove air-suspended dust and odour, but not harmful gases (for example, carbon

monoxide contained in cigarette smoke). Neither can it completely remove odours that are always present (for

example, odours from construction materials and pet odours).

HEPA Filter

Active Carbon Filter

FU-28H-S

SPECIFICATIONS FOR THIS PRODUCT

1.Specifications

Type FU-28H-S

Power supply 220 - 240V 50/60Hz

Fan level adjustment Max Silent

Rated power (W) 29 3.1

Fan level (m3 /hour) 168 30

Fan rotation speed (r.p.m.) 1000 ±10 330 ±10

Noise (dB) 46 14

Applicable floor area 1 Around ~ 21m2

Dust collecting method Mechanical purification

Protective devices Current fuse Turning off when abnormal current (2.5A) flows

Control panel Power ON/OFF, Fan control, OFF timer

Operation indicator light Plasmacluster indicator light (blue), Auto, Max, Silent

OFF-Timer 1 hour, 4 hours

Remote control Operation mode

Power ON/OFF, Auto, Fan control (manual), OFF-timer

OFF TIMER time 1 hour, 4 hours

Outside dimension (mm) 482 (W) x 142 (D) x 337 (H)

Weight (kg) 6.2

Cord length (m) 2.5

Installation Wall mounting

Accessories HEPA filter, Active carbon filter, remote control , 2 AA batteries, Wall mounting Kit (Wall

mounting braket, Wood screws[4], Fisher plugs[4])

Replace the filter 2 HEPA filter : 12 months

Active carbon filter : 12 months

Option Replace filter : FZ-28SEF (1 HEPA Filter, 1 Active Carbon Filter.)

1: The size of the room to be referred to is the one in which dust concentration of 1.25mg/m3 may be reduced to

0.15mg/m 3within 30 minutes under the condition that the natural ventilation is performed once per hour.

2: Ten cigarettes are smoked per day in the place where the air cleaner is installed.

Reduction of stand-by power consumption

While this product is plugged in, it consumes the stand-by power of approximately 1.0W to activate the electric circuit

FU-28H-S

2.External dimentions

1) Simple substance figure

482

[Length unit : mm]

337

139.5

2) Wall tapestry figure

141.5

337

482

[Length unit : mm]

Wall

FU-28H-S

NAMES OF PARTS

MAIN UNIT DISPLAY

Plasmacluster Indicator Light

Fan Speed Indicator Lights

OFF Timer Display Indicator Lights

Remote Control Receiver

Power ON/OFF button

Fan Control button

OFF Timer button

Odour Sensor

Filter Frame

HEPA Filter (white)

(with Microbial Control Filter)(blue)

Active Carbon Filter

(Deodorizing Filter)

Stainless Steel Pre-Filter

Front Panel

BACK

Power Cord

Adjusting Guide

Power Cord

Power Plug

ACCESSORIES

Remote Control

(1 unit)

Battery

(R6(AA) battery X 2 )

Operation Manual

Wall mounting kit

•Wall mounting bracket

•Wood screws (4 pcs)

•Fisher plugs (4 pcs)

Air Outlet

(Shape of plug

depends on country)

FU-28H-S

INSTALLATION

FOR APPROPRIATE INSTALLATION

To remove room odour

Installing the unit high up on the wall is most effective.

To remove room dust

Comparatively large dust particles such as pollen and house dust collect in the lower strata of the

room air.

Select a location in the room where the air circulation is good.

This improves the cleaning performance and causes Plasmacluster ions to spread throughout the

room.

Operating Conditions

Please operate the unit under the following conditions.

It is recommended to use the unit in a room where the temperature is in the range of 0 - 35C°.

Avoid locations where the unit is exposed to condensation, due to drastic temperature changes.

Installation Cautions

•Before fixing the wall mounting bracket, make sure there is nothing that could obstruct installation of the unit.

Then fix the wall mounting bracket through screw holes with the supplied wood screws.

•Install the unit on a wall, wooden pillar, crosspiece or the like that is flat and strong enough..

•If the wall is weak or made of concrete, have the unit installed by a specialist such as an electric appliance

store.

•Avoid locations near inverter lamps or where the unit is exposed to direct sunlight.

Determine the mounting location

Leave space around the bracket referring to the drawing below. The unit cannot

be mounted if there is insufficient spacing around the bracket.

207mm

337mm (Size of main unit)

48mm

54mm

235mm

482mm (

Size of main unit)

Power cord

330mm

16mm

60mm

3mm

92mm

Wall mounting bracket

Screw Holes

Size of main unit

70cm or more from

side wall 70cm or more from

side wall

Center line of Wall mounting bracket

Center line of main unit

Center line of

main unit

45cm or more

from the ceiling

FU-28H-S

Installation on a

wooden pillar

ø5mm

35mm

Installation on a

wooden crosspiece

Wood screws (4)

Wooden pillar

Caution

•To install the unit on a wooden wall that is less than 10 mm thick, consult your

dealer and have them confirm the strength of the wall before installation.

•Install the unit on a wall, wooden pillar, crosspiece, etc. that is flat and strong

enough.

•Make sure that the unit is installed in an upright position, without leaning to

the right or left.

Wooden crosspiece

Wall mounting bracket

Hole on the wall

Fisher plug

Wood screw

Mount wall mounting bracket

•Mount the bracket using the included wood screws so that it is maintained level.

Installation on a concrete, block or mortar surface

Drill holes of at least 35 mm depth and 5 mm diameter into the wall, drive in

Fisher plugs, and fix the unit with wood screws.

Installation on a wooden pillar, crosspiece or other wooden surface

Use wood screws for installation.

FU-28H-S

Before starting the wall installation, be sure to remove the front panel

and filter frame.

In case the power plug to

be lead to the left of the

unit.

Do not wire the

power cord right

below the wall

mountingbracket.

Power cord adjusting guide

Incasethepowerplug tobe lead

to the right of the unit.

Cautions

•To avoid scratching or damaging the unit, place it on a soft piece of cloth

until it is installed on the wall.

•Do not lead the power cord together with other cord and do not twist it.

•Never modify the power cord.

•Take care not to damage the power cord.

Front Panel Filter Frame

Air Outlet

Install the unit on the wall.

Place the unit facing

up, remove the Front

Panel and Filter Frame.

Adjust the length of the power cord.

Measure the distance between the unit and the wall outlet.

(Refer to E-6)

Place the unit face down, and insert the

power cord into the power cord adjust-

ing guide so as to adjust it to the meas-

ured length.

Power Cord

Adjusting Guide

Tabla de contenidos

Otros manuales de Purificador de aire de Sharp

Sharp

Sharp FX-J80J-W Manual de usuario

Sharp

Sharp Plasmacluster IG-A10EU Manual de usuario

Sharp

Sharp FU-551KB Manual de usuario

Sharp

Sharp KC-G60TA Manual de usuario

Sharp

Sharp FP-N40CX - Plasmacluster Ion Air Purifier Manual de usuario

Sharp

Sharp Plasmacluster FP-A40C Manual de usuario

Sharp

Sharp FU-60SE Manual de usuario

Sharp

Sharp KC-930EUW Manual de usuario

Sharp

Sharp Plasmacluster KC-6400E Manual de usuario

Sharp

Sharp UA-KIN50E-W Manual de usuario

Sharp

Sharp FZ-C150DFE Manual de usuario

Sharp

Sharp FP-J40A Manual de usuario

Sharp

Sharp FP-R30CX Manual de usuario

Sharp

Sharp IG-A10EU-W Manual

Sharp

Sharp FP-R65CX Manual de usuario

Sharp

Sharp FP-H30A Manual de usuario

Sharp

Sharp Plasmacluster FP-P40CX Manual de usuario

Sharp

Sharp FP-F60U-W Manual de usuario

Sharp

Sharp FX-S120 Manual de usuario

Sharp

Sharp IG-A20A? IG-A40A Manual de usuario

Sharp

Sharp FP-J60TA Manual de usuario

Sharp

Sharp IG-EX20B Manual de usuario

Sharp

Sharp KC-20TX1 Manual de usuario

Sharp

Sharp Plasmacluster FP-R45CX Manual de usuario

Manuales populares de Purificador de aire de otras marcas

IKEA

IKEA UPPÅTVIND Manual de usuario

Nash

Nash AP-1 PureSmart Manual de usuario

LG PH-U450 Series Manual de usuario

DeLonghi

DeLonghi DDSX 220WFA Manual de usuario

Mitsubishi Electric

Mitsubishi Electric MA-E85R-E Manual de usuario

Philips

Philips AC2721 Manual de usuario

Hitachi

Hitachi EP-A3000 Manual de usuario

TruSens

TruSens Z-2000 Manual de usuario

Motorola

Motorola MBP87SN Manual de usuario

Beko

Beko ATP 7100I Manual de usuario

Carrier

Carrier INFINITY 1620 Manual de usuario

AtmosAir

AtmosAir P2002 Manual de usuario

Winix

Winix NK300 Manual de usuario

Friedrich

Friedrich C-90A Instrucciones de funcionamiento e instalación

Surgically Clean Air

Surgically Clean Air JADE2.0 Manual de usuario

Base aire

Base aire 555 Pro Manual de usuario

Champion

Champion CP25 Manual de usuario

vollara

vollara Air & Surface Pro+ Manual de usuario
