Sharp FP-J40A Manual de usuario
空氣清新機
使用說明書
ภาษาไทย
*The number in this technology mark indicates an
approximate number of ions supplied into air of 1 cm
3
,
which is measured around the center of a room
when the product is placed close to a wall at the MED
AIR PURIFIER
OPERATION MANUAL
ENGLISH
FP-J40A
中文
OM_FP-J40A.indd 1 2018/09/28 12:00:59
Pre-Filter
HEPA Filter
Active Carbon
Deodorizing Filter
NOTE
Please read before operating your new Air Purier
OM_FP-J40A.indd 2 2018/09/28 12:01:00
ภาษาไทย
ENGLISH
ENGLISH
Before using this product, be sure to read the
IMPORTANT SAFETY INSTRUCTIONS
PARTS NAME
FILTER INSTALLATION
OPERATION
CARE AND MAINTENANCE
FILTER REPLACEMENT
TROUBLESHOOTING
SPECIFICATIONS
CONTENTS
FEATURES
Unique Combination of Air Treatment
Technologies
Triple Filtration System + Plasmacluster Ions
TRAPS DUST*
DECREASES ODORS
common household odors
REDUCES POLLEN & MOLD*
FRESHENS
Plasmacluster Ions treats the air similar to the
Sensor Technology continuously monitors air
quality, and automatically adjusting operation
OM_FP-J40A.indd 1 2018/09/28 12:01:01
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should be followed, including the
following:
WARNING
• Do not use the main unit if the power cord or plug is damaged or the connection to the wall
outlet is loosened.
•
• Do not insert ngers or foreign objects into the intake or air outlet.
• When removing the power plug, always hold the plug and never pull the cord.
•
• Do not remove the plug when your hands are wet.
• Do not place the main unit near or on hot objects, such as stoves or heaters, or where it may
come into contact with steam.
• Be sure to remove the power plug, before performing maintenance, when removing and
attaching and replacing the lter and when not using for a long time. Failure to do so can cause
a short circuit resulting in electrical shock or re.
• If the power cord is damaged, it must be replaced by the manufacturer, its service agent, Sharp
Approved Service Center or similarly qualied person in order to avoid a hazard. Contact the
• Do not operate when using aerosol insecticides or in rooms where there is oily residue, incense, sparks
•
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety. Children shall not play with the appliance. Cleaning and user maintenance shall not
be made by children without supervision.
NOTE
one or more of the following measures:
OM_FP-J40A.indd 2 2018/09/28 12:01:01
ภาษาไทย
ENGLISH
CAUTIONS CONCERNING OPERATION
• Always hold the handle on the back of the main unit when moving it.
• If the main unit is on easily damaged flooring, an uneven surface, or thick-piled carpet, lift it up
when moving.
• Do not wash and reuse the HEPA lter and the Active Carbon Deodorizing Filter.
INSTALLATION GUIDELINES
• Avoid using in locations where the main unit is exposed to condensation or drastic temperature
changes. Appropriate conditions is at room temperature 0 – 35 ºC.
• Place on a stable surface with sufcient air circulation.
•
FILTER GUIDELINES
OM_FP-J40A.indd 3 2018/09/28 12:01:02
PARTS NAME
18
17
2
1
1Main Unit 9Plasmacluster Ion Light (blue)
2Air Outlet 10 Cleanliness Monitor
3OFF TIMER Button, Indicator Light (white)
(Press 3 sec.) Filter Reset Button, Indicator Light (orange)
11 Handle
12 Dust Sensor / Dust Sensor Filter
4MODE Button, Indicator Light (white)
(Press 3 sec.) Plasmacluster Ion ON/OFF Button
13 HEPA Filter
14 Active Carbon Deodorizing Filter
5CLEAN ION SHOWER Button, indicator Light (white)
(Press 3 sec.) Light Control Button
15 Pre-Filter
16 Bottom Tabs
6POWER ON/OFF Button 17 Plug
7Light Sensor 18 Power Cord
8Odor Sensor
FRONT
BACK
16
13
14
10
11
12
15
Cleanliness Monitor
Indicates the air purity of the room
Blue
Orange
Clean
Impure
OPERATION PANEL
8
7
34 5 6
9
OM_FP-J40A.indd 4 2018/09/28 12:01:06
ภาษาไทย
ENGLISH
FILTER INSTALLATION
To maintain the quality of the lter, it is installed in the main unit and packed in plastic bag.
Be sure to remove the plastic bag from the lter before using the main unit.
• Do not operate the main unit without the lter.
Be sure to remove the power plug
from the wall outlet.
1 Remove the Pre-Filter ( Back Panel ).
2Remove the plastic bag from the
Filter.
Click
Pull
Tag
3Place the Filter inside the main unit.
4Replace the
Pre-Filter ( Back Panel )
to
the main unit.
OM_FP-J40A.indd 5 2018/09/28 12:01:12
OPERATION
HIGH
START
• When the main unit starts operation, the operation
STOP
CLEAN ION SHOWER
FAN SPEED
OFF TIMER
START/STOP
NOTE
AUTO
SLEEP
switched depending on the amount of impurities in the air and room brightness
Cleanliness Monitor/Plasmacluster Ion Light automatically s
witches
DIM or
Room is bright: light is DIM Room is dark: light is OFF
Plasmacluster Ion is turned off by
•
It is able to change the other mode and
NOTE
OM_FP-J40A.indd 6 2018/09/28 12:01:38
ภาษาไทย
ENGLISH
LIGHT CONTROL
You can set the Cleanliness Monitor /
1
2
PLASMACLUSTER ION ON/OFF
ON OFF
ADJUSTMENT OF SENSOR DETECTION SENSITIVITY
NOTE
1
2
3
Standard High Low
Standard High Low
Dust sensor / Odor sensor Light sensor
•When the main unit starts operation, the
NOTE
DIM
•
•
When the main unit starts operation, the operation
AUTO
OFF
W
NOTE
OM_FP-J40A.indd 7 2018/09/28 12:01:56
To maintain optimum performance of this air puri er, please clean the main unit including the lter periodically.
Be sure to disconnect the power cord from the wall outlet before performing any maintenance.
CARE AND MAINTENANCE
SENSORS
Dust sensor
Dust sensor
Odor sensor
Odor sensor
Do not WASH
Pre-Filter ( Back Panel )
Once in a month
MAIN UNIT
Once in
two months
HEPA FILTER
When the smell is hard to take
ACTIVE CARBON
DEODORIZING FILTER
When the smell is hard to take
SENSORS Once in
two months
cleaner attachment or
Pre-Filter
NOTE How to clean hard to remove dirt
detergent to water and soak for
CAUTION
After
OM_FP-J40A.indd 8 2018/09/28 12:02:08
