Sharkoon MS120 Manual de usuario

Manual

MS120

Content

1. Features 3

2. Package content 4

3.The case at a glance 5

4. Installation notes 7

5. Removing the left HDD mounting plate 8

6. Installation of a mainboard 9

7. Installation of a PSU 11

8. Installation of a HDD 12

8.1 Into the lateral HDD mountings 12

8.2 Into the bottom panel 13

9. Installation of an optical device 14

10. Installation of a 3.5" device 16

11. Installation of an add-on card 17

12. Installation of additional fans / optimized airﬂow 18

Dear customer!

Congratulations for purchasing this premium quality SHARKOON product.

For a long life time and to take full advantage of this product we recommend you to read this manual completely.

Enjoy our product!

SHARKOONTechnologies



MS120

1. Features

• MicroATXcase

• 1x5.25"drivebay(external)

• 1x3.5"mountingbay(external)

• Internalmountingareafor4x3.5"or6x2.5"HDDs

• 4slotsforadd-oncards

• FrontI/Owith1xUSB3.0,3xUSB2.0and2xaudio

• 2x120mmLEDfanspre-installed

• SupportsVGAcardsupto36cmlength

• Dimensions:420x175x375mm(LxWxH)

• Weight:~4kg

• Fanconguration:

Casefront 2x120mmLEDfans

Rearpanel 1x80mmor1x92mmfan(optional)

Casebottom 1x120mmfan(optional)





MS120

2. Package contents

• ATXcase"MS120"

• Screwkit:



Screwsformainboardand

drivemounting

(3.5"and5.25")

Mountingscrewsfor2.5"

HDDs/SSDs

ScrewsforPSU

mounting

ScrewsforHDDmounting

• Accessorykit:

Stand-offsformainboard Washers Cabletie(A)andspeaker(B)





Note:

If you are missing any of the items listed above, please contact our customer service immediately:

[email protected] (Germany and Europe)

[email protected] (international).



MS120

3.The case at a glance

 Frontpanel

A – FrontI/O:

  a – 1xUSB3.0

  b – 3xUSB2.0and

  c – 2xaudio

B – 5.25"drivebay

C – PowerLED

D – On/offbutton

E – 3.5"mountingbay

F – LEDforHDDactivity

G– Resetbutton

H – behindthemeshpanel:2x120mmLEDfans

Sidepanel(closed/left)



A – Airinlet



ab b

MS120

Sidepanel(opened/left)



A – 5.25"drivebay

B – 3.5"mountingbay

C – Attachmentsfor4x3.5"or

  6x2.5"-HDDs/SSDs

D – Mainboardmountingpanel

Rearpanel



A – PSUbracket

B – OpeningforI/Oshield

C – Fanbracket(80or92mm)

D – Slotbezels

E – Thumbscrews

F – ConnectioncableforthefrontUSB3.0plug



MS120

Bottompanel

 A – Casefeet

 B – Attachmentfor3.5"HDD

 C – AttachmentscrewsforHDDmountingpanel

 D – Bracketfor120mmfan

4. Installation notes

 1.ForfurtherinformationonhowtoinstallthePCcomponents,alsorefertotheirrespectiveinstructions.

 2.InordertoinstalllongVGAcards,itmightbenecessarytoremovetheleftHDDmountingpanel(see5.).

  Tohavetheoptiontoinstallatleasttwo3.5"HDDs,thereisanadditionalHDDattachmentinthebottom

  panelofthecase.



A A

B B

C C

MS120



Fig.1

1.Unscrewthethumbscrewsonthebacksideofthecaseandremovebothsidepanels.

2.UnscrewthethreeattachmentscrewsoftheHDDmountingpanelandremovethepanelfromthecase

 (g.2a-c).

  

 Fig.2a-c

5. Removing the HDD mounting plate

InordertoinstalllongVGAcards,andtoutilizethebottomHDDattachment,theleftHDDmountingpanel

(g.1)mustberemovedasfollows:



MS120

6. Installation of a mainboard

 1.Unscrewthethumbscrewsonthebacksideofthecaseandremovetheleftsidepanel.Laydownthe

  casesidewiseonanevensurface.

 2.Themountingpanelofthemainboardinsidethecaseprovidesvariousmountingholestoxthe

  standoffs(g.3).



  Fig.3

  Themainboardcontainsspecialscrewmounts(g.4).



  Fig.4

  Placethemainboardtothemountingpanel.Astandoffmustbescrewedintoeveryholeonthe

  mountingpanelvisiblethroughthemainboard’sscrewopenings.



MS120

 3.Removethemainboardandscrewthestandoffsintotherespectiveholesofthemountingpanel(g.5).



  (Standoffs)



  Fig.5

 4.InserttheI/Oshield(deliveredwiththemainboard)intotheI/Oshieldopeningintherearpanelofthecase.

 5.Placethemainboardbackontothestandoffsandscrewthemainboardtothem(g.6).



  (Screwsformainboardmounting)





  Fig.6


