Seville Classics WEB913 Manual de usuario

Model #: WEB913, WEB914

Thank you for choosing Seville Classics! We hope that you enjoy your

organizer cart. Please read through this user guide for parts list,

assembly instrucons, frequently asked quesons and contact info.

10-Drawer Organizer Cart with Tray

FAQs

Q. How big is it?

A. Unit measures 12.8" W x 15.35" D x 38.19" H

Q. Can I use it without the casters?

A. No, the cart is not designed to be used without the casters.

Q. How much weight can it hold?

A. Weight capacity per drawer: 3.3 lbs. (1.5 kgs)

Weight capacity on top shelf: 16.5 lbs. (7.5 kgs)

Total weight capacity: 49.5 lbs. (22.5 kgs)

052021

Customer Service Informaon

Telephone: (800) 323-5565

Fax: (310) 533-3899

Hours: 8:30 AM – 4:30 PM (PST)

Email: [email protected]

Homepage: www.SevilleClassics.com

STEP 4. Insert Drawers

Slide the drawers into the channels and clip

the TRAY (C) onto the crossbars.

TIP: Once fully assembled, ghten all screws.

Congratulaons!

Enjoy your new organizer cart!

052021

Please make sure you have all the parts on this list.

If you’re missing parts, contact us for replacements at

(800) 323-5565 or send an email to Support@SevilleClassics.com

Assembly Instrucons

STEP 1. Aach Casters

TIP: Make sure channels on each

SIDE FRAME (A) face each other.

Push the SLEEVES (E) into the

boom poles of SIDE FRAMES (A)

unl ush with boom.

Push CASTERS (F) and LOCKING

CASTERS (G) into the SLEEVES (E)

unl click is felt.

STEP 2. Aach Crossbars

Fit a WASHER (I) between SIDE

FRAME (A) and CROSSBAR (B).

Flat side of washer MUST sit in end

crossbar. Curved side of washer

MUST t against side frame.

Screw BOLT (H) through outer bolt

holes on a SIDE FRAME (A) and

into CROSSBAR (B).

TIP: Do not ghten unl drawers

are fully inserted.

STEP 3. Assemble Drawers

Aach DRAWER PULL KNOBS (K) to

all DRAWERS (D) with SCREWS (J)

and screwdriver.

B. Crossbar (4)

C. Tray (1)

D. Drawer (10)

E. Sleeve (4)

F. Caster (2)

G. Locking caster (2)

H. Bolt (8)

I. Washer (8)

J. Screw (10)

K. Drawer Pull Knob (10)

L. Allen Wrench

Parts List

A. Side frame (2)
