B16 Compressor Rev 2.1
Designed around the THAT 4305 dynamics processor IC, the B16 is a fairly easy to build and
use compressor that is useful in a wide variety of applications. The low distortion VCA, Burr-
Brown op-amps, and state of the art line driver and receiver ICs combine to form a transparent
circuit that keeps levels under control while adding a minimal sonic imprint. An optional
transformer allows for a true floating output and some transformer color, if desired. Attack and
release timing is generated by a program dependent non-linear capacitor circuit that eliminates
the need for separate attack and release controls.
Who Should Build This Kit?
The B16 is not difficult to build, well, other than the 4305 IC…but it also is not intended for
absolute beginners. The soldering on the 4305 IC can be done by SCA for an additional
charge! You should have built at least one project on a printed circuit board (PCB) before trying
the B16. Sorry, but soldering cables doesn’t count. If you’ve never built an electronic project
of any kind, this is probably not the one to start with. To guarantee success make sure you
have:
•The ability to make basic voltage and resistance measurements using a digital multi-
meter (DMM).
•At least a rudimentary understanding of Ohm’s Law and the relationship between
voltage, current, and resistance.
•Some experience soldering on printed circuit boards.
•The patience to follow instructions precisely and work carefully.
Essential Tools
Fine tipped 20-30 Watt soldering iron w/ cleaning sponge (Hakko 936 or similar)
Eutectic (63/37) rosin core or “no clean” solder (.025” diameter is usually best)
Good-quality DMM
Small needle nose pliers
Small diagonal cutters
Phillips screwdriver (#1)
Flat jeweler’s screwdriver
Highly Recommended Tools
Lead bender (Mouser 5166-801)
Magnifying glass
To adjust makeup gain, you’ll need the ability to generate and measure audio test signals
between –20dBu and +20dBu. Most DAWs can accomplish this task.
Optional Tools
Panavise with circuit board head (PV-312, PV-300, and PV-315 or PV-366) Oscilloscope
Signal generator
Work Area
Find a clean, flat, stable, well-lit surface on which to work. An anti-static mat is recommended
for this project. If you’re in a dry, static-prone environment, it’s highly recommended. The
importance of good lighting can’t be overstated. Component markings are tiny, and you’ll be
deciphering a lot of them.
Soldering Technique
Make sure your iron's tip is tinned properly and keep it clean! The trick to making perfect
solder joints is to heat the joint quickly and thoroughly before applying the solder, and a
properly tinned and clean tip is essential for this. Apply enough solder to form a "fillet"
between the lead and the pad, a little mound of solder that smoothly transitions from the plane
of the board up to the lead, but don’t use too much. The finished joint should be smooth and
shiny, not rough or gritty looking.
If you've never soldered a board with plated-through holes, you might be surprised to discover
how difficult it can be to remove a component once you've soldered it in place. If you're using
solder wick to correct a mistake, be very careful not to overheat the pads, since they will
eventually delaminate and "lift". It's often better to sacrifice the component and remove its
leads individually, then start over with a new part. If for some reason you need to unsolder a
multipin component (like a rotary switch or integrated circuit), remove as much solder as you
can with solder wick or a solder sucker, and then use a small heat gun to heat all the leads
simultaneously. With care, you can remove the component without damaging the board.
Instruction Conventions
Text in orange indicates a step where extra care needs to be taken. Doing it wrong isn’t a
disaster, but it’ll need to be corrected.
Text in red indicates a step that must be done correctly. Doing it wrong will guarantee
improper operation, and probably damage components and/or the circuit board.
Assembly
1. Before you begin, carefully unpack the kit and examine the parts. Check the contents of
each small bag against the BOM to make sure all the parts have been included. If you
think something’s missing, please e-mail the details to sa[email protected]
and we’ll ship replacement parts ASAP.
2. Generally, the idea when "stuffing" or “populating” a circuit board by hand is to start with
the lowest profile parts, such as the resistors, and work your way up to the taller
components. In each step below, insert the components, flip the board onto your work
surface component-side down, and carefully solder and trim the leads.
Use a piece of stiff cardboard to hold the parts in place while you flip the board. First,
orient the board as shown.
3. Before installing the resistors, prepare
the leads using small needle nose
pliers or a lead-forming tool as shown
here. Whatever you do, don’t bend
the leads at the resistor body and
force them into the board.This not
only results in an ugly job, but it can
also damage the parts.
4.
Solder U1 taking EXTRA care to not use too much solder and create shorts! Use a
microscope, magnifying glass, or cell phone camera, zoomed in, to check your
work! IF YOU ARE UNCOMFORTABLE SOLDERING THIS PART, SCA CAN SOLDER
IT FOR YOU FOR A SMALL CHARGE!
5. Insert the 1/4-watt resistors. Check the Bill of Materials (BOM) for help in reading the
resistor color bands. It's also a good idea to actually measure each resistor with your
DMM as you place it on the board, just in case you've read it incorrectly. Don't rely on the
photos for component placement. If the resistor value silk-screened on the board doesn't
agree with the value on the schematic or parts list, follow the schematic. You can leave
out the two ZERO ohm resistors if you will be installing an output transformer!
6. Next, add switching diodes D1 through D3. Diodes are polarized and must be
installed the right way around! The colored band on the diode matches the white band
on the silkscreen.
7. Next, add the protection diodes D6 through D18, the black ones. Diodes are polarized
and must be installed the right way around! The colored band on the diode matches
the white band on the silkscreen.
8. Install the ceramic, yellow capacitors. These capacitors are not polarized and can be
installed in either direction, but pay close attention to the capacitor markings! These
parts look alike but they are not interchangeable. Putting one in the wrong spot will not
prevent the compressor from passing signal, but it can seriously impair its performance!
9. Install the film capacitors at C16 and C21. These parts are not polarized and can be
installed in either direction, but pay close attention to the capacitor markings!
10. Install LEDs D4 and D5. LEDs are polarized and must be installed the right way
around! Install the long lead opposite the flat side of the silkscreen outline.
11. Add blue EMI filters L1 through L6. These parts are not polarized and can be installed in
either direction.
12. Add tantalum capacitor C10. Electrolytic capacitors are polarized and must be
installed the right way around! Be absolutely sure to observe the correct polarity when
installing these parts. The positive lead is marked with a colored stripe. The positive
pad on the circuit board is marked with a small "+" sign.
13. Install the aluminum electrolytic capacitors now. Electrolytic capacitors are polarized
and must be installed the right way around! Be absolutely sure to observe the correct
polarity when installing these parts. The negative leads of the electrolytic caps are
marked with a colored stripe. The positive pads on the circuit board are marked with a
small "+" sign.
14. Attach trim potentiometer R8.
15. Install relays RLY1 and RLY2.
16. Carefully mount the toggle switches SW1 and SW201. Be sure they're seated flat on the
board before soldering the leads. You may find it easier to solder the first lead of each
switch while the board is component side up.
