Serpent 903780 Manual de usuario
REAR HEAVE DAMPER ASSEMBLY # 903780
1
STEP 1
1.1 2.1
2.2
1.2
Use some silicone oil
during the assembly.
Use some silicone oil
during the assembly.
For the correct piston
holes please check the
default setupsheet.
Insert the o-ring
inside the spring
collar.
Note the correct
orientation of the
shock spacers .
Note the correct
position of the
o-ring .
1
2
STEP 2
2
STEP 3
3.3 3.43.1
SHOCKS LENGTH:
Measure the shock length
fully extended.
14.5
mm
Push the shock top
and the membrane
into the shock cap. 1- Fill up with sillicone oil
fully using the silicone
oil supplied in the kit.
For the correct cst value
please check the default
setupsheet.
2- Extend the shockrod fully
3- Move the shockrod
slowly up and down
to let ALL air bubbles
escape.
4- Close top only 3/4.
1-Bleed: push the
shockrod all the way
in slowly, to allow
excessive oil to escape.
2- Close the shock cap
completely.
3.2
Assemble the spring and spring-
cup (align correctly) to complete
the shock.
3
STEP 5 STEP 6
Remove rear shocks
and brackets
Remove these
2 screws
4
STEP 7 STEP 8
M3x8
M3x6 M3x6
M3x6
M3x6
M3x8
M3x8
M3x8 M3x6
1
1
2
2
M3x6
