Subsurface Mounting
You can mount a Senseon Plus Reader underneath a cabinet surface if the surface is not metallic. You may use the center
or the edge of a cabinet as a reference for the location.
1
HARDWARE INSTALLATION GUIDE I 5
A Senseon Plus Reader Mount in a vertical
arrangement. Mount a Reader via the Reader
Mount seen here. You can remove the vertical
Reader Mount’s detachable side tabs, or keep
them in place.
The dimensions of a VERTICALLY MOUNTED
Senseon Plus Reader. Make sure the cabinet
surface your Reader signals through is no more
than 1” thick.
Reader Mount in a horizontal arrangement with
detachable tabs still connected. As with a vertical
arrangement, you can remove the vertical Reader
Mount’s detachable side tabs, or keep them in place.
The dimensions of a HORIZONTALLY MOUNTED
Senseon Plus Reader. Make sure the cabinet
surface your Reader signals through is no more
than 1” thick.
NOTE!
Material composition, may impact the Reader’s signal strength. It’s recommended a subsurface-mounted Reader be
under a surface ¾” thick or less. Always test scan a Reader in a planned location before you mount it in place. Consider
a visual identier on a subsurface-mounted Reader to help a user know where to scan.
