Sennheiser ConnectStation CS1-M Manual de usuario

4 x analog input

servo balanced, mono

1/4" TRS | 6.35 mm jack plug

2 Connecting audio devices1 Connecting the product to the mains

http://192.168.0.10/

Open your browser and

navigate to: 192.168.0.10

Configure the laptop with the

static IP address 192.168.0.2

user name: admin

password: ******

Enter user name and

password for login.

new password:

1: Administrator Login

2: Configure Regulatory Domain

3: Configure Access Point

Follow the instructions in the Web

Interface to perform the initial setup

of your ConnectStation.

The configuration ist done. The system is ready to connect to a mobile

device containing the MobileConnect App.

Default user name: “admin”

password: “sennheiser”

LAN cable to

5.4 Performing the initial setup

5.2 Configuring the laptop

5.3 Logging in to the system

5.1 Connecting a laptop

Power supply

access point

The Connect Station provides DHCP

service to the access point and clients.

Connect the access point directly

to the ConnectStation.

Zoneflex 7372

access point

4 Connecting the access point3 Switching the product ON

< 1s on

Briefly press

the button

orange green green

boot up system running

AC Power

supply

ConnectStation CS1-M

MobileConnect Quick Guide

Sennheiser Streaming Technologies GmbH

Am Labor 1, 30900 Wedemark, Germany

[email protected]

560069, Publ. 09/14, A01

orange orange

Warning

red

Alert: Fatal error

Briefly press

the button < 1s off

orange

shut down system off

Technical specifications

Dimensions W x D x H

Weight

Voltage

Power

Operating temperature

Storage temperature

Analog In

Line In

Resolution AD

Signal to Noise Ratio (SNR)

Sample rate

THD @ -3 dBFS

Frequency response

@ 44.1 kHz, -0.5dB

Input line

Input impedance

Input sensitivity

Input level for 0 dBFS @ Low Gain

Input level for 0 dBFS @ +4 dBu

Input level for 0 dBFS @ -10 dBV

List of Audio Channels

Analog In 4 Channels

SPDIF

Analog I/O 2 Channels

ADAT Input

ADAT Output

48.3 cm x 24.0 cm x 4.4 cm

(19.0" x 9.5" x 1.7")

2.9 kg (6.39 lbs)

100 - 240 V AC, 50/60 Hz

60 W nominal

+5 °C to +45 °C (41°F to 113 °F)

-20 °C to +75 °C (-4°F to 167 °F)

4 Channels, 1/4" TRS jack

24 Bit

116 dBA

48 kHz

< -110 dB

5 Hz – 21.5 kHz

Servo balanced (Mono)

10 k

Low Gain, +4 dBu, -10 dBV

+19 dBu

+13 dBu

+2 dBV

Active

N.A. (Future use)

6 Switching the product OFF

Delivery includes

1x ConnectStation CS1-M

1x Power Supply Cable 1.8 m (EU/UK/US)

1x Ruckus ZoneFlex 7372 Access Point (worldwide/US)

1x Ruckus Power Supply Adapter for Access Point (EU/UK/US)

INPUT: 100 – 240 V AC, 50/60 Hz, 0.4 A

OUTPUT: 12 V DC, 1.0 A

Audio Cables

1x 15-pin D-sub to 4 x RCA Analog, 2 x MIDI, 1 x Phones

1x 9-pin D-sub to 2 x RCA Digital (SPDIF)

1x Toslink Cable 2 mm, 2m

Quick Guide

Safety Guide

Checking for errors – Troubleshooting

DHCP enabled,

ports 1194 +1195,

UDP open

Sennheiser Service:

Please send an email with the serial number of the ConnectStation CS1-M to

[email protected] for remote service .

For monitoring and remote diagnostics connect the device to the internet.

ConnectStation CS1-M

MobileConnect
