Sennheiser RS 145 COMFORT Manual de usuario
RS 145 comfort
Wireless Listening Pleasure
Instruction mManual
L
I
1
6
2
R
L
BALANCE
43
5
OFF ON
ON/OFF
II
A
B
E
C
D
7
8
CHARGE
9
COMPRESSION
0
INPUT LEVEL
OFF ON
Contents
1
Contents
Important safety instructions ................................................ 2
The RS 145 comfort RF headphone system ......................... 4
Delivery includes ...................................................................... 4
Product overview ..................................................................... 5
Putting the RS 145 comfort system into operation ............ 7
Setting up the transmitter .................................................... 7
Connecting the transmitter to a sound source ................. 8
Connecting the transmitter to the mains ........................... 9
Inserting and changing the headphones’ rechargeable
batteries .................................................................................... 9
Charging the headphones’ rechargeable batteries ........ 10
Adjusting the headband of the headphones ................... 11
Using the RS 145 comfort system ....................................... 12
Switching the transmitter on and off ............................... 12
Switching the headphones on and off .............................. 13
Searching for a sound source .............................................. 14
Changing the transmission channel .................................. 14
Adjusting the signal of the sound source ........................ 15
Adjusting the volume ........................................................... 16
Adjusting the balance .......................................................... 16
Enhancing the speech intelligibility ................................... 16
Switching the acoustic signals (beeps) on and off ........ 17
Cleaning the RS 145 comfort system ................................. 18
If a problem occurs ... ............................................................ 19
Accessories and spare parts ................................................. 21
Specifications .......................................................................... 21
Manufacturer Declarations ................................................... 23
Index ........................................................................................ 24
Important safety instructions
2
Important safety instructions
• Read this instruction manual.
• Keep this instruction manual in a safe place. Always include this
instruction manual when passing the system on to third parties.
• Clean the devices and the mains unit only with a dry cloth.
• WARNING: To reduce the risk of fire or electric shock, do not expose the
devices and the mains unit to rain or moisture.
• Disconnect the mains connector from the wall socket
– to completely disconnect the device from the mains,
– during lightning storms or when unused for long periods of time.
• Only use the supplied mains unit.
• Ensure that the mains unit is
– always readily operable and easily accessible,
– properly plugged into the wall socket,
– only operated within the permissible temperature range (see
“Specifications” on page 21),
– not covered or exposed to direct sunlight for longer periods of time in
order to prevent heat accumulation.
Intended use of the devices
Intended use includes:
• having read this instruction manual, especially the chapter “Safety
instructions”,
• using the devices within the operating conditions and limitations
described in this instruction manual.
“Improper use” means using the devices other than as described in this
instructions, or under operating conditions which differ from those
described herein.
Important safety instructions
3
Safety instructions for NiMH rechargeable batteries
If abused or misused, rechargeable batteries may leak. In extreme cases,
they may even present:
Please understand that Sennheiser does not accept liability for damage
arising from abuse or misuse.
• a heat hazard,
• a fire hazard,
• a leakage hazard,
• an explosion hazard,
• a smoke or gas hazard.
Keep away from
children.
Only use original Sennheiser
rechargeable batteries.
Observe correct
polarity.
Do not short-circuit.
Do not expose to
moisture.
Switch rechargeable battery-
powered devices off after use.
Do not pack charged
batteries loose – danger
of shorting out / fire
hazard.
When not using rechargeable
batteries for extended periods of
time, charge them regularly
(about every three months).
Do not continue to use
defective rechargeable
batteries.
Do not heat above 70°C/158°F,
e.g. do not expose to sunlight or
throw into a fire.
Do not mutilate or
dismantle.
Only charge rechargeable
batteries at ambient
temperatures between 10 °C and
40 °C.
Immediately remove
rechargeable batteries
from obviously
defective devices.
Dispose of rechargeable batteries
at special collection points or
return them to your specialist
dealer.
Only charge rechargeable batteries with the appropriate
Sennheiser chargers.
The RS 145 comfort RF headphone system
4
The RS 145 comfort
RF headphone system
The RS 145 comfort RF stereo hi-fi headphone system offers
excellent sound quality and allows for wireless listening
everywhere in the house and garden. The lightweight
headphones are extremely comfortable to wear and very easy
to use.
The volume can easily be adjusted to individual needs. The
speech intelligibility can be enhanced on the transmitter.
Enjoy a completely unrestricted listening experience without
disturbing others.
Delivery includes
1 HDR 145 headphones
1 TR 145 transmitter with connection cable
2 AAA size NiMH rechargeable batteries, 1.2 V
1 T-RS 100 mains unit
1 adapter 3.5 mm to ¼“ (6.3 mm) jack socket
1 instruction manual
Product overview
5
Product overview
An overview of the headphones and the transmitter is given
on the inside front cover of this instruction manual.
Overview of the headphones
1Headband
2Volume control
3TUNE button
4Balance control for R/L
volume adjustment
5ON/OFF switch
6Earpad
Overview of the transmitter
7Charging cradle
8Operation indicator ,
green
9Charging indicator ,
red
0Indicator for speech
intelligibility and sound
signal, yellow
ACOMPRESSION switch
for speech intelligibility
enhancement
BChannel selector switch
CConnection cable
DAdapter for connection
cable
EConnector of mains unit
I
II
Product overview
6
Overview of the indicators and acoustic signals
Indicators on the transmitter
Acoustic signals and their meaning
Indicator Status Meaning
Operation indicator 8
(ON/OFF)
lit Sound source and
transmitter are switched
on.
Charging indicator 9
(CHARGE)
lit Rechargeable batteries
are being charged.
flashes Rechargeable batteries
are fully charged.
Indicator for speech
intelligibility
(COMPRESSION) and
sound signal
(INPUT LEVEL) 0
lit Speech intelligibility
enhancement is switched
on.
flashes slowly Volume of sound source
is adjusted too low.
flashes rapidly Volume of sound source
is adjusted too high.
Acoustic signal Meaning
6 short beeps No signal!
Transmitter is switched off
or out of range.
2 long beeps Rechargeable batteries are
almost flat.
Sequence of
3 beeps
Headphones have been
switched off.
