E-5
DIGITAL CLOCK
DIGITAL CLOCK FUNCTION
The set has a built-in digital clock, which is displayed into 2 situations:
(1) When the set is in “standby mode” (the display will automatically always show the
correct time). In this situation, the blue backlight is dimmed (to save electricity).
(2) When the set is in “on mode” (the blue backlight of the display is “on” in this mode, to
indicate that the set is powered “on”). In this situation the LCD display normally does
not automatically show the current time. But you can press the “clock” key on the remote
control to display the current time on the LCD screen for approximately 10 seconds.
(3) How to set the correct time:
The unit must be in standby mode and the keys for setting the time found on the remote
control. Follow the below procedures:
Press and hold the Clock key for more then 2 seconds to enter
into clock setting mode.
While “CLK 12” or “CLK 24” is flashing, use the or keys to select
between the clock format. Once desired format is flashing,
press the Clock key to confirm the selection.
Use the or keys to set the “HH” (hour). Then press the Clock key
to confirm the setting.
Repeat above step to input & confirm the “MM” selection. The clock
will begin to function after settings are complete
*Note: During clock setting if no button is pressed within several seconds, the system will exit clock setting
mode automatically. The clock settings will be crossed and need of resetting if power cord of unit is
disconnected as a power failure.
HOW TO SET THE “WAKE-UP” TIMER
1. On standby, press and hold the Timer key on the remote control for more than 2 seconds
to start timer setting mode. The wake up source will flash on the display (for example:
disc or USB).
2. Press or keys on remote control to select the source for timer:
iPod TUNER FM
CARD USB DISC
*The unit LCD display will show “disc” for sources CD-audio, CD-MP3 and DVD.
3. Press Timer on the remote control to confirm the setting.
4. Repeat step 2 and step 3 to set volume and the timer on and off times.
The timer is now fully programmed and the unit will automatically switch “on” (& “off”)
at the set times, as long as the timer function is “active”
- Press the Timer key on the remote control to turn the timer on or off. The “timer” icon
will appear on the display if time is “on”.
*Note: - The timer-off function will not be activated if the start and stop time are the same.
- During timer setting, if no button is pressed within several seconds, the system will exit the time
setting mode automatically.
