Seiko KINETIC 7L22 Manual de usuario

Cal. 7L22

INSTRUCTIONS (P. 3)

BEDIENUNGSANLEITUNG (S. 16)

INSTRUCTIONS (P. 29)

ISTRUZIONI (P. 42)

INSTRUCCIONES (P. 57)

INSTRUÇÕES (P. 70)

用法説明 (83 頁)

English

You are now the proud owner of a SEIKO KINETIC®Cal. 7L22. For best results, please read the

instructions in this booklet carefully before using your SEIKO KINETIC®. Please keep this manual

handy for ready reference.

Sie sind jetzt stolzer Besitzer einer SEIKO KINETIC®Kal. 7L22. Lesen Sie diese Bedienungsanleitung

vor der Verwendung Ihrer SEIKO KINETIC®aufmerksam durch, um die optimale Nutzung dieser

Uhr zu gewährleisten. Heben Sie diese Bedienungsanleitung gut auf, um jederzeit wieder nachlesen

zu können.

Vous voici l’heureux propriétaire d’une montre SEIKO KINETIC®Cal. 7L22. Pour en obtenir de

bonnes performances, veuillez lire attentivement les explications de ce mode d’emploi avant

d’utiliser votre montre SEIKO KINETIC®. Conservez ce mode d’emploi pour toute référence ultérieure.

Grazie per aver acquistato questo orologio SEIKO KINETIC®Cal. 7L22. Per ottenerne i migliori

risultati leggere attentamente le istruzioni di questo libretto prima di passare all’uso dell‘orologio

stesso. Tenere poi il manuale a portata di mano, per ogni eventuale futura, ulteriore consultazione.

Usted es ahora un orgulloso propietario de un Reloj SEIKO KINETIC®Cal. 7L22. Para los mejores

resultados, por favor lea las instruciones de este librito cuidadosamente antes de utilizar su Reloj

SEIKO KINETIC®. Le rogamos que guarde este conveniente manual para pronta referencia.

Você pode sentir-se orgulhoso de ter adquirido um SEIKO KINETIC®Cal. 7L22. Para obter dele os

resultados máximos, solicitamos-lhe que, antes de usar o seu SEIKO KINETIC®, leia atentamente

as instruções contidas neste opúsculo. E guarde este manual para referências futuras.

ENGLISH

CONTENTS

Page

FEATURES .................................................................................................................. 4

HOW TO CHARGE AND START THE WATCH ........................................................... 4

POWER RESERVE IN YOUR SEIKO KINETIC WATCH............................................... 5

REMARKS ON THE KINETIC E.S.U. ........................................................................... 6

ENERGY DEPLETION FOREWARNING FUNCTION................................................... 6

TIME/CALENDAR SETTING ........................................................................................ 7

FOR MODELS WITH SCREW LOCK TYPE CROWN .................................................. 7

STOPWATCH .............................................................................................................. 8

TACHYMETER ............................................................................................................ 11

NOTES FOR USING THE WATCH .............................................................................. 13

SPECIFICATIONS........................................................................................................ 15

✩

For the care of your watch, see “TO PRESERVE THE QUALITY OF YOUR

WATCH” in the attached Worldwide Guarantee and Instruction Booklet.

English

Swing the watch from side to side approximately 500 times.

*Swing rhythmically at a rate of twice a second.

* 500 swings will start the watch and the second hand will move at one-second intervals.

Swing the watch approximately 200 times further to reserve one day of power.

Set the time/calendar and put on the watch.

HOW TO CHARGE AND START THE WATCH

FEATURES

SEIKO KINETIC Cal. 7L22 is an analogue quartz watch equipped with an Automatic

Generating System developed by SEIKO. It generates the electric energy to power the

watch, utilizing the movement of the arm, and stores it in the KINETIC ELECTRICITY

STORAGE UNIT (KINETIC E.S.U.), which requires no periodical replacement unlike

conventional button-type batteries.

English

POWER RESERVE IN YOUR SEIKO KINETIC WATCH

●The electric energy generated while the watch is worn on your wrist is stored in the

KINETICELECTRICITYSTORAGEUNIT(KINETICE.S.U.). Itisapowersourcecompletely

differentfromconventionalbatteriesforwatches,andtherefore,doesnotrequireany

periodicalreplacement.

●TheKINETICE.S.U.isacleanandenvironmentallyfriendlypowersource.

●PowerreserveguidelinesfortheKINETICE.S.U.

YoucanestimatethepowerreserveaccumulatedintheKINETICE.S.U.fromthemanner

inwhichyouwearthewatch.

Wearing the watch continuously for 12 hours will accumulate approximately two

additionaldaysofpowerreserve.

Ifyouwearthe watch everydayfor12 hoursforamonth,for example,twoadditional

monthsofpowerwillbereserved.

●Fullcharge

When the watch is fully charged, the watch will keep operating for approximately

5months. Thedurationofchargedecreasesgraduallyovertime. Theextentofdecrease,

however,variesdependingontheenvironmentandconditionofuse.

●Precautionsforthoseonlywearingthewatchoccasionally

Ifyou use the watchonly occasionally, it is likely that youwill find the watchrunning

downwhenyoudecidetouseit. Beforewearingthewatch,besuretochargeitsufficiently

followingtheprocedurein“HOWTOCHARGEANDSTARTTHEWATCH”.

English

CAUTION

Never install a silver oxide battery for conventional watches in place of the KINETIC

E.S.U. The battery may burst, become very hot or catch fire. Even if the battery

is installed, electricity will not be conducted.

ENERGY DEPLETION FOREWARNING FUNCTION

●When the second hand starts moving at two-second intervals instead of the normal

one-secondintervals,thewatchwillrundowninapproximately12hours.

*If the second hand starts moving at two-second intervals while the stopwatch is in use, the watch will

run down in approximately 45 minutes assuming the stopwatch remains in use. (Refer to “HOW TO

CHARGE AND START THE WATCH”.)

Inthiscase,swingthewatchfromsidetosidetosufficientlychargetheKINETICE.S.U.

REMARKS ON THE KINETIC E.S.U.

●Donotpullthecrownouttothesecondclickwiththeintentionofstoppingthesecond

hand just to save energy. By doing so, a large amount of current flows through the

built-in IC. Therefore, pulling out the crown to the second click will not save energy

but,infact,consumemoreenergythanusual.

English

➠➠

TIME/CALENDAR SETTING

Minute hand

Date

Second hand

Hour hand

a. Screwed-in position c. First click

b. Unscrewed position d. Second click

1. Pull out the crown to the first click and

turn it counterclockwise to set the

previous day’s date.

2. Pull out the crown to the second click

when the second hand is at the 12 o’clock

position, and advance the hands by

turning the crown counterclockwise to

set the desired date.

3. Turn the hands to set the desired time.

4. Push back the crown completely in

accordance with a time signal.

Ifyourwatchhasascrewlocktypecrown,

turnthecrowncounterclockwisetounscrew

it,andthen,pullitout.

Afterusingthecrown,pushitbackintothe

unscrewedposition.

Screwinthecrowncompletelybyturningit

clockwisewhilepressingit.

FOR MODELS WITH SCREW LOCK TYPE CROWN

a b c d

➠➠

English

STOPWATCH

●Thestopwatchcanmeasureupto45minutesin1/5secondincrements.

●ThemeasuredtimeisindicatedbytwoSTOPWATCHhandsthatmoveindependently

ofthehandsfortimeindication.

●After48minutes,thestopwatchwillstopautomatically.

TIPS ON READING THE HANDS

●TheSTOPWATCHsecondhandturnsafullcirclein60seconds.

●TheSTOPWATCHminutehandmovesinone-minuteincrementsupto45minutes. It

moves accordingly as the STOPWATCH second hand moves. Please note that the

measured time may be misread if you only see the time shown by the STOPWATCH

minutehand.

STOPWATCH

Second hand STOPWATCH

Minute hand

English

Ex. ) 9 minutes 58 seconds

Be careful not to misread 9 minutes 58 seconds as 10 minutes 58 seconds even if

the STOPWATCH minute hand is close to the 10 minutes position.

◆

STOPWATCH second hand reading:

The STOPWATCH second hand almost

points to “58”.

◆

STOPWATCH minute hand reading:

The STOPWATCH minute hand almost

points to “10” but should be read as

“9”.

English

STOPWATCH OPERATION

●Beforeusingthestopwatch,besuretoresettheSTOPWATCHhandsto“0”position.

1) Check that the watch is operating normally.

*If the watch has stopped completely or if the second hand is moving at two-second intervals, charge

the watch sufficiently. (See “HOW TO CHARGE AND START THE WATCH”)

2) Press button B to reset the STOPWATCH hands to “0” position.

*When using the stopwatch for the first time after the watch has been charged to start operation, be

sure to reset the stopwatch even if the STOPWATCH hands are at “0” position.

Standard measurement

START RESET

▼

STOP

▼

Accumulated elapsed time measurement

START

▼

STOP

▼

RESTART

▼

• • • • STOP

▼

RESET

* Restart and stop of the stopwatch can be repeated by pressing button A.

*Be careful not to press button B by mistake while the stopwatch is measuring.

*Donotpress buttons A and B atthesametime, nor press one of thetwobuttonswhile keeping

the other pressed.

A BA

A AA BA

START/

STOP

RESET
