The present User Manual covers Protection Linear Microwave Bistatic sensors BARRIER-

24.M (general purpose) (referred to as the sensors for all the modifications) produced in

five modifications: BARRIER-24.M50, BARRIER-24.M100, BARRIER-24.M200,

BARRIER-24.M300, BARRIER-24.M500 differing in dimensions and maximum range of

operation.

The User Manual contains information necessary for learning the sensors and their

operation principle, mounting, powering the sensors and their correct exploitation.

The sensors contain the transmitter unit (referred to as Tx unit) and receiver unit (referred

to as Rx unit). The principle of operation is based on generation in the space between the

Tx unit and Rx unit of the electromagnetic field forming a volumetric detection zone in a

shape of a stretched ellipsoid of rotation and on registration of the alteration of this field in

the receiver in case of crossing the detection zone by an intruder.

The sensor triggers by breaking the contacts of the executive relay.

The sensors are to be used by the staff having learnt the present User Manual and having

practical skills in exploitation of technical security devices.

Start-up works and technical maintenance of the sensors in deployment site are to be made

by the staff having learnt the present User Manual.

BARRIER-24.M500, BARRIER-24.M300, BARRIER-24.M200, BARRIER-24.M100, BARRIER-24.M50 www.SECURITY-SNESORcom

4 14.01.2021

1 Description and Operation of the Sensor

1.1 Purpose of the Sensor

1.1.1 The Protection Linear Microwave Bistatic sensors BARRIER-24.M (general purpose)

are intended for the protection of flat open sites, for generation and transmission of

the alarm signal to the control panel in case of intruder crossing the protected site.

1.1.2 The sensors generate the alarm signal in the following cases:

when the detection zone is crossed by an intruder (a man from 50 kg and from

165 cm high) with the speed from 0,1 to 10 m/s «at his full height» or «bent»

with the probability not less than 0,98;

when the remote control signal is applied to the Tx unit;

when there is no signal from the Tx unit;

when an external electromagnetic field affects the Rx unit with the purpose to

mask it. It is allowed not to have the alarm signal when an external

electromagnetic field affects the Rx unit, in this case the sensor keeps its

working capacity;

when any of the units taking part in forming the detection zone is masked by a

screen;

when an unauthorized access to the control units takes place whether power on

or off;

when the power supply voltage drops below 9 V;

when Tx unit or Rx unit fails.

1.1.3 The sensors do not generate the alarm signal in the following cases:

–when a secondary standard target with linear dimensions up to 0,2 m is moving

within the detection zone at the distance of not less than 5 m from the units;

–when transport or a group of people is moving outside the detection zone at the

distance more than 1,5 m from the limit of the detection zone to the roadside

where such moving is possible;

when raining and snowing up to 40 mm/h;

when thick fog takes place;

when solar radiation takes place;

when winding up to 30 m/s;

when VHF emission in the band of 150-175 MHz up to 40 W takes place at the

distance more than 6 m.

1.1.4 The sensors exploitation conditions

–operating temperature range from minus 500C to plus 800C;

–relative air humidity up to 100% at the temperature of 250C with condensation of

moisture.

BARRIER-24.M500, BARRIER-24.M300, BARRIER-24.M200, BARRIER-24.M100, BARRIER-24.M50 www.SECURITY-SENSOR.com

5 14.01.2021

1.2 Technical Specifications

1.2.1 The configuration of the detection zone formed by the sensors installed on poles,

maximum operation range of the sensors, minimum operation range of the sensors,

width of the sensors detection zone, height of the sensors detection zone are given in

Figure 1.1 and Tables 1.1, 1.2.

Figure 1.1 –The configuration of the detection zone formed by the sensors installed

on poles

Notes

* For the sensors BARRIER-24.M50, BARRIER-24.M100, BARRIER-24.M200: at

the distance of 3-5 m from the poles, where the sensors Tx and Rx units are installed,

the probability of detecting the intruder moving «bent» is less than 0,98, because a

man can pass lower the detection zone.

** For the sensors BARRIER-24.M300, BARRIER-24.M500: the probability of

intruder detection by the sensors is equal on all the range of the detection zone and is

0,98, however the height of the detection zone close to the sensors Tx and Rx units is

reduced.

Table 1.1 –Maximum and minimum operation range of the sensors, width of the

detection zone

Names of sensors

Maximum

operation range

(L), m

Minimum

operation range

(L), m

Width of the

detection zone (b),

m, up to

BARRIER-24.M50

1,0

BARRIER-24.M100

100

1,5

BARRIER-24.M200

200

2,1

BARRIER-24.M300

300

2,7

BARRIER-24.M500

500

3,5

BARRIER-24.M500, BARRIER-24.M300, BARRIER-24.M200, BARRIER-24.M100, BARRIER-24.M50 www.SECURITY-SNESORcom

6 14.01.2021

Table 1.2 –Height of the sensors detection zone

Names of sensors

Height of the detection zone (h), m, not less than

BARRIER-24.M50

1,3*

BARRIER-24.M100

1,5*

BARRIER-24.M200

1,6*

BARRIER-24.M300

1,8*

BARRIER-24.M500

1,8*

____________________

* In the middle of the sector at the maximum range

1.2.2 The parameters of the sensors BARRIER-24.M (general purpose) correspond to the

values given in P. 1.2.1 while meeting the requirements on installation according to

Figure 1.2 and Table 1.3.

Figure 1.2 –Configuration of the protected site

Table 1.3 –Requirements to the parameters of the protected site

Length of the sector, m

100

200

300

500

Width of Zone А, m, not less

1,1

1,6

2,0

2,5

3,0

3,7

4,5

Width of Zone В, m, not less

0,5

0,7

1,0

1,5

2,1

2,7

3,5

Notes

1 Zone A should be free of:

–shrubs, trees, gates moving under the wind, etc.;

–moving people, animals.

2 No transport moving closer than 1 m from Zone A is allowed.

3 Provide in Zone B:

–grass up to 0,3 m high;

–snow up to 0,5 m high;

–irregularities of the ground up to ±0,3 m high;

–no foreign immobile objects and buildings

(separate poles not closer than 0,5 m from the axis of the sector are

allowed).

BARRIER-24.M500, BARRIER-24.M300, BARRIER-24.M200, BARRIER-24.M100, BARRIER-24.M50 www.SECURITY-SENSOR.com

7 14.01.2021

1.2.3 The shape of the detection zone generated by the sensors BARRIER-24.M50,

BARRIER-24.M100, BARRIER-24.M200 installed on the fence, maximum

operational range of the sensors, maximum width of the sensors detection zone,

maximum height of the sensors detection zone are given in Figure 1.3 and Table 1.4.

Figure 1.3 –The shape of the detection zone generated by the sensors BARRIER-24.M50,

BARRIER-24.M100, BARRIER-24.M200 installed on the fence

Table 1.4 –Maximum operational range, maximum width of the detection zone,

maximum height of the detection zone of the sensors BARRIER-24.M50, BARRIER-

24.M100, BARRIER-24.M200 installed on the fence

Name of sensors

Maximum length

of the sector (L),

Maximum width of

the DZ (B), m

Maximum height of

the DZ (Н), m

BARRIER-24.M50

1,0

BARRIER-24.M100

100

1,5

BARRIER-24.M200

100

1,5

Note –Maximum width (В) and maximum height (Н) of the detection zone

correspond to the given values in case the sensor is correctly configures according to

P.2.3.8.

Perimeter inside territory

Rx1

Tx1 Tx2

2,5...3,0 m

BARRIER-24.M500, BARRIER-24.M300, BARRIER-24.M200, BARRIER-24.M100, BARRIER-24.M50 www.SECURITY-SNESORcom

8 14.01.2021

1.2.4 The sensors operation frequency is 24,15 ± 0,10 GHz.

1.2.5 The sensors work by eight frequency channels (8 frequency letters).

1.2.6 The Tx and Rx units are synchronized by the radio beam.

1.2.7 The margin of the received radio signal is not less than 15 dB at the maximum

operation range of the sensors.

1.2.8 The time of the sensors technical readiness after power supply is ON is up to 60 s.

1.2.9 The duration of alarm is not less than 3 s.

1.2.10 The sensors recovery time to normal state after alarm is up to 10 s.

1.2.11 The sensors are powered from a direct current source with voltage from 9 t 30 V.

1.2.12 The sensors current consumption does not exceed 45 mA in all the band of supply

voltage.

1.2.13 The parameters of the executive relay: maximum commutated current up to 0,1 A,

maximum voltage up to 50 V, resistance in the closed state up to 110 Ohm (together

with the elements of lightning guard).

1.2.14 Load parameters of TAMPER button: current up to 0,2 A, voltage up to 80 V.

1.2.15 The sensors operation can be controlled remotely (see P. 3.3.2.1).

1.2.16 The sensors have LED indication of the state.

1.2.17 The input circuits of Tx unit and Rx unit are protected from short electric pick-up

(including storm) with amplitude up to 900 V.

1.2.18 The sensors are immune to electromagnetic interference according to GOST R

50009-2000, severity level 2.

1.2.19 The sensors contain two units –transmitter unit (Tx) and receiver unit (Rx),

protection level IP55 each.

1.2.20 The sensors can be configured and controlled in-field using the laptop working on

Windows platform.

1.2.21 The sensors can be configured and controlled in-field using the tablet working on

Android platform.

1.2.22 The sensors can be configured and controlled remotely using the computer.

1.2.23 Alarm and operation information is transmitted via the interface RS-485.

1.2.24 The Tx unit and Rx unit design assures maximum values of angles of rotation:

–on a bracket –not less than 600in horizontal plane and not less than 800in

vertical plane;

–about a support –360.

1.2.25 Mean time to failure –not less than 60000 hours.

1.2.26 Full mean lifetime –not less than 8 years.

1.2.27 Weight of the sensors including fixing elements, up to:

–2,9 kg for the sensors BARRIER-24.M300, BARRIER-24.M500;

–1,4 kg for the sensors BARRIER-24.M200, BARRIER-24.M100, BARRIER-

24.M50.

BARRIER-24.M500, BARRIER-24.M300, BARRIER-24.M200, BARRIER-24.M100, BARRIER-24.M50 www.SECURITY-SENSOR.com

9 14.01.2021

1.3 Contents of the Device

1.3.1 There are several modifications of the sensors depending on the maximum operation

range (see Table 1.5).

Table 1.5 –Modifications of the Protection Linear Microwave Bistatic sensors

BARRIER-24.M (general purpose)

Name

Security sensor BARRIER-24.M50

Security sensor BARRIER-24.M100

Security sensor BARRIER-24.M200

Security sensor BARRIER-24.M300

Security sensor BARRIER-24.M500

1.3.2 The completion of the sensors is given in Table 1.6

Table 1.6 –The completion of the Protection Linear Microwave Bistatic sensors

BARRIER-24.M (general purpose)

Name

Q-ty

Note

Protection Linear Microwave Bistatic sensor

BARRIER-24.M50

Transmitter unit

Receiver unit

Mounting kit

see Table 1.7

Kit of instruments and accessories

see Table 1.8

User Manual

Passport

Package

BARRIER-24.M500, BARRIER-24.M300, BARRIER-24.M200, BARRIER-24.M100, BARRIER-24.M50 www.SECURITY-SNESORcom

10 14.01.2021

Continuation of Table 1.6

Protection Linear Microwave Bistatic sensor

BARRIER-24.M100

Transmitter unit

Receiver unit

Mounting kit

see Table 1.7

Kit of instruments and

accessories

see Table 1.8

User Manual

Passport

Package

Protection Linear Microwave Bistatic sensor

BARRIER-24.M200

Transmitter unit

Receiver unit

Mounting kit

see Table 1.7

Kit of instruments and

accessories

see Table 1.8

User Manual

Passport

Package

Protection Linear Microwave Bistatic sensor

BARRIER-24.M300

Transmitter unit

Receiver unit

Mounting kit

see Table 1.7

Kit of instruments and

accessories

see Table 1.8

User Manual

Passport

Package

Protection Linear Microwave Bistatic sensor

BARRIER-24.M500

Transmitter unit

Receiver unit

Mounting kit

see Table 1.7

Kit of instruments and

accessories

see Table 1.8

User Manual

Passport

Package

Este manual sirve para los siguientes modelos

Tabla de contenidos

Manuales populares de Accesorios de otras marcas

Hillco

Hillco 2810 Manual de usuario

Siemens

Siemens QSA2700D Manual del operador

Contours

Contours ZY024 Manual de usuario

Saivod

Saivod VS621 Manual de usuario

Virtuox

Virtuox VirtuCLEAN 2.0 Manual de usuario

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manual de usuario

Z-Wave

Z-Wave HSD-200Z Manual de usuario

turck

turck FMX-IM-2UPLI63FX Manual de usuario

Decagon Devices

Decagon Devices 10HS Manual de usuario

UPPAbaby

UPPAbaby Cup Holder Manual de usuario

Elko

Elko SmartSensor Leakage Wireless Manual de usuario

Grizzly

Grizzly H8371 Manual de usuario

Panasonic

Panasonic HG-T Series Manual de usuario

IFM Electronic

IFM Electronic Efector 250 Series Guía de referencia

DigiDesign

DigiDesign 888/24 I/O Manual de usuario

PROZIS

PROZIS QUAY Manual de usuario

patagonia

patagonia PSI Vest Manual de usuario

SFC Energy

SFC Energy EFOY GO! Manual de usuario
