SeatsIncorporatedP/N712294Revision00

SIX-WAY MEMORY

POWER UNIT

USER MANUAL



Seats Incorporated

1515 Industrial Street

Reedsburg, WI 53959

(608) 524-8261 / Toll Free: 1-800-443-0615



SeatsIncorporatedP/N712294Revision00

Contents

Introduction.............................................................................................................3

SafetyAlertSignals...................................................................................................3

Six‐WayMemoryPowerUnitComponents.............................................................4

TransmissionLineConnection.................................................................................5

ProgrammingtheMemorySystem..........................................................................6

UsingtheProgrammedMemoryUnit......................................................................8

ChangingaProgrammedLocation...........................................................................8

Troubleshooting.......................................................................................................9

Maintenance..........................................................................................................10



SeatsIncorporatedP/N712294Revision00

Introduction



ThankyouforpurchasingtheSix‐WayMemoryPowerUnitfromSeats

Incorporated.Thisproductwasdesignedtoprovidemanyyearsofworry‐free

service.Shouldyouexperiencedifficultyduringtheoperationormaintenanceof

theproduct,pleasecallourCustomerServiceDepartment.Donotattemptto

alterormodifythedesignoftheSix‐WayMemoryPowerUnit.

ThismanualprovidesstepbystepinstructionstoproperlyoperateyourSix‐Way

MemoryPowerUnit.Itisimportanttoreadandfollowalldirectionscarefully.

Itemsrequiringspecialattentionarelabeledthroughoutthismanualasshow

below.

SafetyAlertSignals



SeatsIncorporatedP/N712294Revision00



Six‐WayMemoryPowerUnitComponents



SeatsInc.PartNumberDescription Image

782213Six‐WayPowerUnit



782240MemorySwitchand

HarnessAssembly



782241MemoryControlModule



SeatsIncorporatedP/N712294Revision00

TransmissionLineConnection



1. Atransmissionsafetyfeatureisdesignedintothecontrolmoduleto

preventthememorysystemfrombeingactivatedwhilethevehicleisin

motion.Thissafetyfeatureneedstobeconnectedforproperoperationof

thesix‐waymemorypowerunit.Thevehiclehasatransmissionenabled

signallinethatneedstobeconnectedtothewhiteorpinkpigtailwires

locatedattheswitchconnectorofthecontrolmodule(seeFigure1).

Ifyourvehicleprovidesa+12VsignalwhilethetransmissionisNOT

engaged,connectthetransmissionenabledsignalwiretothepinkpigtail.

IfthevehicleprovidesaGROUNDsignalwhenthetransmissionisNOT

engaged,connectthetransmissionenabledsignalwiretothewhitepigtail.



Figure1:TransmissionLineConnection

2. Oncethisfeatureisconnected,allsix‐waymemoryfunctionswilloperate

correctlywhenthevehicleisparked.Ifthevehicleisingear,memory

positionscannotbeactivated.However;allotherfeatureswilloperate,

includingthemanualpoweradjustmentofthepowerunit.



SeatsIncorporatedP/N712294Revision00

ProgrammingtheMemorySystem



Thememorysystemofthissix‐waypowerunitallowstheusertoprogramthe

seattoautomaticallyadjusttotheirspecificneedswiththepressofabutton.



Figure2:ManualControlPanel



Inorderfortheseatto“remember”anyposition,thesix‐waymemorypowerunit

mustbeprogrammedandstoredinthememorycontrolmodule.



1. Usingthefrontpaddleswitch,thecontrolstick,andtherearpaddleswitch

(Figure2),movetheseatintothedesiredseatingposition.Theseatadjust

controlsareasfollows:



FrontPaddleSwitch



Controlsthefrontmotor.



Up:Raisesthefrontof

theunit.

Down:Lowersthefront

oftheunit.

ControlStick



Controlsup,down,forward,and

rearwardoperation



Up:Raisesentireunit.

Down:Lowerstheunit.

Forward:Movesunit

forward.

Rearward:Movesunit

rearward.

RearPaddleSwitch



Controlstherearmotor.



Up:Raisestherearof

theunit.

Down:Lowerstherear

oftheunit.



SeatsIncorporatedP/N712294Revision00



Figure3:MemoryControlPanel



2. Whenthepowerunitispositionedtothedesiredlocation,pressandhold

theProgramSwitchfor3seconds.Allofthegreenmemorypositionslights

willflash.TheProgramSwitchcanbereleasedandthisindicatesthe

systemisreadytosetapositiontomemory.

3. Whileallthegreenlightsareflashing,presstheMemorySwitchyouwishto

program.Forinstance,toprogramposition“one”,pressMemorySwitch

Button1.ThegreenlightabovetheMemorySwitchwillilluminateandthe

powerunitisnowprogrammedtothelocation.

4. Repeatsteps1‐3toprogramothermemorylocations.TheSix‐Way

MemoryPowerUnitcanholdupto(4)programmedlocations.



SeatsIncorporatedP/N712294Revision00

UsingtheProgrammedMemoryUnit



Tomovethepowerunittoaprogrammedlocation,pressoneoftheMemory

Switchbuttonsthathasbeenpresettoalocation.Whenthebuttonispressed,

theseatwillautomaticallyadjusttotheprogrammedposition.

NOTE:Thepowerunitwillnotmovetoaprogrammedlocationwhenthe

vehicleisingear.Ifthepowerunitistravellingtoaselectedmemorylocation

whenthevehicleisplacedingear,itwillcompletetheoperation.

ChangingaProgrammedLocation



Tochangeapreviouslyprogrammedmemorylocation,followthestepsinthe

section“ProgrammingtheMemorySystem”.

NOTE:Movingthepowerunittoanewlocationandprogrammingthenew

locationwilloverrideanypre‐existingprogrammingfortheselectedmemory

switch.



SeatsIncorporatedP/N712294Revision00

Troubleshooting



Theamber(power)andgreen(memory)lightindicatorsactasatroubleshooting

guidefortheuser.PleaserefertothislistshouldanyproblemsoccurwiththeSix‐

WayMemoryPowerUnit.

Key: •On ○Off *Flashing



AmberLightGreenLights

(flash)

ProblemSolution

••Seatisnotinprogrammed

memorylocation.



○ ○ SleepModeStartvehicleandputintogearor

pressanycontrolbuttonto

deactivate“SleepMode”.

○ ○ NoPowertoSeatControl.1. Check30Ampfuse.

Replacewithappropriate

fuseifblown.

2. Powercabledisconnected.

Checkwiringforcable

disconnections.

3. Vehiclebatterydead.

**

(Any/All)

Duringpower‐up:Green

flashinglightsindicatethat

thosememorylocations

arenotset.

Setmemorylocation.

**

(One)

Ifwhenmemorybuttonis

pressed:Memoryatthat

locationisnotset.

Setmemorylocation.

**

(One)

Ifaftertraveltoalocation:

Powerunitstalledbefore

achievingprogrammed

location.

1. Movepowerunitwith

manualcontrolsandthen

pressthedesiredmemory.

2. Manuallymoveseatto

desiredlocationandreset

thememorylocation.



SeatsIncorporatedP/N712294Revision00

NOTE:Tocheckthefuse,opentheinlinefusecapasshowninFigure4and

inspectthefuse.Ifthefuseisdiscoloredorthefusehasblown,replacewith

another30AmpAutomotiveFuse



Figure4:Inline30AmpFuse

Maintenance



TheSix‐WayMemoryPowerUnithasbeendesignedtobemaintenancefree

throughoutthelifeoftheunit.Noadditionalmaintenanceisnecessary.

Thememorycontrolpanelcanbecleanedwithamildinteriorautomotive/

householdcleanerandadampcloth.Donotremovethecontrolpanelwhile

cleaning.

Whenthecleaningthecontrolpanelormemorymodule,besurewaterand/or

cleaningchemicalsdonotgetinsidethepanelormodule.Additionalwateror

cleaningchemicalsintheunitcancauseprematurecorrosionand/orfailuretothe

electricalcomponents.
