Seagull Models ANGEL GLIDER 2000 Manual de usuario

WWW.SEAGULLMODELS.COM

ASSEMBLY MANUAL

www.seagullmodels.com

ANGEL

2000 glider

Specications:

Wingspan---------------78.7 in ( 200cm).

Wing area---------------582.8sq.in ( 37.6sq.dm).

Weight-------------------2.4lbs ( 1.1 kg).

Length-------------------45.1 in ( 114.6cm).

Motor-------------------15 brushless outrunner motor.

Radio--------------------4 channel with 2 servos.

Electric conversion: Optional.

MS: 129

“ Graphics and specications may change without notice “ .

ARF

Angel 2000 Glider Instruction Manual.

ank you for choosing the ANGEL 2000 GLIDER ARTF by SEAGULL MODELS

COMPANY LTD,. e ANGEL 2000 GLIDER was designed with the intermediate/ad-

vanced sport yer in mind. It is a semi scale airplane which is easy to y and quick to as-

semble. e airframe is onventionally built using balsa, plywood to make it stronger

than the average ARTF, yet the design allows the aeroplane to be kept light. You will nd

that most of the work has been done for you already. e motor mount has been t-

ted and the hinges are pre-installed. Flying the ANGEL 2000 GLIDER is simply a joy.

is instruction manual is designed to help you build a great ying earoplane. Please read

this manual throughly before starting assembly of your ANGEL 2000 GLIDER . User the

parts listing below to indentify all parts.

Please be awere that this aeroplane is not a toy and if assemble or used incorrectly it is

capable of causing injury to people or property. WHEN YOU FLY THIS AEROPLANE YOU

ASSUME ALL RISK & REPONSIBILITY.

If you are inexperienced with basic RC ight we strongly recommend you contact your RC

supplier and join your local RC model Flying Club. RC Model Flying Clubs oer a variety of

training procedures designed to help the new pilot on his way to successful RC ight. ey

will also be able to advise on any insurance and safety regulations that may apply.

INTRODUCTION.

WARNING.

KIT CONTENTS

WWW.SEAGULLMODELS.COM

KIT CONTENTS.

SEA12901 Fuselage

SEA12902 Wing set

SEA12903 Tail set

ADDITIONAL ITEMS REQUIRED.

15 brushless outrunner motor.

Radio 4 chanel with 2 servos.

TOOLS & SUPPLIES NEEDED.

ick cyanoacrylate glue.

30 minute epoxy.

5 minute epoxy.

Hand or electric drill.

Assorted drill bits.

Modelling knife.

Straight edge ruler.

2mm ball driver.

Phillips head screwdriver.

220 grit sandpaper.

90° square or builder’s triangle.

Wire cutters.

Masking tape & T-pins.

read-lock.

Paper towels.

HINGING THE RUDDER.

Note : e control surfaces, including the ailer-

ons, elevators, and rudder, are prehinged with

hinges installed, but the hinges are not glued in

place. It is imperative that you properly adhere

the hinges in place per the steps that follow us-

ing a high-quality thin C/A glue.

Epoxy.

Hinge.

Angel 2000 Glider Instruction Manual.

HINGING THE ELEVATORS.

Glue the elevator hinges in place using

the same techniques used to hinge the

rudder.

INSTALLING THE HORIZONTAL

STABILIZER.

1) Using a ruler and a pen, locate the center-

line of the horizontal stabilizer, at the trailing

edge, and place a mark. Use a triangle and

extend this mark, from back to front, across

the top of the stabilizer. Also extend this

mark down the back of the trailing edge of

the stabilizer.

Draw center line.

2) Using a modeling knife, carefully remove

the covering at mounting slot of horizontal

stabilizer ( both side of fuselage).

4) With the stabilizer held rmly in place,

use a pen and draw lines onto the stabilizer

where it and the fuselage sides meet. Do this

on both the right and le sides and top and

bottom of the stabilizer.

Cut.

3) Slide the stabilizer into place in the precut

slot in the rear of the fuselage. e stabilizer

should be pushed rmly against the front of

the slot.

Pen.

5) Remove the stabilizer. Using the lines you

just drew as a guide, carefully remove the

covering from between them using a mod-

eling knife.

Remove covering.

WWW.SEAGULLMODELS.COM

When cutting through the covering to

remove it, cut with only enough pressure to

only cut through the covering itself. Cutting

into the balsa structure may weaken it.

6) Using a modeling knife, carefully remove

the covering that overlaps the stabilizer

mounting platform sides in the fuselage. Re-

move the covering from both the top and the

bottom of the platform sides.

7) When you are sure that everything is

aligned correctly, mix up a generous amount

of 30-minute epoxy. Apply a thin layer to the

top and bottom of the stabilizer mounting

area and to the stabilizer mounting platform

sides in the fuselage. Slide the stabilizer in

place and realign. Double check all of your

measurements once more before the epoxy

cures. Hold the stabilizer in place with T-pins

or masking tape and remove any excess epoxy

using a paper towel and rubbing alcohol.

Epoxy.

Remove covering.

8) Next assemble and install the elevator

control horn.

Start each screw partway into the holes

in the control horn, as shown. read the

screws in until the tip of each screw pro-

trudes just slightly from the bottom of the

horn base.

en hold the control horn clamping plate

in place while you nish threading the

screws all the way in. When done, you can

le or grind o the protruding sharp point

of the screws if you desire.

Angel 2000 Glider Instruction Manual.

Remove covering.

INSTALLING VERTICAL STABILIZER.

2) Using a modeling knife, remove the cov-

ering from over the precut hinge slot cut into

the lower rear portion of the fuselage.

1) While holding the vertical stabilizer rm-

ly in place, use a pen and draw a line on each

side of the vertical stabilizer where it meets

the top of the fuselage.

3) Next assemble and install the rudder con-

trol horn as the process for elevator control

horn.

When cutting through the covering to re-

move it, cut with only enough pressure to only

cut through the covering itself. Cutting into

the balsa structure may weaken it.

4) Slide the vertical stabilizer back in-

place. Using a triangle, check to ensure

that the vertical stabilizer is aligned 90º

to the horizontal stabilizer.

2x15mm

Epoxy.

WWW.SEAGULLMODELS.COM

90º

Vertical

Stabilizer.

Horizontal

Stabilizer.

SERVO ARM INSTALLATION.

Install adjustable servo connector in the

servo arm as same as picture below:

Rudder.

Elevator.

INSTALLING THE FUSELAGE SERVOS.

Because the size of servos dier, you

may need to adjust the size of the precut

opening in the mount. e notch in the

sides of the mount allow the servo lead to

pass through.

1) Install the rubber grommets and brass

collets onto the fuselage servo. Test t the

servo into the aileron servo mount.

2) Secure the servos with the screws pro-

vided with your radio system.

6) When you are sure that everything is

aligned correctly, mix a generous amount

of 30-minute epoxy. Apply a thin layer

to the mouting slot and to bottom of the

vertical stabilizer mounting area. Apply

epoxy to the bottom and top edges of the

ller block and to the lower hinge also. Set

the stabilizer in place and realign. Dou-

ble check all of your measurments once

more before the epoxy cures. Hold the

stabilizer in place with T-pins or masking

tape and remove any excess epxy using a

paper towel and rubbing alcohol. Allow

the epoxy to fully cure before proceeding.

Rudder.

Elevator.

Angel 2000 Glider Instruction Manual.

Elevator pushrod.

Control horn

ELEVATOR - RUDDER PUSHROD

HORN INSTALLATION.

1) Install the elevator control horn using

the same method as with the aileron con-

trol horns.

2) Position the elevator control horn on

the both side of elevator.

M2 lock nut.

M2 clevis.

8mm

Elevator pushrod.

Rudder pushrod.

8mm

Nylon Snap keeper.

Fuel tubing.

Hex Nut. M2 clevis.

Control horn

WWW.SEAGULLMODELS.COM

WING ASSEMBLY.

Remove covering.

ELECTRIC POWER CONVERSION.

Locate the items neccessary to install the

electric power conversion included with

your model.

Angel 2000 Glider Instruction Manual.

Install the spinner backplate, propeller

and spinner cone.

INSTALLING THE SPINNER.

e propeller should not touch any

part of the spinner cone. If it does, use a

sharp modeling knife and carefully trim

away the spinner cone where the propel-

ler comes in contact with it.

2x8 mm
