Seagate ST340016A Manual de usuario

... . . .. . . ... . ... . ... . . .. . . ... . ... . ... . . .. . . ..

Barracuda ATA IV Family

... . . .. . . ... . ... . ... . . .. . . ... . ... . ... . . .. . . ..

ST380021A, ST360021A,

... . . .. . . ... . ... . ... . . .. . . ... . ... . ... . . .. . . ..

ST340016A, ST320011A

... . . .. . . ... . ... . ... . . .. . . ... . ... . ... . . .. . . ..

Ultra ATA Interface Drives

... . . .. . . ... . ... . ... . . .. . . ... . ... . ... . . .. . . ..

Product Manual

... . . .. . . ... . ... . ... . . .. . . ... . ... . ... . . .. . . ..

...... . . . . ........ . . . . ........ . . . . ........ . . .

Barracuda ATA IV Family

. . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . .. . . . . . . .. . .

ST380021A, ST360021A,

...... . . . . ........ . . . . ........ . . . . ........ . . .

ST340016A, ST320011A

...... . . . . ........ . . . . ........ . . . . ........ . . .

Ultra ATA Interface Drives

...... . . . . ........ . . . . ........ . . . . ........ . . .

Product Manual

...... . . . . ........ . . . . ........ . . . . ........ . . .

Publication Number: 100129212, Rev. B, October 2001

Seagate, Seagate Technology and the Seagate logo are registered

trademarks of Seagate Technology LLC. Barracuda, DiscWizard, Sea-

Shield, SeaShell and 3D Defense System are either registered trade-

marks or trademarks of Seagate Technology LLC. Other product names

are registered trademarks or trademarks of their owners.

Seagate reserves the right to change, without notice, product offerings

or specifications. No part of this publication may be reproduced in any

form without written permission from Seagate Technology LLC.

Barracuda ATA IV Family Product Manual, Rev. B iii

Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Specification summary table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

1.0 Drive specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.1 Formatted capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.1.1 Default logical geometry . . . . . . . . . . . . . . . . . . . . . . . . . 5

1.2 Physical organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

1.3 Recording and interface technology . . . . . . . . . . . . . . . . . . . . 6

1.4 Physical characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.5 Seek time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

1.6 Start/stop times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.7 Power specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.7.1 Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

1.7.2 Conducted noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

1.7.3 Voltage tolerance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

1.7.4 Power-management modes . . . . . . . . . . . . . . . . . . . . . 10

1.8 Environmental specifications . . . . . . . . . . . . . . . . . . . . . . . . 11

1.8.1 Ambient temperature . . . . . . . . . . . . . . . . . . . . . . . . . . 11

1.8.2 Temperature gradient . . . . . . . . . . . . . . . . . . . . . . . . . . 12

1.8.3 Humidity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

1.8.4 Altitude . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

1.8.5 Shock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

1.8.6 Vibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

1.9 Drive acoustics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

1.10 Electromagnetic immunity . . . . . . . . . . . . . . . . . . . . . . . . . . 15

1.11 Reliability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

1.12 Agency certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

1.12.1 Safety certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

1.12.2 Electromagnetic compatibility . . . . . . . . . . . . . . . . . . . 16

1.12.3 FCC verification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

iv Barracuda ATA IV Family Product Manual, Rev. B

2.0 Configuring and mounting the drive . . . . . . . . . . . . . . . . . . . 19

2.1 Handling and static-discharge precautions . . . . . . . . . . . . . . 19

2.2 Jumper settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

2.2.1 Master/slave configuration . . . . . . . . . . . . . . . . . . . . . . 20

2.2.2 Cable-select option . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

2.2.3 Alternate capacity jumper . . . . . . . . . . . . . . . . . . . . . . . 21

2.2.4 Ultra ATA/100 cable . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

2.3 Drive mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

3.0 ATA interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

3.1 ATA interface signals and connector pins . . . . . . . . . . . . . . 25

3.1.1 Supported ATA commands . . . . . . . . . . . . . . . . . . . . . . 27

3.1.2 Identify Device command . . . . . . . . . . . . . . . . . . . . . . . 28

3.1.3 Set Features command . . . . . . . . . . . . . . . . . . . . . . . . . 33

3.1.4 S.M.A.R.T. commands . . . . . . . . . . . . . . . . . . . . . . . . . 34

Barracuda ATA IV Family Product Manual, Rev. B v

Figures

Figure 1. Typical startup and operation current profile . . . . . . . . . . . . 9

Figure 2. Master/slave jumper settings . . . . . . . . . . . . . . . . . . . . . . . 20

Figure 3. Ultra ATA cable connectors . . . . . . . . . . . . . . . . . . . . . . . . 22

Figure 4. Mounting dimensions—top, side and end view . . . . . . . . . 23

vi Barracuda ATA IV Family Product Manual, Rev. B

Barracuda ATA IV Family Product Manual, Rev. B 1

Introduction

This manual describes the functional, mechanical and interface specifi-

cations for the ST380021A, ST360021A, ST340016A and ST320011A.

These drives provide the following key features:

•7,200-RPM spindle speed and 2-Mbyte buffer combine for superior

desktop performance

•High instantaneous (burst) data-transfer rates (up to 100 Mbytes per

second) using Ultra DMA mode 5

•Giant magnetoresistive (GMR) recording heads and EPRML technol-

ogy, which provide the drives with increased areal density

•State-of-the-art cache and on-the-fly error-correction algorithms

•Full-track multiple-sector transfer capability without local processor

intervention

•Quiet operation

•350 Gs nonoperating shock

•The innovative, shock-absorbing SeaShield®cover protects the drive

against electrostatic discharge (ESD) and other handling damage. It

also includes installation instructions and jumper settings.

•SeaToolsdiagnosticsoftwareperformsadriveself-test thateliminates

unnecessary drive returns.

•The 3D Defense System™, which includes Drive Defense, Data

Defense and Diagnostic Defense, offers the industry’s most compre-

hensive protection for disc drives.

•Support for S.M.A.R.T. drive monitoring and reporting

•Support for Read Multiple and Write Multiple commands

•Support for autodetection of master/slave drives that use cable select

(CSEL)

2 Barracuda ATA IV Family Product Manual, Rev. B

Specification summary table

The specifications listed in this table are for quick reference. For details

on specification measurement or definition, see the appropriate section

of this manual.

Drive specification ST380021A ST360021A ST340016A ST320011A

Formatted Gbytes

(512 bytes/sector) 80.0 60.0 40.0 20.0

Guaranteed sectors 156,301,488 117,231,408 78,165,360 39,102,336

Bytes per sector 512

Default sectors per

track 63

Default read/write

heads 16

Default cylinders 16,383

Physical read/write

heads 4 3 2 1

Discs 2 2 1 1

Recording density

BPI (bits/inch max) 540,000

Track density TPI

(tracks/inch max) 58,000

Areal density

(Mbits/inch2 max) 31,300

Spindle speed

(RPM) 7,200

Internal data-

transfer rate OD

(Mbits/sec max)

555

I/Odata-transferrate

(Mbytes/sec max) 100

ATA data-transfer

modes supported PIO modes 0–4

Multiword DMA modes 0–2

Ultra DMA modes 0–5

Cache buffer 2 Mbytes

Height (mm max) 26.1

Width (mm max) 101.8

Length (mm max) 147.0

Weight (typical) 635 grams (1.4 lb)
