Seagate ST330610A Instrucciones de instalación y funcionamiento

Publication Number: 100153584, Rev. A, April 2001

Addendum to 100129581, Rev. A

U Series 6 Family Product Manual Addendum, Rev. A 1

Addendum for ST330610A, ST315312A,

ST310213A

This manual describes the functional, mechanical and interface specifi-

cations for the ST330610A, ST315312A and ST310213A. These drives

provide the following key features:

•8.9 msec seek time, 5,400-RPM and 2 Mbyte buffer combine for

excellent desktop performance

•Low power consumption

•High instantaneous (burst) data-transfer rates (up to 100 Mbytes per

second) using Ultra DMA mode 5

•Giant magnetoresistive (GMR) recording heads and GPRML technol-

ogy, which provide the drives with increased areal density

•State-of-the-art cache and on-the-fly error-correction algorithms

•Full-track multiple-sector transfer capability without local processor

intervention

•Quiet operation

•350 Gs nonoperating shock

•The innovative, shock-absorbing SeaShield®cover protects the drive

against electrostatic discharge (ESD) and other handling damage. It

also includes installation instructions and jumper settings.

•SeaTools diagnosticsoftwareperformsadrive self-test that eliminates

unnecessary drive returns.

•Support for S.M.A.R.T. drive monitoring and reporting

•Support for drive self-test (DST) with S.M.A.R.T. Execute Off-line

Immediate

•Support for Read Multiple and Write Multiple commands

•Support for autodetection of master/slave drives that use cable select

(CSEL)

Publication Number: 100153584, Rev. A, April 2001

Addendum to 100129581, Rev. A

2 U Series 6 Family Product Manual Addendum, Rev. A

Specification summary table

The specifications listed in this table are for quick reference. For details

on specification measurement or definition, see the appropriate section

of this manual.

Drive Specification ST330610A ST315312A ST310213A

Formatted Gbytes (×106bytes) 30.6 15.3 10.2

Guaranteed sectors 58,633,344 29,336,832 20,005,650

Bytes per sector 512

Default sectors per track 63

Default read/write heads 16

Default cylinders 16,383

Physical read/write heads 2 2 2

Discs 1 1 1

Recording density

BPI (bits/inch max) 562,436

Track density TPI (tracks/inch) 58,000

Areal density (Mbits/inch2 max) 32,622

Spindle speed (RPM) 5,400

Internal data-transfer rate

(Mbits/sec max)

436

I/O data-transfer rate

(Mbytes/sec max)

100

ATA data-transfer modes

supported PIO modes 0–4

Multiword DMA modes 0–2

Ultra DMA modes 0–5

Cache buffer (Mbytes) 2

Height (mm max) 26.1

Width (mm max) 101.85

Length (mm max) 147.0

Weight (typical) 550 grams (1.2 lb)

Track-to-track seek time

(msec typical) 1.2 (read) 2.0 (write)

Average seek time

(msec typical) 8.9

Publication Number: 100153584, Rev. A, April 2001

Addendum to 100129581, Rev. A

U Series 6 Family Product Manual Addendum, Rev. A 3

Average seek read

(msec typical) 9.9

Average seek write

(msec typical) 10.9

Full-stroke seek time

(msec typical) 22.0 (read) 24.0 (write)

Average latency (msec) 5.55 msec

Power-on to ready (sec typical) 6.5 sec

Standby to ready (sec typical) 6.5 sec

Spindown (sec typical) 10 sec

Startup current

(typical) 12V (peak) 2.0/2.5 amps

Seek power (typical) 7.5 watts

Read/Write power 7.5 watts

Idle mode (typical) 5.0 watts

Standby mode (typical) 1.2 watts

Sleep mode (typical) 0.9 watts

Voltage tolerance

(including noise) 5V ±5%, 12V ±10%

Ambient temperature 0° to 60°C (op.), –40° to 70°C (nonop.)

Temperature gradient

(°C per hour max) 20°C

Relative humidity

(op. and nonop.) 5% to 90% (op.)

5% to 95% (nonop.)

Relative humidity gradient 30% per hour max

Wet bulb temperature (°C max) 29.4 (op.), 40.0 (nonop.)

Altitude, operating –60.96 m to 3,048 m (–200 ft to 10,000+ ft)

Altitude(metersbelowmeansea

level, max) –121.92 m to 12,192 m (–400 ft to 40,000+ ft)

Shock, operating

(Gs max at 2 msec) 63

Shock, nonoperating

(Gs max at 1 and 2 msec) 350 Gs

Vibration, operating 0.5 Gs (0 to peak, 22–350 Hz)

Vibration, nonoperating 5 Gs (0 to peak, 22–350 Hz)

Drive Specification ST330610A ST315312A ST310213A

Publication Number: 100153584, Rev. A, April 2001

Addendum to 100129581, Rev. A

4 U Series 6 Family Product Manual Addendum, Rev. A

Electromagnetic compatibility

Korean RRL

If these drives have the Korea Ministry of Information and Communica-

tion (MIC) logo, they comply with paragraph 1 of Article 11 of the

Electromagnetic Compatibility control Regulation and meet the Electro-

magnetic Compatibility (EMC) Framework requirements of the Radio

Research Laboratory (RRL) Ministry of Information and Communication

Republic of Korea. These drives have been tested and comply with the

Electromagnetic Interference/Electromagnetic Susceptibility (EMI/EMS)

for Class B products. Drives are tested in a representative, end-user

system by a Korean-recognized lab.

•EUT name (model numbers): ST330610A, ST315312A, ST310213A

•Certificate numbers: E-H011-01-0713 (B), E-H011-01-0715 (B),

E-H011-01-0709 (B)

•Trade name or applicant: Seagate Technology

•Manufacturing date: April, 2001

•Manufacturer/nationality: Singapore

Drive acoustics

Sound power in bels

Idle mode

Quiet Seek

Performance Seek

3.0 (typical), 3.3 (max)

3.2 (typical), 3.5 (max)

3.4 (typical), 3.7 (max)

Nonrecoverable read errors 1 per 1013 bits read

Mean time between

failures (power-on hours) 600,000

Contact start-stop cycles (25°C,

40% relative humidity) 50,000

SeaShield Yes

Drive Specification ST330610A ST315312A ST310213A
