Seagate Exos E 2U12 Series Manual de funcionamiento

Exos® E 2U12, 2U24, 5U84 Series

Hardware Installation and

Maintenance Guide

Abstract

This guide describes initial hardware setup for Seagate Exos E 2U12, 2U24, 5U84 Series controller enclosures and disk

enclosures. It also describes removal and installation of customer-replaceable components. The guide is intended for

use by storage system administrators familiar with servers and computer networks, network administration, storage

system administration and configurations, storage area network management, and relevant protocols.

Part Number: 204380800-00

Revision: A

Published: December 2022

the United States and/or other countries. Exos is a trademark of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries. All other

trademarks or registered trademarks are the property of their respective owners. When referring to disk capacity, one gigabyte (GB) equals one billion bytes, one terabyte (TB)

equals one trillion bytes, and one petabyte (PB) equals one thousand terabytes. Your computer's operating system may use a different standard of measurement and report a

lower capacity. In addition, some of the listed capacity is used for formatting and other functions, and thus will not be available for data storage. All coded instruction and

program statements contained herein remain copyrighted works and confidential proprietary and trade secret information of Seagate Technology LLC or its affiliates. Any use,

derivation, disassembly, reverse engineering, dissemination, reproduction, or any attempt to modify, prepare derivative works, reproduce, distribute, disclose copyrighted

material of Seagate Technology LLC, for any reason, in any manner, medium, or form, in whole or in part, if not expressly authorized, is strictly prohibited. Seagate reserves the

right to change, without notice, product offerings or specifications.

Regulatory and compliance information

For the latest regulatory and compliance information see www.seagate.com/support/data-storage-systems/. Scroll down to the Compliance, Safety and Disposal Guide link.

Contents 3

Contents

1 Introduction 8

Knowledge prerequisites 8

Product documentation and support 8

Intended audience 9

2 System overview 10

Expansion enclosure components 10

Expansion enclosure chassis 11

2U enclosure components 11

5U enclosure components 13

Optional components 16

3 Initial install preparations 18

Installation checklist 18

Complete installation prerequisites 19

4 Installation of 2U enclosures 21

Unpack and prepare the 2U enclosure 21

Install the 2U rackmount rail kit 22

Mount the 2U enclosure into the rack cabinet 25

Populate the 2U enclosure 27

Test enclosure electrical earth connection 28

Route 2U enclosure data cables and power cords 28

Route 2U enclosure host cables and expansion data cables 29

Route 2U enclosure power cords 30

5 Installation of 5U enclosures 32

Unpack and prepare the 5U enclosure 32

Install the 5U rackmount rail kit 33

Mount the 5U enclosure into the rack cabinet 37

Access a drawer 40

Populate the 5U enclosure 41

Test enclosure electrical earth connection 42

Route 5U enclosure data cables and power cords 42

Route 5U enclosure host cables and expansion data cables 43

Route 5U enclosure power cords 44

6 Operation of 2U enclosures 46

Apply power to the 2U enclosure 46

Remove power from the 2U enclosure 47

Set the unit identification number 47

Interpret system LEDs 47

Interpret 2U12 and 2U24 operator's panel LEDs 48

Interpret SAS 12Gb/s expansion input/output module LEDs 49

7 Operation of 5U enclosures 51

Apply power to the 5U enclosure 51

Remove power from the 5U enclosure 52

Set the unit identification number 52

Interpret system LEDs 52

Interpret 5U enclosure operator's panel LEDs 53

Interpret drawer LED panels 54

Interpret SAS 12Gb/s expansion input/output module LEDs 55

8 Hardware installation and configuration issues 57

Address initial start-up issues 57

Interpret storage and expansion enclosure fault LEDs 58

2U12 and 2U24 enclosure fault LEDs 58

5U84 enclosure fault LEDs 60

Identify 2U enclosure fault conditions 65

Identify 5U enclosure fault conditions 65

Isolate hardware and connectivity faults 66

Isolate system application faults 67

Take corrective action for 2U enclosures 68

Take corrective action for 5U enclosures 69

9 In-service field maintenance for 2Uenclosures 73

Replace a 2U enclosure drive module in its carrier 74

Replace a 2U enclosure input/output module 76

Replace a 2U power cooling module 78

10 In-service field maintenance for 5Uenclosures 82

Replace a 5U enclosure drive module in its carrier 83

Replace a 5U enclosure input/output module 87

Replace a 5U fan cooling module 90

Replace a 5U power supply unit 91

A Technical specifications 95

B Standards and regulations 97

International standards 97

WEEE recycling 97

Index 98

4Contents

Contents 5

Figures

Figure 1 2U12 and 2U24 front panel area 12

Figure 2 2U12 and 2U24 rear panel area 13

Figure 3 5U84 front panel area 14

Figure 4 5U84 rear panel area 15

Figure 5 Profile and top views of fully populated 5U84 drawers 16

Figure 6 2U12 and 2U24 expansion enclosure packaging, shown without plastic for clarity 21

Figure 7 2U enclosure outer rail components 23

Figure 8 Attachment of front mount bracket to front rack cabinet posts 24

Figure 9 Adjustment of rail length to fit rack cabinet 24

Figure 10 Attachment of rear mount bracket to rear rack cabinet posts 25

Figure 11 Alignment between 2U chassis and rails (removed rear components for clarity) 26

Figure 12 Installation of 2U rear screw to secure chassis to rail 27

Figure 13 Sample reverse cabling method among the host system and 2U expansion modules 30

Figure 14 Sample invalid loop (in red) among the host system and 2U expansion modules 30

Figure 15 2U power cord routing to independent power distribution units 31

Figure 16 Default belt straps already around the 5U expansion enclosure 32

Figure 17 5U left and right rail components 35

Figure 18 Insertion of 5U front mount bracket screw 36

Figure 19 Insertion of 5U rear mount bracket screws 36

Figure 20 Alignment between 5U chassis and rails, minus rear components for clarity 38

Figure 21 Secure chassis operator's panel to rack posts 39

Figure 22 5U rear chassis connection to outer rails, detail, minus rear components for clarity 39

Figure 23 Safety lock to release left drawer slide rail (lower drawer used for relational clarity) 40

Figure 24 Carrier latch features 41

Figure 25 Release latch open and unlocked 41

Figure 26 Release latch properly locked 41

Figure 27 Sample reverse cabling method among the 5U host system and expansion modules 44

Figure 28 Sample invalid loop (in red) among the 5U host system and expansion modules 44

Figure 29 5U power cord routing to independent power distribution units 45

Figure 30 2U12 and 2U24 operator's panel LEDs 49

Figure 31 SAS 12Gb/s expansion input/output module LEDs 50

Figure 32 5U84 operator's panel LEDs 54

Figure 33 5U84 drawer LED panel 55

Figure 34 SAS 12Gb/s expansion input/output module LEDs 56

Figure 35 2U12 and 2U24 operator's panel fault LEDs 58

Figure 36 2U12 and 2U24 fault LEDs on carrier bezel 59

Figure 37 SAS 12Gb/s expansion module fault LEDs 59

Figure 38 Power cooling module fault LEDs 60

Figure 39 5U84 operator's panel fault LEDs 61

Figure 40 5U84 drawer fault LEDs on drawer LED panel 62

Figure 41 Drive fault LED on carrier bezel 62

Figure 42 SAS 12GB expansion module fault LEDs 63

Figure 43 Fan cooling module fault LEDs 64

Figure 44 Power supply unit fault LEDs 64

Figure 45 2U12 and 2U24 fault LEDs on carrier bezel 74

Figure 46 Removal of 2U12 and 2U24 drive in carrier 75

Figure 47 Replacement with open 2U12 and 2U24 carrier handle 76

Figure 48 SAS 12Gb/s expansion input/output module LEDs 77

Figure 49 Input/output module removal, upper 78

Figure 50 Replacement input/output module 78

Figure 51 Power cooling module removal 80

Figure 52 Replacement power cooling module 80

Figure 53 Drive fault LED on carrier bezel 83

Figure 54 Operator's panel 84

Figure 55 Drawer panel 84

Figure 56 Drawer release and access 84

Figure 57 Carrier latch features 85

Figure 58 Removal of drive in its carrier 85

Figure 59 Replacement of drive in its carrier 86

Figure 60 Release latch open and unlocked 86

Figure 61 Release latch properly locked 86

Figure 62 Safety lock to release left drawer slide rail of lower drawer 87

Figure 63 SAS 8Gb/s input/output module LEDs 88

Figure 64 Input/output module removal, left 89

Figure 65 Replacement input/output module 89

Figure 66 Fan cooling module fault LEDs 90

Figure 67 Fan cooling module removal 91

Figure 68 Replacement fan cooling module 91

Figure 69 Power supply unit fault LEDs 92

Figure 70 Power supply unit removal 93

Figure 71 Replacement power supply unit 93

6Contents

Contents 7

Tables

Table 1 Expansion enclosure variations 10

Table 2 Installation checklist tasks 18

Table 3 Fault LED prioritization 48

Table 4 Fault LED prioritization 53

Table 5 2U enclosure non-fault conditions 65

Table 6 5U enclosure non-fault conditions 66

Table 7 2U enclosure corrective action for fault conditions 68

Table 8 5U enclosure corrective action for fault conditions 69

Table 9 2U enclosure time limits for FRU replacement 73

Table 10 5U enclosure time limits for FRU replacement 82

Table 11 Expansion enclosure dimensions 95

Table 12 Expansion enclosure FRU weights 95

Table 13 Environmental specifications 95

Table 14 Power specifications 96

Table 15 Standard and approvals 97

8Chapter 1 Introduction

1 Introduction

Seagate Exos E expansion enclosures combine strong performance with high reliability, flexibility, and manageability. Powerful

and compact, the series expandable storage solution supports business with high-capacity and high-availability options.

The system is designed for high availability (HA), with no single point of failure for data or power. Input/output modules

(IOMs) are Storage Bridge Bay (SBB) v2.1 compatible for interconnects, power budgets and rails, form factors, and footprints.

WARNING! Heed all warnings and cautions on labeling and throughout this guide to reduce risk of personal injury or

damage to equipment. You must adhere to all safety requirements in this document. Some relate to the entire system, some to

the rack, some to the storage or expansion enclosure, and others to the FRUs within it.

Knowledge prerequisites

Make sure you have the appropriate knowledge base prior to product installation or service.

lServer system administration

lStorage system configuration

lStorage area network (SAN) management

lFibre Channel (FC) protocol

lSerial Attached SCSI (SAS) protocol

lEthernet protocol

Product documentation and support

To obtain documentation, videos, and product information, visit www.seagate.com/support/data-storage-systems/.

Content description Document Seagate QR codes

Enhancements, known issues, and updates Release Notes Documentation,

Support

2U documentation,

support

5U documentation,

support

Installation of the rail kit and enclosure into a rack Rackmount Guide*

Initial installation of hardware and component replacement Hardware Installation and Maintenance Guide

Regulatory compliance, safety, and disposal information Compliance, Safety, and Disposal Guide

*Printed document included in the shipkit

Chapter 1 Introduction 9

Intended audience

This guide is for software integration providers, storage installation professionals, and system administration personnel.

10Chapter 2 System overview

2 System overview

The Seagate Exos E expansion series enclosures consist of a sheet metal chassis that contains an integrated midplane and

module runner system. You can mount the expansion enclosure into a standard 19-inch rack cabinet, occupying either two

(2U) or five (5U) EIA rack space units. All plug-in modules are hot-swappable, but you must adhere to all safety precautions

and time limitations.

Type Typical set of plug-in modules Maximum expansions

2U12 expansion enclosure 2U chassis and rackmount railkit Up to 12

12 3.5-inch large form factor (LFF) drive modules in carriers (DDICs)

Two input/output modules (IOMs)

Two power cooling modules (PCMs)

2U24 expansion enclosure 2U chassis and rackmount railkit Up to 6

24 2.5-inch small form factor (SFF) DDICs

Two input/output modules (IOMs)

Two power cooling modules (PCMs)

5U84 expansion enclosure 5U chassis and rackmount railkit:

Contains two drawers, each with 42 drive modules

Up to 4

84 3.5-inch or 2.5-inch drive modules with adapters in carriers

Two input/output modules (IOMs)

Five fan cooling modules (FCMs)

Two power supply units (PSUs)

Four sideplane printed circuit boards (PCBs), two per drawer

Authorized service personnel only

Table 1 Expansion enclosure variations

Expansion enclosures can be configured as either an EBOD or a JBOD. An EBOD is an expansion enclosure attached to a

controller enclosure (RBOD). A JBOD is an expansion enclosure attached directly to a server that is equipped with a SAS HBA

or SAS RAID adapter.

CAUTION Make sure you are not connected to power at any time during installation procedures.

CAUTION Only operate the expansion enclosure in a dust-free environment to meet temperature control and airflow

requirements.

Expansion enclosure components

All Seagate Exos E expansion enclosures have 2 main access points:

1. Front panel area — Contains the operator's (ops) panel and access to drive modules in their carriers (DDICs)

a. 2U enclosures — Direct access to DDICs

b. 5U enclosures — Access to DDICs by opening the related drawer

2. Rear panel area — Contains input/output modules and methods for cooling and powering the expansion enclosure

Otros manuales para Exos E 2U12 Series

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Almacenamiento de Seagate

Seagate

Seagate ST8000NM0065 Manual de usuario

Seagate

Seagate ST6000VN0011 Manual de usuario

Seagate

Seagate ST336737LW Manual de usuario

Seagate

Seagate ST8000VX0002 Manual de usuario

Seagate

Seagate ST9235 Family Manual de usuario

Seagate

Seagate Momentus ST250LT003 - 9YG14C Manual de usuario

Seagate

Seagate 15K.4 - Cheetah - Hard Drive Manual de usuario

Seagate

Seagate ST39204LC - Cheetah 9.2 GB Hard Drive Manual de usuario

Seagate

Seagate PIPELINE HD MINI SERIES SATA ST9320328CS Manual de usuario

Seagate

Seagate ST625211CF Manual de usuario

Seagate

Seagate ST9160411AS - Momentus 7200.3 160 GB Hard... Manual de usuario

Seagate

Seagate Backup Plus Desktop Manual de usuario

Seagate

Seagate BARRACUDA GREEN ST1500DL003 Manual de usuario

Seagate

Seagate CTT 8000 Manual de usuario

Seagate

Seagate Constellation ES.2 SAS Manual de usuario

Seagate

Seagate MOMENTUS ST9500325AS Manual de usuario

Seagate

Seagate ST8000AS0002 Manual de usuario

Seagate

Seagate MARATHON 810 Manual de usuario

Seagate

Seagate ST3500601XS-RK - 500 GB External Hard Drive Manual de usuario

Seagate

Seagate ST9160511NS - Constellation 7200 160 GB Hard... Manual de usuario

Seagate

Seagate Momentus Thin 7200 RPM Manual de usuario

Seagate

Seagate ST9120823AS Manual de usuario

Seagate

Seagate Pulsar.2 ST800FM0022 Manual de usuario

Seagate

Seagate ST9100A Manual de usuario

Manuales populares de Almacenamiento de otras marcas

QNAP

QNAP TS 32PXU Series Manual de usuario

LaCie

LaCie RUGGED RAID Manual de usuario

Freecom

Freecom CLS DOCK Manual de usuario

PNY

PNY Attache P-FD64MBATT3 Manual de usuario

HP StorageWorks MSL2024 Manual de usuario

OLT

OLT 6x6 Maximizer Manual de usuario

Transcend

Transcend JetFlash 160 Manual de usuario

LaCie

LaCie RUGGED MINI Manual de usuario

Thunderbolt

Thunderbolt 600 Manual de usuario

Panasonic

Panasonic LB-DH8 series Manual

Intel

Intel RAID High Availability Manual de usuario

LaCie

LaCie 12big Thunderbolt 3 Manual de usuario

Spectra Logic

Spectra Logic T-Series Spectra T50e Manual de usuario

Panasonic

Panasonic LKM-F931-1 Manual de usuario

Tabernus

Tabernus Enterprise Erase E2400 Manual de usuario

Rocstor

Rocstor COMMANDER 3F series Manual de usuario

HP P9000 Manual de usuario

Western Digital

Western Digital Ultrastar Data60 Manual de usuario
