BL100 Fingerprint Lock User Manual
Version: 1.0
About This Manual
This user manual explains how to operate the BL100 fingerprint deadbolt
and how to navigate through its programming menu options. For the
fingerprint deadbolt installation, see the installation manual.
BL100 User Manual
BL100 User Manual
Thank you for purchasing the Scilox BL-100 fingerprint deadbolt.
Please read the documentation carefully before operating the deadbolt.
This manual describes all possible operations of the fingerprint deadbolt.
Note: The manufacturer, dealers and distributors of the Scilox BL100 will
not be held responsible for any damages caused by incorrect installation or
mishandling of the fingerprint deadbolt. Any such damages will void the
manufacturer’s warranty.
Due to manufacturer’s product updates during the life of the deadbolt, the
manufacturer cannot guarantee 100% consistency of the actual deadbolt as
described by this manual. If the reader discovers inconsistencies in this manual,
please bring them to the attention of the manufacturer so the corrections can be
published in subsequent revisions of the manual. Thank you.
BL100 User Manual
i
IMPORTANT NOTICE
–To ensure optimum performance of the fingerprint deadbolt, please
read the tips below before programming and installing.
1. Keep your fingers clean when operating the deadbolt, so that your fingerprints
can be recognized by the deadbolt’s fingerprint sensor.
2. When you first purchase and operate your new deadbolt, its factory default
setting allows you to unlock the deadbolt with ANY finger.
3. To ensure security, the manufacturer strongly suggests you immediately change
the default master passcode (98989) after initial installation
4. Prior to enrolling ordinary (non-Administrator) users, you must first enroll at least
one “Administrator User”. Administrator Users have the unique ability to
program the deadbolt and add/delete users. Conversely, “Ordinary Users”can
only open the door and have no access to the deadbolt’s programming menu.
5. Each user can register one fingerprint and one PIN (Personal Identification
Number).
6. When opening the door, if you hear the deadbolt alarm beep and see the
indicator light flashing, this indicates the deadbolt’s AA batteries soon need to be
changed with fresh AA batteries.
7. The deadbolt automatically shuts off after 10 seconds of inactivity. This setting
helps conserve battery life.
8. You can register up to 100 users on the deadbolt. 5 can be Administrator Users
(Code: 995-999), and the other 95 will be Ordinary Users (Code: 000-994).
9. To ensure accuracy of the deadbolt’s fingerprint sensor, be sure to keep the
sensor clean.
10. When cleaning the entire deadbolt, exercise caution by not using corrosive
cleaning agents which could damage the deadbolt’s glossy finish. Instead, the
manufacturer recommends periodically cleaning the deadbolt with furniture
polish wax (e.g. Pledge).
BL100 User Manual
ii
11. If after installation you discover the deadbolt’s latch-bolt fails to freely move back
and forth or that the door no longer closes properly, this can normally be
corrected by properly re-aligning the strike plate's position on the door.
12. If at times you discover registered fingerprints or passwords fails to unlock the
deadbolt, use the mechanical key to unlock the deadbolt.
13. While programming the deadbolt, you can cancel out of any operation by
pressing and holding “0” at any time. When cancelling, NO changes will be saved.
Notice:
Remember to record user names along with user ID and codes on the provided
page in the back of this user manual.
BL100 User Manual
iii
Table of Contents
1 Operating Instructions ......................................................................- 1 -
1.1 Introduction to Fingerprint Deadbolt Functions....................- 1 -
1.2 Front and Rear Views.............................................................- 2 -
1.3 Precautions ............................................................................- 4 -
1.4 User Privileges........................................................................- 4 -
1.5 Finger Placement...................................................................- 5 -
2. Basic Operation................................................................................- 6 -
2.1 Change Master Pass Code (MPC)...........................................- 6 -
2.2 Enroll an Administrator User..................................................- 7 -
2.2.1 Enroll Administrator User’s Fingerprint ......................- 7 -
2.2.2 Enroll Administrator User’s PIN Code .........................- 8 -
2.3 Enroll an Ordinary User..........................................................- 8 -
2.3.1 Enroll an Ordinary User’s Fingerprint .........................- 9 -
2.3.2 Enroll an Ordinary User’s PIN Code.......................... - 10 -
2.4 User Verification.................................................................. - 11 -
2.4.1 Fingerprint Verification............................................ - 11 -
2.4.2 PIN Code Verification............................................... - 11 -
2.5 Delete a User....................................................................... - 12 -
2.5.1 Delete a User............................................................ - 12 -
2.5.2 Delete All Ordinary Users......................................... - 12 -
2.6 Enable / Disable a User....................................................... - 13 -
2.7 Reset Deadbolt to Factory Default Settings ........................ - 14 -
3 Other Functions ............................................................................. - 15 -
3.1 Routine Operation Indications............................................ - 15 -
3.2 Deadbolt Initialization......................................................... - 16 -
3.3 Unlock the Non-lock Status Alarm.......................................- 17 -
3.4 Automatic Menu Program Exit and System Power-off ........- 17 -
BL100 User Manual
iv
3.5 Using External Power...........................................................- 17 -
3.6 Unlocking Deadbolt with Mechanical Key .......................... - 19 -
3.7 Battery “Low Voltage”Warning...........................................- 20 -
4. Appendix....................................................................................... - 21 -
4.1 Technical Specifications ...................................................... - 21 -
Warranty........................................................................................... - 22 -
Support ............................................................................................. - 23 -
User Codes........................................................................................ - 24 -
BL100 User Manual
1
1 Operating Instructions
1.1 Introduction to Fingerprint Deadbolt Functions
1. By leveraging the perfect combination of biometrics and cryptography,
the Scilox BL100 fingerprint dead-bolt ensures door-security through its
fingerprint and PIN unlocking feature.
2. The deadbolt is very intuitive and user friendly. Indicator sounds and
lights help guide the user.
3. Enroll both “ordinary” users and “Administrator” users. Ordinary Users
only have door access, while Administrator Users can program the
deadbolt and add/delete users.
4. Administrator Users can quickly and easily delete users whose door access
rights have been revoked.
5. Deadbolt can recognize users by either Fingerprint or PIN code
verification.
6. Upon total AA battery failure, the deadbolt can still operate temporarily
by connecting a 9V battery to the deadbolt’s 9V battery external
connector.
7. Non-lock Alarm: When the deadbolt’s latch-bolt fails to pop out and
secure the door, the deadbolt’s deadbolt will make a short, sharp
alarming sound which will last one minute unless the alarm is
de-activated manually by locking or unlocking the deadbolt.
BL100 User Manual
2
1.2 Front and Rear Views
①Fingerprint sensor: You can only register or match fingerprints by placing your
finger on the fingerprint sensor when the green light in the fingerprint sensor
window is turned on; otherwise nothing will happen when you place your finger on
the fingerprint sensor.
②Lock/Unlock Button: Besides locking and unlocking the deadbolt, this button
can be used to open the deadbolt’s program menu. Press and hold this button for 3
seconds until it beeps to enter the program menu.
1. Fingerprint Sensor
6. Battery cover
2. Lock/Unlock button
3. Numerical Keypad
4. Key Hole/cover
5. Emergency 9V external
battery connector
7. Mounting Screw Holes
8. Lock lever
BL100 User Manual
3
③Numerical Keypad: Used to enter a user’s PIN code or user ID.
④Key Hole/cover: You can use the included mechanical key for emergency door
opening. The key hole also has a detachable cover, to help hide the keyhole from
unauthorized users.
⑤9V External battery connector: External battery connector to be used with a
9-volt battery when internal batteries do not operate.
LED Indicators:
The deadbolt’s lock/unlock button and keypad change color to further help the user
operate the deadbolt.
The general rule:
Successful = 1 Long Beep, flashes green
Failed = 2 Short Beeps, flashes red
Verify State: Fingerprint sensor flashes green every second
Management Mode: Keypad LED flashes blue every second
All deadbolt LED indicators should respond as above. If not, please contact
your local dealer/distributor or visit our website at www.scilox.com.
