Scilogex D160 Manual de usuario

D-500 HOMOGENIZER

____________________________________________________________________________

CE/ cULus-Declaration of Conformity

EC-Declaration of Conformity

Contents

Product Description 4

Important Safeguards 4

Unpacking the instrument 5

Proper use of the D-500 6

Dispersing Aggregates 7

Cleaning 8

Sterilization 9

Corrosion 9

Working with D-500 9

Working with Speed Control 9

Overload protection 10

Maintenance of Motor 10

Specification and Technical D-500 11

Stand 11

Assembly of H Stand 11

Assembly of the PT plate stand 12

Warranty 13

Product Description

The D-500 Disperser is a high speed dispersing instrument. It is based on the

Rotor/Stator Technology. The shaft and rotor/stator can be disassembled for easy

cleaning. You will receive the dispersing tools completely assembled for immediate use

with your disperser. Should you dismantle these (e.g. for cleaning) please refer to page

6. This product is for laboratory use only and is used in chemical industry, cosmetic

industry, pharmaceutical industry, paint industry as well as in universities and a wide

range of medical laboratories. The unit is a high performance dispersing/homogenizing

unit and also can be used as a high speed mixing unit with certain dispersing shafts.

The drive unit can be used, based on the dispersing shaft used for volumes from 10ml

to 8,000ml. There is a wide range of dispersing shafts with diameters of 20mm, 30mm

and 40mm stator diameters. It is to be mounted on a stand and not used as a hand

held instrument.

Safety Instructions

•When using electrical equipment, basic safety

precautions are necessary to reduce the risk of fire, electric shock and personal

injury.

•Only use the instrument for its intended purpose.

•Ensure that the correct electric voltage of the instrument and the power supply

correspond correctly.

•Do not use this instrument in a hazardous area or manner. When handling

hazardous chemicals, use appropriate hand and eye protection.

•Do not immerse electrical equipment in water.

•The drive must not be used in highly combustible areas and operated with

easily inflammable liquids. It is recommended to run the units in fume hoods

during operation.

•To avoid electrical shock, do not open housing. Remove cord from the power

source when it is being checked or serviced. This instrument should only be

opened by a qualified service personnel only.

•The D-500 is designed for continuous operation, however normally the

ultimate fineness will be reached within a few minutes. Any further dispersing

will only introduce unnecessary heat into the medium.

•The D-500 must never run without liquid – the lower slide bearing is cooled and

lubricated by the liquid phase of the treated medium. Any dry running will

destroy the slide bearing!

•Ensure that the dispersing shafts are cleaned properly after every use. When

cleaning, remove the power cord from the power source.

•Never touch the spinning rotor, or shaft, or motor side coupling parts.

•It is recommended that the operator should be using hearing protection when

operating the unit at maximum speed.

•Do not operate after the equipment malfunctions or has been damaged in any

manner. Return unit to our service center for examination and repair.

•Switch off the unit before changing the dispersing element.

•Only suitable dispersing shafts from SCILOGEX may be used.

•Glass vessels must always be secured with a clamp to prevent them from

sliding.

•Use caution when adjusting the speed to avoid possible spraying of medium.

•The ventilation slots of the drive must not be obstructed.

•Never let the aggregate touch the bottom of the vessel.

Unpacking the Instrument

Please unpack the instrument carefully and inspect the unit, the tools and the stand for

damage. It is important that any damage during transport is noted at the time of

unpacking. In certain cases it may be necessary to follow up with the forwarder.

D-500: A typical package includes:

• D-500 drive

• One support rod for the drive

• One or more dispersing element according to your order

• One H stand with double rod, boss head and strap clamp

• A plate stand with boss head and strap clamp

• Operating instructions

Proper Use

The voltage on the name plate must match the main voltage. If it does not, do not

operate the instrument.

Screw the support rod into the flange of the drive and tighten it. Make sure that the

“nylon” washer is between the flange and the nut to avoid scratching and rubbing

marks on the flange.

Make sure that the unit is switched off when connecting or disconnecting the

dispersing shaft into the drive.

For correct use the D-500 drive must be secured to a stand with a boss head. We

recommend that for this purpose you only use the H-600 plate stand or the PT-plate

stands. For safety reasons the container should be fixed with a strap clamp (which is a

part of the H-600 stand).

Insert the dispersing element into the drive flange by pressing upwards and turning

clockwise until it locks into place. A click confirms the correct insertion. Once inserted

the dispersing element should not move any longer.

To remove the dispersing element from the flange, hold the dispersing element and

turn anticlockwise and gently remove the dispersing element downwards. The distance

between the bottom of the vessel and the shaft should not be less than 8mm.

Dispersing Aggregates

• Disassembly of the dispersing tool

1. Hold the dispersing tool with a cloth (to avoid cutting of your hand due to sharp

edges at the stator). At the same time turn the shaft tube clockwise. Screw the shaft

tube of the stator and pull it over the axle and put it aside.

2. Now hold the rotor with a cloth and turn the axle anticlockwise. Slowly screw the

axle from the rotor and put it aside.

3. Remove the PTFE bearing from the axle. After this disassembly you should have the

following five parts: shaft tube, axle, rotor, stator and PTFE bearing.

To assemble the dispersing tool please follow above 3 steps in reverse

order (3./2./1.)

When assembling the dispersing tool, always make sure that the PTFE

bearing is fixed correctly and cooled by the working medium.

Otherwise, it may cause serious defects to the whole dispersing tool. Examine the

PTFE bearings regularly. Treat the dispersing tools carefully as they are the hearts of

your dispersing unit. In

particular the axle reacts very sensitive to impacts.

Cleaning

• Immediately after finishing work with the apparatus, the dispersing element must be

cleaned so that substance residues do not stick to the threads.

• Small bacterial cultures can form in the small grooves, and this will create difficulties.

For this reason, and to clean the dispersing tool effectively, it should be run in a solvent

that dissolves the residue, but does not harm the Teflon bearing and the steel.

• For proper cleaning, the dispersing element must be disassembled.

• Proper care and cleaning of the equipment will ensure a longer and better use of the

equipment.

Sterilization

• Chemical processes: Germicidal solutions (formalin, phenol, alcohol etc) can disinfect

in most cases. However, residues must subsequently be removed with sterilized water.

• Sterilizing by humid heat: This means sterilizing with steam at a pressure bar of 2

above atmospheric and a temperature of 120°C

• Sterilizing by hot air: Hot air sterilization is normally carried out at 160°C or 190°C

Corrosion

• Stainless steel is not corrosion proof. Certain chemicals can seriously attack this

material.

• All corrosive agents should only be in contact with the fine steel for a short period of

time. Make sure they do not dry out the material.

• Ensure that the dispersing element is always cleaned properly after every use.

Neutralize lye with solutions and acids.

• Protect all parts from aggressive agents.

Working with D-500

The optimal immersion depth of the dispersing shaft is approximately 2/3 below the

liquid surface and 1/3 above the bottom of the beaker. When inserting the dispersing

shaft slightly slanted (approximately at an angle 15 degrees), it improves the efficiency

of the disperser. The dispersing shaft should not be immersed more than 30mm below

the flange.

Working with Speed Control

The drive and control are in the same housing. Before using the unit, run a test without

the dispersing shaft by switching the ON button on the front of the drive. The speed is

selected by the control knob on the top of the drive. Approximate rpm of the drive is:

A= 10,000 rpm B= 12,000 rpm C= 15,000 rpm D= 18,000 rpm E= 22,000 rpm F= 25,000

rpm G= 30,000 rpm

For an emergency stop, press the large button on the drive.

For reaching the best effects, the rotor speed of D-500 should be adapted to the

dispersion problem.

IMPORTANT

The maximum rotor speed depends on the kind of sample and its viscosity. The

speed is reduced by its viscosity in order to protect the drive from overload. If the

viscosity is too high, the motor will stop automatically to prevent damage to the

equipment. The electronic control system prevents damage to the motor drive.

Overload Protection

When the motor overloads and the power supply cuts off, switch off the main switch to

O, disconnect the aggregate and re-start the instrument as fast as possible, without the

load in order to accelerate cooling by the built-in fan.

Maintenance of Motor

The motor does not need any maintenance and there are no parts inside which can be

repaired by the user. The only parts which are excluded from this are the carbon

brushes. Please contact or your authorized supplier for replacement and use original

spare parts only. The carbon brushes can be replaced after disconnecting the power

supply!

Stand

The D-500 homogenizer is normally delivered with either the H-600 stand or the PT 800

plate stand. It is always important to safely fix the unit even when not using the original

stand for it, as the center of gravity is relatively high.

Make sure that the motor drive is fixed safely and cannot move downwards at any time

as this may cause damage to the instrument, the user or the sample.

Assembly of H stand

This H stand consisting of a double rod, two boss heads, a safety ring and a strap clamp

to secure the vessel.

The unit comes semi-assembled as the two double rods are connected and the two

boss heads and the safety ring is fixed in place already.

Put together the foot of the stand as

following: put each of the two bolts into its

place in the middle foot piece and screw

the both side pieces together with the

provided larger screws and the allen key.

Assembly of the PT plate stand

This stand is delivered with a base plate and a rod which is either 600mm, 800mm or

1000mm long. Assembly is very easy as you only have to screw in the rod into the plate

stand and secure it with the counter nut. Attach necessary boss heads such to the rod.

Once this bottom “H” has been fixed, take the

double rod and insert into the middle piece of

the foot stand. Turn it around and fix it with

the other allen key using the smaller screws

for it. Turn it around and fix the drive with the

support rod at the upper boss head and the

strap clamp at the lower boss head.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Equipo de laboratorio de Scilogex

Scilogex

Scilogex DM0636 Manual de usuario

Scilogex

Scilogex SCI280-Pro Manual de usuario

Scilogex

Scilogex SCI-T6-Pro Manual de usuario

Scilogex

Scilogex DM 0412 Manual de usuario

Scilogex

Scilogex MS-H280 Manual de usuario

Scilogex

Scilogex SCI120-S Manual de usuario

Scilogex

Scilogex SK-R1807-E Manual de usuario

Scilogex

Scilogex MS-H-Pro-T Manual de usuario

Scilogex

Scilogex MS7-S Manual de usuario

Scilogex

Scilogex MX-T6-Pro Manual de usuario

Scilogex

Scilogex SCI7-S Manual de usuario

Scilogex

Scilogex SCI636 Manual de usuario

Scilogex

Scilogex SCI100-Pro Manual de usuario

Scilogex

Scilogex D-500 Manual del operador

Scilogex

Scilogex SCI20-S Manual de usuario

Scilogex

Scilogex SCI-L180-E Manual de usuario

Scilogex

Scilogex SCI100-S Manual de usuario

Scilogex

Scilogex MS-H-Pro Manual de usuario

Scilogex

Scilogex D2012 Manual de usuario

Scilogex

Scilogex SCI550-H Manual de usuario

Scilogex

Scilogex HB120-S Manual de usuario

Scilogex

Scilogex MX-RD-PRO Manual de usuario

Scilogex

Scilogex SCI100VC Manual de usuario

Scilogex

Scilogex SCI412S Manual de usuario

Manuales populares de Equipo de laboratorio de otras marcas

Qiagen

Qiagen DML 3000 Manual de usuario

Queensgate

Queensgate NANOSCAN OP400 Manual de programación

Conviron

Conviron GEN1000-GE Manual de usuario

Parr Instrument

Parr Instrument 4560 Manual de instrucciones

IKA

IKA IC control Manual de usuario

Integra

Integra DOSE IT Manual de usuario

Agilent Technologies

Agilent Technologies 5800 ICP-OES Manual de usuario

Endress+Hauser

Endress+Hauser Cleanfit CPA875 Manual de usuario

NI PXI-5422 Manual

Collomix

Collomix Aqix Manual de usuario

SPEX SamplePrep

SPEX SamplePrep 6875 Freezer/Mill Series Manual de usuario

Ocean Insight

Ocean Insight FLAME-NIR+ Manual de usuario

Parker

Parker ALIGN-MG-NA Manual de usuario

BD 644787 Manual de usuario

DENTAURUM

DENTAURUM Compact Megaplus Manual de usuario

Biuged Laboratory Instruments

Biuged Laboratory Instruments BGD 626 Manual de usuario

VWR

VWR SAS Super IAQ Manual de usuario

illumina

illumina MiSeqDx Manual de usuario
