Schweitzer Engineering Laboratories SEL-351R Manual de usuario

SEL-351R

RECLOSER CONTROL

INSTRUCTION MANUAL

IMPORTANT: Use this manual in conjunction with the SEL-351R

Quick-Start Installation and User’s Guide.

SCHWEITZER ENGINEERING LABORATORIES

2350 NE HOPKINS COURT

PULLMAN, WA USA 99163-5603

TEL: (509 332-1890 FAX: (509 332-7990

CAUTION: The relay contains devices sensitive to

electrostatic discharge (ESD). When working on

the relay with front or top cover removed, work

surfaces and personnel must be properly grounded

or equipment damage may result.

ATTENTION: Le relais contient des pièces

sensibles aux décharges électrostatiques (DES).

Quand on travaille sur le relais avec le panneau

avant ou du dessus enlevé, les surfaces de travail et

le personnel doivent être mis à la terre

convenablement pour éviter les dommages à

l'équipement.

CAUTION: There is danger of explosion if the

battery is incorrectly replaced. Replace only with

Ray-O-Vac®no. BR2335 or equivalent

recommended by manufacturer. Dispose of used

batteries according to the manufacturer’s

instructions.

ATTENTION: Il y a un danger d’explosion si la

pile électrique n’est pas correctement remplacée.

Utiliser exclusivement Ray-O-Vac®No. BR2335 ou

un équivalent recommandé par le fabricant. Se

débarrasser des piles usagées suivant les

instructions du fabricant.

WARNING: This device is shipped with default

passwords. Default passwords should be changed to

private passwords at installation. Failure to change

each default password to a private password may

allow unauthorized access. SEL shall not be

responsible for any damage resulting from

unauthorized access.

AVERTISSEMENT: Cet équipement est expédié

avec des mots de passe par défaut. A l'installation,

les mots de passe par défaut devront être changés

pour des mots de passe confidentiels. Dans le cas

contraire, un accès non-autorisé à l'équipement

pourrait être possible. SEL décline toute

responsabilité pour tout dommage résultant de cet

accès non-autorisé.

The software (firmware), schematic drawings, relay commands, and relay messages are copyright protected by the United States Copyright Law and

International Treaty provisions. ll rights are reserved.

You may not copy, alter, disassemble, or reverse-engineer the software. You may not provide the software to any third party.

ll brand or product names appearing in this document are the trademark or registered trademark of their respective holders.

Schweitzer Engineering Laboratories, SELOGIC, Connectorized, Job Done, SEL-PROFILE, CSELER TOR, and are registered trademarks of Schweitzer

Engineering Laboratories.

The English language manual is the only approved SEL manual.

This product is covered by U.S. Patent Numbers: 5,790,418; 5,208,545; 5,317,472; 5,602,707; 5,367,426; 5,515,227; 5,883,578; 5,349,490; 5,365,396;

5,041,737; 5,479,315; 5,793,750; 5,694,281; and U.S. Patent(s) Pending, and Foreign Patent(s) Issued and Pending.

This product is covered by the standard SEL 10-year warranty. For warranty details, visit www.selinc.com or contact your customer service

representative. Note: The 24 Vdc battery inside the SEL-351R Recloser Control enclosure is excluded from the product warranty. PM351R-01

Date Code 20020215 Manual Change Information i

SEL-351R Instruction Manual

MANUAL CHANGE INFORMATION

The date code at the bottom of each page of this manual reflects the creation or revision date.

Date codes are changed only on pages that have been revised and any following pages affected

by the revisions (i.e., pagination). If significant revisions are made to a section, the date code on

all pages of the section will be changed to reflect the revision date.

Each time revisions are made, both the main table of contents and the affected individual section

table of contents are regenerated and the date code is changed to reflect the revision date.

Changes in this manual to date are summarized below (most recent revisions listed at top).

Revision

Date Summary of Revisions

The Manual Change Information section has been created to begin a record of revisions to

this manual. All changes will be recorded in this Summary of Revisions table.

20020215 This revision includes the following changes:

- Reissued entire manual with post script fonts.

Section 1:

- Added the setting “Phantom voltages from

(VA,VB,VC,VAB,VBC,VCA,OFF)” to Table 1.1.

Section 7:

- Increased the number of local, latch, and remote bits and display points to 16

for SEL-351R-2.

- Added description of new SELOGIC counter feature.

Section 8:

- Added description of how the relay generates phantom voltages.

Section 9:

- Included Relay Word bits for additional local, remote, and latch bits in

Table 9.3 and Table 9.4.

- Added eight set and reset equations for latch bits; increment, decrement, and

reset equations for SELOGIC counters; and eight additional display point

equations to the SELOGIC control equation settings sheets.

Section 10:

- Included the COU command in Table 10.5, and also added a description and

screen capture of the command. The description of the metering command

also briefly describes how phantom voltages are generated.

- Additional screen captures for SHO G and SHO FZ commands on an

SEL-351R-2 show the new phantom voltage setting.

- The descriptions of SHO L and SHO T now mention the availability of eight

additional latch, local, and remote bits and display points.

- Eight additional local, remote, and latch bits were added to Table 10.6 for the

SEL-351R-2.

ii Manual Change Information Date Code 20020215

SEL-351R Instruction Manual

Revision

Date Summary of Revisions

Appendix A:

- Updated firmware version information.

Appendix B:

- Incorporated new Firmware Upgrade Instructions: Date Code 20020118

Appendix D:

- Changed Fast commands to reflect additional Relay Word bits and remote bits

available on the SEL-351R-2.

Appendix G:

- Created a description of an SELOGIC analog compare statement, which is now

available in the SEL-351R-2, and added the processing slot for the counters to

Table G.3.

Appendix H:

- Updated the DNP map in Table H.3 to show the new capabilities of the

SEL-351R-2.

20010518 This revision includes the following changes:

- Reissued entire manual.

- Replaced Standard Product Warranty page with warranty statement on cover

page.

Section 1:

- Discussed defeating three-second delay on LOCK operator control

(Figure 1.38).

- Discussed changes to front-panel AC SUPPLY LED settings in Reclose

Supervision Logic subsection and made LED11 logic settings change in

Figure 1.51.

Section 2:

- Added caution note to the Clock Battery subsection.

Section 3:

- Doubled the voltage ranges (e.g., 150 to 300 V secondary) of the voltage

element settings in Table 3.8, Table 3.9, and Table 3.10.

Section 4:

- Changed the impedance settings ranges for load-encroachment and directional

elements to match the 1 a nominal secondary settings ranges in other SEL-351

family relays.

Section 5:

- Added SELOGIC Control Equation Setting FAULT subsection at end of

section.

Date Code 20020215 Manual Change Information iii

SEL-351R Instruction Manual

Revision

Date Summary of Revisions

Section 7:

- Added ac setting description to Input Debounce Timers subsection.

- Updated subsection Note: Make Latch Control Switch Settings With Care.

- Updated subsection Note: Make Active Setting Group Switching Settings

With Care.

- Added subsection Displaying Values (other than user-entered text) on the

Rotating Default Display near the end of the section.

Section 9:

- Relay Words bits DDATA and DCONN added to Table 9.3 and Table 9.4

(row 56)—used in automatic dial-out via DNP.

- Changed the impedance settings ranges for line settings, load-encroachment

elements, and directional elements to match the 1 A nominal secondary

settings ranges in other SEL-351 family relays (Settings Sheet pages 1, 6, and

7 respectively).

- Doubled the voltage settings ranges (e.g., 150 to 300 V secondary) on Setting

Sheets page 7 and page 8.

- Added ac setting choice to optoisolated input timers on Setting Sheets page 18.

- Added Y1 and N1 settings options and explanation for setting RSTLED on

Setting Sheets page 19 (for defeating the three-second delay on the LOCK

operator control).

- Added PROTO = DNPE, and AUTO = DTA settings choices to the Port

Settings Sheet page 23.

Section 10:

- Added DTA2 compatibility information.

- Added MIRRORED BITS Communications subsection.

- Added notes about powering down the relay after setting the date and time.

- Added MET X command description.

- Updated SELOGIC setting LED11 = !DISCHG in listing of factory default

settings in the SHO Command (Show/View Settings) subsection.

- Updated password information.

- Added warning note to the PAS Command (View/Change Passwords)

subsection.

- Updated Command Summary to include MET X command.

Section 12:

- Corrected explanation for column “32 NG”in Table 12.3 (“F32I”and “R32I”

should be “F32N”and “R32N”, respectively; corresponding symbols should be

“N”and “n”.

Appendix A:

- Updated firmware version information.

i Manual Change Information Date Code 20020215

SEL-351R Instruction Manual

Revision

Date Summary of Revisions

Appendix H:

- Added Extended Mode DNP details and settings.

- Added UNSOL = DIAL as a settings choice for DNP (for automatic dial-out).

- Added DNP automatic dial-out information.

20000602 This revision includes the following changes:

Section 3:

- Corrected Figure 3.20.

Section 8:

- Added qualifying statement about changing the LDAR setting.

Section 9:

- Added qualifying statement concerning the SET scommand in Settings

Changes via the Serial Port.

Appendix A:

- Released new firmware version.

Appendix H:

- DNP labels (DECPLA, DECPLV, DECPLM) now correctly identified.

20000407 This revision includes the following changes:

Reissued entire manual.

Section 3:

- Clarified the operation of the synchronism check elements for breaker close

time setting TCLOSD = 0.00 in the Synchronism Check Elements subsection

(see Figure 3.25).

Section 5:

- Added explanation to the target LEDs information near the end of the section

that the target LEDs no longer reset if a TRIP condition is present.

Section 9, Settings Sheet 20 of 23:

- Corrected demand ammeter element names for load profile.

Section 10:

- Corrected number of event reports stored in relay in HIS Command subsection.

- Added NOMSG state and explanation to battery monitor/charger mode

displayed with STATUS command.

- Added note to the TAR R command explanation that the target LEDs no longer

reset if a TRIP condition is present.

- Corrected Relay Word bit entries 32NE (row TAR 15) and F32N and R32N

(row TAR 17) in Table 10.6.

Date Code 20020215 Manual Change Information

SEL-351R Instruction Manual

Revision

Date Summary of Revisions

Appendix D:

- Corrected length and digital bank parameters for A5D1 Fast Meter data block.

- Corrected 32NE, F32N, and R32N entries for DNA message. Added 50NF,

50NR, 32NF, and 32NR entries for DNA message.

Appendix G:

- Updated SELOGIC®Control Equation limitations.

991123 Appendix H:

- Corrected documentation errors in DNP 3.0 Device Profile, page H-5.

990628 This revision includes the following changes:

- Updated MIRRORED BITS™format throughout to reflect new trademark.

Section 1:

- Added phase pickup setting 50P4P to Table 1.1. Setting 50P4P is set (in A

secondary) when Min. trip-phase is set (in A primary) in the EZ setting routing

(SET EZ command). Phase pickup setting 50P4P controls single-phase

elements 50A4, 50B4, and 50C4, listed in Table 1.2. These single-phase

elements indicate faulted phases for the trip operations counters (see

discussion on trip operation counters in the Breaker/Recloser Contact Wear

Monitor subsection in Section 8: Breaker/Recloser Monitor, Battery System

Monitor, and Load Profile Functions).

Section 3:

- Added explanation to the Synchronism Check Elements subsection for the

new angle setting option for the SYNCP (synchronizing phase) setting.

Synchronism check can now be accomplished for synchronism check voltage

input VS connected phase-phase or beyond a delta-wye transformer. Setting

SYNCP accounts for the constant angle difference between reference voltage

input VA and synchronism check voltage input VS.

Section 7:

- Clarified the operation of the latch control switches when the SEL-351R

Recloser Control loses power (see the Latch Control Switches subsection).

Section 8:

- Added discussion on the per-phase and ground trip operation counter

information now available via the BRE A command in the Breaker/Recloser

Contact Wear Monitor subsection.

Section 9:

- Expanded the setting range for the SYNCP (synchronizing phase) setting to

accommodate compensation angle settings for synchronism check (Settings

Sheet 8 of 23).

- Added the MB8A and MB8B serial port protocol settings options for

MIRRORED BITS protocol operating on communication channels requiring an 8

data bit format (Settings Sheet 23 of 23).

i Manual Change Information Date Code 20020215

SEL-351R Instruction Manual

Revision

Date Summary of Revisions

Section 10:

- Added the BRE A and BRE W A serial port commands. These new

commands have the additional feature of displaying and preloading,

respectively, per-phase and ground trip operation counters.

Appendix B:

- Updated Firmware Upgrade Instructions.

Appendix I:

- Explained the MB8A and MB8B serial port protocol settings options for

MIRRORED BITS protocol operating on communication channels requiring an 8

data bit format.

990323 This revision includes the following changes:

Section 1:

- Changed logic in Figure 1.11 and Figure 1.12 to allow high current trips to

operate if auto-reclosing is nonexistent.

- Changed logic in bottom of Figure 1.23 to allow time-overcurrent pickups

51N1 and 51N2 to indicate ground current above Min. trip-ground level for the

drive-to-lockout logic (51N1 and 51N2 don’t have the built-in 2 cycle delay

that 50N6 has - thus, 51N1 and 51N2 are useful indication for instantaneous

trips).

- Changed logic in Figure 1.54 to allow time-overcurrent pickups 51N1 and

51N2 to indicate ground current above Min. trip-ground level for the fault-type

trip target LED “G.”

Section 3:

- Changed routing of Directional Control to Figure 3.8 (67N elements) and

Figures 3.16 and 3.17 (51NT elements)

Section 4:

- Added zero-sequence voltage polarized, neutral current directional elements to

Best Choice Ground Directional™ Logic.

- Inserted the following drawings:

Figure 4.7: Internal Enable (32NE) for Zero-Sequence Voltage-Polarized,

Neutral-Current Directional Element

Figure 4.11: Zero-Sequence Voltage-Polarized, Neutral-Current

Directional Element for Neutral Ground Overcurrent Elements

Figure 4.13: Routing of Directional Element to Neutral Ground

Overcurrent Elements

Figure 4.15: Direction Forward/Reverse Logic for Neutral Ground

Overcurrent Elements

Date Code 20020215 Manual Change Information ii

SEL-351R Instruction Manual

Revision

Date Summary of Revisions

Section 8:

- Changed setting range for kA Interrupted set points KASP1, KASP2, and

KASP3 listed in Table 8.1 (new lower limit is 0.10 kA and new setting

increment is 0.01 kA).

Section 9:

- Settings Sheet 1 of 23: changed setting increment to 0.01 for CTR, CTRN,

PTR and PTRS settings.

- Settings Sheet 18 of 23: changed setting range for kA Interrupted set points

KASP1, KASP2, and KASP3 (new lower limit is 0.10 kA and new setting

increment is 0.01 kA).

Section 10:

- Changed factory default logic settings listed on page 10-32 for settings SV14

and LED24 (see preceding Section 1 references for corresponding Figure 1.23

and Figure 1.54).

Section 11:

- Corrected rotating display figures on the right-hand side of pages 11-7 through

11-9 (showing IA, IB, IC, and IN metering quantities as part of the “2 seconds

per screen”rotation).

Section 12:

- Corrected references to the number of available event reports, depending on

the length of event report format chosen: 15 or 30 cycles (twenty-eight 15-

cycle event reports or fourteen 30-cycle event reports).

Appendix F:

- Changed Figure F.1 to reflect the built-in minimum response time feature of

the 51QT negative-sequence time-overcurrent element.

Appendix H:

- Changed the setting range of setting UTIMEO to 1-50 seconds.

- Corrected the designation for the ECLASS setting in Table H.1.

981216 This revision includes the following changes:

- Updated references to figures in the SEL-351R Quick-Start Installation and

User’s Guide throughout manual (no date code change).

Section 1:

- Added Table 1.2 to clarify the function of the overcurrent elements when the

factory default EZ settings are active for a particular settings group.

- Clarified the function of EZ setting Close power wait time (corresponding

setting 79CLSD) in Reclose Supervision Logic.

- Added clarifying reference below Figure 1.51 in Front-Panel Status and Trip

Target LEDs.

iii Manual Change Information Date Code 20020215

SEL-351R Instruction Manual

Revision

Date Summary of Revisions

Section 3:

- Added clarifying reference to introduction and in Frequency Elements

subsection.

Section 4:

- Removed a Setting Description in Settings Ranges (under setting ZLR).

- Revised the example at the end of Apply Load-Encroachment to a Phase

Time-Overcurrent.

Section 7:

- Added clarifying reference in the Recloser Trip and Close Circuits.

- Expanded Figure 7.29 to show the 22000ìF capacitor in parallel with the

24 Vdc supply to the recloser trip and close circuitry.

Section 8:

- Changed battery amp-hour rating from 6.5 to 8.0 Ah (factory-shipped batteries

have changed as detailed in the Battery Replacement subsection in the Battery

section of the SEL-351R Quick-Start Installation and User’s Guide).

Note: The Battery Amp-hours setting was not changed in the factory-default

global settings listed in SHO Command (Show/View Settings) in Section 10:

Serial Port Communications and Commands –it remains at 6.5 Ah. This is a

conservative setting for the new 8.0 Ah batteries. The user can change the

Battery Amp-hours setting to 8.0 Ah, if desired.

981203 This revision includes the following changes:

- Corrected Figure 1.22 in Section 1: Factory-Set Logic.

- SELOGIC Control Equations torque control settings can no longer be set

directly to logical 0, as explained in the overcurrent element sections of

Section 3: Overcurrent, Voltage, Synchronism Check, Frequency, and

Power Elements and the SELOGIC Control Equations settings sheets in the

back of Section 9: Setting the SEL-351R Recloser Control.

- SELOGIC Control Equations drive-to-lockout setting 79DTL has a 60-cycle

dropout time, as explained in Section 6: Close and Reclose Logic.

- Corrected typographical error in Factory Settings Example in Section 6:

Close and Reclose Logic (no date code change).

- Corrected typographical error in Determining the Size of the Load Profile

Buffer in Section 8: Breaker/Recloser Monitor, Battery System Monitor,

metering, and Load Profile Functions (no date code change).

- More SELOGIC Control Equations settings limitations information added to

Appendix G: Setting SELOGIC Control Equations.

Otros manuales para SEL-351R

Tabla de contenidos

Otros manuales de Relé de Schweitzer Engineering Laboratories
