Scheppach TIGER2000S Manual de usuario

WET GRINDER

ASSEMBLY AND OPERATING INSTRUCTIONS

TO PREVENT SERIOUS INJURY,

READ AND UNDERSTAND ALL WARNINGS

AND INSTRUCTIONS BEFORE USE.

Due to continuing improvements, actual product may differ slightly from the product described herein.

# W859 28-9-12

TIGER2000S

PAGE2

grounded in accordance with all codes and ordinances. Never remove the

grounding prong or modify the plug in any way. Do not use any adapter

plugs. Check with a qualified electrician if you are in doubt as to whether

the outlet is properly grounded. If the tools should electrically malfunction or

break down, grounding provides a low resistance path to carry electricity away

from the user.

5. Double insulated tools are equipped with a polarized plug (one blade is

wider than the other). This plug will fit in a polarized outlet only one way. If

the plug does not fit fully in the outlet, reverse the plug. If it still does not

fit, contact a qualified electrician to install a polarized outlet. Do not

change the plug in any way. Double insulation eliminates the need for the

three wire grounded power cord and grounded power supply system.

6. Avoid body contact with grounded surfaces such as pipes, radiators,

ranges, and refrigerators. There is an increased risk of electric shock if your

body is grounded.

7. Do not expose power tools to rain or wet conditions. Water entering a power

tool will increase the risk of electric shock.

8. Do not abuse the Power Cord. Never use the Power Cord to carry the tools

or pull the Plug from an outlet. Keep the Power Cord away from heat, oil,

sharp edges, or moving parts. Replace damaged Power Cords immediately.

Damaged Power Cords increase the risk of electric shock.

PERSONAL SAFETY

9.Stay alert. Watch what you are doing, and use common sense when

operating this product. Do not use the Wet Grinder while tired or under the

influence of drugs, alcohol, or medication. A moment of inattention while

operating this product may result in serious personal injury.

10.Dress properly. Do not wear loose clothing or jewelry. Contain long hair.

Keep your hair, clothing, and gloves away from moving parts. Loose

clothes, jewelry, or long hair can be caught in moving parts.

PAGE3

11.Avoid accidental starting. Make sure the Power Cord remains unplugged from

its electrical outlet until this product is completely assembled, filled with water,

and ready to use.

12.Do not overreach. Keep proper footing and balance at all times. Proper

footing and balance enables better control of this product in unexpected

situations.

13.Use safety equipment. Wear eye protection when assembling and

using this product.

TOOL USE AND CARE

14.Disconnect the Power Cord Plug from the power source before making any

adjustments, changing accessories, or storing the Wet Grinder. Such

preventive safety measures reduce the risk of starting the unit accidentally.

15.Store idle equipment out of reach of children and other untrained persons.

Electrically powered products are dangerous in the hands of untrained users.

16.Check for misalignment or binding of moving parts, breakage of parts, and

any other condition that may affect this product’s operation. If damaged,

have the Wet Grinder serviced before using. Many accidents are caused

by poorly maintained equipment.

PAGE4

SERVICE

17.Service must be performed only by qualified repair personnel. Service

or maintenance performed by unqualified personnel could result in a risk of injury.

18.When servicing this product, use only identical replacement parts. Follow

instructions in the

“Inspection, Maintenance, And Cleaning”

section of this

manual. Use of unauthorized parts or failure to follow maintenance instructions

may create a risk of electric shock or injury.

SPECIFIC SAFETY RULES

1. Maintain labels and nameplates on theWet Grinder. These carry important

information. If unreadable or missing, contact Harbor Freight Tools for a

replacement.

2. Wear AS/NZSapproved safety impact eye glasses under a full face

shield when using the Wet Grinder. Using personal safety devices

reduce the risk for injury. Safety impact eye glasses and full face shields

are available from Harbor Freight Tools.

3. Maintain a safe environment. Keep the area well lit. Make sure there is

adequate surrounding space. Always keep the area free of obstructions, grease,

oil, trash, and other debris. Do not use an electrically powered product in areas

near flammable chemicals, dusts, and vapors.

PAGE5

4. Never leave the Wet Grinder unattended when it is plugged into an electrical

outlet. Turn off the Grinder and unplug the tool before leaving.

5. Carefully inspect the condition of the Wet Grinder before use, and check

the tool continually during use. If any damage is noted, stop immediately

and repair or replace the Grinder.

6. Avoid electrical shock. Make sure the Wet Grinder is unplugged from

its electrical outlet prior to performing any inspection, maintenance, or

cleaning procedures. Do not use the Grinder/Buffer in the rain or in wet

conditions.

7. Use the right product for the job. There are certain applications for which this

product was designed. Do not use small tools, equipment, or accessories to do

the work of larger industrial tools, equipment, or accessories. Do not use this

product for a purpose for which it was not intended.

8. Do not allow children or other unauthorized people to handle or play with

this product.

9. Industrial applications must follow WHSA requirements.

10. Frequently immerse the workpiece in water to prevent overheating.

11. Use the Tool Attachments to steady the workpiece. If the Tool Attachments

are not used, the torque of the spinning Grinding/Polishing Wheel may pull the

workpiece from your hands.

12. Do not use aluminum oxide wheels when grinding nonferrous metals such

as aluminum and brass. Use silicon carbide wheels (not included) for

nonferrous metals.

13. Never install a Grinding Wheel on the polishing side of the tool. Never use

any accessory not specifically designed for this machine. Never attempt to install

a wire brush, abrasive flap wheel, or sanding disc on this Wet Grinder.

14. Performance of this tool (if powered by line voltage) may vary depending on

variations in local line voltage. Extension cord usage may also affect tool

performance.

15. WARNING! Some dust created by power sanding, sawing, grinding, drilling,

16. WARNING! People with pacemakers should consult their physician(s)

before using this product. Operation of electrical equipment in close proximity to

a heart pacemaker could cause interference or failure of the pacemaker.

17. WARNING! The warnings and cautions discussed in this manual cannot

cover all possible conditions and situations that may occur. It must be understood

by the operator that common sense and caution are factors which cannot be built

into this product, but must be supplied by the operator.

SAVE THESE INSTRUCTIONS

and other construction activities, contain chemicals known to cause cancer, birth

defects or other reproductive harm. Some examples of these chemicals are:

lead from lead-based paints, crystalline silica from bricks and cement or other

masonry products, arsenic and chromium from chemically treated lumber.

Your risk from these exposures varies, depending on how often you do this type of

work. To reduce your exposure to these chemicals:

work in a well ventilated area, and work with approved safety equipment, such as

those dust masks that are specially designed to filter out microscopic particles.

GROUNDING

WARNING!

Improperly connecting the grounding wire can result in the risk of electric shock.

Check with a qualified electrician if you are in doubt as to whether the outlet is

properly grounded. Do not modify the power cord plug provided with the tool.

Never remove the grounding prong from the plug. Do not use the tool if the power

cord or plug is damaged. If damaged, have it repaired by a service facility before

use. If the plug will not fit the outlet, have a proper outlet installed by a qualified

electrician.

PAGE6

PAGE7

PAGE8

SYMBOLOGY

UNPACKING

When unpacking, check to make sure all the parts shown on the Parts List on page 17

are included. If any parts are missing or broken, please call Harbor Freight Tools at the

number shown on the cover of this manual as soon as possible.

OPERATING INSTRUCTIONS

NOTE:

For additional information regarding the parts listed in the

following pages, refer to the Assembly Diagram on page 16.

1. CAUTION! Always make sure the Wet Grinder is disconnected from its

electrical outlet prior to assembling the tool, changing accessories, or performing

service to the product.

2. Wear AS/NZSapproved safety impact eye glasses under a full face

shield when assembling and operating the Wet Grinder.

3. Make sure the workbench you intend to position the Wet Grinder upon is flat,

level, and sturdy enough to bear the weight of the Grinder, any additional tools

and accessories, and workpieces.

4. The Tool Support (23) may be attached to the Wet Grinder for

vertical

grinding/

honing or

horizontal

grinding/honing, depending on the application.

5. To attach the Tool Support for

vertical

grinding/honing, insert the Tool Support

PAGE9

PAGE10

KNOB

(21)

TOOL SUPPORT

(23)

POWER SWITCH

(34)

WITH SAFETY KEY

KNOB

(21)

TOOL SUPPORT

(23)

ABRASION PASTE

(43)

HONING WHEEL

(27)

WATER TANK

(41)

WATER TANK

(41)

TOOL SUPPORT

(23)

SUPPORT PLATE

(16)

KNOB

(15)

KNOB

(15)

TOOL BLADE

(NOT INCLUDED)
