SC&T SP006 Manual de usuario
Smart Cabling & Transmission Corp. V1.0
Surge Protector
User Manual
Model : SP006
Network, IP Camera Surge Protector
1
User Manual
SP006
Introduction
SP006 is a surge protector designed to protect network devices from high voltage surges, supporting
bandwidth up to 100Mbps.
Features
Supports bandwidth up to 100Mbps
Response time less than 1 ns..
Installation View
Application
CATV System
Antenna of Television
Video Cassette Recorders
Satellite Receivers
FM receivers
Video Cameras and monitors
Multiplexers and Quad Processor
2
User Manual
SP006
Specification
ITEM NO.
SP006
Support
Network Bandwidth
10/100/1000 Mbps
Response Time
Less than 1ns
Max. Surge Voltage
4 KV
Surge Life
300 times (100A per surge)
Normal Resistance Across Coax
10,000 MΩ
Surge Resistance
Approx. 0Ω
Band Pass
0 to 1 GHz
Breakdown Voltage
7.6V
Clamping Voltage
10V
Insertion Loss
Less than 0.2 dB
Return Loss (75Ω)
16dB
Ports & Interfaces
Equipment End
1 x RJ45
Cable End
1 x RJ45
Ambient Temperature
Operation
-10 to 75℃
Storage
-40 to 90℃
Humidity
95%
Physical Characteristics
Dimensions
67 x 87 x 27mm
Weight
126g
