SCAN 48 Manual de usuario

SCAN 48

INSTRUCTIONS FOR

INSTALLATION AND USE

This manual is accompanied by a pamphlet

with General Instructions for Installation. Edition 12/05 - GB

MONTERINGSVEJLEDNING

med brugs- og fyringsanvisning

Indhold:

Generelle råd og anvisninger . . . . . . . . . .2-3

Reklamationsret

Type- og miljøgodkendelse

Udpakning

Tilbehør til din pejs

Montering af kakler og fedtsten

Kvalitetskontrol

Anmeldelsespligt

Skorstenstjek

Skorstensløsninger

Bærende underlag

Brændbar eller ikke brændbar væg

Gulvplade

Varmefordeling

Justerskrue

Typeskilt

Produktionsnr.

Servicepakke

Monteringsvejledning. . . . . . . . . . . . . . . . .4-7

Tilslutning til eksisterende/muret skorsten

Tilslutning topafgang til stålskorsten

Forbrændingsluft udefra

Brugs- og fyringsanvisning . . . . . . . . . . . 8-10

Vedligeholdelse af pejseovnen

Håndtering af brændsel

Optænding og fyring

Fejlsøgning . . . . . . . . . . . . . . . . . . . . . . . . 11

SCAN 3

BRUGSANVISNING

TildenneBrugsanvisninghørerogsåen

generelMonteringsvejledning.Udgave03.03-DK

MONTERINGSVEJLEDNING

medbrug

s-ogfyringsanvisning

Indhold:

Generellerådoganvisninger..........2-3

Reklamationsret

Type-ogmiljøgodkendelse

Udpakning

Tilbehørtildinpejs

Monteringafkaklerogfedtsten

Kvalitetskontrol

Anmeldelsespligt

Skorstenstjek

Skorstensløsninger

Bærendeunderlag

Brændbarellerikkebrændbarvæg

Gulvplade

Varmefordeling

Selvlukkendelåge

Justerskrue

Typeskilt

Produktionsnr.

Servicepakke

Monteringsvejledning.................4-7

Tilslutningtileksisterende/muretskorsten

Tilslutningtopafgangtilstålskorsten

Forbrændingsluftudefra

Brugs-ogfyringsanvisning...........8-10

Vedligeholdelseafpejseovnen

Håndteringafbrændsel

Optændingogfyring

Fejlsøgning........................11

Tildennemonteringsvejledninghørerogsåen

separatbrugsanvisningfordenenkeltepejs.

Udgave02/03-DK

Til dennemonteringsvejledning hørerogsåen

separatbrugsanvisning fordenenkelte pejs.

Udgave 02/03 - DK

Approved according to EN 13240 2003

Declaration of Conformity

Manufacturer:

Krog Iversen & Co. A/S

DK - 5492 Vissenbjerg

Product:

SCAN 48

Description of product:

Room heater for closed operation

This product complies with the requirements

of the directive

CPD 89/106/EEC

Applied to harmonized standard EN 13240

Signature: _____________________________

Managing director Henning Krog Iversen

Clean combustion

The SCAN 48 uses the "CB technique" (Clean-

Burn) to ensure an optimally clean combustion.

The extra combustion air is preheated and led

into the combustion chamber close to the ceramic

smoke deflector.

Ceramic smoke deflectors

Lift up the lower ceramic smoke deflector, pull out

the pins in the lateral combustion chamber plates

and remove the deflector. The upper deflector is

removed in the same way.

You have chosen a product from one of Europe's leading

manufacturers of wood-burning stoves. We are convinced that

your stove will be to your full satisfaction and give you many

hours of pleasure if you follow the advice and instructions of

this manual.

Please read this manual as well as the General Instructions

for Installation before beginning the installation.

Congratulations on your new SCAN stove!

1Ashtray. When you open the door in front of the

wood compartment, you have access to the ashtray,

which is placed below the combustion chamber.

Attention! Be careful when you empty ashes from

the stove. There may be embers left for up to 24

hours after the stove was last used.

2 Lid for ashtray. Under the ashtray you will find a lid

to put on top of the ashtray when you carry it out for

emptying.

3 Handle for shaking grate. The stove is equipped

with a shaking grate. When you activate the grate

handle, the ashes from the combustion chamber are

emptied into the ashtray.

4 Regulation for primary air. Push the air control rod

sideways. Left position is closed and right position

is open. The primary air is used when lighting and

refuelling the stove. It should always be closed dur-

ing continuous firing.

5 Regulation for combustion air. Push the air con-

trol rod sideways. Left position is closed and right

position is open. The air is used for combustion and

re-gulates the output of the stove.

SCAN 48

The ashtray, shaking grate, and primary air should

always be closed during continuous firing.

Accessories

For this model you can have the following accessories:

Handle

Pull out the handle to open.

Adjustment screws

The stove has two adjustment screws on

the bottom that can be used for levelling

the stove.

Self-closing door (BA1)

The door is prepared with a self-closing function at the fac-

tory. If you tighten the spring with the hexagon spanner, the

door will close automatically when you let go of it.

• Baking-compartment door

• Top plate in soapstone

• Shaped floor plate (steel or glass)

• Connection piece for fresh-air intake

You should read this manual as well as the General Instructions for Installation before beginning the installation.

SCAN 48

The stove can be prepared for an external air supply where

fresh air is let directly into the combustion chamber (can

also be done subsequently by the authorized dealer).

Adjustment of the air + fuel consumption (EN 13240):

Combustion air % Primary air % Max. fuel, kg Fuel consumption, kg/h

90 60 2 2

Krog Iversen & Co. A/S - DK-5492 Vissenbjerg

1065

138

771

506 454

160

904

Warranty conditions

All SCAN wood-burning stoves and inserts are made of first-

class material and are subject to a strict quality control before

they leave the factory. However, if an error should occur,

we back all SCAN wood-burning stoves and inserts with an

extensive, five-year limited warranty.

See also the General Instructions for Installation delive-

red with your stove for more details.

***

* To the middle of the rear outlet

** Height to the beginning of the flue pipe at top outlet

***Connection piece to fresh-air intake

Distances to flammable materials

(mm)

Production number Write the production number of your

stove here so that you have it at hand

in case you need to contact us.

You can choose between several floor plates in different shapes and

dimensions for your stove. Furthermore, you can have a specially

made, shaped floor plate for the SCAN 48, which is to be placed in

front of the stove. Please contact your local authorities concerning the

security distances needed.

SCAN 48

100

405

100

300

100

Distance to furniture: 800 mm

Technical info

Emission (% CO at 13% O2): 0.08%

Efficiency: 84%

Rated output: 6 kW

Chimney temperature: 215 oC

Flue outlet flow: 5.0 g/sec

Recommended low pressure in conn. piece: 15 Pa

Recommended fuel: Wood

Amount of fuel: 1,9 kg

Min./max. (information from the factory): 2-8 kW

Weight, stove with convection: 100 kg

Weight, stove with soap stone: 150 kg

Connection piece, int. diameter: 135 mm

Connection piece, ext. diameter: 148 mm
