MODEL SZC

OPERATOR’S MANUAL

THIS MANUALCONTAINS THE OPERATING

INSTRUCTIONS AND SAFETY INFORMA-

TION FOR YOUR SCAG MOWER. READING

THIS MANUAL CAN PROVIDE YOU WITH

ASSISTANCE IN MAINTENANCE AND AD-

JUSTMENT PROCEDURES TO KEEP YOUR

MOWER PERFORMING TO MAXIMUM EFFI-

CIENCY. THE SPECIFIC MODELS THATTHIS

BOOK COVERS ARE CONTAINED ON THE

INSIDECOVER. BEFORE OPERATINGYOUR

MACHINE, PLEASE READ ALL THE INFOR-

MATION ENCLOSED. PART NO. 03149

PRINTED9/04

PRINTED IN USA

SCAGPOWEREQUIPMENT

DIVISION OF METALCRAFT OF MAYVILLE, INC.

FAILURE TO FOLLOW SAFE OPERATING PRACTICES

MAY RESULT IN SERIOUS INJURY.

* Keepall shields in place,especially the grass dischargechute.

* Before performing any maintenance or service, stop the machine and

remove the spark plug wire and ignition key.

* If a mechanism becomes clogged, stop the engine before cleaning.

* Keep hands, feet and clothing away from power-driven parts.

* Read this manual completely as well as other manuals that came

with your mower.

* Keep others off the tractor (only one person at a time)

REMEMBER - YOUR MOWER IS ONLY AS SAFE AS THE OPERATOR!

Hazard control and accident prevention are dependent upon the awareness,

concern, prudence, and proper training of the personnel involved in the

operation, transport, maintenance, and storage of the equipment.

Thismanualcoverstheoperatinginstructions

andillustratedparts list for:

SZC36A-17KA with a serial number of A4200001 to A4299999

SZC36A-19KA with a serial number of A9800001 to A9899999

SZC42A-19KA with a serial number of A4400001 to A4499999

SMZC-36A with a serial number of A4600001 to A4699999

SMZC-42A with a serial number of A4700001 to A4799999

Alwaysusetheentireserialnumber listed on the serial number

tag when referring to this product.

WARNING:

TABLE OF CONTENTS

SUBJECT PAGE

Section 1 - General Information

1.1 Introduction .............................................................................................................................1

1.2 Directional Reference.............................................................................................................1

1.3 Servicing the Engine and DriveTrain Components ................................................................1

1.3 Symbols ............................................................................................................................... 2-3

Section 2 - Safety Information

2.1 Introduction .............................................................................................................................4

2.2 SignalWords ...........................................................................................................................4

2.3 Before Operation Considerations ...........................................................................................4

2.4 Operation Considerations ........................................................................................................5

2.5 Roll Over Protection System (Optional) .................................................................................6

2.6 Maintenance Considerations ...................................................................................................8

2.7 Safety and Instructional Decals ..............................................................................................9

Section 3 - Specifications ....................................................................................................10-11

Section 4 - Operating Instructions

4.1 Controls and Instrument Identification ..................................................................................12

4.2 Safety Interlock System........................................................................................................13

4.3 Initial Run-In Procedures......................................................................................................14

4.4 Starting the Engine ................................................................................................................14

4.5 Ground Travel and Steering ..................................................................................................14

4.6 Engaging the Deck Drive .....................................................................................................15

4.7 HillsideOperation .................................................................................................................16

4.8 Parking the Mower ...............................................................................................................16

4.9 After Operation ....................................................................................................................16

4.10 Removing Clogged Material .................................................................................................17

4.11 Moving Mower with Engine Stopped ...................................................................................17

4.12 Recommendations for Mowing .............................................................................................17

4.13 Adjusting Cutting Height .......................................................................................................17

Section 5 - Troubleshooting Cutting Conditions .............................................................. 19-21

TABLE OF CONTENTS (CONT'D)

SUBJECT PAGE

Section 6 - Adjustments

6.1 Parking Brake Adjustment ....................................................................................................22

6.2 TravelAdjustments ...............................................................................................................23

6.3 Throttle Control and ChokeAdjustments..............................................................................24

6.4 BeltAdjustment ....................................................................................................................24

6.5 BeltAlignment ......................................................................................................................24

6.6 Cutter Deck Adjustments .....................................................................................................25

Section 7 - Maintenance

7.1 Maintenance Chart ...............................................................................................................28

7.2 LubricationFittingPoints ......................................................................................................29

7.3 Hydraulic System ..................................................................................................................31

7.4 EngineOil .............................................................................................................................32

7.5 Engine Fuel System ..............................................................................................................32

7.6 EngineAir Cleaner................................................................................................................33

7.7 Battery ..................................................................................................................................33

7.8 Drive Belts ............................................................................................................................35

7.9 Cutter Blades ........................................................................................................................35

7.10 Tires ......................................................................................................................................36

7.11 Body, Deck and Upholstery ..................................................................................................36

Section 8 - Replacement Parts

Notes ..............................................................................................................................................37

SZWC36A, 42A Cutter Deck .................................................................................................. 38-39

Cutter Deck Controls................................................................................................................ 40-41

Sheet Metal Components.......................................................................................................... 42-43

SZC Roll Over Protection System............................................................................................ 44-45

Drive System Components ....................................................................................................... 46-47

Engine and Attaching Parts - Kohler....................................................................................... 48-49

Steering Components ................................................................................................................ 50-51

Brake Components ................................................................................................................... 52-53

Fuel and Hydraulic System ....................................................................................................... 54-55

Electrical System ...................................................................................................................... 56-57

Hydraulic Pump (BDP-10A) .................................................................................................... 48-59

Replacement Decals................................................................................................................. 60-61

Electrical Schematic (Kohler & Kawasaki) ...................................................................................62

Warranty Statement............................................................................................. Inside Back Cover

GENERAL INFORMATION

1.1 INTRODUCTION

Your mower was built to the highest standards in the

industry. However, the prolonged life and maximum

efficiency of your mower depends on you following the

operating, maintenance and adjustment instructions in this

manual.

If additional information or service is needed, contact your

Scag Power Equipment Dealer.

We encourage you to contact your dealer for repairs. All

Scag dealers are informed of the latest methods to service

this equipment and provide prompt and efficient service in

the field or at their service shop. They carry a full line of

Scag service parts.

USE OF OTHER THAN ORIGINAL SCAG

REPLACEMENT PARTS WILL VOID THE

WARRANTY.

When ordering parts, always give the model and serial

number of your tractor. The serial number plate is located

where shown in Figure 1-1.

For pictorial clarity,some illustrations and figures

in this manual may show shields, guards or plates

open or removed. Under no circumstances should

your mower be operated without these devices in

place.

All information is based upon product information

available at the time of approval for printing. Scag

Power Equipment reserves the right to make changes

at any time without notice and without incurring any

obligation.

1.2 DIRECTION REFERENCE

The“Right” and “Left”, “Front” and “Rear” ofthe machine

are referenced from the operator’s right and left when

seated in the normal operating position and facing the

forward travel direction.

1.3 SERVICINGTHE ENGINE AND DRIVE

TRAIN COMPONENTS

The detail servicing and repair of the engine and hydraulic

pumps are not covered in this manual; only routine

maintenance and general service instructions are provided.

Forserviceofthese components during the limited warranty

period, it is important to contact your Scag dealer or find a

local authorized servicing agent of the component

manufacturer. Any unauthorized work done on these

components during the warranty period may void your

warranty.

Section 1

Figure 1-1Tractor Serial Number Plate Location

WARNING:

USE ONLY SCAG APPROVED ATTACHMENTS

AND ACCESSORIES.

Attachments and accessories manufactured by companies

otherthanScagPowerEquipmentarenotapprovedforuse

on this machine.

Scag approved attachments and accessories:

GC-4D (p/n 9038)

GC-4F (p/n 9040)

Mulch Plate (p/n)

Hurricane Mulch (p/n 9272, 9273)

Blade Buddy (p/n 9212)

STC Lights (p/n 9274)

SERIAL NUMBER

PLATE LOCATION

CE Mark

TransmissionChoke

On/Start Spring Tension on Idler

Oil

Off/Stop

SYMBOL DESCRIPTION

ISO Symbols

SpinningBlade

48071S

Parking Brake

WARNING

FALLING HAZARD

USE ONLY SCAG APPROVED

RIDING ATTACHMENTS

SEE OPERATOR'S MANUAL

481109

FallingHazard

Section 1

Slow

Fast

Cutting Element - Engage

Cutting Element - Basic symbol

Cutting Element - Disengage

Continuously Variable - Linear

Read Operator's Manual

Keep Bystanders Away

Pinch Point

481039S

SYMBOL DESCRIPTION SYMBOL DESCRIPTION

Hourmeter/Elapsed Operating Hours

Thown Object Hazard

Section 1

SAFETY INFORMATION

2.1 INTRODUCTION

Your mower is only as safe as the operator.

Carelessness or operator error may result in serious

bodily injury or death. Hazard control and accident

prevention are dependent upon the awareness, concern,

prudence, and proper training of the personnel involved in

the operation, transport, maintenance and storage of the

equipment. Make sure every operator is properly trained

and thoroughly familiar with all of the controls before

operating the mower. The owner/user can prevent and is

responsible for accidents or injuries occuring to

themselves, other people or property.

READ THIS OPERATOR’S MANUAL BEFORE

ATTEMPTING TO START YOUR MOWER.

A replacement manual is available from your authorized

Scag Service Dealer or by contacting Scag Power

Equipment, Service Department at P.O. Box 152,

Mayville, WI 53050 or via the Internet at

www.scag.com. The manual for your machine can be

downloaded by using the model and serial number or use

the contact form to make your request. Please indicate

the complete model and serial number of your Scag

product when requesting replacement manuals.

2.2 SIGNAL WORDS

This symbol means “Attention! Become Alert! Your

Safety is Involved!" The symbol is used with the

following signal words to attract your attention to safety

messages found on the decals on the machine and

throughout this manual. The message that follows the

symbol contains important information about safety. To

avoid injury and possible death, carefully read the

message! Be sure to fully understand the causes of

possible injury or death.

Signal Word:

It is a distinctive word found on the safety decals on the

machine and throughout this manual that alerts the

viewer to the existence and relative degree of the

hazard.

The signal word “WARNING” denotes that a hazard

exists on or near the machine that can result in injury or

death if proper precautions are not taken.

The signal word “DANGER” denotes that an extremely

hazardous situation exists on or near the machine that

could result in high probability of death or irrepairable

injury if proper precautions are not taken.

CAUTION:

The signal word “CAUTION” is a reminder of safety

practices on or near the machine that could result in

personal injury if proper precautions are not taken.

Your safety and the safety of others depends significantly

upon your knowledge and understanding of all correct

operating practices and procedures of this machine.

2.3 BEFORE OPERATION

CONSIDERATIONS

1. NEVER allow children to operate this riding mower.

Do not allow adults to operate this machine without

proper instructions.

2. DO NOT mow when children and/or others are

present. Keep children out of the mowing area and

in the watchful care of a responsible adult other than

the operator. Be alert and turn machine off if a child

enters the area.

3. Clear the area to be mowed of objects that could be

picked up and thrown by the cutter blades.

4. DO NOT carry passengers.

5. DO NOT operate the machine under the influence

of alcohol or drugs.

WARNING:

Section 2

9. Keep the machine and attachments in good operating

condition. Keep all shields and safety devices in

place. If a shield, safety device or decal is defective

or damaged, repair or replace it before operating the

machine.

This machine is equipped with an interlock system

intended to protect the operator and others from

injury. This is accomplished by preventing the

engine from starting unless the deck drive is

disengaged, the parking brake is on, the steering

control levers are in the neutral position and the

operator is in the seat. The system shuts off the

engine if the operator leaves the seat with the deck

driveengagedand/orthesteering control levers are

not in the neutral postion and/or the parking brake

is not engaged. Never operate equipment with the

interlock system disconnected or malfunctioning.

10. Be sure the interlock switches are functioning

correctly.

11. Fuel is flammable; handle it with care. Fill the fuel

tank outdoors. Never fill it indoors. Use a funnel or

spout to prevent spillage. Clean up any spillage

before starting the engine.

12. DO NOT add fuel to a running or hot engine. Allow

the engine to cool for several minutes before adding

fuel.

13. Keep flammable objects (cigarettes, matches, etc.),

open flames and sparks away from the fuel tank and

fuel container.

14. Equipment must comply with the latest requirements

per SAE J137 and/or ANSI/ASAE S279 when

driven on public roads.

If the mower is driven on public roads, it must

comply with state and local ordinances as well as

SAE J137 and/or ANSI / ASAE S279

requirements. Contact your local authorities for

regulations and equipment requirements.

15. DO NOT operate without the side discharge chute

installed and in the down position or with an optional

grass catcher or mulch plate completely installed.

16. Check the blade mounting bolts at frequent intervals

for proper tightness.

17. Make sure all hydraulic fluid connections are tight

and all hydraulic hoses and lines are in good condition

before starting the machine.

2.4 OPERATION CONSIDERATIONS

1. Know the function of all controls and how to stop

quickly.

2. Reduce speed and exercise extreme caution on

slopes and in sharp turns to prevent tipping or loss of

control. Be especially cautious when changing

directions on slopes.

DO NOT operate on steep slopes. To check a slope,

attempt to back up it (with the cutter deck down). If

the machine can back up the slope without the

wheels slipping, reduce speed and use extreme

caution. ALWAYS FOLLOW OSHA APPROVED

7. DO NOT wear loose fitting clothing. Loose

clothing, jewelry or long hair could get tangled in

moving parts. Do not operate the machine wearing

shorts; always wear adequate protective clothing

including long pants. Wearing safety glasses, safety

shoes and a helmet is advisable and is required by

some local ordinances and insurance regulations.

8. Operator hearing protection is recommended,

particularly for continuous operation of the mower.

Wear suitable hearing protection. Prolonged

exposure to loud noise can cause hearing

impairment or loss.

2.3 BEFORE OPERATION

CONSIDERATIONS (CONT'D)

6. If the operator(s) or mechanic(s) cannot read English

or Spanish, it is the owner's responsibility to explain

this material to them.

Section 2

WARNING:

OPERATION.

-NOTE-

WARNING:

Section 2

2.4 OPERATION CONSIDERATIONS

(CONT'D)

3. To prevent tipping or loss of control, start and stop

smoothly, avoid unnecessary turns andtravelatreduced

speed.

4. When using any attachment, never direct the discharge

of material toward bystanders or allow anyone near

the machine while in operation.

5. Before attempting to start the engine, with the operator

in the seat, disengage power to the cutter deck, place

the steering control levers in the neutral position and

engage the parking brake.

6. If the mower discharge ever plugs, shut off the engine,

remove the ignition key, and wait for all movement to

stop before removing the obstruction.

DO NOT use your hand to dislodge the clogged

discharge chute. Use a stick or other device to

remove clogged material.

7. Bealert for holes, rocks, roots and other hidden hazards

in the terrain. Keep away from any dropoff. Beware

ofoverheadobstructions(lowlimbs,etc.),underground

obstacles(sprinklers,pipes,treeroots,etc.). Cautiously

enter a new area. Be alert for hidden hazards.

8. Disengage power to cutter deck before backing up.

Do not mow in reverse unless absolutely necessary

andthenonlyafterobservationoftheentireareabehind

the mower.

9. DO NOT turn sharply. Use care when backing up.

10. Disengage power to cutter deck before crossing roads,

walks or gravel drives.

11. Mowonlyin daylight or good artificial light.

12. NEVER raise the deck with the blades engaged.

13. Take all possible precautions when leaving the machine

unattended, such as disengaging the mower, lowering

theattachments, setting the parking brake, stoppingthe

engine, and removing the key.

14. Disengagepower to theattachments when transporting

or when not in use.

15. The machine and attachments should be stopped and

inspected for damage after striking a foreign object,

and damage should be repaired before restarting and

operating the machine.

DO NOT touch the engine or the muffler while

the engine is running or immediately after

stopping. These areas may be hot enough to

cause a burn.

DO NOT run the engine inside a building or a

confined area without proper ventilation. Exhaust

fumes are hazardous and could cause death.

16. Keep hands and feet away from cutter blades and

moving parts. Contact can injure.

17. Use care when loading or unloading the machine onto

a trailer or truck.

18. Usecarewhenapproachingblindcorners,shrubs,trees,

or other objects that may obscure vision.

2.5 ROLL OVER PROTECTION SYSTEM

WARNING:

CAUTION:

WARNING:

Seat belt must be securely fastened during

operation. Failure to do so could cause

serious injury or loss of life.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cortacésped de Scag Power Equipment

Scag Power Equipment

Scag Power Equipment STHM-18KH Manual de usuario

Scag Power Equipment

Scag Power Equipment SM-52 Manual de usuario

Scag Power Equipment

Scag Power Equipment Tiger Cat II STCII-48V-22FS Manual de usuario

Scag Power Equipment

Scag Power Equipment SW32-15KAI Manual de usuario

Scag Power Equipment

Scag Power Equipment Turf Tiger STT61V-25KBD-SS Manual de usuario

Scag Power Equipment

Scag Power Equipment STC48V-24BS Manual de usuario

Scag Power Equipment

Scag Power Equipment Tiger Cat II STCII-48V-22FX Manual de usuario

Scag Power Equipment

Scag Power Equipment STZ52-18KH Manual de usuario

Scag Power Equipment

Scag Power Equipment SMTC-48V Guía de configuración

Scag Power Equipment

Scag Power Equipment SWZT-36H-14FS Manual de usuario

Scag Power Equipment

Scag Power Equipment LIBERTY Z Manual de usuario

Scag Power Equipment

Scag Power Equipment ST 12B Tractor Manual de usuario

Scag Power Equipment

Scag Power Equipment Turf Tiger Propane STT52V-25CH-LP Manual de usuario

Scag Power Equipment

Scag Power Equipment STC Manual de usuario

Scag Power Equipment

Scag Power Equipment SWZV36A-16KAI Manual de usuario

Scag Power Equipment

Scag Power Equipment SW Manual de usuario

Scag Power Equipment

Scag Power Equipment Turf Tiger II Manual de usuario

Scag Power Equipment

Scag Power Equipment Turf Tiger STT61V-31EFI-SS Manual de usuario

Scag Power Equipment

Scag Power Equipment Turf Tiger STT61V-25KBD-SS Manual de usuario

Scag Power Equipment

Scag Power Equipment SLM-48 Manual de usuario

Scag Power Equipment

Scag Power Equipment TIGER CAT STC48V-19KAI Manual de usuario

Scag Power Equipment

Scag Power Equipment SW36-12B6 Manual de usuario

Scag Power Equipment

Scag Power Equipment SW32-14BV Manual de usuario

Scag Power Equipment

Scag Power Equipment ST 18B Tractor Manual de usuario

Manuales populares de Cortacésped de otras marcas

RHINO

RHINO 1958 Manual de usuario

Wolf Garten

Wolf Garten Compact plus 40 B Manual de usuario

Cub Cadet

Cub Cadet LTX 1045 Manual de usuario

Craftsman

Craftsman 917.378461 Manual de usuario

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manual de usuario

Challenge

Challenge CH18V2 Instrucciones de operación

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manual de usuario

DEWEZE

DEWEZE ATM-725 Manual de operación

Weed Eater

Weed Eater 180083 Manual de usuario

Husqvarna

Husqvarna Poulan Pro PP185A42 Manual de usuario

Better Outdoor Products

Better Outdoor Products Quick Series Manual de usuario

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manual de funcionamiento

MTD

MTD 795, 792, 791, 790 Manual de usuario

Toro

Toro Groundsmaster 3505-D Manual de usuario

Dennis

Dennis FT 610 Manual de usuario

AIRFORCE

AIRFORCE F-15 Gen 3 Manual de usuario

MTD

MTD 126-220-000 Manual de usuario

Toro

Toro 74806 Manual de usuario
