OPERATION
• TO RAISE:
1. Turn the release valve with the end of the handle clockwise until it is firmly closed before
pumping.
2. Position the jack under the load and turn the extension screw or head cap until solid
contact can be made with the load to be lifted.
3. Operate the jack handle until the head cap contacts the load. Once again, check to see
that the head cap is correctly positioned.
4. After the load is lifted to desired height. Use appropriate means (e.g. vehicle support
stands) to support the load immediately.
• TO LOWER:
1. Raise the jack to remove the vehicle support stands or other supporting object.
2. Slowly turn the release valve counterclockwise (again using the handle) no more than
ONE full turn. When under a load, the jack will lower to the original point of contact. If
the piston is still extended, push the piston down manually so that the piston is not left
exposed to rusting.
MAINTENANCE PROCEDURES
• IMPORTANT:
- Do not use brake fluid, alcohol, glycerin, detergent, motor oil or dirty oil.
- Use a good grade Hydraulic Fluid (ISO 15 or equivalent).
- Improper fluid added can cause serious internal damage to the jack rendering it
inoperative.
• TO ADD OIL:
With the head cap fully lowered and the piston depressed,
place the jack horizontally and then remove the oil filler plug
(refer to figure 1). Fill until oil is level with the filler plug hole
when the jack is upright.
• TO CHANGE OIL:
- For best performance and longest life, replace the complete oil supply at least once a
year. To drain the oil, remove the filler plug. Lay the jack with oil filler hole downward
and allow the oil to run out into a suitable drain pan. The oil will run slowly because air
must enter as the oil drains out.
- DO NOT allow dirt or foreign matter to get into the system. Replace with the proper oil
as described above.
• LUBRICATION:
Add proper lubricant oil to all pivoting sections every 3 months.
• PREVENTING RUST:
Check ram (B) every 3 months for any sign of rust or corrosion. Clean as needed by
wiping with an oil cloth. When not in use always leave the head cap (A) and ram (B) all
the way down.
