Saramonic Vlink2 Manual de usuario
User Manual
2.4 GHz Wireless Microphone System
Vlink2
Statement
Please read this manual carefully before use and operate and store in
strict accordance with the instructions provided. Please retain for
future reference.
For any issues that cannot be resolved with the user manual, please
Cautions
1. Take care not to use the unit underwater or unprotected in rainy
conditions. Store in a cool, dry place.
2. Designed for use and storage at normal temperatures. Do not move
the unit from overheated to cold conditions frequently, and keep
away from heat sources such as heaters and ovens.
3. When in use, or when storing, avoid contact with dust and moisture.
4. Do not subject to device to violent collisions, as this can damage the
device.
5. In order to avoid acoustic feedback, do not hold the microphone
close to loudspeakers.
6. For optimal sound detection, do not hold your hand against the
microphone head.
01
General Introduction
The Saramonic Vlink2 wireless microphone system provides a premium
2-person wireless audio solution for vloggers, mobile journalists and
content creators.It is an easy-to-use, high-quality and flexible 2.4
GHz system. The external microphone input allows the receiver to
be connected to a mic device. The system can be powered through
its USB-C ports, allowing it to run for numerous hours on a USB-C 5V
power bank.
Portable Receiver Vlink2 RX
Introduction
The Saramonic Vlink2 RX is a camera-mountable dual-channel 2.4GHz
wireless receiver. It features a high-contrast OLED display and talkback
function to transmitter. The two detachable antennas can be rotated
360° for better reception. The receiver's output can be toggled
between mono and stereo modes. The talkback and monitor function
on the receiver allows camera operators to select individually if desired,
and communication can be controlled by a mute button.
02
Product Structure
①Antennas
②LINE OUT Jack
Connect the Vlink2 RX to a DLSR camera, smartphone with a 3.5mm
headphone jack, mixer or amplifier with the supplied output cable.
③3.5mm Talkback and Headphone Jack
Using the talkback function with the supplied headphone, the
receiver can monitor the real-time feedback and deliver talkback
communication with transmitter.
④USB-C Charging Port (DC 5V)
⑤Cold Shoe Mount Adapter
①
⑪
⑨
⑩
⑦
⑥
⑧
⑤
②
③
④
03
⑥ SET Button
Long press the SET button to enter the displayed menu. Then, short
press the SET button to confirm your setting change, or long press
again to exit without saving.
⑦Power / Mute Button
Status Operation
Power ON Long press for at least three seconds
Power OFF Long press until it turns off
Mute ON Short press
Mute OFF
⑧RF Indicator
Status Indicators
Disconnected Lights off
Pairing Quickly flashing blue light
Paired Successfully Solid blue light
Mute ON (Paired Successfully) Slowly flashing blue light
⑨OLED Display
⑩POWER Indicator
Status Indicators
Power On / Fully charged Solid blue light
Low battery / Charging Solid red light
Low battery warning Flashing red light
(the unit shutdowns whitin 10 mins)
04
⑪+/- button (Pair button)
Press the buttons “+” and “-“ for 3 seconds at the same time, entering
pairing mode.
Attaching Accessories
Connect the supplied cable to the output jack.
①Plug the supplied cable into the LINE OUT jack.
②For a secure connection, turn to lock the connector.
05
Attach the shoe mount adapter
③ Please attach the belt clip as shown before attaching the shoe mount
adapter.
④ Press the bottom of the belt clip to make some space between the
belt clip and the receiver.
⑤ Align the belt clip with the two vertical grooves on the shoe mount
adapter and insert the adapter in the direction of the arrow.
⑥ Push the shoe mount adapter in fully until the belt clip fits into the
horizontal groove on the adapter holds.
06
OLED Display Operation Guide
Home screen: If no operation is performed for 20 seconds on the
other screens, the display will automatically return to the home screen.
①Pairing Indicator
Paired Successfully Disconnected
②Output Mode Indicator
M: Mono S: Stereo
③Mic & Audio Monitoring Icon
Mute Off Mute On
④Headphone Volume
⑤RX's Battery Level Indicator
Displays the RX battery level. Please recharge the device immediately
when the indicator starts flashing.
23
07
⑥Channel A Icon
⑦RF Level Indicator (Channel A)
Indicates the current reception level.
⑧Audio Input Level Meter (Channel A)
Displays the audio input level.
⑨TX's Battery Level Indicator (Channel A)
Displays the TX battery level. Please recharge the device immediately
when the indicator starts flashing.
⑩Channel B Icon
⑪ RF Level Indicator (Channel B)
Indicates the current reception level.
12 Audio Input Level Meter (Channel B)
Displays the audio input level.
13 TX's Battery Level Indicator (Channel B)
Displays the TX battery level. Please recharge the device immediately
when the indicator starts flashing.
Mic Gain
Adjust the external microphone’s gain level (0-19). Default is “16”.
08
Set Output Volume
Set the volume of output audio within the range of 0 to 31. The setting
is retained even after the power is turned off. Default volume is 28.
Output Mode
The output mode can be set to mono or stereo. When the output mode
is in mono, the audio from the left and right channel will be mixed.
When in stereo, receiver A's and receiver B's audio output will be
separated to the left and right of the stereo output.
System default is mono.
Set Backlight
Set backlight to Always On or On for 10, 30, or 60 seconds. Default is
"On".
09
