Sanyo CM14SW8S Manual de usuario

POLYPRO 0.12U J 200V

ASSY,PWB,MAIN F8STG

414 009 5001

645 027 5739

403 082 6916

403 082 7408 POLYPRO 0.15U J 200V

Page &

Section Key No

C441

L902 610 224 5783

Page 20

CRT A34KPU02XX

DEFLECTION YOKE

610 295 4333

POLYPRO 0.12U J 200V

C442 403 082 7408 POLYPRO 0.15U J 200V

SERVICE MANUAL

(SUPPLEMENT) Colour Television

Product Code:

1 113 506 13 (CM14SW8S)

1 113 506 33 (CM14SW8SA)

1 113 507 13 (CM20SW8S)

1 113 507 33 (CM20SW8SA)

1 113 508 13 (CM21SW8S)

1 113 508 33 (CM21SW8SA)

Original Version

Chassis Series: AC3-A

FILE NO.

Service Ref. No. CM14SW8S-00

CM14SW8SA-00

CM20SW8S-00

CM20SW8SA-00

CM21SW8S-00

CM21SW8SA-00

(Middle East)

Give complete “SERVICE REF. NO.” for parts

order or servicing.It is shown on the rating plate

at the cabinet back of the unit.

TV/AVM

VIDEOAUDIO

-NOTE-

These models (CM14SW8S, CM14SW8SA, CM20SW8S, CM20SW8SA, CM21SW8S,

CM21SW8SA) are electrically similar to original models (CM14SW8, CM14SW8A, CM20SW8,

CM20SW8A, CM21SW8, CM21SW8A).

Any information not contained in this manual will be found in the original model’s service manual

SM5110013 (Issue date-Nov., 1999).

REFERENCE NO. SS 5110250

CRT A34LRQ91X

414 010 3201

Q901

Page 17

Part No. Description

DEFLECTION YOKE

Model CM14SW8 & CM14SW8A Model CM14SW8S & CM14SW8SA

Part No. Description

610 284 2340 ASSY,PWB,MAIN F8ST

DIFFERENCES

CHASSIS ELECTRICAL PARTS LIST

F8SR/F8SRA/F8TR/F8TRA/F8VR/F8VRA

Model No. CM14SW8S

CM14SW8SA

CM20SW8S

CM20SW8SA

CM21SW8S

CM21SW8SA

TV/AVM

VIDEOAUDIO

TV/AVM

VIDEOAUDIO

TV/AV M

VIDEOAUDIO

Cabinet Parts List F8SR/F8SRA

1 610 263 3887 BUTTON POWER

610 229 8406 SPRING

2 610 291 7062 BUTTON UNITED

3 610 291 7222 DEC SHEET

4 610 291 6980 ASSY,CABINET FRONT

5 645 023 4316 BADGE,SANYO

6 610 292 0604 CABINET BACK

7 610 294 4792 LABEL RATING (CM14SW8S)

610 294 4808 LABEL RATING (CM14SW8SA)

8 610 011 6405 ROD ANTENNA ASSY

or 610 216 4886 ROD ANTENNA ASSY

or 610 217 1006 ROD ANTENNA ASSY

or 645 012 0428 ROD ANTENNA ASSY

or 645 042 4519 ROD ANTENNA ASSY

9 645 003 2837 ANT MATCHING BOX

or 610 230 3216 ANT MATCHING BOX

10 645 045 8606 ASSY,REMOCON JXMPA

11 610 291 6829 RC-BATTERY LID

610 293 8326 INSTRUCTIONS MANUAL

(English)

610 294 4365 INSTRUCTIONS MANUAL

(Arabic)

610 294 4372 SIMPLIFIED INST

(Spanish/Russian)

Key No. Part No. Description Key No. Part No. Description

Note: Parts order must contain Service Ref. No., Part No., and descriptions.

P▲

P▼

BASS

JXMPA

PIC MODE SWAP

-/--

TV/AV

A/B

CH SCAN

TIMER

10 11

Model CM14SW8S/CM14SW8SA

ANT. 75Ω

VIDEO IN

VIDEO OUT

AUDIO OUT

AUDIO IN

-2-

Cabinet Parts List

-3-

1 610 263 3887 BUTTON POWER

610 229 8406 SPRING

2 610 294 5676 BUTTON UNITED

3 610 294 5683 DEC SHEET

4 610 291 6973 ASSY,CABINET FRONT

5 645 023 4316 BADGE,SANYO

6 610 292 0598 CABINET BACK

7 610 294 4846 LABEL RATING (CM20SW8S)

610 294 4853 LABEL RATING (CM20SW8SA)

8 610 011 6405 ROD ANTENNA ASSY

or 610 216 4886 ROD ANTENNA ASSY

or 610 217 1006 ROD ANTENNA ASSY

or 645 012 0428 ROD ANTENNA ASSY

or 645 042 4519 ROD ANTENNA ASSY

9 645 003 2837 ANT MATCHING BOX

or 610 230 3216 ANT MATCHING BOX

10 645 045 8606 ASSY,REMOCON JXMPA

11 610 291 6829 RC-BATTERY LID

610 293 8326 INSTRUCTIONS MANUAL

(English)

610 294 4365 INSTRUCTIONS MANUAL

(Arabic)

610 294 4372 SIMPLIFIED INST

(Spanish/Russian)

Key No. Part No. Description Key No. Part No. Description

Note: Parts order must contain Service Ref. No., Part No., and descriptions.

Model CM20SW8S/CM20SW8SA

F8TR/F8TRA

TV/AVM

VIDEOAUDIO

VIDEO IN

VIDEO OUT

AUDIO OUT

AUDIO IN

ANT. 75Ω

P▲

P▼

BASS

JXMPA

PIC MODE SWAP

-/--

TV/AV

A/B

CH SCAN

TIMER

10 11

Cabinet Parts List

A14800 /May /’01 /300 BB SANYO Electric Co.,Ltd.

Printed in Japan

1 610 265 6381 BUTTON POWER

610 229 8406 SPRING

2 610 294 5980 BUTTON UNITED

3 610 294 6000 DEC SHEET

4 610 291 6997 ASSY,CABINET FRONT

5 645 003 9256 BADGE,SANYO

6 610 292 0611 CABINET BACK

7 610 294 4891 LABEL RATING (CM21SW8S)

610 294 4907 LABEL RATING (CM21SW8SA)

8 645 004 8616 ROD ANTENNA ASSY

or 645 004 8753 ROD ANTENNA ASSY

9 645 003 2837 ANT MATCHING BOX

or 610 230 3216 ANT MATCHING BOX

10 645 045 8606 ASSY,REMOCON JXMPA

11 610 291 6829 RC-BATTERY LID

610 293 8326 INSTRUCTIONS MANUAL

(English)

610 294 4365 INSTRUCTIONS MANUAL

(Arabic)

610 294 4372 SIMPLIFIED INST

(Spanish/Russian)

Key No. Part No. Description Key No. Part No. Description

Note: Parts order must contain Service Ref. No., Part No., and descriptions.

Model CM21SW8S/CM21SW8SA

F8VR/F8VRA

TV/AV M

VIDEOAUDIO

ANT. 75Ω

VIDEO IN

VIDEO OUT

AUDIO OUT

AUDIO IN

P▲

P▼

BASS

JXMPA

PIC MODE SWAP

-/--

TV/AV

A/B

CH SCAN

TIMER

10 11
