INSTRUCTION MANUAL CDP-M470

Compact Disc Player with

MP3 Decoder

CDP-M470_AU 10/05/2004, 18:0621

CLASS 1 LASER PRODUCT

LUOKAN 1 LASERLAITE

KLASS 1 LASERAPPARAT

PRECAUTIONS

CAUTION

USE OF CONTROLS OR ADJUSTMENT OR PERFORMANCE OF

PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RE-

SULT IN HAZARDOUS RADIATION EXPOSURE.

THIS COMPACT DISC PLAYER SHOULD NOT BE ADJUSTED OR

REPAIRED BY ANYONE EXCEPT QUALIFIED SERVICE

PERSONNEL.

CAUTION – INVISIBLE LASER RADIATION WHEN OPEN AND

INTERLOCKS DEFEATED. AVOID EXPOSURE TO BEAM.

ADVARSEL – USYNLIG LASER STRÅLING VED ÅBNING, NÅR

SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION, UNDGÅ UDS ÆTTELSE

FOR STRÅLING.

VARNING – OSYNLIG LASER STRÅLNING NÄR DENNA DEL ÄR ÖPPNAD

OCH SPÄRR ÄR URKOPPLAD. STRÅLEN ÄR FARLIG.

VORSICHT – UNSICHTBARE LASERSTRAHLUNG TRITT AUS, WENN

DECKEL GEÖFFNET UND WENN SICHERHEITSVERRIEGELUNG

ÜBERBRÜCKT IST. NICHT, DEM STRAHL AUSSETZEN.

VARO – AVATTAESSA JA SUOJALUKITUS OHITETTAESSA OLET ALTTIINA

NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE. ÄLÄ KATSO SÄTEESEEN.

CDP-M470_AU 10/05/2004, 18:061

• Do not use where there are extremes

of temperature (below 5°C or exceed-

ing 35°C).

• Sudden changes in the ambient tem-

perature may cause condensation to

form on the optical lens inside the

unit. If this happens, take out the disc,

leave the unit for about 1 hour, and

then proceed to operate.

• Do not insert pins, etc., inside the

unit.

This unit is equipped with a safety

device which automatically turns the

laser beam off when the disc com-

partment is opened. If a pin or other

metal object should get inside the

unit, however, this safety device may

be deactivated.

• The rating label is located on the

bottom of the unit.

• High volume levels can create poten-

tially dangerous situations by drown-

ing out surrounding sounds. Use cau-

tion when driving while operating the

unit, and obey all applicable laws.

Do not play your headset at a high

volume level. Hearing experts advise

against continuous extended play.

If you experience a ringing in your

ears, reduce the volume or discon-

tinue use.

• No objects filled with liquids, such as

vases, shall be placed on the

apparatus.

• Do not use while bicycling, running or

operating a motorized vehicle.

• The rating label is located on the

bottom of the unit.

• The apparatus shall not be exposed

to dripping or splashing.

CDP-M470_AU 10/05/2004, 18:062

234567

131415

CONTROLS

1. Open switch (OPEN)

2. Disc compartment

3. Bass expander switch (DBBS)

4. Stop button ( n/)

5. Volume control (VOLUME)

6. Headphones socket (PHONES)

7. Line output socket (LINE OUT)

8. Hold switch (HOLD)

9. Skip-up/Search button ( e/)

10. External DC socket (DC IN 4.5V)

11. Play/Pause button ( i/)

12. Mode/Clear button (MODE/CLEAR)

13. Display

14. Battery compartment (bottom)

15. Menu/ASR button (MENU/ASR)

16. PROG/ENTER button

(PROG/ENTER)

17. Skip-down button ( f/)

CDP-M470_AU 10/05/2004, 18:063

The buttons on the remote control function in the same way as the corresponding buttons

on the unit.

1. Skip down button ( f)

2. Skip up button ( e)

3. Play/Pause button (PLAY/PAUSE/ L)

4. Stop button (STOP/ N)

5. Volume control (VOLUME a)

REMOTE CONTROL

STOP

12 34

REMOTE CONTROLLER

RB-CDPM470

CDP-M470_AU 10/05/2004, 18:064

POWER SUPPLY

AC adaptor

Plug one end of the supplied AC adaptor

into the DC IN 4.5V socket, then plug the

other end into an AC outlet.

•Use only the supplied AC adaptor

•If the AC adaptor is connected. The

power supply automatically switches

to the AC power source and the in-

stalled batteries are disconnected.

Alkaline batteries

Install four “R03/AAA”batteries (not

supplied) as shown below. Observe

proper polarity.

Battery replacement

If the batteries are weak, “LOW BAT-

TERY”appears on the display. Replace

the batteries.

•Dispose of all used batteries safety

and in accordance with all applicable

laws.

Note:

When you are not going to use the unit for

one month or more, take the batteries out

of the battery compartment.

CDP-M470_AU 10/05/2004, 18:065

BEFORE OPERATION

Note:

•Press the MENU/ASR button to turn

the anti rolling shock function off. “AS”

disappears. Press the button again

to turn it on.

•Sound may skip or mute for a few

seconds when you press the MENU/

ASR button during play.

•Playing may stop when the unit gets

strong shock even when the anti roll-

ing shock function is on.

•When playing back MP3 CD, this

function always works even if “AS”

doesn’t appear.

(The function is not cancelled by

pressing the MENU/ASR button.)

Anti rolling shock function

In the previous anti-shock function, when

skips occurred while available memory

runs out, then the sound would suffer

some interruption.

The new anti rolling shock function is

designed to prevent skipping to the great-

est extent possible instead of supple-

menting the skipped portion of the sound.

Thisisachievedbyexpandingthememory

capacity, and in addition full attention has

been given also to increasing the unit's

signal reading capability.

Moreover, consideration has been given

toeliminatingthebasiccausesofskipping,

both from the standpoint of horizontal

shock and vertical shock.

Use this function when listening during

walk or playing in a car.

When the i/button is pressed first

time, the anti rolling shock function turns

on automatically. “AS”blinks on the

display. Then “AS”is remain standby

when the buffer memory is full of next 45

seconds music data to Music Cd and full

of next 120 seconds music data to MP3

CD.

CD 01 AS

00:41

CD 01 AS

00:01

CDP-M470_AU 10/05/2004, 18:066

Dynamic bass boost system (DBBS)

Set the DBBS switch to ON to enhance

the bass sound.

Auto power on function

The power turns on automatically when

i/button is pressed.

Auto power off function

The power turns off automatically after

about 60 seconds when all tracks on a

disc have been played or when the n/

button is pressed once to stop play.

Hold function

The HOLD switch disables the buttons

from operating to prevent play from start-

ing or stopping due to accidental

operation. For normal use, leave the

switch in the off position.

To prevent battery drain:

Set the HOLD switch to the on position

when carrying the unit in a bag. The i/

button will not function even if the button is

pressed accidentally. “HOLD”appears

briefly on the display.

To prevent play from being interrupted:

Set the HOLD switch to the on position

after starting play. “HOLD”appears.

If the operating buttons do not func-

tion when pressed ...

1. Check whether the HOLD switch is

on or not.

2. Remove the batteries and/or dis-

connect the AC adaptor from the

unit. Wait a few seconds, then re-

install the batteries or reconnect the

AC adaptor.

3. If the buttons still do not function,

insert new batteries .

ON OFF

CDP-M470_AU 10/05/2004, 18:067

HANDLING COMPACT DISCS

Use compact discs bearing the symbol

shown below. In addition to conventional

12 cm CDs, this unit can be used to play

8 cm CDs without an adaptor.

•Do not expose the disc to direct sun-

light, high humidity or high tempera-

tures for extended periods of time.

•Discs should be returned to their

cases after use.

•Do not apply paper or write anything

on the disc surface.

•Handle the disc by its edge. Do not

touch the playing surface (glossy

side).

•Fingerprints and dust should be care-

fully wiped off the playing surface of

the disc with a soft cloth.

Wipe in a straight motion from the

center to the outside of the disc.

•Never use chemicals such as record

cleaning sprays, antistatic sprays or

fluids, benzene or thinner to clean

compact discs.

The unit will not play a disc that has been

inserted upside down, or discs which do

notconformtotheCompactDiscstandard.

CDP-M470_AU 10/05/2004, 18:068

INFORMATION

This unit can play back the CD-R/RW that has recorded music data or MP3 files.

Before playing back Music CD or MP3 CD, please read the following.

•MP3 CD is the disc that standardized by ISO9660, its file name must include 3-digits

extension letters, “mp3”.

•The directory and file names of the MP3 CD must be corresponded to the ISO stan-

dardized files.

•Single-session disc can be played back.

•Some multi-session discs and mixed discs cannot be played back depending on the

recording condition.

•This unit can recognize up to 99 folders or 300 files per disc.

The CD with 99 folders or 300 files and over is not available to this unit.

And if CD has a long file name, this unit can’t recognize up to 300 files.

•This unit can recognize up to 8 directory trees per disc.

•MP3 CD may not be played in the recorded order.

•Music section in “CD Extra”can be played back, not Data section.

•Music files recorded by “Packet Writing”cannot be played back.

Notes on disc writing method

When you make MP3 CD by using your PC, set 44.1 kHz of sampling frequency.

There are three basic methods for writing to a CD: “Track-at-Once”, “Disc-at-Once”, and

“Packet Writing”.

Music files recorded by “Track-at-Once”or “Disc-at-Once”can be played back on this unit.

(Note: The unit cannot play back the music files added with “Track-at-Once”.)

Music files recorded by “Packet Writing”cannot be played back.

CDP-M470_AU 10/05/2004, 18:069
