Sanus DMF215 Manual de usuario

Our US-based

install experts

are standing

by to help.

Call us at:

888-333-9952

Get it right the

ﬁrst time.

HeightFinder™

shows you

where to drill.

Check it out at:

SANUS.com/1174

Want to watch

a video that

shows how

easy this DIY

project will be?

Watch it now at:

SANUS.com/2888

Recommended placement

WE’RE HERE TO HELP

DMF215

INSTRUCTION MANUAL

Para Español ver página 20

DMF215

IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE

Before getting started, let’s make sure this mount is perfect for you!

—

Perfect!

Yes

—

This mount is NOT compatible. Visit MountFinder.sanus.com or call

1-888-333-9952 to ﬁnd a compatible mount.

Do you have

all the tools

needed?

What is your

wall made of?

50 lbs.

(22.6 kg)

Ready to begin?

Does your TV

(including accessories)

weigh more than

50 lbs. (22.6 kg)?

Drywall with

wood studs?

Solid concrete or

concrete block?

Perfect!

Wood Stud Install

Concrete Install

Awl

Pencil Level Stud Finder

Screwdriver

Tape

Measure

7/32 in.

(5.5 mm)

Wood

Drill Bit

Electric

Drill Hammer

1/2 in.

(13 mm)

Socket

Wrench Drill Bit

3/8 in.

(10 mm)

Concrete

Unsure?

Call Customer Service: 1-888-333-9952

Concrete kit CMK1 (not included)

CAUTION:

DO NOT

install into

drywall alone

Please read through these instructions completely to be sure you’re comfortable with this easy install process.

Also check your TV owner’s manual to see if there are any special requirements for mounting your TV.

If you do not understand these instructions or have doubts about the safety of the installation, assembly or use

of this product, contact Customer Service at 1-888-333-9952.

CAUTION: Avoid potential personal injury or property damage!

●This product is designed for use in wood stud, solid concrete, and concrete block walls - DO NOT install into drywall alone

●This product is designed for INDOOR USE ONLY

●The wall must be capable of supporting ﬁve times the weight of the TV and mount combined

●Do not use this product for any purpose not explicitly speciﬁed by manufacturer

●Manufacturer is not responsible for damage or injury caused by incorrect assembly or use

Dimensions

7.87in

200mm

3.94in

100mm

15.75in

400mm

11.81in

300mm

.34in

8.7mm

4.02in

102mm

.99in

25.2mm

45deg 45deg

5deg

15deg

15.0in

381mm

9.06in

230mm

8.27in

210mm

2.91in

74mm

.33in

8.4mm

3.1in

78mm

2.8in

71mm

WITHOUT EXTENSION

BRACKETS

17.07in

433.7mm

17.07in

433.7mm

6deg

TV INTERFACE

WALL PLATE

ROLL CONTROL

TOP VIEW - EXTENDED

TOP VIEW - RETRACTED

SIDE VIEW - EXTENDED

SIDE VIEW - RETRACTED

3-D

Before getting started, let’s make sure this mount is perfect for you!

M4 x 12mm

M6 x 12mm M6 x 35mm

M4 x 35mm

M6 x 20mm

M8 x 20mm

M8 x 12mm M8 x 40mm

2.5mm

M4 M6/M8

22mm

5mm M8 x 30mm M8 x 50mm

NOTE: Not all hardware included will be used.

WARNING: This product contains small items that could be a choking hazard if swallowed.

Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to

your dealer; contact Customer Service. Never use damaged parts!

Supplied Parts and Hardware

STEP 1 Parts and Hardware

Faceplate

TV Screws

Washers Spacers

TV Bracket

Extender

TV Bracket

Screw

09 x4 10 x4

13 x4

12 x4

11 x4

14 x4 15 x4

17 x4

16 x4

04 x4 05 x4 06 x4 08 x4

03 x8

02 x4

07 x4

5/16 x 2¾ in.

M5 x 6mm

5/16 x 2¾ in.

Fischer UX10 x 60R Anchor

STEP 2B: Concrete Installation Kit CMK1 [NOT INCLUDED]

STEP 2 Parts and Hardware

STEP 3 Parts and Hardware

Nut Cap

18 x1 19 x1

Full Motion Arm

Wall Plate

Template

Lag Bolt

Concrete Anchor

20 x2

22 x1

21 x1 23 x1

Washer

Contact Customer Service at 1-888-333-9952 to have these

additional pieces shipped directly to you.

Locking Screw

inches

inch dimensions are approximate

inches cm mm

3 7.5 75

4 10 100

7 ⅞ 20 200

11 ¾ 30 300

15 ¾ 40 400

STEP 1 Attach Faceplate to TV

1.1 Measure Your TV Hole Pattern 1.2 Assemble Your Faceplate

Measure the width and height of your TV

hole pattern in mm.

Record your measurements:

Width_______mm x Height_______mm

Based on your TV hole pattern measurements

(Wmm x Hmm), determine your Faceplate

configuration: A, B, C, D or E.

200

[7 ⅞ in.]

200

[7 ⅞ in.]

400

[15¾ in.]

400

[15¾ in.]

These smaller hole patterns only use

Faceplate 01 . Do not use the four TV

brackets 02 and eight screws 03 .

100

[4 in.]

100

[4 in.]

Assemble TV brackets 02 onto Faceplate

01 and secure using eight screws 03 in

the corner holes indicated.

300

[11 ¾ in.]

300

[11 ¾ in.]

100 x 100

200 x 100

200 x 200

For TV Hole Pattern

Measurements

(Dimensions in mm)

300 x 300

400 x 400

For TV Hole Pattern

Measurements

(Dimensions in mm)

D E

200

[7 ⅞ in.]

200

[7 ⅞ in.]

Assemble TV brackets 02 onto Faceplate

01 and secure using eight screws 03 in

the corner holes indicated.

Assemble TV brackets 02 onto Faceplate

01 and secure using eight screws 03 in

the corner holes indicated.

Assemble TV brackets 02 onto Faceplate

01 and secure using eight screws 03 in

the corner holes indicated.

400

[15¾ in.]

400

[15 ¾ in.]

400

[15¾ in.]

300

[11 ¾ in.]

300

[11 ¾ in.]

300

[11 ¾ in.]

400 x 300

For TV Hole Pattern

Measurements

(Dimensions in mm)

300 x 200

400 x 200

For TV Hole Pattern

Measurements

(Dimensions in mm) 200 x 300

200 x 400

For TV Hole Pattern

Measurements

(Dimensions in mm)

or required.

Too Long

Too Short

Correct

1.3 Select TV Screw Diameter 1.4 Select TV Screw Length

Standard conﬁgurations

are shown. For special

applications, or ifyou

are uncertain aboutyour

hardware selection, contact

Customer Service.

CAUTION:

Verify adequate thread

engagementwith yourscrew/

washer/spacercombination

AND TV bracket.

–Too short will not holdthe TV.

–Too long will damage the TV.

a:For ﬂat-back TVs,

no spacers 06 07

b:Spacers 06 and,

07 08 supplied for:

●Round (irregular) back TVs

●Extra space needed (forcables

or inset mounting holes)

FLAT BACK ROUND BACK CABLES INSET HOLES

Test the four TV screw diameters (M4,

M6, and M8) in the threaded inserts on

the back of your TV to determine which

screw diameter ﬁts your TV.

0706

06 07 08

1.5 Attach TV Bracket

TV Bracket Conﬁguration B

Illustrated (with spacers) 04 05

04 05

a: Flat Back

b: Round Back / Extra Space

TV Bracket Conﬁguration A

Illustrated (with spacers)

Positionyour TV bracket conﬁguration (A, B, C, Dor E) onto your TV, making sure the bracketis both centered and level overyour TV hole pattern.

NOTE: The hanging tab Hon faceplate 01 must be oriented toward the top of the TV.

Secure the TV bracket using your selection: (a) screw/washer or (b) screw/washer/spacer.

CAUTION:Avoid potential personal injuries and property damage! DO NOT use power tools for this step. Tighten the screws only enough to

secure the TVbracket to the TV. DO NOT overtighten thescrews.

center of the stud by ﬁnding the stud edges using an awl, a thin nail, or an edge to edge stud finder.

1. Locate your stud. Verify and mark the

2. Position the template 18at your desiredheight and line up the holes with your stud center line. Level the template and tape in place.

≤ 5/8 in.

(16 mm)

STEP 2A Attach Wall Plate to Wall Wood Stud Installation

CAUTION: Avoid potential personal injury or property damage!

●Drywall covering the wall must not exceed 5/8 in. (16 mm)

●Minimum wood stud size: nominal 2 x 4 in. (51 x 102 mm) actual 1 ½x 3 ½in. (38 x 89 mm)
