Sangean H201 Manual de usuario

381Q101-A

H201

Operating instruction

Mode d’emploi

Instruccions de manejo

Gebruiksaanwijzing

Bedienungsanleitung

AM/FMDigital Tuning Shower Radio

Radio numériqueAM/FM

pourdouche

Radio de Baño con Sintonización

DigitalAM/FM

AM/FMDigitaalAfstembare

Doucheradio

MW/UKW Digitales Duschradio

Features

1. Built-inAM/FM antenna for best reception

2. 10 presets ( 5 each wave band )

3. Water resistant up to JIS7 standard

4.Auto seek stations

5. Large and easy to read LCDdisplay

6. Easy to fix bracket and hanger

7. Battery power indicator

8. Clock

9.Adjustable sleep timer

10. Adjustable short timer

11. Emergency LEDillumination ( Torch )

12. Emergency Buzzer

13. Water-resistant 3 inches speaker

Controls

LCDDisplay

Preset stations ( preset 3 also for tuning step change )

Nap timer ( Short timer )

Power button

Tuning Control

Speaker

Hanger Ring

Torch button

Multi Purpose Handle

Battery Cover

Band and Time Set button

Volume Control

DC IN socket

EmergencyBuzzer

Torch

Bracket Holder

FM wire antenna compartment

10 11

12 13

14 15

16 17

LCD Display

Battery Power Status

Volume level

Auto Off status

Short Timer set

Memory number and seconds

Time and Frequency

Band indicator

Installing batteries

1. Position the radio face down on a soft surface.

2. Remove the catch as shown and lift out the battery cover.

3. Insert 2 x “D“ size/UM-1/LR20 batteries.

4. Replace the battery cover and catch.

5. Reduced power, distortion, a “ stuttering “ sound are all signs that

the batteries may need replacing. The batteries should be

replaced when the battery indicator flashes and E shows in

the display.

6. If the radio is not to be used for any extended period of time,

it is recommended that the batteries are removed from the radio.

Using the AC adaptor ( not supplied )

1. Remove the rubber cover ofDC in socket on the left hand side

of your radio.

2. Insert the adaptor plug into theDC socket.

3. Plug the adaptor into mains socket outlet. Whenever the adaptor

is used, the batteries are automatically disconnected.

TheAC adaptor should be disconnected from the mains supply and

the radio when not in use.

Note:

For safety purpose, DO NOT use AC adaptor in the shower

room. Use the batteries only.

Setting the clock

1. The clock will start running when the batteries are installed or

when the radio is connected to the mains supply. The display

will show “ - : - - “.

2. The time can be set with your radio switched off.

3. Press and hold down the Time Set button for approx.

2 seconds until the hours digits flash in the display with a beep.

4. Press theTuning Up/Down buttons to set the required hour.

5. Press theTime Set button, the minute digits will flash in

the display.

6. Press theTuning Up/Down buttons to set the required minute.

7. Press theTime Set button to complete time setting.

The second will start to count.

Operating your radio

Your radio is equipped with three tuning methods – Manual Tuning,

Search tuning and Memory preset tuning.

Manual Tuning

1. Press the Power button to turn on the radio.

2. Select the required waveband by repeatedly pressing the

Band button. For FM waveband, pull out and extend the

FM wire antenna located in the battery compartment to

get best reception. For MW ( AM ) waveband, rotate the

radio for best reception.

3.Asingle press on eitherTuning up orTuning down buttons will

change the frequency in the following increments:

FM: 100 or 200 kHz ( USA version )

50 or 100 kHz ( standard version )

AM ( MW ): 9 or 10 kHz

4. When the waveband end is reached, the radio will continue tuning

from the opposite waveband end.

5. Press theVolume Up/Down buttons to the required level.

6. To switch off your radio, press the Power button. The display will

show OFF.

Search tuning

1. Press the Power button to turn on the radio.

2. Press the Band button to get required waveband, then extend and

position telescopic aerial ( FM ) or rotate the radio (AM).

3. Press and hold down either Tuning up or Tuning down buttons for

more than 0.5 seconds to commerce Search tuning.

4. The radio will search and stop automatically when it finds a station

of sufficient strength.

5. When the waveband end is reached, the radio will continue tuning

from the opposite waveband end .

6. Press theVolume Up/Down buttons to the required level.

7. To switch off your radio, press the Power button. The display will

show OFF.

Memory preset tuning

Storing stations in preset memories

There are 5 presets for each waveband.

1. Press the Power button to turn on the radio.

2. Tune to the required station using one of the methods

previously described.

3. Press and hold down required preset until the radio beeps

( more than 2 seconds ). The preset number will appear with a M

( memory ) and the station will be stored under the chosen

preset button.

4. Repeat the procedures for the remaining presets.

5. Stations stored in preset memories may be overwritten by

following the above procedures.

Recalling preset stations

1. Press the Power button to turn on the radio.

2. Select the required waveband by pressing the Band button.

3. Momentarily press the required Preset button, the preset number

and station frequency will appear in the display.

Tuning step change

In Europe and other parts of the world MW(AM ) tuning steps are

9 kHz, inAmerica the MW(AM ) tuning step is 10 kHz.

On FM step can be set to either 50 or 100 kHz ( standard version )

and 100 or 200 kHz ( USA version ).

To change tuning step

1. Ensure that your radio is switched off.

2. Press and hold down the Step/Preset button 3 for 2 sec.,

the display will show current FM tuning step. Continue holding

down the Step/Preset button 3 for 7 seconds. Your radio will beep

and the display will flash FM and current tuning step.

3. Press theTuning Up/Down button to change required

FM tuning step.

4. Press the Step/Preset button 3 to display MW (AM ) tuning step,

display will showAM and flash current tuning step.

5. Press theTuning Up/Down button to change required MW (AM )

tuning step.

6. Complete the setting by pressing the Step/Preset button 3.

Sleep function –Auto Off

The sleep timer will automatically switch off your radio after a preset

time has elapsed.

1. Press and continue to hold down the Power button, the display will

cycle through the available sleep times in the order 50-40-30-20-

10-60-50………… Release the button when the required

sleep time appears in the display.Display will appearAUTO OFF

and radio will play the last station selected.

2. To cancel the sleep function , press the Power button,

theAUTO OFF will disappear and the radio will switch off.

Nap timer ( short timer )

You can set theNap timer ( short timer ) either radio is on or off.

PressNap timer button , display will appear and flash last

nap timer time. PressTuning up/down button to select required nap

timer time, pressNap timer button again to complete setting.

Nap timer will start to count by second, display will show and

remaining nap timer time ( when radio is off ). The buzzer will sound

for 3 minutes when it reaches the period of time which you have set.

Press Power button to turn the buzzer off.

To turn off theNap timer before the time is up, simply press and

release theNap timer button. will disappear from display.

You can also memory the nap timer time by long pressing Preset

1-5 button for the timer time you require ( same procedures you

store the station ) and recall it whenever you need to set timer. e.g.

you can store 10 minutes timer in preset 1 and 20 minutes timer in

preset 2, so each time after you need to select short timer time,

press short timer button then preset 1 to get 10 minutes timer and

preset 2 to get 20 minutes timer and so on.

Display backlight

The display backlight will be switched on for approximately

15 seconds when any button is pressed.

Emergency buzzer

To activate Emergency buzzer, press and release Emergency

buzzer button . Press and release the button again to switch off

thebuzzer.

Torch

Press to release the torch button to turn on the torch.

Note:

The torch won’t turn off automatically. To turn off the torch,

press torch button again.

Multi-purpose handle

Using the multi-purpose handle, you may hang or carry the radio

when not used in bathroom.
