Sangean dpr-39 Manual de usuario
Operating instruction GB
Mode d’emploi F
Instruccions de manejo E
Gebruiksaanwijzing NL
Bedienungsanleitung D
DPR-39
DAB+ / FM-RDS Hand-held Receiver
DAB+ / FM-RDS Récepteur portable
DAB+ / FM-RDS Receptor de mano
DAB+ / FM-RDS Draagbare ontvanger
DAB+ / UKW-RDS Handempfänger
3A81X51000000
1
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings.
Install in accordance with the manufacturer’
s instructions.
8. Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that
produce heat.
2
9. Do not defeat the safety purpose of
GB
the polarized or grounding-type plug. A
polarized plug has two blades with one
wider than the other. A grounding type
plug has two blades and a third grounding
prong. The wide blade or the third
prong are provided for your safety. If the
provided plug does not fit into your outlet.
consult an electrician for replacement of
the obsolete outlet.
10. Protect the power cord from being walked
on or pinched particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/ accessories
specified by the manufacturer.
3
12. Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
13. Unplug this apparatus during lightning
storms or when unused for long periods
of time.
14. Refer all servicing to qualified service
personnel. Servicing is required when
the apparatus has been damaged in
anyway, such as power-supply cord or
plug is damaged. liquid has been spilled
or objects have fallen into the apparatus,
the apparatus has been exposed to rain
or moisture, does not operate normally, or
has been dropped.
4
15. To Reduce the Risk of Fire or Electric
Shock, Do not Expose This Appliance To
Rain or Moisture. GB
16. T h e S h o c k H a z a r d M a r k i n g a n d
Associated Graphical Symbol is provided
on the bottom panel of unit.
17. Apparatus shall not be exposed to
dripping or splashing and no objects filled
with liquids, shall not be placed on the
apparatus.
5
6
Controls
1 Headphone socket
GB
2 Preset buttons (1-5)
3 Power button
4 LCD display
5 Volume control
6 Tuning/Menu jog wheel
7 Lock switch (Note: If this is activated the
radio will not operate)
8 USB socket for software upgrade
9 Battery compartment
10 Strap holder
7
Battery Installation
Battery cover is located on the back of the
unit. Slide the cover downwards to gain
access to the battery compartment. Insert
two AA (UM-3/R6/LR6) batteries into the
compartment. Make sure that the battery is
positioned in accordance with the indicated
diagram. Replace cover.
Note:
You can always monitor the battery power
from LCD display battery icon. When battery
power becomes very low and unable to
operate the radio, low battery indicator will
appears on the LCD display. The radio will
shut off.
Headphones
The 3.5 mm stereo headphone socket located
on the top of your radio is provided for use
with stereo headphones or an earpiece.
8
Important:
Excessive volume levels from earphones GB
and headphones may cause damage to your
hearing.
Setting the clock
The clock will automatically update each time
you turn on the radio and tune to a DAB radio
station or to an FM station which is
broadcasting the time via RDS. Time display
will flash 0:00 for a few seconds then display
the clock time when it receives DAB or FM –
RDS clock time signal.
Initial operation –DAB
This step is only necessary for initial setup –
1. Make sure a headphones/an earpiece is
plugged in.
2. Press the Power button on the top of your
radio.
