Samsung WW65A Series Manual de usuario

WASHING MACHINE

DRUM TYPE

WASHING MACHINE (DRUM) CONTENTS

SERVICE

Manual

REPAIR GUIDE

1. Safety Instructions

2. FeaturesandSpecications

3. Disassembly and Reassembly

4. Troubleshooting

5. Wiring Diagram

6. Reference

Model Name : (WW5100A Project)

WW8*A******

WW7*A******

WW65A******

WW70AA626AE/LE

Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Samsung

WW80AA126AE o cerca il tuo prodotto tra le migliori offerte di Lavatrici eAsciugatrici

CONTENTS

1. Safety instructions .........................................................................1

1-1. Safety instructions ...........................................................................1

2. FeaturesandSpecications ................................................................4

2-1. Specications................................................................................4

2-2. Comparingspecicationswithexistingmodels ................................................5

2-3. Optionsspecications........................................................................6

3. Disassembly and Reassembly...............................................................7

3-1. Toolsfordisassemblyandreassembly.........................................................7

3-2. Standarddisassemblydrawings...............................................................8

4. Troubleshooting ..........................................................................24

4-1. InformationCode ...........................................................................24

4-2. Problemcheckpoint ........................................................................28

5. Wiring diagram ...........................................................................29

5-1. Wiring Diagram .............................................................................29

6. Reference.................................................................................30

6-1. Modelname................................................................................30

6-2. Terminology ................................................................................31

Safety Instructions _ 1

1. SAFETY INSTRUCTIONS

1-1. SAFETY INSTRUCTIONS

► Makesuretoobservethefollowinginstructionstooperatetheproductcorrectlyandsafelyandpreventpossibleaccidentsand

hazardswhileservicing.

► Twotypesofsafetysymbols,WarningandCaution,areusedinthesafetyinstructions.

WARNING

Hazardsorunsafepracticesthatmayresultinseverepersonalinjuryordeath.

CAUTION

Hazardsorunsafepracticesthatmayresultinminorpersonalinjuryorpropertydamage.

► Followingtherepairbyanon-authorisedserviceprovider,self-repairornon-professionalrepairoftheproduct,Samsungisnot

liableforanydamagetotheproduct,anyinjuryoranyotherproductsafetyissuecausedbyanyattempttorepairtheproduct

whichdoesnotcarefullyfollowtheserepairandmaintenanceinstructions.Anydamagetotheproductcausedbyanattemptto

repairtheproductbyanypersonotherthanaSamsungcertiedserviceproviderwillnotbecoveredbythewarranty.

WARNING BEFORE SERVICING

• (Whenservicingelectricalpartsorharnesses)Makesuretodisconnectthepowerplugbeforeservicing.

4 Failingtodosomayresultinariskofelectricshock.

• Adviseconsumersnottoconnectseveralappliancestoasinglepoweroutletatthesametime.

4 Thereisariskofreduetooverheating.

• Whenremovingthepowercord,makesuretoholdthepowerplugwhenpullingtheplugfrom

theoutlet.

4 Failingtodosomaydamagetheplugorpoweroutletandresultinreorelectricshock.

• Whenthewashingmachineisnotbeingused,makesuretodisconnectthepowerplugfromthe

poweroutlet.

4 Failingtodosomayresultinresultinaccidentaloperationofthewashingmachine.

• Donotplaceorusegasoline,thinners,alcohol,orotherammableorexplosivesubstancesnearthewashingmachine.

4 Thereisariskofexplosionandrecausedfromelectricsparks.

2 _ SafetyInstructions

WARNING WHILE SERVICING

• Checkifthepowerplugandoutletaredamaged,attened,cutorotherwisedegraded.

4 Iffaulty,replaceitimmediately.

Failingtodosomayresultinelectricshockorre.

• Completelyremoveanydustorforeignmaterialfromthehousing,wiringandconnectionparts.

4 Thiswillpreventariskofreduetotrackingandshortsinadvance.

• Whenconnectingwires,makesuretoconnectthemusingtherelevantconnectorsandcheckthattheyareproperlyconnected.

4 Donotusetapeinsteadoftheconnectors,itmaycausereduetotracking.

• MakesuretodischargethePBApowerterminalsbeforestartingtheservice.

4 Failingtodosomayresultinahighvoltageelectricshock.

• Whenreplacingtheheater,makesuretofastenthenutafterensuringthatitisinsertedintothebracket-heater.

4 Ifnotinsertedintothebracket-heater,ittouchesthedrumandcausesnoiseandelectricleakage.

• Donotrepairthewashingmachinewithoutsafetygloves.

4 Itcancauseinjury.

WARNING AFTER SERVICING

• Checkthewiring.

4 Ensurethatthewiringcannotbedamagedbyanysharpedgesormovingparts.

• Checkforanywaterleakage.

4 Performatestrunforthewashingmachineusingthestandardcourseandcheckwhetherthereisanywaterleakage

throughtheoorsectionorthepipes.

• Adviseconsumersnottorepairorserviceanypartofthewashingmachinethemselves.

4 Thismayresultinpersonalinjuryandshortentheproductlifetime.

SafetyInstructions _ 3

CAUTION BEFORE SERVICING

• Donotsprinklewaterontothewashingmachinedirectlywhencleaningit.

4 Thismayresultinelectricshockorre,andmayshortentheproductlifetime.

• Donotplaceanycontainerswithwateroranyotherliquidonthewashingmachine

4 Ifthewaterisspilled,itmayresultinelectricshockorre.Thiswillalsoshortentheproduct

lifetime.

• Donotinstallthewashingmachineinalocationexposedtosnoworrain.

4 Thismayresultinelectricshockorre,andshortentheproductlifetime.

• Donotpressacontrolbuttonusingasharptoolorobject.

4 Thismayresultinelectricshockordamagetotheproduct.

CAUTION WHILE SERVICING

• Whenwiringaharness,makesuretosealitcompletelysonoliquidcanenter.

4 Takecarewhendisconnectingconnectors,donotuseexcessiveforceasthismaydamage

theconnector.

• Checkifthereisanyresiduethatshowsthatliquidenteredtheelectricpartsorharnesses.

4 Ifanyliquidhasenteredintoapart,replaceitorcompletelyremoveanyremainingmoisturefromit.

• Ifyouneedtoplacethewashingmachineonitsbackforservicingpurposes,placeasupport(s)ontheoorandlayitdown

carefullysoitssideisontheoor.

4 Donotlayitdownonitsfront.Thismayresultintheinsidetubdamagingparts.

• Atleasttwopeopleshouldworkwhenworkingwithheavyproducts.

FeaturesandSpecications_4

2. FEATURES AND SPECIFICATIONS

2-1. SPECIFICATIONS

MODEL WW70AA626AE/LE

Modelname FRONT LOADING TYPE

Dimensions 600x850x450

Water pressure 50kPa~800kPa

DrumVolume 48L

NETweight 48L

Washandspincapacity 7kg

Powerconsumption 1900 - 2300W

Spinrevolutions 1200rpm

pleasevisitSamsungofcialwebsitetoreceivemostup-to-dateinformationaboutsoftwareandproductmaintenance.

Model WW70AA626AE/LE

Width(A) 600 mm

Height-Overall(B) 850 mm

Depth(C) 450 mm

Depthwithdooropen90°(D) 965 mm

5_FeaturesandSpecications

2-2. COMPARING SPECIFICATIONS WITH EXISTING MODELS

Model Name WW70AA626AE/LE


Main Spec

Capacity

DrumVolume 48

MaxRPM 1200

Motor DIT

WaterSupply Coldonly

Drainage Pump

USP

ECOBUBBLE ●

AddWash ●

Steam ●

AOW/AD X

SuperSpeed X

Wi X

Q-Drive X

Design

DOOR Basic

Drum Swirl

DISPLAY G. LED

FeaturesandSpecications_6

2-3. OPTIONS SPECIFICATIONS

NO Unit Part Code Figure Description Qty

1BoltSpanner DC60-40146A Toremovetheshippingbolts

Toadjustthelevelingleg 1

Assy Hose

Water

DC97-17845A(Cold)

DC97-17845B(Hot)

Tosetupwatersupply. Coldonly1,

Cold+Hot2(★)

3Hose Water

(Aqua-Stop) DC67-00675A Tosetupwatersupply. 1(★)

4ManualUsers DC68-03649A~Z Toexplaintheproduct

operationandinstallation 1

5CapFixer DC67-00307A Tocovertheholes 3

6Hose Hanger DC67-00357A Tosecurethedrainhose. 1

7GuideLiquid DC61-03510A Touseliquiddetergent. 1(★)

Note

• (H)issuppliedforspecicmodelsonlyamongthosewithoutwatersupplyhoses.

• Customercanpurchaseadditionalwatersupplyanddrainhosesfromaservicecenter.

• Forbuilt-inmodels,thespanner,watersupplyanddrainhosesarenotsupplied.Boththewatersupplyanddrainhosesare

suppliedduringtheinstallation.

Disassemblyand Reassembly _ 7

3. DISASSEMBLY AND REASSEMBLY

3-1. TOOLS FOR DISASSEMBLY AND REASSEMBLY

Tool Type Remarks

Boxdriver

10mm Heater(1),Tub(12),Fixerscrew(5),Motor(2),

Balance(9)

13mm ShockAbsorber(2holeseachinleft/right),

Damper(2),Damper(friction2)

19mm Pulley(1)

Double-ended

spanner

10mm

13mm

19mm

Replacedbyboxdriver

Leg

Vicepliers

AToolforprotectingemptyturningofboltor

abrasionfromusingboxdriver

FordisassemblyofSpindrum

Others

(screwdriver,nipper,long

nosepliers)

Commontoolsforservicing

Torquewrench TheToolforassemblyofheaterandTub

-Forinformationaboutpurchasingpartsandtool,pleasevisit

http://www.samsung.com/support

-Forthepartcodeinformation,pleaserefertheattachedle'ExplodedView'.

8 _ Disassemblyand Reassembly

3-2. STANDARD DISASSEMBLY DRAWINGS

► Thisisastandarddisassemblydiagramandmaydifferfromtheactualproduct.

Usethismaterialasareferencewhendisassemblingandreassemblingtheproduct.

Disassembly

Part Figure Description

Assy Cover Top

1. Remove2screwsholdingtheCoverTopatthe

backoftheunitusing(+)screwdriver.

BACK FRONT

2. RemovetheCoverTopbyliftingitupafter

pullingitbackabout15mm.

Assy Drawer

1. OpentheDrawerbyhand

2. Whileholdingdownthereleaseleverinsidethe

drawer(redbox),slideopenthedrawer.

3. PulluptheCapRinsetoremoveit.
