Samsung WB24K2 Manual de usuario

ERVICE

WASHING MACHINE CONTENTS

WASHING MACHINE

1. Precautions

2. Specifications

3. Features

4. Operating Instructions

5. Schematic and Circuit Diagrams

6. Disassembly and Reassembly

7. Troubleshooting

8. Exploded Views

Manual

When performing trouble - shooting and part replacement during servicing note the following safety precautions.

1-1 Safety Precautions

1-2 Servicing Precautions

1. Precautions

Samsung Electronics Co., LTD.

The information in this manual is subject to change without notice.

1-1-1 Use Genuine Parts

The components of the washing machine have

safety -features such as non - combustibility and

voltage withstanding. Therefore, always use the

same part as used when replacing parts. In

particular, be sure to use only designated parts in

case of major safety parts identified by the making.

1-1-2 Grounding

Connect the grounding wire to the shell plate, and

bury it under at least 25cm of earth ; alternatively,

connect the ground wire to the appropriate pin on a

properly grounded power receptacle.

•Never ground it to the telephone line, lightning rod,

or gas pipe.

1-2-1 Observe warnings

Be sure to follow special warnings and precautions

that are described on part labels and in the owner's

manual.

1-2-2 Special Precautions for Parts Assembly

and wiring

When assembling parts that use safety - insulation

material (such as tube and tape), or when installing

internal wiring, be sure to restore all parts and wiring

to their original positions.

Take special care to avoid contact with sharp edges.

1-2-3 Safety Checks after Servicing

After servicing, check to see that the screws, parts,

and wiring are restored to their original positions,

and check the insulation between the external

metals and the socket plug. In addition, place the

washing machine in a level position (less than 1° of

grade) to prevent vibration and noise during

operations.

1-2-4 Insulation Check

Pull out the plug from the power receptacle, pour

water into the spin tub, and then set the timer.

Check to see that the insulation resistance

between the terminals of the plug and the

exposed metal is greater, than 1 M

Ω

Note :

When it is impossible to perform the

insulation check with a 500V insulation

resistance tester, use other testers for

inspection.

* Caution during service

1-2-5 Before Repair

a) In case of laying the washing machine, do not lay

it down to the front(round) side. It may cause the

deformation of round part not to match with top-park

and round part together.

b) In case of removing top-cover from out case, take

care that wire bundle down to bottom may not touch

the sharp edge and may not be interrupted from tention.

c) When disassembling of top-cover, take care not to

be deformed of Check-S/W

d) In case of moving the washing machine over the rough

floor, do not pull it as possible. (Otherwise, runner

packing may come out and excessive vibration may

occur during spinning.)

1-2-6 During Repair

a) In case of replacing suspension-bar assembly,

obviously check the position of springs and do

not mix them up.(Otherwise, excessive vibration

can occur during spinning.)

b) The installation of a deformed check-S/W rod will

result in malfunction of the safety switch during

severe vibration, thus causing an unbalanced error.

Shape

CASE-D BAR-S SPRING COLLOR-S

Front White White Yellow Red

Rear White Yellow Yellow Ntr

Checker-S/W

Front

Rear

1-2-7 After Repair

a) Confirm the level of washing machine. When

leveling,left&rightsidelevelingshouldbe

performed after front side leveling. (In case that

the machine is not leveled, excessive vibration

may occur.)

b) Level the machine with leveling legs.

◎Pull down the handles of leveling legs in

front side,

◎level the machine

◎after leveling, push back the handles of

leveling legs.

Caution

Do not kick or step on the handles of the

leveling legs.

c) Install the washer on sturdy flat surface.

d) When the lower wiring is arranged, it should be

arranged not to be tensioned in case that the

tub assembly is biased to one side.(When the

tension is not considered, that may cause

vibration and noise.)

e) The wiring and connector should be kept dry.

(Otherwose, that may cause fire and short circuit.)

Leveled Un leveled

Handle of

leveling leg

Pull

Push

WIRE HOLDER

Check the level with position of spin

basket on opening the door.
