Samsung EB40D Manual de usuario

User Manual

The color and the appearance may differ depending on the

product, and the specifications are subject to change without

prior notice to improve the performance.

Recommended hours of use per day of this product is under 16

hours.

If the product is used for longer than 16 hours a day, the

warranty may be void.

EB40D EB48D

Table of contents

Before Using the Product

Safety Precautions 7

Symbols 7

Cleaning 7

Storage 8

Electricity and Safety 8

Installation 9

Operation 11

Preparations

Checking the Components 15

Parts 17

Control Panel 17

Reverse Side 19

Anti-theft Lock 20

Remote Control 21

Before Installing the Product

(Installation Guide) 23

Tilting Angle and Rotation 23

Ventilation 23

Dimensions 24

Installing the Wall Mount 25

Wall Mount Kit Specifications 26

Remote Control (RS232C) 27

Cable Connection 27

Connection 28

Control Codes 29

Connecting and Using a Source

Device

Before Connecting 35

Pre-connection Checkpoints 35

Connecting to a PC 35

Connection using the D-SUB cable

(Analog type) 35

Connection Using an HDMI Cable 36

Connection Using an HDMI-DVI Cable 36

Connecting to a Video Device 37

Connection Using the AV Cable 37

Connection Using an HDMI-DVI Cable 38

Connection Using an HDMI Cable 38

Connecting the Antenna 39

Initial Setup 40

Changing the Input source 40

Source List 40

Using MDC

MDC Program Installation/Uninstallation 41

Installation 41

Uninstallation 41

Connecting to MDC 42

Using MDC over RS232C connections and Wi-Fi 42

Screen Adjustment

Picture Mode 43

If the input source is PC or HDMI

(when a PC is connected) 43

If the input source is TV, HDMI or AV 43

Backlight / Contrast / Brightness /

Sharpness / Color / Tint (G/R) 44

Picture Size 45

Position 47

Zoom/Position 47

Resolution 48

Auto Adjustment 49

PC Screen Adjustment 49

PIP 50

PIP Settings 50

Advanced Settings 51

Dynamic Contrast 52

Table of contents

Black Tone 52

Flesh Tone 52

RGB Only Mode 52

Color Space 52

White Balance 53

Gamma 53

Motion Lighting 53

Picture Options 54

Color Tone 55

Color Temp. 55

Digital Clean View 55

MPEG Noise Filter 55

HDMI Black Level 56

Film Mode 56

Dynamic Backlight 56

Picture Off 57

Reset Picture 57

Sound Adjustment

Sound Mode 58

Sound Effect 59

Speaker Settings 60

Additional Settings 61

DTV Audio Level 61

Dolby Digital Comp 61

Reset Sound 62

Broadcasting

Auto Tuning 63

Antenna 64

Channel List 65

Mode 65

Guide 66

Schedule Manager 67

Edit Channel 68

Edit Favorites 70

Channel Settings 73

Digital Manual Tuning 73

Fine Tune 73

Color System 73

Subtitle 74

Primary Subtitle 74

Secondary Subtitle 74

Caption 75

Audio Options 77

Multi-Track Sound 77

Audio Language 77

Audio Format 77

Channel Lock 78

Network

Network Status 79

Network Settings 79

Network Setting (Wireless) 80

WPS(PBC) 82

Soft AP (Wi-Fi Hotspot) 83

Wi-Fi Direct 84

AllShare Settings 85

Device Name 85

Applications

Source List 86

MagicInfo 87

Schedule 88

MagicInfo Express Content Creator

Using MagicInfo Express Content Creator 90

Managing templates 90

Managing schedules 90

Table of contents

Playing photos, videos and music

(Media Play)

Read the following before using media play

with a USB device 91

Using a USB device 93

Menu items in the media content list page 94

Available buttons and features during photo

playback 95

Available buttons and features during video

playback 96

Available buttons and features during music

playback 97

Supported Subtitle and Media play file

formats 98

Subtitle 98

Compatible image file format 98

Supported music file formats 99

Supported Video Formats 99

System

Setup 102

Initial settings (Setup) 102

Menu Language 104

Multi Control 105

Configuring settings for Multi Control 105

Time 106

Clock 106

Sleep Timer 107

On Timer 107

Holiday Management 108

MagicInfo On/Off Timer 109

Eco Solution 110

Energy Saving 110

Eco Sensor 110

No Signal Power Off 111

Auto Power Off 111

Auto Protection Time 112

Screen Burn Protection 113

Pixel Shift 113

Timer 114

Immediate Display 116

Side Gray 116

Ticker 117

Source AutoSwitch Settings 118

Source AutoSwitch 118

General 119

Game Mode 119

Auto Power 119

Safety Lock 119

Button Lock 119

USB Auto Play Lock 120

Standby Control 120

Lamp Schedule 120

OSD Display 120

AV Color System 121

Change PIN 122

Clone Product 123

Reset System 123

Reset All 124

DivX® Video On Demand 124

Support

Software Update 125

Update now 125

Contact Samsung 125

Troubleshooting Guide

Requirements Before Contacting Samsung

Customer Service Center 126

Testing the Product 126

Checking the Resolution and Frequency 126

Check the followings. 127

Q & A 133

Table of contents

Specifications

General 135

Power Consumption 137

Preset Timing Modes 138

Appendix

Responsibility for the Pay Service

(Cost to Customers) 140

Not a product defect 140

A Product damage caused by customer's fault 140

Others 140

Optimum Picture Quality and Afterimage

Burn-in Prevention 141

Optimum Picture Quality 141

Prevention of Afterimage Burn-in 141

License 143

Terminology 144

Before Using the Product

Chapter 01

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited.

Microsoft, Windows are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Ownership of all other trademarks is attributed to their due owner.

Safety Precautions

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)

THERE ARE NO USER SERVICEABLE PARTS INSIDE.

REFER ALL SERVICING TO QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside.

It is dangerous to make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and maintenance has been

included with this product.

Symbols

Warning

A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.

Cleaning

―Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

―Take the following steps when cleaning.

―The following images are for reference only. Real-life situations may differ from what is shown in the

images.

Power off the product and computer.

Disconnect the power cord from the product.

―Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

Wipe the product with a clean, soft and dry cloth.

•Do not use detergents that contain alcohol, solvent or

surface-active agents.

•Do not spray water or detergent directly on the product.

Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the product.

Connect the power cord to the product when cleaning is finished.

Power on the product and computer.

Storage

Due to the characteristics of high-glossy products, using a UV humidifier nearby may create white-

colored stains on the product.

―Contact Customer Service Center if the inside of the product needs cleaning (service fee will be

charged).

Electricity and Safety

―The following images are for reference only. Real-life situations may differ from what is shown in the

images.

Warning

Do not use a damaged power cord or plug, or a loose power socket.

•An electric shock or fire may result.

Do not use multiple products with a single power socket.

•Overheated power sockets may cause a fire.

Do not touch the power plug with wet hands. Otherwise, an electric shock

may result.

Insert the power plug all the way in so it is not loose.

•An unsecure connection may cause a fire.

Connect the power plug to a grounded power socket (type 1 insulated

devices only).

•An electric shock or injury may result.

Do not bend or pull the power cord with force. Be careful not to leave the

power cord under a heavy object.

•Damage to the cord may result in a fire or electric shock.

Do not place the power cord or product near heat sources.

•A fire or electric shock may result.

Clean any dust around the pins of the power plug or the power socket with

a dry cloth.

•A fire may result.

Caution

Do not disconnect the power cord while the product is being used.

•The product may become damaged by an electric shock.

Only use the power cord provided with your product by Samsung. Do not

use the power cord with other products.

•A fire or electric shock may result.

Keep the power socket where the power cord is connected unobstructed.

•The power cord must be disconnected to cut off power to the product

when an issue occurs.

•Note that the product is not completely powered down by using only

the power button on the remote.

Hold the plug when disconnecting the power cord from the power socket.

•An electric shock or fire may result.

Installation

Warning

DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP OF

THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.

•A fire may result.

Have a technician install the wall-mount hanger.

•Installation by an unqualified person can result in an injury.

•Only use approved cabinets.

Do not install the product in poorly ventilated spaces such as a bookcase or

closet.

•An increased internal temperature may cause a fire.

Install the product at least 10 cm away from the wall to allow ventilation.

•An increased internal temperature may cause a fire.

Keep the plastic packaging out of the reach of children.

•Children may suffocate.

Bend and keep part of the outdoor TV antenna cable hanging downwards

(the part inside the room) to prevent rainwater from entering the product.

•If rainwater enters the product, a fire or electric shock can occur.

When using an outdoor antenna, be sure to install the antenna away from

nearby power lines to prevent the antenna from collapsing onto them in

strong winds.

•A collapsed antenna can cause an electric shock or injury.

Do not install the product on an unstable or vibrating surface (insecure shelf,

sloped surface, etc.)

•The product may fall and become damaged and/or cause an injury.

•Using the product in an area with excess vibration may damage the

product or cause a fire.

Do not install the product in a vehicle or a place exposed to dust, moisture

(water drips, etc.), oil, or smoke.

•A fire or electric shock may result.

Do not expose the product to direct sunlight, heat, or a hot object such as a

stove.

•The product lifespan may be reduced or a fire may result.

Do not install the product within the reach of young children.

•The product may fall and injure children.

•As the front is heavy, install the product on a flat and stable surface.

Edible oil, such as soybean oil, can damage or deform the product. Do not

install the product in a kitchen or near a kitchen counter.

Otros manuales para EB40D

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de TELEVISOR de Samsung

Samsung

Samsung UC6400 Manual de programación

Samsung

Samsung HL-S4676S - 46" Rear Projection TV Manual de usuario

Samsung

Samsung QE98C Manual de usuario

Samsung

Samsung LS03B Manual de usuario

Samsung

Samsung CS29Z30SPBXBWT Manual de usuario

Samsung

Samsung ue40h6500 Manual de usuario

Samsung

Samsung HL-P5063W Manual de usuario

Samsung

Samsung CW25D83NS8XXEC Manual de usuario

Samsung

Samsung LN40D567F9H Guía de inicio rápido

Samsung

Samsung 9000 Series Manual de usuario

Samsung

Samsung HL-R5688W - 56" Rear Projection TV Guía de configuración

Samsung

Samsung CL29Z30MQTXXAZ Manual de usuario

Samsung

Samsung Crystal UHD TU7170 Manual de usuario

Samsung

Samsung TXN3235F Manual de usuario

Samsung

Samsung UN32D6000SF Guía

Samsung

Samsung HL-R5656W Manual de usuario

Samsung

Samsung CS-29Z30BP Manual de usuario

Samsung

Samsung 5 Series Manual de usuario

Samsung

Samsung Plasma TV 4 Series Manual de usuario

Samsung

Samsung TX-R2028, TX-R2035, TX-R1635 Guía del usuario

Samsung

Samsung UA49KS8500 Manual de usuario

Samsung

Samsung UA43KU7500 Manual de usuario

Samsung

Samsung PS-50Q7HD Manual de usuario

Samsung

Samsung CS15K2X/NWT Manual de usuario

Manuales populares de TELEVISOR de otras marcas

Philips

Philips Colour Television Manual de usuario

Toshiba

Toshiba 27A10 Manual de usuario

Philips

Philips 42PF9630A/37 Manual de usuario

Hitachi

Hitachi 32FX48B Manual de usuario

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Manual de usuario

Changhong Electric

Changhong Electric uhd55b6000is Manual de usuario

Philips

Philips Matchline 21CE7551 Manual de usuario

Panasonic

Panasonic Genus TX-G10 Manual de usuario

Toshiba

Toshiba 19A20 Manual de usuario

Philips

Philips 25PT4523-16 Manual de usuario

Sony

Sony XBR-100Z9D Manual de usuario

Philips

Philips PR0930X3 Manual de usuario

Philips

Philips Brilliance 231P4QPY Manual de usuario

Philips

Philips 32HF9385D Guía de solución de problemas

Sharp

Sharp LC-40FI5012E Manual de usuario

Loewe

Loewe Table Stand Reference 55 Manual de usuario

Philips

Philips 32PFH5300 Manual de usuario

Sylvania

Sylvania 6427FB Manual de usuario
