Samsung CS15K2X/NWT Manual de usuario
COLOR TELEVISION RECEIVER
Chassis : KS1A
Model : CS15K2X/BWT,NWT,VWT
CS15K8WX/BWT,NWT,VWT
CS2073S/BWT,NWT,VWT
CS21F5X/BWT,NWT,VWT
CS2173S/BWT,NWT,VWT
CS21D8S/NWT,BWT,VWT
CS21S1S/NWT,BWT,VWT
COLOR TELEVISION RECEIVER CONTENTS
Precautions
Specifications and IC Data
Disassembly and Reassembly
Alignment and Adjustment
Troubleshooting
Exploded View and Parts List
Electrical Parts List
Block Diagram
Wiring Diagram
Schematic Diagrams
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
SAMSUNGSAMSUNG
SAMSUNGSAMSUNG
2007.04.27
QQ :376315150
手机:13942296513
ELECTRONICS
©Samsung Electronics Co., Ltd. APR. 2001
Printed in Korea
3KS1A-1502
Samsung Electronics 2-1
Specifications and IC Data
2. Specifications and IC Data
2-1 Specifications
Television System:
Channels:
Intermediate Frequencies (MHz) :
Picture Tube:
Power Requirements:
Antenna Input Impedance:
Speaker Impedance
NTSC - M
2 - 13
14-69
NTSC - M
38.90
34.40
35.32
PAL/SECAM-
B/G,I
2 - 12
21 - 69
PAL/
SECAM- B/G
38.90
33.40
34.47
System
Band
VHF
UHF
SYSTEM
IF Carrier Frequency
Picture IF Carrier
Sound IF Carrier
Color Sub Carrier
PAL,
SECAM- D/K
1 - 13
21 - 69
PAL/SECAM-D/K,
SECAM-K1
38.90
32.40
34.47
SECAM-K1,
PAL-D
2 - 9
13 - 57
PAL - I
38.90
32.90
34.47
MODEL
CI
CII
CX
CK
CW
CS
14 Inch
20 Inch
21 Inch
AC 100~240V, 50/60Hz
VHF, UHF : Telescopic dipole antenna (75 ohm unbalanced type )
8 ohm, 5W+5W (Dual Type)
16 ohm, 3W (Monitor Type & Dual Type)
SYSTEM
PAL-I (UHF)
PAL-I (VHF/UHF)
PAL-B/G, SECAM-B/G
PAL-B/G, D/K, SECAM-B/G, D/K
PAL-B/G, D/K, SECAM-B/G, D/K, NT 4.43
PAL-B/G, D/K, SECAM-B/G, D/K, NT4.43, NT3.58
A34KQV42X
A48KRD82X(H)
A51KQJ63X
Quick start, in-line-gun,
Black stripe, 90 degree deflection
2-2 Samsung Electronics
2-2 IC Line Up
Specifications and IC Data
Loc. No Specification Description Remark
HC101 PAP103 IF PRE-AMP
IC501 TDA6107Q RGB DRIVE AMP
Table 2-1 IC Line-Up
IC902 24C08/KS28C040 EEPROM
PC801S TCET1108 / LTV817B PHOTO COUPLER
SPM802ER TTX, English/Croatian/Romanian/Hungarian/Polish/Czech/
Bulgarian/Russian/Portugal
IC201S Philips
Philips
SPM802ERN W/O TTX, English/Croatian/Romanian/Hungarian/Polish/Czech/
Bulgarian/Russian/Portugal
VERTICAL OUTPUT
LA7840
TDA7266S
IC301
IC601 SOUND-AMP (3W x 1CH or 3W x 2CH or 5W x 2CH)
IC801S KA5Q0765R POWER IC (STR)
IC802 KA7632 CUSTOM REGULATOR (5V, 8V, 3.3V)
IC101 U4468B SIF - IC TEMIC
Sanyo
2-3 Semiconductor Base Diagrams
Specifications and IC Data
Samsung Electronics 2-3
ELECTROLYTIC-
CONDENSER IC
DIODE
SPM-802ERN(Pin 64)
SPM-802ER(Pin 64)
X24CO8P(Pin 8)
KS24C080(Pin 8)
U4468B(Pin 16)
IC TRANSISTOR
LA7840
TDA6107Q
KA7632
TRANSISTOR
TRANSISTOR
2SD1651
2SD1650
2SD2499
KSA614
BCEE B C
KSC815-Y
KSA539-Y
BC548
KTC9014
IC
UPC574J
or
KA33V
SAW-FILTER
E C B
KSR1012
KSR1010
KSR2010
KTD863-Y
KSC2331-Y
1
1
1
G3956M
K9260M
Fig. 2-1 Semiconductor Base Diagrams
2-4
MEMO
Alignment and Adjustments
Samsung Electronics 4-1
4. Alignment and Adjustments
4-1 Preadjustment
4-1-1 Factory Mode
1. Do not attempt these adjustments in the Video
Mode.
2. The Factory Mode adjustments are necessary
when either the EEPROM (IC902) or the CRT
is replaced.
3. Do not tamper with the “Adjustment” screen
of the Factory Mode menu. This screen is
intended only for factory use.
4-1-2 When EEPROM (IC902) Is Replaced
1. When IC902 is replaced all adjustment data
revert to initial values. It is necessary to
re-program this data.
2. After IC902 is replaced, warm up the TV for
10 seconds.
4-1-3 When CRT Is Replaced
1. Make the following adjustments AFTER set-
ting up after setting up purity and conver-
gence :
White Balance
Sub-Brightness
Vertical Center
Vertical Size
Horizontal Size
Fail Safe (This adjustment must be the last
step).
2. If the EEPROM or CRT is replaced, set PVA to
40 (factory mode) and set SC as follows.
14 inch : 0
20 inch : 9
21 inch : 9
4-2 Factory/Service Mode
4-2-1 Procedure for the “Adjustment” Mode
1. This mode uses the standard remote control.
The Service Mode is activated by entering the
following remote-control sequence :
(1) DISPLAY→FACTORY.
(2) STAND-BY→ DISPLAY→MENU→MUTE
→POWER ON.
2. The “SERVICE (FACTORY)” message will be
displayed. The Service Mode has four compo-
nents: ADJUST, OPTION and Reset.
3. Access the Adjustment Mode by pressing the
“VOLUME” keys ( Up or Down). The adjust-
ment parameters are listed in the accompany-
ing table, and selected by pressing the CHAN-
NEL keys (▲ ,▼).
4. Selection sequences for the all system:
DOWN or UP key:
SCT>SBT>BLR>BLB>RG>GG>BG>VSL>
VS>VA>HS>SC>SDL>STT>SSP>PDL>
NDL>PSR>NSR>AGC>VOL>LCO>TXP
5. The VOLUME keys increase or decrease the
adjustment values (stored in the
non-volatile memory) when Adjustment Mode
is cancelled.
6. Cancel the Adjustment Mode by re-pressing
the “FACTORY” or “Power OFF” keys.
4-2-2 Main Adjustment Parameter
NOTE : PVS,PVA, PHS, parameters must be aligned using the 50Hz vertical-field rates.
Alignment and Adjustments
4-2 Samsung Electronics
SCT Sub Contrast 0~23
SBT Sub Bright ness 0~23
BLR Black Level offset Blue 0~15
BLB Black Level offset Red 0~15
RG Red Gain 0~63
GG Green Gain 0~63
BG Blue Gain 0~63
VSL Vert ical Slope 0~63
VS Vert ical Shift 0~63
VA Vertical Amplitude 0~63
HS Horizontal Shift 0~63
SC S- Correct ion 0~63
CDL Cathode Drive Level 0~15
STT Sub Tint 0~7
SSP Sub Sharpness 0~7
PDL PAL Del ay 0~15
NDL NTSC Delay 0~15
PSR PAL Sub coloR 0~23
NSR NTSC Sub coloR 0~23
AGC Automatic Gain Control 0~63
VOL Volume pre setti ng 0~63
LCO SECAM-L Vision IF 0~1
TXP TTX Position 0~15
13
9
9
7
32
25(Fix)
31
19
38
40(Fix)
30
9
9
3
0
15(Fix)
10
2
5
23
10
0
9
OSD FUNCTION RANGE INITIAL DATA REMARK
Alignment and Adjustments
Samsung Electronics 4-3
4-2-3 Option Bytes
In the Service Mode, various can be selected via the Option Table. Example:
1
2
3
4
5
6
7
8
9
10
OptionTable:xx xx xx xx
LNA
SYSTEM
AUDIO
JACK
ZOOM
AUTOPOWER
SBL
2ndSIF
HOTELMODE
BKS
ON
CZ
MONO
RCA
NOR/ZOOM/16:9
ON
OFF
ON
OFF
ON
Alignment and Adjustments
4-4 Samsung Electronics
4-3 Other Adjustments
4-3-1 General
1. Usually, a color TV needs only slight touch-
up adjustment upon installation. Check the
basic characteristics such as height, horizontal
and vertical sync and focus.
2. The picture should have good black and white
details. There should be no objectionable
color shading; if color shading is present, per-
form the purity and convergence adjustments
described below.
3. Use the specified test equipment or its equiva-
lent.
4. Correct impedance matching is essential.
5. Avoid overload. Excessive signal from a sweep
generator might overload the front-end of the
TV. When inserting signal markers, do not
allow the marker generator to distort test
results.
6. Connect the TV only to an AC power source
with voltage and frequency as specified on the
backcover nameplate.
7. Do not attempt to connect or disconnect any
wires while the TV is turned on. Make sure
that the power cord is disconnected before
replacing any parts.
8. To protect against shock hazard, use an isola-
tion transformer.
4-3-2 Automatic Degaussing
A degaussing coil is mounted around the pic-
ture tube, so that external degaussing after
moving the TV should be unnecessary. But
the receiver must be properly degaussed upon
installation.
The degaussing coil operates for about 1 sec-
ond after the power is switched ON. If the set
has been moved or turned in a different direc-
tion, disconnect its AC power for at least 30
minutes.
If the chassis or parts of the cabinet become
magnetized, poor color purity will result. If
this happens, use an external degaussing coil.
Slowly move the degaussing coil around the
faceplate of the picture tube and the sides and
front of the receiver. Slowly withdraw the coil
to a distance of about 6 feet before removing
power.
4-2-4 RESET
The Reset Mode is used during factory inspection.
Function Reset:
1. Picture Custom
2. Auto Volume Off
3. Color System Auto (option)
4. Sound System D/K (option)
5. Blue Screen Off
6. Low Noise AMP Off (option)
7. Volume 10
8. CH. Skip Erased
9. CH. Lock Off
10. Timer Off
