Samsung SM-W627Y Manual de usuario

www.samsung.com

User Manual

English. 05/2017. Rev.1.2

SM-W620

SM-W627

SM-W627Y

Table of Contents

Basics

3 Read me first

4 Device overheating situations and

solutions

7 Package contents

8 Device layout

12 Battery

15 SIM or USIM card (mobile network-

enabled models)

17 Memory card (microSD card)

20 Turning the device on and off

21 Keyboard Cover

28 Controlling the touchscreen

31 Windows

39 Entering text

41 Screen capture

42 Device and data management

42 InstantGo (Modern standby)

43 Connecting to an external display

Applications

44 Installing or uninstalling apps

45 Air Command

48 Samsung Notes

52 Samsung Flow

54 Show Window

55 Camera

56 Book Settings

Settings

57 Windows Settings

59 BIOS (Setup utility)

Appendix

62 Troubleshooting

67 Windows recovery function

67 Removing the battery

Basics

Read me first

Please read this manual before using the device to ensure safe and proper use.

•

Descriptions are based on the device’s default settings.

•

Some content may differ from your device depending on the region, service provider,

model specifications, or device’s software.

•

Content (high quality content) that requires high CPU and RAM usage will affect the

overall performance of the device. Apps related to the content may not work properly

depending on the device’s specifications and the environment that it is used in.

•

Samsung is not liable for performance issues caused by apps supplied by providers other

than Samsung.

•

Samsung is not liable for performance issues or incompatibilities caused by edited

registry settings or modified operating system software. Attempting to customise the

operating system may cause the device or apps to work improperly.

•

Software, sound sources, wallpapers, images, and other media provided with this device

are licensed for limited use. Extracting and using these materials for commercial or other

purposes is an infringement of copyright laws. Users are entirely responsible for illegal

use of media.

•

You may incur additional charges for data services, such as uploading and downloading,

auto-syncing, or using location services depending on your data plan. For large data

transfers, it is recommended to use the Wi-Fi feature.

•

Default apps that come with the device are subject to updates and may no longer be

supported without prior notice. If you have questions about an app provided with

the device, contact a Samsung Service Centre. For user-installed apps, contact service

providers.

•

Modifying the device’s operating system or installing softwares from unofficial sources

may result in device malfunctions and data corruption or loss. These actions are violations

of your Samsung licence agreement and will void your warranty.

•

Depending on the region, you can view the regulatory information on the device. To

view the information, tap

→

Book Settings

→

Legal information

→

Regulatory

information

Basics

Instructional icons

Warning: situations that could cause injury to yourself or others

Caution: situations that could cause damage to your device or other equipment

Notice: notes, usage tips, or additional information

Device overheating situations and solutions

When the device heats up while charging the battery

While charging, the device and the charger may become hot. During wireless charging or fast

charging, the device may feel hotter to the touch. This does not affect the device’s lifespan

and is in the device’s normal range of operation. If the battery becomes too hot, the charger

may stop charging.

Do the following when the device heats up:

•

Disconnect the charger from the device and close any running apps. Wait for the

device to cool down and then begin charging the device again.

•

If the lower part of the device overheats, it could be because the connected USB

cable is damaged. Replace the damaged USB cable with a new Samsung-approved

one.

•

When using a wireless charger, do not place foreign materials, such as metal objects,

magnets, and magnetic stripe cards, between the device and the wireless charger.

The wireless charging or fast charging feature is only available on supported models.

Basics

When the device heats up during use

When you use features or apps that require more power or use them for extended periods,

your device may temporarily heat up due to increased battery consumption. Close any

running apps and do not use the device for a while.

The following are examples of situations in which the device may overheat. Depending on

the functions and apps you use, these examples may not apply to your model.

•

During the initial setup after purchase or when restoring data

•

When downloading large files

•

When using apps that require more power or using apps for extended periods

–

When playing high-quality games for extended periods

–

When recording videos for extended periods

–

When streaming videos while using the maximum brightness setting

–

When connecting to a TV

•

While multitasking (or, when running many apps in the background)

–

When using Multi window

–

When updating or installing apps while recording videos

–

When downloading large files during a video call

–

When recording videos while using a navigation app

•

When using large amount of data for syncing with the cloud, email, or other accounts

•

When using a navigation app in a car while the device is placed in direct sunlight

•

When using the mobile hotspot and tethering feature

•

When using the device in areas with weak signals or no reception

•

When charging the battery with a damaged USB cable

•

When the device’s multipurpose jack is damaged or exposed to foreign materials, such as

liquid, dust, metal powder, and pencil lead

•

When you are roaming

Basics

Do the following when the device heats up:

•

Keep the device updated with the latest software.

•

Conflicts between running apps may cause the device to heat up. Restart the device.

•

Deactivate the Wi-Fi, GPS, and Bluetooth features when not using them.

•

Close apps that increase battery consumption or that run in the background when

not in use.

•

Delete unnecessary files or unused apps.

•

Decrease the screen brightness.

•

If the device overheats or feels hot for a prolonged period, do not use it for a while. If

the device continues to overheat, contact a Samsung Service Centre.

Device limitations when the device overheats

When the device heats up, the features and performance may be limited or the device may

turn off to cool down. This feature is only available on supported models.

•

To lower the device’s temperature, the screen brightness and the performance speed will

be limited and battery charging will stop.

•

If the device overheats or feels hot for a prolonged period, turn off the device, and wait

until it cools down.

Precautions for operating environment

Your device may heat up due to the environment in the following conditions. Use caution to

avoid shortening the battery’s lifespan, damaging the device, or causing a fire.

•

Do not store your device in very cold or very hot temperatures.

•

Do not expose your device to direct sunlight for extended periods.

•

Do not use or store your device for extended periods in very hot areas, such as inside a

car in the summertime.

Basics

•

Do not place the device in any areas that may overheat, such as on an electric heating

mat.

•

Do not store your device near or in heaters, microwaves, hot cooking equipment, or high

pressure containers.

•

Never use a damaged charger or battery.

Package contents

Check the product box for the following items:

•

Device

•

Keyboard Cover

•

S Pen

•

S Pen holder

•

Quick start guide

•

The items supplied with the device and any available accessories may vary

depending on the region or service provider.

•

The supplied items are designed only for this device and may not be compatible

with other devices.

•

Appearances and specifications are subject to change without prior notice.

•

You can purchase additional accessories from your local Samsung retailer. Make

sure they are compatible with the device before purchase.

•

Use only Samsung-approved accessories. Using unapproved accessories may cause

the performance problems and malfunctions that are not covered by the warranty.

•

Availability of all accessories is subject to change depending entirely on

manufacturing companies. For more information about available accessories, refer

to the Samsung website.

Basics

Device layout

Device

Keyboard dock port

Touchscreen

Microphone

Front camera

Light sensor

Speaker

SIM card (mobile

network-enabled

models) / Memory

card tray

Headset jack

Multipurpose jack

(USB Type-C)

Volume key

Power key

Speaker

Main antenna

(mobile

network-enabled

models)

Basics

The device and the Keyboard Cover contain magnets. The American Heart Association

(US) and the Medicines and Healthcare Products Regulatory Agency (UK) both warn

that magnets can affect the operation of implanted pacemakers, cardioverters,

defibrillators, insulin pumps or other electro medical devices (collectively,“Medical

Device”) within the range of 15 cm (6 inches). If you are a user of any of these Medical

Devices, DO NOT USE THIS DEVICE AND THE KEYBOARD COVER UNLESS YOU HAVE

CONSULTED WITH YOUR PHYSICIAN.

Do not store your device and the Keyboard Cover near magnetic fields. Magnetic

stripe cards, including credit cards, phone cards, passbooks, and boarding passes,

may be damaged by magnetic fields.

•

Connectivity problems and battery drain may occur in the following situations:

–

If you attach metallic stickers on the antenna area of the device

–

If you attach a device cover made with metallic material to the device

–

If you cover the device’s antenna area with your hands or other objects while

using certain features, such as the mobile data connection

•

Using a Samsung-approved screen protector is recommended. Unapproved screen

protectors may cause the sensors to malfunction.

•

Do not allow water to contact the touchscreen. The touchscreen may malfunction

in humid conditions or when exposed to water.

Keys

Key Function

Power

•

Press and hold to turn the device on or off.

•

Press to turn on or lock the screen.

Volume

•

Press to adjust the device volume.

Basics

S Pen

S Pen button

S Pen clip

S Pen nib

Tweezers

Name Functions

S Pen nib

•

Use the S Pen to write, draw, or perform touch actions on the

screen.

•

Hover the S Pen over items on the screen to access additional

S Pen features.

S Pen button

•

Hover the S Pen over the screen and press the S Pen button to

display the air command features.

Tweezers

•

Remove the S Pen nib with the tweezers when replacing the nib.

The supplied S Pen is already calibrated. Do not calibrate the screen for pen input

randomly. Doing so may cause performance degradation or malfunction.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Tableta de Samsung

Samsung

Samsung GALAXY Tab SGH-I987ZKAATT Manual de usuario

Samsung

Samsung SCH-I915 Manual de usuario

Samsung

Samsung SM-T355Y Manual de usuario

Samsung

Samsung Galaxy Tab Active Manual de usuario

Samsung

Samsung NP-Q1EX Manual de usuario

Samsung

Samsung AT&T Galaxy Tab S9+ 5G Manual de usuario

Samsung

Samsung SM-T560 Manual de usuario

Samsung

Samsung Galaxy Tab S7 FE Manual de usuario

Samsung

Samsung Galaxy Tab S SM-T805 Manual de usuario

Samsung

Samsung Galaxy Note 10.1 2014 Edition Manual de usuario

Samsung

Samsung Galaxy Tab S2 Manual de usuario

Samsung

Samsung SM-T815C Manual de usuario

Samsung

Samsung GT-N8010 Manual de usuario

Samsung

Samsung Galaxy Tab S Manual de usuario

Samsung

Samsung SM-T705 Manual de usuario

Samsung

Samsung SM-T737 Manual de usuario

Samsung

Samsung GALAXY TAB GT-p6200 Manual de usuario

Samsung

Samsung GALAXY TAB Manual de usuario

Samsung

Samsung GALAXY TAB Manual de usuario

Samsung

Samsung Galaxy Tab S2 Hoja de especificaciones

Samsung

Samsung GALAXY Note 10.1 Manual rápido

Samsung

Samsung GT-P3100 Manual de usuario

Samsung

Samsung ATIV Smart PC Pro Manual de usuario

Samsung

Samsung SM-T900 Manual de usuario

Manuales populares de Tableta de otras marcas

Laser

Laser MID-1060 Guía del usuario

MUNBYN

MUNBYN IRT09J Guía de inicio rápido

Motorola

Motorola MC3090R - Win CE 5.0 Professional 520 MHz Manual de usuario

Dell

Dell Latitude ST Manual del propietario

Lenovo

Lenovo IdeaTab S6000L Manual del propietario

Venturer

Venturer WT9L11 Manual de usuario

EDUGEAR

EDUGEAR UnoBook Manual de usuario

Philips

Philips PI3210G/58 Manual de usuario

ADLINK Technology

ADLINK Technology IMT-BT Manual de usuario

TwinMOS

TwinMOS TwinTAB-T102D1 Manual de usuario

Archos

Archos 9.7 xenon Manual de usuario

Getac

Getac E100 Manual de usuario

HANNspree

HANNspree HANNspad SN70T3 Manual de usuario

Philips

Philips PI3105W2/55 Manual de usuario

LG LG-V935 Manual de usuario

Zeki

Zeki TBDB763B Manual de usuario

Ricoh

Ricoh eQuill Manual de usuario

DT Research

DT Research DT365CT Instrucciones de montaje
