User manual

SM-T707A

This device is capable of operating in 802.11a/n/ac mode. For 802.11a/n/ac devices operating

in the frequency range of 5.15 - 5.25 GHz, they are restricted for indoor operations to reduce

any potential harmful interference for Mobile Satellite Services (MSS) in the US. WIFI

Access Points that are capable of allowing your device to operate in 802.11a/n/ac mode (5.15

- 5.25 GHz band) are optimized for indoor use only. If your WIFI network is capable of

operating in this mode, please restrict your WIFI use indoors to not violate federal regulations

to protect Mobile Satellite Services.

Draft

DRAFT

Internal Use Only

Important safety precautions

Failure to comply with the following precautions may be dangerous or illegal.

●Bluetooth? is a registered trademark of the Bluetooth SIG, Inc. worldwide.

●JavaTM is a trademark or registered trademark of Sun Microsystems, Inc.

●Picsel and Picsel ViewerTM are trademarks of Picsel Technologies, Inc.

Drive safely at all times

Do not use a hand-held device while driving. Park your vehicle first.

Switch off the device when refuelling

Do not use the device at a refuelling point (service station) or near fuels or chemicals.

Switch off in an aircraft

Wireless devices can cause interference. Using them in an aircraft is both illegal and

dangerous.

Switch off the device near all medical equipment

Hospitals or health care facilities may be using equipment that could be sensitive to

external radio frequency energy.

Follow any regulations or rules in force.

Interference

All wireless devices may be subject to interference, which could affect their performance.

Be aware of special regulations

Meet any special regulations in force in any area and always switch off your device

whenever it is forbidden to use it, or when it may cause interference or danger.

Water resistance

Your device is not water-resistant. Keep it dry.

DRAFT

Internal Use Only

Sensible use

Use only in the normal position (held to your ear). Avoid unnecessary contact with the

antenna when the device is switched on.

Emergency calls

Key in the emergency number for your present location, then press [ ].

Keep your device away from small children

Keep the device and all its parts, including accessories, out of the reach of small children.

Accessories

Use only Samsung-approved accessories, such as headsets and PC data cables. Use of

any unauthorized accessories could damage you or your device and may be dangerous.

Qualified service

Only qualified service personnel may repair your device.

For more detailed safety information, see Health and safety information on page 20.

• The device could explode if the battery is replaced with an incorrect type.

• Dispose of used batteries according to the manufacturer’s instructions.

Excessive exposure to sound at high volumes can cause hearing damage.

Always turn the volume down before plugging the eardevices into an audio source

and use only the minimum volume setting necessary to hear your conversation or

music.

DRAFT

Internal Use Only

Unpack

Make sure you have each item

• Device

• Adapter

• Stereo headset

• User’s manual

Suitable Adapter or Charger, certified according to the relevant safety standard, will be provided

for each country in use.

You can obtain the following accessories for your device from your local Samsung dealer.

• Multi adapter

• Travel charger

• Car charger

• PC data cable

• Portable PC data cable

• Music controller

• Bluetooth mono/ stereo headset kit

Get started

First steps to operate your device

Install and charge the device

1. Install the battery:

To remove the battery, slide the battery catch toward the top of the device and hold it.

Plug the adapter into the device.

Plug the adapter into a standard AC wall outlet.

When the device is completely charged (the battery icon stops blinking), unplug the

adapter from the power outlet.

Remove the adapter from the device.

Low battery indicator

When the battery is low:

• a warning tone sounds,

• the battery low message displays, and

• the empty battery icon [ ] blinks.

If the battery level becomes too low, the device automatically turns off. Recharge your

battery.

DRAFT

Internal Use Only

Keys and display

Buttons Function

Power

• Press and hold to turn the device on or off.

• Press and hold for more than 7 seconds to reset the device if it

has fatal errors or hang-ups, or freezes.

• Press to lock or unlock the device. The device goes into lock

mode when the touch screen turns off.

• Tap to open a list of options available for the current screen.

• Tap and hold on the Home screen to launch Google

application.

Home

• Press to return to the Home screen.

• Press twice to launch S Voice application.

• Press and hold to open the list of recent applications.

Back • Tap to return to the previous screen.

Volume • Press to adjust the device volume.

DRAFT

Internal Use Only

Overview of menu functions

To access Menu mode, press [환경설정] in ldle mode.

Tservice ChatON Maps

Call log Samsung Link Local

Device Group Play Navigation

Contacts S Health Downloads

Messaging SVoice OpticalReader

Samsung Hub S Memo Messenger

Samsung Apps S Translator Play Books

WatchON Email PlayMovies&TV

Camera Shopping & wallet T nao

Gallery T cloud App Guide

Story Album hoppin T Membership

DMB MelOn RemoteCare

Tstore Chrome Tworld

TLTEPack Gmail 11st

Music Google SmartWallet

Video VoiceSearch NATE

Internet YouTube Calculator

Clock Talk VoiceRecorder

S Planner Google+ Dictionary

Settings PlayStore MyFiles

DRAFT

Internal Use Only

B tv mobile

Pickat

Basket

Cyworld

SmartTouch

Cymera

NateOnUC

Dropbox

Samsung service

V3 Mobile 2.0

Help

Google Settings

DRAFT

Internal Use Only

Solve problems

Help and personal needs

To save the time and expense of an unnecessary service call, perform the simple checks

in this section before contacting a service professional.

When you switch on your device, the following messages may appear:

“Insert USIM card”

• Be sure that the USIM card is correctly installed.

“Device locked Enter password”

• The automatic locking function has been enabled. You must enter the device’s

password before you can use the device.

“Enter PIN1”

• You are using your device for the first time. You must enter the PIN1 supplied with the

USIM card.

• The PIN1 Check feature is enabled. Every time the device is switched on, the PIN1 has

to be entered. To disable this feature, use the PIN check menu.

“Enter PUK”

• The PIN1 code has been entered incorrectly three times in succession, and the device

is now blocked. Enter the PUK1 supplied by your service provider.

“No Service” “Network Failure,” or “Not Done” displays

• The network connection has been lost. You may be in a weak signal area. Move and try

again.

• You are trying to access an option for which you have no subscription with your

service provider. Contact the service provider for further details.

You have entered a number but it was not dialed

• Be sure that you have pressed [ ].

• Be sure you have accessed the right cellular network.

• Be sure that you have not set an outgoing call barring option.

Your correspondent cannot reach you

• Be sure your device is switched on. ( [ ] pressed for more than one second.)

• Be sure you are accessing the correct cellular network.

• Be sure that you have not set an outgoing call barring option.

DRAFT

Internal Use Only

Your correspondent cannot hear you speaking

• Be sure you have switched off the microphone.

• Be sure you are holding the device close enough to your mouth. The microphone is

located at the bottom of the device.

The device starts beeping and LOW BATTERY flashes on the display

• Your battery is insufficiently charged. Recharge the battery.

The audio quality of the call is poor

• Check the signal strength indicator on the display ( ).

The number of bars indicates the signal strength from strong ( ) to weak ( ).

• Try moving the device slightly or moving closer to a window if you are in a building.

No number is dialed when you re-call a Contacts entry

• Use the Contact Search feature to ensure the number has been stored correctly.

• Re-store the number, if necessary.

If the above guidelines do not help you to solve the problem, take note of:

• The model and serial numbers of your device

•Your warranty details

•A clear description of the problem

Then contact your local dealer or Samsung after-sales service.

DRAFT

Internal Use Only

DRAFT

Internal Use Only

Specific Absorption Rate (SAR)

Certification Information

Your wireless mobile device is a radio transmitter and

receiver. It is designed and manufactured not to exceed

the exposure limits for Radio Frequency (RF) energy set

by the Federal Communications Commission (FCC) of

the U.S. Government.

These FCC RF exposure limits are derived from the

recommendations of two expert organizations: the

National Council on Radiation Protection and

Measurement (NCRP) and the Institute of Electrical and

Electronics Engineers (IEEE). In both cases, the

recommendations were developed by scientific and

engineering experts drawn from industry, government,

and academia after extensive reviews of the scientific

literature related to the biological effects of RF energy.

The RF exposure limit set by the FCC for wireless

mobile devices employs a unit of measurement known

as the Specific Absorption Rate (SAR). The SAR is a

measure of the rate of absorption of RF energy by the

human body expressed in units of watts per kilogram

(W/kg). The FCC requires wireless devices to comply

with a safety limit of 1.6 watts per kilogram (1.6 W/kg).
