1. Safety Precautions

1-1

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

1-1. Repair Precaution

Before attempting any repair or detailed tuning, shield the device from RF noise or static

electricity discharges.

Use only demagnetized tools that are specifically designed for small electronic repairs,

as most electronic parts are sensitive to electromagnetic forces.

Use only high quality screwdrivers when servicing products. Low quality screwdrivers can

easily damage the heads of screws.

Use only conductor wire of the properly gauge and insulation for low resistance, because of

the low margin of error of most testing equipment.

We recommend 22-gauge twisted copper wire.

Hand-soldering is not recommended, because printed circuit boards (PCBs) can be easily

damaged, even with relatively low heat. Never use asoldering iron with apower rating of

more than 100 watts and use only lead-free solder with a melting point below 250°C (482°F).

Prior to disassembling the battery charger for repair, ensure that the AC power is disconnected.

Always use the replacement parts that are registered in the SEC system. Third-party replac

ement parts may not function properly.

Safety Precautions

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

1-2

1-2. ESD(Electrostatically Sensitive Devices) Precaution

Many semiconductors and ESDs in electronic devices are particularly sensitive to static discha

rge and can be easily damaged by it. We recommend protecting these components with cond

uctive anti-static bags when you store or transport them.

Always use an anti-static strap or wristband and remove electrostatic buildup or dissipate

static electricity from your body before repairing ESDs.

Ensure that soldering irons have AC adapter with ground wires and that the ground wires are

properly connected.

Use only desoldering tools with plastic tips to prevent static discharge.

Properly shield the work environment from accidental electrostatic discharge before opening

packages containing ESDs.

The potential for static electricity discharge may be increased in low humidity environments,

such as air-conditioned rooms. Increase the airflow to the working area to decrease the

chance of accidental static electricity discharges.

2. Specification

2-1

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

2-1. GSM General Specification

GSM850 EGSM 900 DCS1800 PCS1900 WCDMA

2100 WCDMA

1900 WCDMA

900 WCMDA

850

Freq.

Band[MHz]

Uplink/

Downlink

824~849

869~894 880~915

925~960 1710~1785

1805~1880 1850~1910

1930~1990 1922~1977

2112~2167 1852~1907

1932~1987 880~915

925~960 824~849

869~894

ARFCN

range 128~251 0~124 &

975~1023 512~885 512~810 UL:

9612~9888

DL:

10562~10838

UL:

9262~9538

DL:

9662~9938

UL:

2712~2863

DL:

2937~3088

UL:

4132~4233

DL:

4357~4458

Tx/Rx

spacing 45MHz 45MHz 95MHz 80MHz 190MHz 80MHz 45MHz 45MHz

Mod. Bit

rate/

Bit Period

270.833kbps

3.692us 270.833kbps

3.692us 3.84Mcps 3.84Mcps 3.84Mcps 3.84Mcps

Time Slot

Period/

Frame

Period

576.9us

4.615ms 576.9us

4.615ms

FrameLength:

10ms

Slotlength:

0.667ms

FrameLength:

10ms

Slotlength:

0.667ms

FrameLength:

10ms

Slotlength:

0.667ms

FrameLength:

10ms

Slotlength:

0.667ms

Modulation 0.3GMSK 0.3GMSK 0.3GMSK 0.3GMSK QPSKHQPSK QPSKHQPSK QPSKHQPSK QPSKHQPSK

MS Power 33dBm~5dBm 33dBm~5dBm 30dBm~0dBm 30dBm~0dBm 24dBm~

-50dBm 24dBm~

-50dBm

Power

Class 5pcl ~19

pcl 5pcl ~19

pcl 0pcl ~15

pcl 3(max+24dBm) 3(max+24dBm) 3(max+24dBm) 3(max+24dBm)

Sensitivity -102dBm -102dBm -100dBm -100dBm -106.7dBm -106.7dBm -106.7dBm -106.7dBm

TDMA Mux 8 8 8 8 8888

Cell Radius 35Km 35Km 2Km 2Km 2Km 2Km 2Km 2Km

Specification

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

2-2

2-2. GSM Tx Power Class

TX Power

control

level

GSM850

533±2

dBm

631±2

dBm

729±2

dBm

827±2

dBm

925±2

dBm

10 23±2 dBm

11 21±2 dBm

12 19±2 dBm

13 17±2 dBm

14 15±2 dBm

15 13±2 dBm

16 11±3 dBm

17 9±3dBm

18 7±3 dBm

19 5±3 dBm

TX Power

control

level

EGSM900

533±2

dBm

631±2

dBm

729±2

dBm

827±2

dBm

925±2

dBm

10 23±2 dBm

11 21±2 dBm

12 19±2 dBm

13 17±2 dBm

14 15±2 dBm

15 13±2 dBm

16 11±3 dBm

17 9±3dBm

18 7±3 dBm

19 5±3 dBm

TX Power

control

level

DCS1800

030±3

dBm

128±3

dBm

226±3

dBm

324±3

dBm

422±3

dBm

520±3

dBm

618±3

dBm

716±3

dBm

814±3

dBm

912±4

dBm

10 10±4 dBm

11 8±4 dBm

12 6±4 dBm

13 4±4 dBm

14 2±5 dBm

15 0±5 dBm

TX Power

control

level

PCS1900

030±3

dBm

128±3

dBm

226±3

dBm

324±3

dBm

422±3

dBm

520±3

dBm

618±3

dBm

716±3

dBm

814±3

dBm

912±4

dBm

10 10±4 dBm

11 8±4 dBm

12 6±4 dBm

13 4±4 dBm

14 2±5 dBm

15 0±5 dBm

3. Operation Instruction and Installation

3-1

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Main Function

•Android OS: Jelly Bean

•Main 3MP FF, Sub 1.3FF

• 10.1" WXGA TFT Full Touch (C-Type)

•HSDPA 21.1Mbps /HSUPA 5.76Mbps

•A-GPS /GLONASS/ BT v4.0 +EDR with LE /USB v2.0 /Wi-Fi (802.11 a/b/g/n)/ OTG

•Recording definition: 720p

•Sensors: Accelation, Magnetic, ALS

•Additional :

-1.6

GHz Dual Core CPU

5. MAIN Electrical Parts List

5-1

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

SEC Code Design LOC Description

0403-001870 ZD5005,ZD7000 DIODE-ZENER

0404-001250 D7002 DIODE-SCHOTTKY

0404-001394 D7000 DIODE-SCHOTTKY

0404-001669 D8000 DIODE-SCHOTTKY

0406-001239 D5001 DIODE-TVS

0406-001267 ZD5000,ZD5001,ZD9001 DIODE-TVS

0406-001267 ZD9002,ZD9003,ZD9004 DIODE-TVS

0406-001267 ZD9005,ZD9006 DIODE-TVS

0406-001293 ZD7001,ZD7002 DIODE-TVS

0406-001390 ZD9000 DIODE-TVS

0406-001413 ZD3000,ZD3001,ZD3002 DIODE-TVS

0406-001413 ZD3003,ZD3004,ZD4000 DIODE-TVS

0406-001413 ZD4001,ZD4004,ZD4005 DIODE-TVS

0406-001413 ZD4007,ZD4008,ZD4009 DIODE-TVS

0406-001505 D4000,D4001,ZD4003 DIODE-TVS

0406-001505 ZD4006,ZD5003 DIODE-TVS

0406-001506 ZD5004 DIODE-TVS

0406-001561 ZD5002 DIODE-TVS

0406-001583 ZD5006 DIODE-TVS

0407-001002 D7001 DIODE-ARRAY

0504-001113 TR7001,TR7002 TR-DIGITAL

0504-001171 Q5001 TR-DIGITAL

0505-001995 Q7000 FET-SILICON

0505-002341 Q5000,Q5004,Q9000 FET-SILICON

0505-002384 Q100,Q4000 FET-SILICON

0505-002388 Q5003 FET-SILICON

0505-002720 Q5002 FET-SILICON

0801-003024 U4000 IC-CMOS LOGIC

0801-003079 U6012 IC-CMOS LOGIC

0801-003346 U6002 IC-CMOS LOGIC

0801-003435 U6015 IC-CMOS LOGIC

0801-003437 U3000,U5000,U7007 IC-CMOS LOGIC

0902-003015 UCP6001 IC-MICROPROCESSOR

0904-002738 U8004 IC-GRAPHIC CONT.

1001-001846 U4004 IC-ANALOG MULTIPLEX

1003-002391 U104 IC-LEVEL DRIVER

1006-001552 U6014 IC-BUS TRANSCEIVER

1009-001058 U103 IC-HALL EFFECT S/W

1105-002212 UME3000 IC-RDRAM

1105-002305 UCP6001UP IC-DDR2 SDRAM

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-2

1107-002239 UME6000 IC-FLASH MEMORY

1201-003400 PAM1000 IC-POWER AMP

1201-003579 U2001 IC-GPS AMP

1202-001123 U4002 IC-VOLTAGE COMP.

1203-002250 U5004,U5007 IC-VOL. DETECTOR

1203-004776 FPC7000,U5008 IC-POSI.FIXED REG.

1203-004818 U6010,U9000 IC-POSI.FIXED REG.

1203-004819 U9002 IC-POSI.FIXED REG.

1203-005512 U5006 IC-POSI.FIXED REG.

1203-005574 U105 IC-POSI.FIXED REG.

1203-005599 U8007 IC-DC/DC CONVERTER

1203-006044 U9004 IC-DC/DC CONVERTER

1203-006115 U9001 IC-POWER SUPERVISOR

1203-006766 U3001,U5001 IC-VOL. DETECTOR

1203-006768 U7001,U8005 IC-DC/DC CONVERTER

1203-006801 U1004 IC-DC/DC CONVERTER

1203-006817 U107 IC-POSI.FIXED REG.

1203-006872 U108 IC-MULTI REG.

1203-006874 U100,U8000 IC-MULTI REG.

1203-006920 U8006 IC-BACKLIGHT DRIVER

1203-007084 U7005 IC-RESET

1203-007142 U6000 IC-DC/DC CONVERTER

1203-007333 U1002 IC-DC/DC CONVERTER

1203-007623 U7003 IC-BATTERY

1203-007702 U8001 IC-DC/DC CONVERTER

1203-007791 U4001,U6016 IC-POSI.FIXED REG.

1203-007842 U8002 IC-POSI.FIXED REG.

1203-007909 U7002 IC-POWER SUPERVISOR

1203-007951 U5005 IC-POWER SUPERVISOR

1204-003387 U109 IC-REMOTE CONTROL

1205-003692 U9006 IC-EXPANDER

1205-004233 U106 IC-TRANSMITTER

1205-004511 UCP3000 IC-MODEM

1205-004513 U5002 IC-SWITCH

1205-004515 U1001 IC-TRANSCEIVER

1205-004548 U8003 IC-TRANSMITTER

1205-004598 U2003 IC-WIFI

1205-004649 U2002 IC-GPS RECEIVER

1205-004803 U9003 IC-COMM. CONTROLLER

1205-004804 U4003 IC-CODEC

1209-002142 U102 IC-SENSOR

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-3

1209-002153 U101 IC-SENSOR

1209-002221 U1007 IC-SENSOR

1404-001694 TH7001,TH7002 THERMISTOR-NTC

1404-001726 V1000 THERMISTOR-NTC

1404-001728 TH3000 THERMISTOR-NTC

2007-000141 R6088 R-CHIP

2007-000143 R123,R124 R-CHIP

2007-000162 R5010,R5030 R-CHIP

2007-000163 R8009 R-CHIP

2007-000169 R1003 R-CHIP

2007-000170 R8004 R-CHIP

2007-001217 R104,R105,R106,R107 R-CHIP

2007-001217 R109,R110,R111,R112 R-CHIP

2007-001217 R113,R114,R115,R116 R-CHIP

2007-001217 R117,R118,R119,R120 R-CHIP

2007-002796 R7000 R-CHIP

2007-002970 R6016,R6103,R6105 R-CHIP

2007-003010 R1007 R-CHIP

2007-003015 R5025,R5027,R5038 R-CHIP

2007-007107 R3007 R-CHIP

2007-007131 R9014 R-CHIP

2007-007137 R4002 R-CHIP

2007-007142 R5023,R9023 R-CHIP

2007-007307 R6018,R6019 R-CHIP

2007-007318 R1017 R-CHIP

2007-007489 R8001 R-CHIP

2007-007538 R6060 R-CHIP

2007-007590 R9011 R-CHIP

2007-007627 R8011 R-CHIP

2007-0077419 R127,R128,R5013 R-CHIP

2007-007741 R5018,R7020,R7029 R-CHIP

2007-007741 R7031,R7032,R7033 R-CHIP

2007-007741 R9000,R9001,R9002 R-CHIP

2007-007942 R4016,R4017,R4024 R-CHIP

2007-007942 R4027,R4028 R-CHIP

2007-007943 R4025,R4026 R-CHIP

2007-007981 R8000,R9020 R-CHIP

2007-008045 R3005,R4018,R5000 R-CHIP

2007-008045 R5006,R5041,R6021 R-CHIP

2007-008045 R6077,R6109,R7040 R-CHIP

2007-008045 R7041,R9004 R-CHIP

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-4

2007-008048 R131,R132,R2015 R-CHIP

2007-008052 R125,R133,R134,R3009 R-CHIP

2007-008052 R5014,R6011,R6012 R-CHIP

2007-008052 R6033,R6034,R6107 R-CHIP

2007-008052 R6108 R-CHIP

2007-008055 R3030,R5022,R5043 R-CHIP

2007-008055 R6026,R6058,R6080 R-CHIP

2007-008055 R7036,R7043,R8010 R-CHIP

2007-008055 R9022,R9024,R9025 R-CHIP

2007-0080579 R6104 R-CHIP

2007-008137 R7002,R7003 R-CHIP

2007-008210 R9021 R-CHIP

2007-008298 R6051,R6094 R-CHIP

2007-008312 R4023 R-CHIP

2007-008354 R6055,R8014 R-CHIP

2007-008403 R5044 R-CHIP

2007-008419 R5004,R5007,R5042 R-CHIP

2007-008420 R5028 R-CHIP

2007-008483 R9015,R9016,R9018 R-CHIP

2007-008483 R9019 R-CHIP

2007-008486 R100,R5021 R-CHIP

2007-008516 R121,R126,R2000 R-CHIP

2007-008516 R2002,R2003,R2023 R-CHIP

2007-008516 R2024,R3025,R4011 R-CHIP

2007-008516 R4012,R5001,R5003 R-CHIP

2007-008516 R5008,R5037,R6000 R-CHIP

2007-008516 R6005,R6006,R6007 R-CHIP

2007-008516 R6036,R6038,R7004 R-CHIP

2007-008516 R7025,R9007,R9017 R-CHIP

2007-008531 R1008,R6048 R-CHIP

2007-008588 R1015,R3012,R3013 R-CHIP

2007-008588 R3014,R4004 R-CHIP

2007-008697 R6047 R-CHIP

2007-008721 R7017,R8013 R-CHIP

2007-008774 R9003 R-CHIP

2007-008800 R5005 R-CHIP

2007-008806 R4000,R4019 R-CHIP

2007-008812 R7022 R-CHIP

2007-009084 R108,R122,R4009 R-CHIP

2007-009084 R4010,R5016,R5031 R-CHIP

2007-009084 R5040,R7014,R8003 R-CHIP

Main Electrical Parts List

Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited.

Confidential and proprietary-the contents in this service guide subject to change without prior notice.

5-5

2007-009111 R6027 R-CHIP

2007-009155 R3006,R3010,R3031 R-CHIP

2007-009155 R5011 R-CHIP

2007-009158 R129,R130 R-CHIP

2007-009168 R8012 R-CHIP

2007-009171 R2007,R2008,R2009 R-CHIP

2007-009171 R2010,R2011,R6039 R-CHIP

2007-009171 R6040,R6041,R6042 R-CHIP

2007-009171 R6043,R6044,R6045 R-CHIP

2007-009171 R6046 R-CHIP

2007-009182 R6086 R-CHIP

2007-009199 R6031 R-CHIP

2007-009208 R4021,R4022 R-CHIP

2007-009212 R4001,R6052,R6053 R-CHIP

2007-009314 R6025 R-CHIP

2007-009315 R3002,R3008 R-CHIP

2007-009323 R7030 R-CHIP

2007-009361 R1001 R-CHIP

2007-009408 R6008,R6009,R6010 R-CHIP

2007-009793 R5009 R-CHIP

2007-009801 R1005,R1006 R-CHIP

2007-009805 R6030 R-CHIP

2007-009920 R6057,R6059 R-CHIP

2007-009954 R7011 R-CHIP

2007-010233 R3016 R-CHIP

2007-010856 R5012 R-CHIP

2203-000233 C1017,C2065 C-CER,CHIP

2203-000254 C1037,C2013,C8014 C-CER,CHIP

2203-000254 C8020,C9044 C-CER,CHIP

2203-000278 C6096,C7061 C-CER,CHIP

2203-000359 C8030 C-CER,CHIP

2203-000386 C134,C135 C-CER,CHIP

2203-000425 C4014,C4015,C4016 C-CER,CHIP

2203-000425 C4017 C-CER,CHIP

2203-000438 C7031 C-CER,CHIP

2203-000489 C8024 C-CER,CHIP

2203-000627 C8006 C-CER,CHIP

2203-000725 C5040 C-CER,CHIP

2203-001239 C4018,C4019 C-CER,CHIP

2203-001383 C1019 C-CER,CHIP

2203-001437 C1020 C-CER,CHIP

Otros manuales para GT-P5200

Tabla de contenidos

Otros manuales de Tableta de Samsung

Samsung

Samsung GT-P5220 Manual de usuario

Samsung

Samsung XE700T1C-N Manual de usuario

Samsung

Samsung GT-P7320 Manual de usuario

Samsung

Samsung SM-T365M Manual de usuario

Samsung

Samsung SM-T560 Manual de usuario

Samsung

Samsung Galaxy Tab GT-P6210 Manual de usuario

Samsung

Samsung Galaxy Tab SGH-T849 Guía del usuario

Samsung

Samsung GALAXY TAB Manual de usuario

Samsung

Samsung TAB E Manual de usuario

Samsung

Samsung Galaxy Tab A Manual de usuario

Samsung

Samsung GT-P3100 Manual de usuario

Samsung

Samsung Galaxy Note Manual de usuario

Samsung

Samsung SM-T805M Manual de usuario

Samsung

Samsung Galaxy Tab S Manual de usuario

Samsung

Samsung Galaxy Tab S7 5G Manual de usuario

Samsung

Samsung Galaxy Tab S4 Manual de usuario

Samsung

Samsung SM-T805W Manual de usuario

Samsung

Samsung SM-T800 Manual de usuario

Samsung

Samsung SCH-I705 Manual de usuario

Samsung

Samsung SM-T500 Manual de usuario

Samsung

Samsung SHW-M185S Manual de usuario

Samsung

Samsung GalaxyTab 10.1N GT-P7511 Manual de usuario

Samsung

Samsung GALAXY Tab Pro Manual de usuario

Samsung

Samsung Galaxy Tab S2 Manual de funcionamiento

Manuales populares de Tableta de otras marcas

Laser

Laser MID-1060 Guía del usuario

MUNBYN

MUNBYN IRT09J Guía de inicio rápido

Motorola

Motorola MC3090R - Win CE 5.0 Professional 520 MHz Manual de usuario

Dell

Dell Latitude ST Manual del propietario

Lenovo

Lenovo IdeaTab S6000L Manual del propietario

Venturer

Venturer WT9L11 Manual de usuario

EDUGEAR

EDUGEAR UnoBook Manual de usuario

Philips

Philips PI3210G/58 Manual de usuario

ADLINK Technology

ADLINK Technology IMT-BT Manual de usuario

TwinMOS

TwinMOS TwinTAB-T102D1 Manual de usuario

Archos

Archos 9.7 xenon Manual de usuario

Getac

Getac E100 Manual de usuario

HANNspree

HANNspree HANNspad SN70T3 Manual de usuario

Philips

Philips PI3105W2/55 Manual de usuario

LG LG-V935 Manual de usuario

Zeki

Zeki TBDB763B Manual de usuario

Ricoh

Ricoh eQuill Manual de usuario

DT Research

DT Research DT365CT Instrucciones de montaje
