Samsung NX58F5700WS Manual de usuario

Free-Standing Gas

Range

user manual

imagine the possibilities

Thank you for purchasing this Samsung product.

To receive more complete service, please register

your product at

www.samsung.com/register

1-800-SAMSUNG (726-7864)

NX58F5700WS

This manual is made with 100 % recycled paper.

ENGLISH

130603_(IB)NX58F5700WS_AA_DG68-00517A_EN+CFR.indb 1 03/06/2013 20:48:03

2_ features of your new range

features of your new

range

Enhanced convenience. Better cooking. Easy maintenance. Your new gas

range has been designed to bring you these beneﬁts and more.

• Bigger is better

With a capacity of 5.8 cubic feet, your new range has more space than

many other leading brands in the United States and Canadian markets.

This means greater convenience for you when cooking for the holidays or

when entertaining.

• A cooktop with 5 burners

Power burners, simmer burners, as well as a center oval burner provide

ﬂexible cooktop heat for a variety of cookware.

The center oval burner provides even heating over large areas, so it is

perfect for griddle cooking.

130603_(IB)NX58F5700WS_AA_DG68-00517A_EN+CFR.indb 2 03/06/2013 20:48:03

important safety instructions _3

IMPORTANT SAFETY INSTRUCTIONS

important safety

instructions

READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE

All electrical and gas equipment with moving parts can be dangerous. Please read the

important safety instructions for this appliance in this manual. The instructions must be

followed to minimize the risk of injury, death, or property damage.

Save this manual. Please Do Not Discard.

SAFETY SYMBOLS

What the icons and signs in this user manual mean:

WARNING

Means that death or serious personal injury is a risk.

CAUTION

Means that there is a potential risk for personal injury or

property damage.

CAUTION

To reduce the risk of ﬁre, explosion, electric shock, or

personal injury when using your gas range, follow these basic

safety precautions:

Do NOT attempt.

Do NOT disassemble.

Do NOT touch.

Follow directions explicitly.

Unplug the power cord from the electrical outlet.

Make sure the range is plugged into an earth grounded

electrical outlet to prevent electric shock. An outlet equipped

with a Ground Fault Interrupter (GFI) is highly recommended.

Call the service center for help. see page 82.

Note

These warning icons are here to prevent injury to you and others.

Please observe them explicitly.

Do not discard this manual. Please keep it in a safe place for future reference.

130603_(IB)NX58F5700WS_AA_DG68-00517A_EN+CFR.indb 3 03/06/2013 20:48:04

4_ important safety instructions

WARNING: If the information in this manual is not followed

exactly, a ﬁre or explosion may result causing property

damage, personal injury or death.

– DO NOT store or use gasoline or other ﬂammable vapors

and liquids in the vicinity of this or any other appliance.

– WHAT TO DO IF YOU SMELL GAS:

• DO NOT try to light any appliance.

• DO NOT touch any electrical switch.

• DO NOT use any phone in your building.

• Immediately call your gas supplier from a neighbor’s

phone. Follow the gas supplier’s instructions.

• If you cannot reach your gas supplier, call the ﬁre

department.

– Installation and service must be performed by a qualiﬁed

installer, service agency, or the gas supplier.

ANTI-TIP DEVICE

WARNING WARNING

Tip-Over Hazard

• A child or adult can tip the range and be killed.

• Install anti-tip device to range and/or structure

per installation instructions.

• Engage the range to the anti-tip device installed

to the structure.

• Re-engage anti-tip device if range is moved.

• Failure to follow these instructions can result in

death or serious burns to children or adults.

130603_(IB)NX58F5700WS_AA_DG68-00517A_EN+CFR.indb 4 03/06/2013 20:48:04

important safety instructions _5

IMPORTANT SAFETY INSTRUCTIONS

To prevent accidental tipping of the range, attach an approved anti-tip device

to the ﬂoor. (See Installing the Anti-Tip Device in the Installation Instructions.)

Check for proper installation by carefully tipping the range forward. The anti-tip

device should engage and prevent the range from tipping over.

If the range is pulled out away from the wall for any reason, make sure the anti-

tip device is reengaged after the range has been pushed back into place.

Follow the installation instructions found in the Installation Manual. Failure to

follow these instructions can result in death, serious personal injury, and / or

property damage.

DO NOT step / sit / lean on the door or drawer to prevent accidental tipping of

the range.

IMPORTANT SAFETY

PRECAUTIONS

WARNING

Follow basic precautions when installing and using this range to reduce the risk

of ﬁre, electrical shock, injury, or death to persons, including:

Installation and Service

This range must be properly located and installed in accordance with the

installation instructions before it is used.

Professional installation is strongly recommended.

Due to the size and weight of the range, it is highly recommended that two or

more people move or install this appliance.

All ranges can tip over and cause severe injuries. Install the anti-tip device

packed with this range following the instructions found in the Installation

Instructions.

Never try to repair or replace this appliance on your own unless it is speciﬁcally

recommended in this manual. This appliance should be serviced only by a

qualiﬁed service technician.

Know the location of the gas shut-o valve and how to shut it o if necessary.

Properly remove or destroy the packaging materials after the appliance is

unpacked.

Electrical/Mechanical

Unplug or disconnect power before servicing.

Do not tamper with the controls.

Grates and griddles (if equipped) are heavy. They can be dangerous if dropped.

The inner portion of the split oven rack (if equipped) could drop down

accidentally if not assembled properly. Place the inner rack in the proper

position within the outer rack.

Always position the oven racks at the same level on each cavity side. Uneven

racks could cause food to slide to the lower side, posing a risk of burns.

130603_(IB)NX58F5700WS_AA_DG68-00517A_EN+CFR.indb 5 03/06/2013 20:48:04

6_ important safety instructions

Danger to Children

Do not store any object of interest to children on the cooktop or backguard

of the range. Children climbing on the range to reach items could be killed or

seriously injured.

The inner rack of the Split Rack can be dropped if it is not assembled properly.

Place the Inner rack in the proper place on the Outer rack. Always insert the

rack or split rack assembly (if equipped) on the same level of the oven cavity

side.

Keep children away from the door when opening or closing it as they may

bump themselves on the door or catch their ﬁngers in the door.

Keep all packaging materials out of reach of children. Children may play with

them. Failure to dispose of plastic bags could result in suocation.

Do not leave children alone or unattended in an area where a range is in use.

They should never be allowed to sit or stand on any part of a range.

Do not let little children touch the range.

The cooktop grates and griddle (if equipped) are heavy and presents a risk of

injury if dropped on a foot. Teach children not to touch or play with grates or

griddle.

Teach children not to touch or play with the controls or any part of the range.

We recommend you utilize the control / door lockout feature to reduce the risk

of mis-use by children.

Before disposing of the range, cut o the power cord to prevent it from being

connected to a power source. Remove the door to prevent children and

animals from getting trapped.

Fire

Do not touch oven burners, drawer burners, or interior surfaces of the oven

during or immediately after cooking. Cooking surfaces, grates, cooktop burners

and caps, as well as oven walls may be hot even though they are dark in color.

Interior oven surfaces can become hot enough to cause burns. During and

after use, do not touch or let clothing or other ﬂammable materials contact

oven burners, drawer burners, or interior surfaces of the oven until they have

had sucient time to cool.

Do not let a pot holder touch a hot heating element. Do not use a towel or

other bulky cloth as a pot holder.

Do not use your range to heat unopened food containers or to dry wet items or

clothing.

Keep oven vent ducts unobstructed. Clean vents frequently to avoid grease

buildup. See page 59. There can be slight popping sound during oven cooking.

This sound may occur during the normal oven burner cycling, when the oven

burner ﬂame is extinguished.

130603_(IB)NX58F5700WS_AA_DG68-00517A_EN+CFR.indb 6 03/06/2013 20:48:05

important safety instructions _7

IMPORTANT SAFETY INSTRUCTIONS

Never use your range for any purposes but cooking. Doing so could result in

carbon monoxide poisoning and/or overheating of the oven.

Do not wear loose-ﬁtting or hanging garments while using this appliance.

DO NOT STORE OR USE combustible materials, gasoline, or other ﬂammable

vapors or liquids in the vicinity of this appliance. See “WHAT TO DO IF YOU

SMELL GAS” under the Gas Warnings.

Do not pour water into the cooktop well while cleaning the cooktop. This could

leak down into the range gas and electrical systems creating a risk of electrical

shock or high levels of Carbon Monoxide, due to corrosion of the gas valves or

ports.

Do not use water on a grease ﬁre. Water might cause a grease ﬁre to explode,

spreading the ﬁre and creating a larger ﬁre and health hazard. To put out a

grease ﬁre, turn o the heat source and smother the ﬁre with tight-ﬁtting lid or

use a multipurpose dry chemical or foam-type ﬁre extinguisher.

Never leave surface units unattended at high heat settings. Boilovers cause

smoke, and greasy spillovers could ignite.

Do not use a ﬂame to check for gas leaks. Instead, use a brush to spread a

soapy water mixture around the area you are checking. If there is a gas leak,

you will see small bubbles in the soapy water mixture at the point of the leak.

Do not place portable appliances, or any other object other than cookware on

the cooktop. Damage or ﬁre could occur if the cooktop is hot.

Do not attempt to operate this appliance if it is damaged, malfunctioning, or

has missing or broken parts.

Never place plastic, paper, or other items that could melt or burn near the oven

vents or any of the surface burners.

If the self-clean mode malfunctions, turn the oven o and disconnect the power

supply. Refer to pages 82 to contact a qualiﬁed service technician.

There can be slight popping sound during oven cooking.

Steam and Vapors

Use care when opening the oven door. Let hot air or steam escape before

removing or placing food in a hot oven.

Use only dry pot holders. Putting moist or damp pot holders on hot surfaces

may result in burns from steam.

130603_(IB)NX58F5700WS_AA_DG68-00517A_EN+CFR.indb 7 03/06/2013 20:48:05

8_ important safety instructions

Surface Burner Warnings

– The burner spreader can be blocked by food or dust. Clean the spreader

if it appears blocked. If you clean the spreader with water, assemble it only

after it is completely dry. If the spreader is wet, it might prevent the burners

from igniting.

– Do not pour water on the cooktop for cleaning. It can get inside the range

and cause the parts inside to rust.

– Only ignite the cooktop burners with the burner caps in place. If the

burner caps are not in place, you can damage the controls or cause an

unintended large or dangerous ﬂame.

– Heating of beverages can result in delayed eruptive boiling. To prevent

delayed eruptive boiling, ALWAYS allow heated beverages to stand at least

20 seconds after you have turned the burner o so that the temperature

in the liquid can stabilize. In the event of scalding, follow these FIRST AID

instructions:

• Immerse the scalded area in cold water for at least 10 minutes

• Cover with clean, dry dressing

• Do not apply any creams, oils or lotions

– After turning on a surface burner, check to make sure that the burner has

ignited. Adjust the level of the ﬂame by turning the burner knob.

– When you set a burner to simmer, do not turn the burner knob quickly.

Watch the ﬂame to make sure it stays on.

130603_(IB)NX58F5700WS_AA_DG68-00517A_EN+CFR.indb 8 03/06/2013 20:48:05

important safety instructions _9

IMPORTANT SAFETY INSTRUCTIONS

GAS WARNINGS

WARNING

If the instructions in this manual are not followed exactly, a ﬁre or explosion

may result, causing death, personal injury, or property damage.

If you smell gas:

1. Close the valve and do not use the range.

2. DO NOT light a match, candle, or cigarette.

3. DO NOT turn on any gas or electric appliances.

4. DO NOT touch any electrical switches or plug a power cord into an outlet.

5. DO NOT use any phone in your building.

6. Clear the room, building, or area of all occupants.

7. Immediately call your gas supplier from a neighbor’s phone. Follow the gas

supplier’s instructions.

8. If you cannot reach your gas supplier, call the ﬁre department.

Read instructions completely and carefully.

Installation of this range must conform with local codes or, in the absence of

local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA.54, latest

edition. In Canada, installation must conform with the current Natural Gas

Installation Code, CAN/CGA-B149.1, or the current Propane Installation Code,

CAN/CGA-B149.2, and with local codes where applicable. This range has

been design-certiﬁed by ETL according to ANSI Z21.1, latest edition, and

Canadian Gas Association according to CAN/CGA-1.1, latest edition.

Do not install this range in a place which is exposed to a strong draft.

Installation and service must be performed by a qualiﬁed installer, service

agency, or gas supplier.

Have the installer show you the location of the gas shut-o valve and how to

shut it o.

Always use NEW ﬂexible connectors when installing a gas appliance. Never

reuse old ﬂexible connectors. The use of old ﬂexible connectors can cause gas

leaks and personal injury.

Never use this appliance as a space heater to heat or warm the room. Doing

so may result in carbon monoxide poisoning and overheating of the oven.

Never block the oven vents (air openings). They provide the air inlet and

exhaust that are necessary for the oven to operate properly with correct

combustion.

130603_(IB)NX58F5700WS_AA_DG68-00517A_EN+CFR.indb 9 03/06/2013 20:48:05

10_ important safety instructions

STATE OF CALIFORNIA

PROPOSITION 65 WARNINGS

The California Safe Drinking Water and Toxic Enforcement Act requires the

Governor of California to publish a list of substances known to the state to

cause birth defects or other reproductive harm and requires businesses to

warn customers of potential exposure to such substances.

WARNING

Gas appliances can cause minor exposure to three of these substances,

namely, carbon monoxide, formaldehyde, and soot, caused primarily by the

incomplete combustion of natural gas or LP fuels. Properly adjusted burners,

indicated by a bluish rather than yellow ﬂame, will minimize incomplete

combustion. Exposure to these substances can be minimized by venting with

an open window or by using a ventilation fan or hood.

IN THE COMMONWEALTH OF

MASSACHUSETTS

This product must be installed by a licensed plumber or gas ﬁtter qualiﬁed or

licensed by the State of Massachusetts.

When using ball-type gas shut-o valves, you must use the T-handle type.

Multiple ﬂexible gas lines must not be connected in series.

130603_(IB)NX58F5700WS_AA_DG68-00517A_EN+CFR.indb 10 03/06/2013 20:48:05

Otros manuales para NX58F5700WS

Tabla de contenidos

Idiomas:

Otros manuales de Rango de Samsung

Samsung

Samsung FTQ307NWGX Manual de usuario

Samsung

Samsung NE63 851 Series Manual de usuario

Samsung

Samsung NE58K9852 Series Manual de usuario

Samsung

Samsung NX60T8311SG Manual de usuario

Samsung

Samsung NX58 560 Series Manual de usuario

Samsung

Samsung NE594R0ABBB/AA Manual de usuario

Samsung

Samsung NX58F5500SS Manual de usuario

Samsung

Samsung NSI6D 95 Series Manual de usuario

Samsung

Samsung NE59M7630 Series Manual de usuario

Samsung

Samsung NX60BG8315SSAA Manual de usuario

Samsung

Samsung NX60 63 Series Manual de usuario

Samsung

Samsung NX58M5600S Series Manual de usuario

Samsung

Samsung NX58F5700WS Manual de usuario

Samsung

Samsung NY63T8751SS Manual de usuario

Samsung

Samsung NE58F9500SS Manual de usuario

Samsung

Samsung NE59M9430 Series Manual de usuario

Samsung

Samsung NX58H5600S series Manual de usuario

Samsung

Samsung NX60 65 S Series Manual de usuario

Samsung

Samsung NE595R0ABWW Manual de usuario

Samsung

Samsung NE58F9500SS Manual de usuario

Samsung

Samsung NE63A6111SW Manual de usuario

Samsung

Samsung NE63 675 Series Manual de usuario

Samsung

Samsung NX58F5500SS Manual de usuario

Samsung

Samsung FE-R300SX Manual de usuario

Manuales populares de Rango de otras marcas

Kenmore

Kenmore 790.45712 Manual de usuario

Wolf

Wolf CHR CHSSR Manual de usuario

Smeg

Smeg Built-in Microwave Oven Manual de instrucciones

Zanussi

Zanussi ZCG054G Manual de usuario

Whirlpool

Whirlpool 8575985-W Manual de lista de piezas

Frigidaire

Frigidaire 316000635 Manual de usuario

GE JCSS630 Manual de usuario

Hotpoint

Hotpoint RB524R Guía de instalación

Whirlpool

Whirlpool Roper FGP305KW3 Manual de usuario

Amana

Amana ART6610 SERIES Manual de usuario

Maytag

Maytag MERH770WB Manual de usuario

Fulgor Milano

Fulgor Milano SOFIA Manual de usuario

Premier

Premier EF-4358GH Manual de usuario

Kenmore

Kenmore 790.9010 Series Manual de usuario

KitchenAid

KitchenAid KESC300 Manual de usuario

Frigidaire

Frigidaire FFEF3012LS Guía del usuario

Diamond

Diamond G65/2F4T Manual de usuario

LG LRE3091 Manual de usuario
