Samsung NE59J7850WS Manual de usuario

Please be advised that the Samsung warranty does NOT cover service calls to explain product

operation, correct improper installation, or perform normal cleaning or maintenance.

QUESTIONS OR COMMENTS

COUNTRY CALL OR VISIT US ONLINE AT

CANADA 1-800-SAMSUNG (726-7864)

www.samsung.com/ca/support (English)

www.samsung.com/ca_fr/support

(French)

U.S.A

Consumer

Electronics

1-800-SAMSUNG (726-7864) www.samsung.com/us/support

U.S.A

Mobile Phones 1-800-SAMSUNG (726-7864) www.samsung.com/us/support

DG68-00600A-00

Scan the QR code* or visit

www.samsung.com/spsn

to view our helpful

How-to Videos and Live Shows

*Requires reader to be installed on your

smartphone

NE59J7850WS_AA_DG68-XXXXXX_EN.indd 84 2015-01-21  11:24:00

Electric Range

NE59J7850**/NE59J7750**

User manual

NE59J7850WS_AA_DG68-XXXXXX_EN.indd 1 2015-01-21  11:24:00

English

WARNING

To reduce the risk of tipping the range, the range must be secured by a

properly installed Anti-Tip device. AFTER THE RANGE HAS BEEN INSTALLED,

CONFIRM THAT THE ANTI-TIP DEVICE HAS BEEN PROPERLY INSTALLED AND

VERIFY THAT THE ANTITIP DEVICE IS PROPERLY ENGAGED. Refer to the

installation manual for instructions.

a) If the anti-tip device is not installed, a child or adult can tip the range and

be killed.

b) Verify that the anti-tip device has been properly installed and engaged at

the rear right (or rear left) of the range bottom.

c) If you move the range and then move it back into place, ensure the antitip

device is re-engaged at the right or left rear of the range bottom.

d) Do not operate the range without the anti-tip device in place and engaged.

e) Failure to do so can result in death or serious burns to children or adults.

WARNING

Do not step, lean, or sit on the doors of the range. You can cause the

range to tip, resulting in burns or serious injuries.

Confirm that the Anti-Tip device is installed properly. Then, to verify that

the Anti-Tip device is engaged, grasp the top rear edge of the range and

carefully attempt to tilt it forward. The Anti-Tip device should prevent

the range from tilting forward more than a few inches.

If you pull the range out from the wall for any reason, make sure the

antitip device is properly engaged when you push the range back

against the wall. If it is not, there is a risk of the range tipping over and

causing injury if you or a child stand, sit, or lean on the open door.

Never completely remove the leveling legs. If you remove the leveling

legs, the range will not be secured to the anti-tip device properly.

Anti-tip device

NE59J7850WS_AA_DG68-XXXXXX_EN.indd 2 2015-01-21  11:24:00

English

Contents

Important safety instructions 5

Introducing your new range 22

Overview 22

What’s included with your range 23

Dual Door ™ (NE59J7850** only) 24

How to use the upper door 24

How to use the full door 24

Before you begin 26

Energy saving tips 26

Cooktop cooking 27

About cooktop cooking 27

How to set the appliance for cooktop cooking 30

Using the proper cookware 32

Choosing the proper cookware 33

Protecting the smoothtop 33

Operating the oven 35

The oven control panel 35

Setting the clock 37

Setting the kitchen timer 37

Timed cooking 38

Delay start 39

Turning the oven light on and off 39

Minimum and maximum settings 40

Twin cooking mode temperature setting ranges 41

Using the oven racks 42

Using the partition 44

Baking 45

Convection baking 46

Convection roasting 47

Broiling 48

Using the easy cook feature 50

Using the favorite cook feature 51

Using the keep warm feature 51

Using the sabbath feature 52

Extra features 54

NE59J7850WS_AA_DG68-XXXXXX_EN.indd 3 2015-01-21  11:24:01

English

Contents

Using the warming drawer 57

About the warming drawer 57

Turning the warming drawer on or off 58

Maintaining your appliance 59

Self-cleaning 59

Steam-cleaning 62

Care and cleaning of the oven 63

Care and cleaning of the glass cooktop 65

Removing and replacing the oven door 68

Removing and replacing the warming drawer 70

Changing the oven light 71

Troubleshooting 72

Information codes 78

Warranty (U.S.A) 79

Warranty (CANADA) 81

NE59J7850WS_AA_DG68-XXXXXX_EN.indd 4 2015-01-21  11:24:01

English

Important safety instructions

What you need to know about safety

instructions

Warnings and Important Safety Instructions in this manual do not cover all

possible conditions and situations that may occur. It is your responsibility

to use common sense, caution, and care when installing, maintaining, and

operating your oven.

Important safety symbols and precautions

What the icons and signs in this user manual mean:

WARNING

Hazards or unsafe practices that may result in severe personal injury or

death.

CAUTION

Hazards or unsafe practices that may result in minor personal injury or

property damage.

CAUTION

To reduce the risk of fire, explosion, electric shock, or personal injury when

using your oven, follow these basic safety precautions.

Do NOT attempt.

Do NOT disassemble.

Do NOT touch.

Follow directions explicitly.

Unplug the power plug from the wall socket.

Make sure the machine is grounded to prevent electric shock.

Important safety instructions

Read and follow all instructions before using your oven to prevent the risk

of fire, electric shock, personal injury, or damage when using the range.

This guide does not cover all possible conditions that may occur. Always

contact your service agent or manufacturer about problems that you do not

understand.

NE59J7850WS_AA_DG68-XXXXXX_EN.indd 5 2015-01-21  11:24:01

English

Important safety instructions

Call the service center for help.

Note

These warning signs are here to prevent injury to you and others. Please

follow them explicitly.

After reading this section, keep it in a safe place for future reference.

For your safety

When using electrical appliances, you should follow basic safety precautions,

including the following:

CAUTION

• Use this appliance only for its intended purpose as described in this

Owner’s Manual.

• Potentially hot surfaces include the cooktop, areas facing the cooktop, oven

vent opening, surfaces near the opening, crevices around the oven door.

Be sure your appliance is properly installed and grounded by a qualified

technician.

User servicing - Do not repair or replace any part of the appliance unless

specifically recommended in this manual. All other servicing should be

referred to a qualified technician.

Always disconnect the power to the appliance before servicing by

removing the fuse or switching off the circuit breaker.

• Do not enter the oven.

• Do not store items of interest to children in cabinets above a range or

on the back guard of a range. Children climbing on the range to reach

items could be seriously injured.

• Do not leave children alone. Never leave children alone or unattended

in an area where this appliance is in use. They should never be allowed

to sit or stand on any part of the appliance.

• Never use your appliance for warming or heating the room.

NE59J7850WS_AA_DG68-XXXXXX_EN.indd 6 2015-01-21  11:24:01

English

Important safety instructions

• Do not use water on grease fires. Turn off the oven to avoid spreading

the flames. Smother the fire or flames by closing the door or use a dry

chemical, baking soda, or foam-type extinguisher.

• Avoid scratching or impacting glass doors, cooktops or control panels.

Doing so may lead to glass breakage. Do not cook on a product with

broken glass. Shock, fire, or cuts may occur.

• If there is a fire in the oven during self clean, turn the oven off and wait

for the fire to go out. Do not force the door open. Introduction of fresh

air at self-clean temperatures may lead to a burst of flame from the

oven. Failure to follow this instruction may result in severe burns.

• If the oven is heavily soiled with oil, self clean the oven before using

the oven again. Leaving the oil in place creates a risk of fire.

• Wipe up heavy soil on the oven bottom with a paper tower or rag

before self cleaning. Self cleaning the oven when there is heavy soil

on the oven bottom requires longer cleaning cycles and produces more

smoke.

• Storage in or on the appliance. Do not store flammable materials in

the oven or near the surface units. Be sure all packing materials are

removed from the appliance before operating it. Keep plastics, clothes,

and paper away from parts of the appliance that may become hot.

• Wear proper apparel. Never wear loose-fitting or hanging garments

while using the appliance.

• Use only dry potholders. Placing moist or damp potholders on hot

surfaces may result in burns from steam. Do not let the potholder touch

hot heating elements. Do not use a towel or other bulky cloth.

• Teach children not to play with the controls or any other part of the

range.

• For your safety, do not use high-pressure water cleaners or steam jet

cleaners.

• If the power cord is damaged, it must be replaced by the manufacturer,

its service agent, or similarly qualified persons to avoid creating a

hazard.

NE59J7850WS_AA_DG68-XXXXXX_EN.indd 7 2015-01-21  11:24:01

English

Important safety instructions

• The appliance is not intended for use by persons (including children)

with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person responsible for

their safety.

Surface cooking units

• Never leave surface units unattended at high heat settings. Boilovers

cause smoking and greasy spillovers that may ignite.

• Protective Liners – Do not use aluminum foil to line surface unit drip

bowls or oven bottoms, except as suggested in the manual. Improper

installation of these liners may result in a risk of electric shock or fire.

• To avoid oil spillover and fire, use a minimum amount of oil when

shallow pan-frying and avoid cooking frozen foods with excessive

amounts of ice.

• Do not lift the cooktop. Lifting the cooktop can damage the range and

cause the range to malfunction.

• Do not operate the cooktop without cookware. If the cooktop operates

without cookware, the control knobs will become hot.

• Never use the glass cooktop surface as a cutting board.

NE59J7850WS_AA_DG68-XXXXXX_EN.indd 8 2015-01-21  11:24:01

English

Important safety instructions

• Use care when touching the cooktop. The glass surface of the cooktop

will retain heat after the controls have been turned off.

• Be careful when placing spoons or other stirring utensils on the glass

cooktop surface when it is in use. They may become hot and could

cause burns.

• Use proper pan sizes. This appliance is equipped with surface units of

different size. Select pots and pans that have flat bottoms large enough

to cover the surface area of the heating element. Using undersized

cookware will expose a portion of the heating element to direct contact

and may result in the ignition of clothing. Matching the size of the pot

or pan to the burner will also improve efficiency.

• Utensil Handles Should Be Turned Inward and Not Extend Over Adjacent

Surface Units – To reduce the risk of burns, ignition of flammable

materials, or spillage due to unintentional contact with utensils, position

utensil handles so that they are turned inward and do not extend over

adjacent surface units.

• Glazed cooking utensils. Only certain types of glass, glass/ceramic,

ceramic, earthenware, or other glazed cookware can be used for

rangetop service without breaking due to sudden changes in

temperature.

• Cleaning. Read and follow all instructions and warnings on the cleaning

cream labels.

• Be sure you know which control knob operates each surface unit. Make

sure you turned on the correct surface unit.

• Always turn the surface units off before removing cookware.

• When preparing flaming foods under the hood, turn the fan on.

• Keep an eye on foods being fried at high or medium high heat settings.

• Do not store heavy items above the cooktop surface that could fall and

damage it.

• Do not Use Decorative Surface Element Covers – If an element is

accidentally turned on, the decorative cover will become hot and

possibly melt. Burns will occur if the hot covers are touched. Damage

may also be done to the cooktop.

NE59J7850WS_AA_DG68-XXXXXX_EN.indd 9 2015-01-21  11:24:01

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Rango de Samsung

Samsung

Samsung NSG6 83 Series Manual de usuario

Samsung

Samsung NX58K7850S SERIES Manual de usuario

Samsung

Samsung NX58M9960P series Manual de usuario

Samsung

Samsung NX60A6751SS Manual de usuario

Samsung

Samsung NE63B8611SS/AA Manual de usuario

Samsung

Samsung NE595R0ABBW Manual de usuario

Samsung

Samsung NX60 65 S Series Manual de usuario

Samsung

Samsung NX58 9420S Series Manual de usuario

Samsung

Samsung NE58F9710WS Manual de usuario

Samsung

Samsung FTQ387 Series Manual de usuario

Samsung

Samsung NE597N0PBSR Instrucciones de construcción

Samsung

Samsung NE59T4321SW/AA Manual de usuario

Samsung

Samsung FTQ386LWUX Manual de usuario

Samsung

Samsung NX58K7850SG Manual de usuario

Samsung

Samsung NX60 67 S Series Manual de usuario

Samsung

Samsung NE599N1PBSR Manual de usuario

Samsung

Samsung NE58 93 Series Manual de usuario

Samsung

Samsung NX58H5600SS/AA Manual de usuario

Samsung

Samsung NX58K7850SS Manual de usuario

Samsung

Samsung NX60 8 Series Manual de usuario

Samsung

Samsung NX58H9500WS Manual de usuario

Samsung

Samsung NX60T8311SG Manual de usuario

Samsung

Samsung NE63 895 S Series Manual de usuario

Samsung

Samsung Chef Collection NX36R9966PS/AA Manual de usuario

Manuales populares de Rango de otras marcas

Kenmore

Kenmore 790.45712 Manual de usuario

Wolf

Wolf CHR CHSSR Manual de usuario

Smeg

Smeg Built-in Microwave Oven Manual de instrucciones

Zanussi

Zanussi ZCG054G Manual de usuario

Whirlpool

Whirlpool 8575985-W Manual de lista de piezas

Frigidaire

Frigidaire 316000635 Manual de usuario

GE JCSS630 Manual de usuario

Hotpoint

Hotpoint RB524R Guía de instalación

Whirlpool

Whirlpool Roper FGP305KW3 Manual de usuario

Amana

Amana ART6610 SERIES Manual de usuario

Maytag

Maytag MERH770WB Manual de usuario

Fulgor Milano

Fulgor Milano SOFIA Manual de usuario

Premier

Premier EF-4358GH Manual de usuario

Kenmore

Kenmore 790.9010 Series Manual de usuario

KitchenAid

KitchenAid KESC300 Manual de usuario

Frigidaire

Frigidaire FFEF3012LS Guía del usuario

Diamond

Diamond G65/2F4T Manual de usuario

LG LRE3091 Manual de usuario
