Samsung SRP - 350 Manual de usuario

Operator’s Manual

All specifications are subjected to change without notice

SRP -350

RECEIPT PRINTER

Warning -U.S.

This equipment has been tested and found to comply with the limits for a Class A digital device

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a commercial environment. This

equipment generates uses, and can radiate radio frequency energy and , if not installed and used

in accordance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his own

expense.

Notice -Canada

This Apparatus complies with class “A” limits for radio interference as specified in the Canadian

department of communications radio interference regulations.

Get appareil est conforme aux normes class “A” d’interference radio tel que specifier par ministre

canadien des communications dans les reglements d’interference radio.

Caution

Some semiconductor devices are easily damaged by static electricity. You should turn the printer

“OFF”, before you connect or remove the cables on the rear side, in order to guard the printer

against the static electricity. If the printer is damaged by the static electricity, you should turn the

printer “OFF”.

INTRODUCTION

The SRP-350, SRP-350S, SRP-350P and SRP-350U Roll Printer are designed for use with

electronic instruments such as system ECR, POS, banking equipment, computer peripheral

equipment, etc.

The main features of the printer are as follows:

1. High speed printing : 35.5(1/6”Feed) lines per second.

2. Low noise thermal printing.

3. RS-232(SRP-350), RS-485(SRP-350S), Parallel(SRP-350P), USB(SRP-350U)

4. The data buffer allows the unit to receive print data even during printing.

5. Peripheral units drive circuit enables control of external devices such as cash

drawer.

6. Characters can be scaled up to 64 times compared to it’s original size.

7. Bar code printing is possible by using a bar code command.

8. Different print densities can be selected by DIP switches.

Please be sure to read the instruction in this manual carefully before using your new

SRP-350/SRP-350P.

NOTE : The socket-outlet shall be near the equipment and it

shall be easy accessible.

Table of Contents

CHAPTER 1. SETTING UP THE PRINTER.....................................4

1-1. UNPACKING ............................................................................ 4

1-2. CONNECTING THE CABLES ........................................................... 5

1-3. CONNECTING THE COMPUTER........................................................ 6

1-4. CONNECTING THE DRAWER.......................................................... 6

1-5. CONNECTING THE POWER SUPPLY.................................................. 7

1-6. INSTALLING OR REPLACING THE PAPER ROLL ..................................... 8

1-7. ADJUSTMENTS AND SETTINGS......................................................10

1-8. USING THE PRINTER .................................................................11

CHAPTER 2. HEXADECIMAL DUMPING.....................................14

CHAPTER 3. THE SELF TEST......................................................15

CHAPTER 4. CODE TABLE..........................................................16

CHAPTER 5. CONTROL COMMANDS LIST .................................24

APPENDIX.................................................................................27

A. STAR MODE COMMAND SUMMARY....................................................27

B. CONNECTORS............................................................................30

Interface Connector.................................................................31

Drawer Connector ...................................................................34

C. NOTES....................................................................................34

D. SPECIFICATION..........................................................................35

Chapter 1. Setting Up the Printer

1-1. Unpacking

Your printer box should include these items. If any items are damaged or missing,

please contact your dealer for assistance.

1-2. Connecting the Cables

You can connect up the three cables to the printer. They all connect to the connector

panel on the back of the printer, which is shown below:

Notes : Before connecting any of the cables, make sure that both the printer and the

host are turned off.

1-3. Connecting the computer

You need an appropriate interface cable.

1. Plug the cable connector securely into the printer’s interface connector.

2. Tighten the screws on both sides of the cable connector.

3. Attach the other end of the cable to the computer.

1-4. Connecting the Drawer

WARNING:

Use a drawer that matches the printer specification. Using an improper drawer may

damage the drawer as well as the printer.

CAUTION:

Do not connect a telephone line to the drawer kick-out connector; otherwise the

printer and the telephone line may be damaged.

Plug the drawer cable into the drawer kick-out connector on the back of the printer

next to the power supply connector.

1-5. Connecting the Power Supply

CAUTIONS:

When connecting or disconnecting the power supply from the printer, make sure that

the power supply is not plugged into an electrical outlet. Otherwise you may damage

the power supply or the printer.

If the power supply’s rated voltage and your outlet’s voltage do not match, contact your

dealer for assistance. Do not plug in the power cord. Otherwise, you may damage the

power supply or the printer.

1. Make sure that the printer’s power switch is turned off, and the power supply’s power

cord is unplugged from the electrical outlet.

2. Check the label on the power supply to make sure that the voltage required by the

power supply matches that of your electrical outlet.

3. Plug in the power supply’s cable as shown below. Notice that the flat side of the plug

faces down.

Notes : To remove the DC cable connector, make sure that the power supply’s power

cord is unplugged; then grasp the connector at the arrow and pull it straight out.

1-6. Installing or Replacing the Paper Roll

1. Make sure that the printer is not receiving data; otherwise, data may be lost.

2. Open the paper roll cover by pressing the cover-open button.

3. Remove the used paper roll core if there is one.

4. Insert the paper roll as shown.

Notes : Be sure to use paper rolls that meet the specifications. Do not use paper rolls

that have the paper glued to the core because the printer cannot detect the

paper end correctly.

Notes : Do not open the print cover while the printer is operating.

This may damage the printer.

5. Be sure to note the correct direction that the paper comes off the roll.

6. Pull out a small amount of paper, as shown. Then close the cover.

7. Tear off the paper as shown.

Notes : When closing the cover, press the center of printer cover firmly to prevent

Paper miss-loading.

1-7. Adjustments and Settings

The SRP-350 is set up at the factory to be appropriate for almost all users. It does,

however, offer some settings for users with special requirements.

It has DIP switches that allow you to change communication settings, such as

handshaking and parity check, as well as print density.

The SRP-350 also has a near-end sensor for the paper. This can give you a warning

when the paper is almost out. If you find that there is not enough paper remaining on

the roll when the near-end detector is triggered, you can change the near-end sensor

setting. Rotate the near end sensor tab at front or rear position.(See the below figure)
