Samsung M-202X series Manual de usuario

BASIC

User’s Guide

M-202x Series

M-202xW Series

BASIC

User’s Guide

This guide provides information concerning installation, basic operation and

troubleshooting on windows.

ADVANCED

This guide provides information about installation, advanced configuration, operation and

troubleshooting on various OS environments.

Some features may not be available depending on models or countries.

1. Introduction

This chapter provides information you need to know before using the machine.

•Keybenefits 2

• Features by models 4

• Useful to know 6

• About this user’s guide 7

• Safety information 8

• Machine overview 13

• Control panel overview 16

• Turning on the machine 18

• Installing the driver locally 19

• Reinstalling the driver 20

Key benefits

Environmentally friendly

• To save toner and paper, this machine supports the Eco feature (see "Easy

Eco Driver" on page 3).

• To save paper, you can print multiple pages on a single sheet of paper (see

"Using advanced print features" on page 5).

• To save paper, you can print on both sides of the paper (manual double-

sided printing) (see "Using advanced print features" on page 5).

• To save electricity, this machine automatically conserves electricity by

substantially reducing power consumption when not in use.

Print with excellent quality and speed

• You can print with a resolution of up to 1,200 x 1,200 dpi effective output.

• Fast, on-demand printing.

- For single-side printing, 20 ppm (A4) or 21 ppm (Letter).

Convenience

• Easy Capture Manager allows you to easily edit and print whatever you

captured using the Print Screen key on the keyboard (see "Understanding

Easy Capture Manager" on page 4).

• Samsung Easy Printer Manager and Samsung Printer Status (or Smart Panel)

are a program that monitors and informs you of the machine’s status and

allows you to customize the machine’s settings (see "Using Samsung Easy

Printer Manager" on page 8).

• AnyWeb Print helps you screen-capture, preview, scrap, and print the

screen more easily than when you use the ordinary program (see "Samsung

AnyWeb Print" on page 2).

• Smart Update allows you to check for the latest software and install the

latest version during the printer driver installation process. This is available

only for Windows OS users.

• If you have Internet access, you can get help, support application, machine

drivers, manuals, and order information from the Samsung website,

www.samsung.com > find your product > Support or Downloads.

Key benefits

Wide range of functionality and application support

• Supports various paper sizes (see "Print media specifications" on page 4).

• Print watermark: You can customize your documents with words, such as

“Confidential” (see "Using advanced print features" on page 5).

• Print posters: The text and pictures of each page of your document are

magnified and printed across the multiple sheets of paper and can then be

taped together to form a poster (see "Using advanced print features" on

page 5).

• You can print in various operating systems (see "System requirements" on

page 7).

• Your machine is equipped with a USB interface.

Supports various wireless network setting method

• Using the WPS (Wi-Fi Protected Setup™) button

- You can easily connect to a wireless network using the WPS button on

the machine and the access point (a wireless router).

• Using the USB cable or a network cable

- You can connect and set various wireless network settings using a USB

cable or a network cable.

• Using the Wi-Fi Direct

- You can conveniently print from your mobile device using the Wi-Fi or

Wi-Fi Direct feature.

See "Introducing wireless set up methods" on page 18.

Features by models

Some features and optional goods may not be available depending on model or country.

Operating System

Software

Operating System M-202x Series M-202xW Series

Windows ● ●

Macintosh ● ●

Linux ● ●

Unix

Software M-202x Series M-202xW Series

PCL printer driver

SPL printer driver ● ●

PS printer driver

XPS printer driver1

1. For XPS driver, it is only supported for windows through the Samsung website (www.samsung.com)

● ●

Samsung Easy Printer Manager ● ●

SyncThru™ Web Service ●

Features by models

Variety feature

(●: Included, Blank: Not available)

Features M-202x Series M-202xW Series

Hi-Speed USB 2.0 ● ●

Network Interface Ethernet 10/100 Base TX wired LAN

Network Interface 802.11b/g/n wireless LAN ●

IPv6 ●

Eco printing(Easy Eco Driver)1

1. Setting the ECO settings is available from the windows driver.

● ●

Wi-Fi Protected Setup™ (WPS) ●

Manual duplex (2-sided) printing ● ●

Useful to know

Where can I download the machine’s driver?

• Visit www.samsung.com/printer to download the latest machine’s

driver, and install it on your system.

Where can I purchase accessories or supplies?

• Inquire at a Samsung distributor or your retailer.

• Visit www.samsung.com/supplies. Select your country/region to

view product service information.

The status LED flashes or remains constantly on.

• Turn the product off and on again.

• Check the meanings of LED indications in this manual and

troubleshoot accordingly (see "Understanding the status LED" on

page 6).

A paper jam has occurred.

• Open and close the top cover (see "Front view" on page 14).

• Check the instructions on removing jammed paper in this manual

and troubleshoot accordingly (see "Clearing paper jams" on page

3).

Printouts are blurry.

• The toner level might be low or uneven. Shake the toner cartridge.

• Try a different print resolution setting.

• Replace the toner cartridge.

The machine does not print.

• Open the print queue list and remove the document from the list

(see "Canceling a print job" on page 13).

• Remove the driver and install it again (see "Installing the driver

locally" on page 19).

• Select your machine as your default machine in your Windows.

About this user’s guide

This user's guide provides information for your basic understanding of the

machine as well as detailed steps to explain machine usage.

• Read the safety information before using the machine.

• If you have a problem using the machine, refer to the troubleshooting

chapter.

• Terms used in this user’s guide are explained in the glossary chapter.

• All illustrations in this user’s guide may differ from your machine

depending on its options or model you purchased.

• The screenshots in this user's guide may differ from your machine

depending on the machine’s firmware/driver version.

• The procedures in this user’s guide are mainly based on Windows 7.

Conventions

Some terms in this guide are used interchangeably, as below:

• Document is synonymous with original.

• Paper is synonymous with media, or print media.

• Machine refers to printer or MFP.

General icons

Icon Text Description

Caution Gives users information to protect the machine from

possible mechanical damage or malfunction.

Note Provides additional information or detailed

specification of the machine function and feature.

1. Introduction

Safety information

These warnings and precautions are included to prevent injury to you and

others, and to prevent any potential damage to your machine. Be sure to read

and understand all of these instructions before using the machine. After reading

this section, keep it in a safe place for future reference.

Important safety symbols

Explanation of all icons and signs used in this chapter

Operating environment

Warning

Warning Hazards or unsafe practices that may result in severe

personal injury or death.

Caution Hazards or unsafe practices that may result in minor

personal injury or property damage.

Do not attempt.

Do not use if the power cord is damaged or if the electrical outlet is

not grounded.

This could result in electric shock or fire.

Do not place anything on top of the machine (water, small metal or

heavy objects, candles, lit cigarettes, etc.).

This could result in electric shock or fire.

• If the machine gets overheated, it releases smoke, makes

strange noises, or generates an odd odor, immediately turn off

the power switch and unplug the machine.

• The user should be able to access the power outlet in case of

emergencies that might require the user to pull the plug out.

This could result in electric shock or fire.

Do not bend, or place heavy objects on the power cord.

Stepping on or allowing the power cord to be crushed by a heavy

object could result in electric shock or fire.

Do not remove the plug by pulling on the cord; do not handle the

plug with wet hands.

This could result in electric shock or fire.

Safety information

1. Introduction

Caution

Operating method

Caution

During an electrical storm or for a period of non-operation,

remove the power plug from the electrical outlet.

This could result in electric shock or fire.

Be careful, the paper output area is hot.

Burns could occur.

If the machine has been dropped, or if the cabinet appears

damaged, unplug the machine from all interface connections and

request assistance from qualified service personnel.

Otherwise, this could result in electric shock or fire.

If the machine does not operate properly after these instructions

have been followed, unplug the machine from all interface

connections and request assistance from qualified service

personnel.

Otherwise, this could result in electric shock or fire.

If the plug does not easily enter the electrical outlet, do not

attempt to force it in.

Call an electrician to change the electrical outlet, or this could

result in electric shock.

Do not allow pets to chew on the AC power, telephone or PC

interface cords.

This could result in electric shock or fire and/or injury to your pet.

Do not forcefully pull the paper out during printing.

It can cause damage to the machine.

Be careful not to put your hand between the machine and paper

tray.

You may get injured.

This machine's power reception device is the power cord.

To switch off the power supply, remove the power cord from the

electrical outlet.

Be care when replacing paper or removing jammed paper.

New paper has sharp edges and can cause painful cuts.

When printing large quantities, the bottom part of the paper

output area may get hot. Do not allow children to touch.

Burns can occur.

When removing jammed paper, do not use tweezers or sharp metal

objects.

It can damage the machine.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Impresora de Samsung

Samsung

Samsung ML-3560 Series Manual de usuario

Samsung

Samsung SCX-1100 Manual de usuario

Samsung

Samsung SL-M3820DW/XAA Manual de usuario

Samsung

Samsung ELLIX-35II Manual de usuario

Samsung

Samsung CLP-415NW Manual de usuario

Samsung

Samsung ML-1640 Series Manual de usuario

Samsung

Samsung CLX-6260ND Manual de usuario

Samsung

Samsung ML-2550 Manual de usuario

Samsung

Samsung ML-1665 Manual de usuario

Samsung

Samsung ML-1451N Manual de usuario

Samsung

Samsung CLP-310 Manual de usuario

Samsung

Samsung ML-6050 Manual de usuario

Samsung

Samsung 500N - CLP Color Laser Printer Manual de instrucciones

Samsung

Samsung xpress m282 series Manual de usuario

Samsung

Samsung ML-2150 Manual de usuario

Samsung

Samsung CLP-775ND Manual de usuario

Samsung

Samsung CLX-9201NA Manual de usuario

Samsung

Samsung ML-2250/XBG Manual de usuario

Samsung

Samsung ProXpress M4030 Series Manual de usuario

Samsung

Samsung ML-2550 Manual de usuario

Samsung

Samsung ML-3750ND Manual de usuario

Samsung

Samsung ProXpress M458x Series Manual de usuario

Samsung

Samsung ML 4050N - B/W Laser Printer Guía del usuario

Samsung

Samsung SCX-4600 Series Manual de usuario

Manuales populares de Impresora de otras marcas

Lexmark

Lexmark 1400 Series Manual

Canon

Canon i70 Series Manual de usuario

Evolis

Evolis Elypso Manual de usuario

Kyocera

Kyocera FS-9530DN Manual de usuario

Canon

Canon LASER SHOT LBP-1210 Manual de usuario

Canon

Canon PIXMA PRO-1 Series Manual de usuario

Canon

Canon PIXMA G3560 Guía de configuración

Dell

Dell Color Laser Printer 2130cn Manual de usuario

Tektronix

Tektronix Phaser 840 Manual de usuario

Epson

Epson ET-7750 Instrucciones de funcionamiento

Canon

Canon CLBR 460ps Manual de usuario

Eltron

Eltron P210 Guide Manual de usuario

Ricoh

Ricoh MD-P1 Manual de usuario

Epson

Epson SC-F7100 series Manual de usuario

Epson

Epson Stylus C40UX Manual de usuario

Canon

Canon imagePASS-A2 Manual de usuario

Canon

Canon S820D Manual de usuario

IRA3D

IRA3D POETRY4 Manual de usuario
