Samsung Bixolon SRP-500 Instrucciones de instalación

Command Manual

SRP-500

Inkjet Printer

Rev. 1.00

http://www.samsungminiprinters.com

Rev. 1.00 - 2 -

SRP-500

1. EPSON Mode (TM-U200)

nCommand Description Hexadecimal

1 CR Print and carriage return 0D

2 HT Horizontal tab 09

3 LF Print and linefeed 0A

4 DLE EOT Transmit real-time status 10 04

5 DLE ENQ Real-time request to printer 10 05

6 ESC SP Set right-side character spacing 1B 20

7 ESC % Select/Cancel user defined characters 1B 25

8 ESC & Define user-defined characters 1B 26

9 ESC * Select bit-image mode 1B 2A

10 ESC ! Select print mode 1B 21

11 ESC - Turn underline mode on/off 1B 2D

12 ESC = Select peripheral device status 1B 3D

13 ESC 2 Select default line spacing 1/6 lpi 1B 32

14 ESC 3 Set line spacing 1B 33

15 ESC < Return home 1B 3C

16 ESC ? Cancel user defined characters 1B 3F

17 ESC @ Initialize printer 1B 40

18 ESC D Set horizontal positions 1B 44

19 ESC E Turn emphasized mode on/off 1B 45

20 ESC G Turn double-strike mode on/off 1B 47

21 ESC J Print and feed paper <n> vertical units 1B 4A

22 ESC R Select an international character set 1B 52

23 ESC U Turn unidirectional printing mode on/off 1B 55

24 ESC a Select justification 1B 61

25 ESC c 3 Select paper sensor to output paper end signal 1B 63 33

26 ESC c 4 Select paper sensor to stop printing 1B 63 34

27 ESC c 5 Enable/disable panel button 1B 63 35

28 ESC d Print and feed <n> line 1B 64

29 ESC g <0> Start macro record (For logo) 1B 67 00

30 ESC g <n> Execute macro (For logo) 1B 67 <n>

31 ESC m Execute partial cut 1B 6D

32 ESC p Generate pulse 1B 70

33 ESC r Select color 1B 72

34 ESC t Select character code table 1B 74

35 ESC v Transmit paper sensor status 1B 76

36 ESC { Turn upside-down printing mode on/off 1B 7B

37 GS ( A Execute test print 1B 28 41

38 GS I Transmit printer ID 1D 49

39 GS V Select cut mode and cut paper 1D 56

40 GS a Enable/disable Automatic Status Back (ASB) 1D 61

41 GS j Enable/disable Automatic Status Back (ASB) for ink 1D 6A

42 GS r Transmit status 1D 72

Rev. 1.00 - 3 -

SRP-500

2. STAR Mode (SP-320)

n Command Descri

tion Hexadecimal

1 BEL Deferred drive command “A” for peripheral unit 1 07

2 FF Page feed (Form feed) 0C

3 CR Print and linefeed (same as LF) 0D

4 SO Select expanded character mode 0E

5 SI Select upside-down 0F

6 DC2 Cancel upside-down character 12

7 DC4 Cancel expanded character mode (Default setting) 14

8 CAN Cancel print data in buffer 18

9 EM Immediate drive command for peripheral unit2 19

10 SUB Immediate drive command for peripheral unit 2 1A

11 ESC BEL Adjust drive pulse width for peripheral unit

(Default setting)

1B 07

12 ESC - Set or Cancel underline mode 1B 2D

13 ESC 4 Red color print selection 1B 34

14 ESC 5 Red color print deselection 1B 35

15 ESC @ Initialize printer 1B 40

16 ESC C Set page length at n lines 1B 43

17 ESC E Emphasized print mode 1B 45

18 ESC F Emphasized print mode deselection (Default setting) 1B 46

19 ESC M Select 9 x 7(Half dots) character size 1B 4D

20 ESC R Select international character set 1B 52

21 ESC U Set or cancel uni-direction mode 1B 55

ESC W 1

ESC W <1>

Select expanded character mode

1B 57 31

1B 57 01

ESC W 0

ESC W <0>

Cancel expanded character mode (Default setting)

1B 57 30

1B 57 00

ESC _ 1

ESC _ <1>

Select over-line mode

1B 5F 31

1B 5F 01

ESC _ 0

ESC _ <0>

Cancel over-line mode

1B 5F 30

1B 5F 01

26 ESC a Feed paper n lines 1B 61

27 ESC d 0 Partial cut 1B 64 30

28 ESC d 1 Partial cut 1B 64 31

ESC e 1

ESC e <1>

Set the control panel switch invalid

1B 65 31

1B 65 01

ESC e 0

ESC e <0>

Set the control panel switch valid

1B 65 30

1B 65 00

ESC f 1

ESC f <1>

Set the ON LINE switch invalid

1B 66 31

1B 66 01

ESC f 0

ESC f <0>

Set the ON LINE switch valid

1B 66 30

1B 66 00

33 FS Immediate drive command “B” for peripheral unit 1 1C

Rev. 1.00 - 4 -

SRP-500

3. CITIZEN Mode (iDP-3541)

n Command Description Hexadecimal

1 BEL First drawer drive command1 07

2 LF Paper feed command 0A

3 FF n “n”-lines paper feed command 0C n

4 SO Enlarged character command 0E

5 SI Normal character command 0F

6 DC1 Initial set command 11

7 DC2 Inverted character command 12

8 DC3 Red color print command 13

9 CAN Clear command 18

10 SUB Second drawer drive command 1A

11 ESC BEL Drive pulse setting command for the first drawer 1B 07

12 ESC - Underline command 1B 2D

13 ESC 1 1/9 inch paper feed preset command 1B 31

14 ESC 2 2/9 inch paper feed preset command 1B 32

15 ESC C Paper length set command 1B 43

16 ESC P <0> Paper partial cut command 1B 50 00

17 ESC P <1> Paper partial cut command 1B 50 01

18 FS First drawer quick drive command 1C

19 CR Printing ØD

20 ESC * n1 n2 Specifying the bit image mode 1B 2A n1 n2

21 ESC f <1> Form feed 1B 66 Ø1

Rev. 1.00 - 5 -

SRP-500

4. Control Commands Details

4-1 Command Notation

[Name]

[Format]

[Range]

[Description]

The name of the command.

The code sequence. ASCII Indicates the ASCII equivalents.

Hex indicates the hexadecimal equivalents.

Decimal indicates the decimal equivalents.

[ ] k indicates the contents of the [ ] should be repeated k times.

Gives the allowable ranges for the arguments.

Describes the function of the command.

4-2 Explanation of Terms

LSB

Least Significant Bit

4-3 Control Commands Details

[Name] Horizontal tab

[Format] ASCII HT

Hex 09

Decimal 10

[Description] Moves the print position to the next horizontal tab position.

[Notes]

This command is ignored unless the next horizontal tab position has been set.

Horizontal tab positions are set with ESC D.

The default tab positions are at intervals of 8 characters (columns 9, 17, 25..) for the

font B (12 x 12).

[Reference] ESC D

[Name] Print and line feed

[Format] ASCII LF

Hex 0A

Decimal 10

[Description] Prints the data in the print buffer and feeds one line based on the

current line spacing.

[Note] This command sets the print position to the beginning of the line.

[Reference] ESC 2, ESC 3

Rev. 1.00 - 6 -

SRP-500

[Name] Print and carriage return

[Format] ASCII CR

Hex 0D

Decimal 13

[Description] This command prints the data in the print buffer and does not feed the

paper.

[Note] Sets the print starting position to the beginning of the line

[Reference] LF

DLE EOT n

[Name] Real-time status transmission

[Format] ASCII DLE EOT n

Hex 10 04 n

Decimal 16 4 n

[Range] 1 ≤n ≤4

[Description] Transmits the selected printer status specified by n in real time,

according to the following parameters:

n = 1: Transmit printer status

n = 2: Transmit off-line status

n = 3: Transmit error status

n = 4: Transmit paper roll sensor status

[Notes]

This command should not be used within the data sequence of another command that

consists of 2 or more bytes. For example, If you attempt to transmit ESC 3 n to the

printer, but DTR (DSR for the host computer) goes to MARK before n is transmitted

and then DLE EOT 3 interrupts before n is received, the code <10>H for DLE EOT 3 is

processed as the code for ESC 3

<10>H.

n = 1 : Printer status

Bit Off/On Hex Decimal Function

0 Off 00 0 Not used. Fixed to Off.

1 On 02 2 Not used. Fixed to On.

Off 00 0 Drawer kick-out signal is LOW (connector pin 3)2

On 04 4 Drawer kick-out signal is HIGH (connector pin 3)

Off 00 0 On-line.3

On 08 8 Off-line.

4 On 10 16 Not used. Fixed to On.

5 Off 00 0 Not used. Fixed to Off.

6 Off 00 0 Not used. Fixed to Off.

7 Off 00 0 Not used. Fixed to Off.

Rev. 1.00 - 7 -

SRP-500

n = 2 : Off-line status

Bit Off/On Hex Decimal Function

0 Off 00 0 Not used. Fixed to Off.

1 On 02 2 Not used. Fixed to On.

2 Off 00 0 Cover is closed (front & rear)

On 04 4 Cover is open (front or rear)

Off 00 0 Paper is not being fed by using the paper feed

button.

On 08 8 Paper is being fed by the paper feed button.

4 On 10 16 Not used.

Off 00 0 Fixed to On.5

On 20 32 No paper-end stop.

Off 00 0 Printing stops due to paper end.6

On 40 64 No error. Error occurs.

7 Off 00 0 Not used. Fixed to Off.

Bit 5 : On (printing stops due to paper-end) when printing stops due to paper-end detected

by the paper-end sensor or the paper near-end enabled by using the ESC c 4.

n = 3 : Error status

Bit Off/On Hex Decimal Function

0 Off 00 0 Not used. Fixed to Off.

1 On 02 2 Not used. Fixed to On.

Off 00 0 No mechanical error.2

On 04 4 Mechanical error occurred.

Off 00 0 No auto-cutter error.

3 On 08 8 Auto-cutter error occurs.

4 On 10 16 Not used. Fixed to On.

Off 00 0 No unrecoverable error.5

On 20 32 Unrecoverable error occurs.

Off 00 0 Automatic recover error.6

On 40 64 No automatic recover error.

7 Off 00 0 Not used. Fixed to Off.

Bit 2 : If these errors occur due to paper jams or the like, it is possible to recover by

correcting the cause of the error and executing DLE ENQ 2. If an error due to a

circuit failure (e.g. wire break) occurs, it is impossible to recover.

n = 4 : Continuous paper sensor status

Bit Off/On Hex Decimal Function

0 Off 00 0 Not used. Fixed to Off.

1 On 02 2 Not used. Fixed to On.

Off 00 0 Paper near-end sensor. Paper adequate.

2, 3

On 0C 12

Paper near-end is detected by the paper near-end

sensor.

4 On 10 16 Not used. Fixed to On.

Off 00 0 Paper end sensor. Paper adequate.5, 6

On 60 96 Paper end is detected by the paper end sensor.

7 Off 00 0 Not used. Fixed to Off.

Rev. 1.00 - 8 -

SRP-500

DLE ENQ n

[Name] Real-time request to printer

[Format] ASCII DLE ENQ n

Hex 10 05 n

Decimal 16 5 n

[Range] n = 2

[Description] The printer responds to a request from the host specified by n.

n = 2: Recovers from an error after clearing the receive and print

buffers.

[Notes]

This command should not be used within the data sequence of another command that

consists of two or more bytes. For example,

If you attempt to transmit ESC 3 n to the printer, but DTR (DSR for the host computer)

goes to MARK before n is transmitted, and DLE ENQ 2 interrupts before n is received,

the code <10>H for DLE ENQ 2 is processed as the code for ESC 3 <10>H.

This command n = 2 is valid only when a mechanical error or an auto-cutter error has

occurred.

DLE ENQ 2 enables the printer to recover from an error after clearing the data in the

receive buffer and the print buffer.

The printer retains the settings (by ESC !, ESC 3, etc.) in effect when the error

occurred. The printer can be initialized completely by using this command and ESC @.

This command is enabled only for errors that have the possibility of recovery

ESC SP n

[Name] Set right-side character spacing

[Format] ASCII ESC SP n

Hex 1B 20 n

Decimal 27 32 n

[Range] 0 ≤n ≤255

[Description] Sets the character spacing for the right side of the character to [ n x

0.122 mm {1/208 inches}] .

[Notes] The right-side character spacing for double-width mode is twice the

normal value.

[Default] n = 0

ESC ! n

[Name] Select print mode(s)

[Format] ASCII ESC ! n

Hex 1B 21 n

Decimal 27 33 n

[Range] 0 ≤n ≤255

[Description] Selects print mode(s) using n as follows:

Rev. 1.00 - 9 -

SRP-500

Bit Off/On Hex Decimal Function

Off 00 0 Character font A (12 x 14) selected.0

On 01 1 Character font B (12 x 12) selected.

1 - - - Undefined.

2 - - - Undefined.

Off 00 0 Emphasized mode not selected.3

On 08 8 Emphasized mode selected.

Off 00 0 Double-height mode not selected.4

On 10 16 Double-height mode selected.

Off 00 0 Double-width mode not selected.5

On 20 32 Double-width mode selected.

6 - - - Undefined.

Off 00 0 Underline mode not selected.7

On 80 128 Underline mode selected.

[Notes]

When both double-height and double-width modes are selected, quadruple size

characters are printed.

Underlining is added to the entire width of each character, including the space to the

right of a character, but is not added to portions of lines that were skipped by means of

an HT.

[Default] n = 1

[Reference] ESC E, ESC –

ESC % n

[Name] Select/cancel user-defined character set

[Format] ASCII ESC % n

Hex 1B 25 n

Decimal 27 37 n

[Range] 0 ≤n ≤255

[Description] Selects or cancels the user-defined character set.

When the Least Significant Bit (LSB) is 0, the user-defined character

set is canceled and the internal character set is enabled.

When the LSB is 1, the user-defined character set is selected.

[Notes]

When the downloaded character set has been released, the internal character set is

specified automatically.

[Default] n = 0

[Reference] ESC &, ESC ?

Rev. 1.00 - 10 -

SRP-500

ESC & y c1 c2 [x1 d1...d(y x x1)]...[ xk d1... d(y x xk)]

[Name] Define user-defined characters

[Format] ASCII ESC & y c1 c2 [x1 d1...d(y x x1)]...[ xk d1... d(y x xk)]

Hex 1B 26 y c1 c2 [x1 d1...d(y x x1)]...[ xk d1... d(y x xk)]

Decimal 27 38 y c1 c2 [x1 d1...d(y x x1)]...[ xk d1... d(y x xk)]

[Range] y = 2

32 ≤c1 ≤c2 ≤255

0 ≤x ≤14 (Font A)

0 ≤x ≤12 (Font B)

0 ≤d1 ... d(y x x) ≤255

[Description] Defines user-defined characters.

y specifies the number of bytes in the vertical direction.

c1 specifies the beginning character code for the definition, and c2

specifies the final code. When only one character is desired, use c1 = c2.

x specifies the number of dots in the horizontal direction.

[Notes]

Consecutive character codes for multiple characters can be defined in one definition.

When specifying only one character, specify c1 = c2.

"d" is definition data that indicates the pattern for " x" dots in the horizontal direction

starting from the left edge. If " x" does not satisfy the number of dots in the character

configuration pattern, the remaining dots on the right are spaces.

The number of bytes required to download a character definition for one character is "

y" x " x".

In the definition data, a "1" represents a dot that is to be printed, and a "0" represents a

dot that is not to be printed.

Independent downloaded character definitions are possible for each font.

The font is selected by the "ESC !" command.

The defined downloaded characters are cleared in the following circumstances:

1) When "ESC @" is executed

2) When deleted by "ESC ?"

3) When the printer is reset or turned off

[Default] The internal character set

[Reference] ESC %, ESC ?

ESC * m nL nH d1...dk

[Name] Select bit-image mode

[Format] ASCII ESC * m nL nH d1...dk

Hex 1B 2A m nL nH d1...dk

Decimal 27 42 m nL nH d1...dk

[Range] m = 0, 1

0 ≤nL ≤255

0 ≤nH ≤3

0 ≤d ≤255

[Description] Selects a bit-image mode using m for the number of dots specified by

nL and nH

Otros manuales para Bixolon SRP-500

Tabla de contenidos

Otros manuales de Impresora de Samsung

Samsung

Samsung ML-4050NDT Manual de usuario

Samsung

Samsung CLP-680ND: CLP-775ND Manual del operador

Samsung

Samsung ML-6512ND SERIES Manual de usuario

Samsung

Samsung ML-1630W/SEE Manual de usuario

Samsung

Samsung ML-3050 Series Manual de usuario

Samsung

Samsung CLP-610 Series Manual de usuario

Samsung

Samsung ML-1710 Manual de usuario

Samsung

Samsung CLP 510N - Color Laser Printer Manual de usuario

Samsung

Samsung SL-M2070W Manual de usuario

Samsung

Samsung ML-6040 Manual de usuario

Samsung

Samsung ML-2165W Instrucciones de instalación y mantenimiento

Samsung

Samsung SPP 2020 - Photo Printer - 20 Sheets Manual de usuario

Samsung

Samsung SPP 2020 - Photo Printer - 20 Sheets Manual de usuario

Samsung

Samsung CLP-775ND Manual de usuario

Samsung

Samsung CLP 610ND - Color Laser Printer Manual de usuario

Samsung

Samsung CLP-415NW Manual de usuario

Samsung

Samsung ML-2550 Guía del usuario

Samsung

Samsung xpress m283 series Manual de usuario

Samsung

Samsung 2 COLOR THERMAL PRINTER SRP-275 Manual de usuario

Samsung

Samsung CLP 300N - Network-ready Color Laser Printer Manual de instrucciones

Samsung

Samsung Xpress M2021 Manual de usuario

Samsung

Samsung ML 1630 - B/W Laser Printer Manual de usuario

Samsung

Samsung CLP-415NW Manual de usuario

Samsung

Samsung ML-2955DW Manual de usuario

Manuales populares de Impresora de otras marcas

Lexmark

Lexmark 1400 Series Manual

Canon

Canon i70 Series Manual de usuario

Evolis

Evolis Elypso Manual de usuario

Kyocera

Kyocera FS-9530DN Manual de usuario

Canon

Canon LASER SHOT LBP-1210 Manual de usuario

Canon

Canon PIXMA PRO-1 Series Manual de usuario

Canon

Canon PIXMA G3560 Guía de configuración

Dell

Dell Color Laser Printer 2130cn Manual de usuario

Tektronix

Tektronix Phaser 840 Manual de usuario

Epson

Epson ET-7750 Instrucciones de funcionamiento

Canon

Canon CLBR 460ps Manual de usuario

Eltron

Eltron P210 Guide Manual de usuario

Ricoh

Ricoh MD-P1 Manual de usuario

Epson

Epson SC-F7100 series Manual de usuario

Epson

Epson Stylus C40UX Manual de usuario

Canon

Canon imagePASS-A2 Manual de usuario

Canon

Canon S820D Manual de usuario

IRA3D

IRA3D POETRY4 Manual de usuario
