Samsung UD22B Manual de usuario

BN46-00286A-02

User Manual

UD22B

The color and the appearance may differ depending on

the product, and the specifications are subject to

change without prior notice to improve the performance.

Table Of Contents 2

Table Of Contents

BEFORE USING THE

PRODUCT

8 Copyright

9 Cleaning

9Storage

10 Safety Precautions

10 Symbols

11 Electricity and Safety

12 Installation

14 Operation

PREPARATIONS 18 Checking the Contents

18 Removing the Packaging

19 Checking the Components

21 Parts

21 External sensor

23 Reverse Side

25 Remote Control

27 Controlling more than one display product using

an external sensor kit

28 Before Installing the Product (Installation

Guide)

28 Ventilation

30 Dimensions

31 RS232C

31 Cable Connection

34 Connection

36 Control Codes

CONNECTING AND USING

A SOURCE DEVICE

45 Before Connecting

45 Pre-connection Checkpoints

46 Connecting and Using a PC

46 Connecting to a PC

48 Changing the Resolution

50 Connecting an External Monitor

Table Of Contents

Table Of Contents 3

51 Connecting to a Video Device

51 Connection Using an HDMI-DVI Cable

52 Connection Using an HDMI Cable

52 Connecting to an Audio System

53 Connecting the network box (Sold

separately)

53 MagicInfo

54 Changing the Input source

54 Source List

USING MDC 55 Configuring Settings for Multi Control

55 ID Setup

55 ID Input

55 MDC Connection

55 Network Setting

56 MDC Program Installation/Uninstallation

56 Installation

56 Uninstallation

57 What is MDC?

57 Connecting to MDC

59 Connection Management

60 Auto Set ID

61 Cloning

62 Command Retry

63 Getting Started with MDC

65 Main Screen Layout

66 Menus

67 Screen Adjustment

71 Sound Adjustment

72 System Setup

80 Tool Settings

82 Other Functions

87 Troubleshooting Guide

SCREEN ADJUSTMENT 89 Source List

Table Of Contents

Table Of Contents 4

90 Edit Name

91 Source AutoSwitch Settings

SCREEN ADJUSTMENT 92 Mode

92 If the input source is DVI or DP

92 If the input source is HDMI

93 Custom

93 Contrast

93 Brightness

93 Sharpness

93 Gamma

94 Color

94 Tint

95 Color Tone

95 If the input source is DVI or DisplayPort

95 If the input source is HDMI

96 Color Control

96 Color Temp.

97 Size

97 If the input source is DVI or DisplayPort

98 If the input source is HDMI

98 Picture Sizes available by Input Source

99 Digital NR

99 HDMI Black Level

99 Film Mode

99 Dynamic Contrast

100 Lamp Control

100 Picture Reset

SOUND ADJUSTMENT 101 Mode

Table Of Contents

Table Of Contents 5

102 Custom

102 Bass

102 Treble

102 Balance

103 Auto Volume

103 SRS TS XT

103 Sound Reset

SETUP 104 Language

104 Time

104 Clock Set

105 Sleep Timer

106 Timer1 / Timer2 / Timer3

107 Holiday Management

107 Menu Transparency

108 Safety Lock

108 Change PIN

108 Lock

109 Energy Saving

109 Video Wall

110 Format

110 Horizontal

111 Vertical

111 Screen Position

112 Safety Screen

112 Pixel Shift

113 Timer

114 Bar

114 Eraser

114 Pixel

115 Side Gray

115 Resolution Select

Table Of Contents

Table Of Contents 6

116 Power On Adjustment

116 OSD Rotation

117 Advanced Settings

117 Fan & Temperature

119 Auto Power

119 Button Lock

119 User Auto Color

120 Standby Control

121 Lamp Schedule

121 OSD Display

122 Software Upgrade

123 Setup Reset

123 Reset All

TROUBLESHOOTING

GUIDE

124 Requirements Before Contacting

Samsung Customer Service Center

124 Testing the Product

124 Checking the Resolution and Frequency

124 Check the followings.

127 Q & A

SPECIFICATIONS 128 General

130 PowerSaver

131 Preset Timing Modes

APPENDIX 133 Contact SAMSUNG WORLDWIDE

138 Responsibility for the Pay Service (Cost

to Customers)

138 Not a product defect

138 A Product damage caused by customer's fault

138 Others

Table Of Contents

Table Of Contents 7

139 Optimum Picture Quality and Afterimage

Burn-in Prevention

139 Optimum Picture Quality

140 Prevention of Afterimage Burn-in

142 Correct Disposal of This Product (Waste

Electrical & Electronic Equipment)

142 Correct disposal of batteries in this

product

143 Terminology

INDEX

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

2012 Samsung Electronics

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is

prohibited.

The SAMSUNG and SyncMaster logos are registered trademarks of Samsung Electronics.

Microsoft, Windows are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Ownership of all other trademarks is attributed to their due owner.

An administration fee may be charged if either

(a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

(b) you bring the unit to a repair center and there is no defect in the product

(i.e. where you have failed to read this user manual).

The amount of such administration charge will be advised to you before any work or home visit is

carried out.

TruSurround XT, SRS and the symbol are trademarks of SRS Labs, Inc.

TruSurround XT technology is incorporated under license form SRS Lab, Inc.

The terms HDMI and HDMI High-Definition Multimedia Interface, and the

HDMI Logo are trademarks or registered trademarks of HDMI Licensing

LLC in the United States and other countries.

Before Using the Product

Cleaning

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

Take the following steps when cleaning.

The following images are for reference only. Real-life situations may differ from what is shown in the

images.

Storage

High-glossy models can develop white stains on the surface if an ultrasonic wave humidifier is used

nearby.

Contact Customer Service Center if the inside of the product needs cleaning (service fee will be

charged).

1. Power off the product and computer.

2. Disconnect the power cord from the product.

Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

3. Wipe the product with a clean, soft and dry cloth.

Do not use detergents that contain alcohol, solvent or

surface-active agents.

Do not spray water or detergent directly on the product.

4. Wet a soft and dry cloth in water and wring thoroughly to clean the exterior

of the product.

5. Connect the power cord to the product when cleaning is finished.

6. Power on the product and computer.

Before Using the Product

Safety Precautions

Symbols

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)

THERE ARE NO USER SERVICEABLE PARTS INSIDE.

REFER ALL SERVICING TO QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside.

It is dangerous to make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and maintenance

has been included with this product.

Warning A serious or fatal injury may result if instructions are not followed.

Caution Personal injury or damage to properties may result if instructions are not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.
