Samsung SyncMaster S19B420BW Manual de usuario

User manual

S19B420BW

S19B420B

S19B420M

S22B420BW

S24B420BW

The color and the appearance may differ depending on

the product, and the specifications are subject to

change without prior notice to improve the performance.

BN46-00232A-13

Table Of Contents 2

Table Of Contents

BEFORE USING THE

PRODUCT

7 Copyright

7 Icons used in this manual

7 Symbols for safety precautions

8 Cleaning

9 Securing the Installation Space

9 Precautions for storage

10 Safety Precautions

10 Electricity and Safety

11 Installation and Safety

13 Operation and Safety

16 Correct posture to use the product

PREPARATIONS 17 Checking the Contents

17 Removing the Packaging

18 Checking the Components

19 Parts

19 Frontal Buttons

21 Reverse Side

22 Installation

22 Attaching the Stand

23 Adjusting the Product Tilt and Height

23 Rotating the Monitor

24 Installing a Wall-mount Kit or Desktop Stand

25 Anti-theft Lock

CONNECTING AND USING

A SOURCE DEVICE

26 Before Connecting

26 Pre-connection Checkpoints

26 Connecting the Power

Table Of Contents

Table Of Contents 3

27 Connecting and Using a PC

27 Connecting to a PC

30 Driver Installation

31 Setting Optimum Resolution

32 Changing the Resolution Using a PC

SCREEN SETUP 36 Brightness

36 Configuring Brightness

37 Contrast

37 Configuring Contrast

38 Sharpness

38 Configuring Sharpness

39 SAMSUNG MAGIC Bright

39 Configuring SAMSUNG MAGIC Bright

40 SAMSUNG MAGIC Angle

40 Configuring SAMSUNG MAGIC Angle

41 Coarse

41 Adjusting Coarse

42 Fine

42 Adjusting Fine

CONFIGURING TINT 43 SAMSUNG MAGIC Color

43 Configuring SAMSUNG MAGIC Color

44 Red

44 Configuring Red

45 Green

45 Configuring Green

46 Blue

46 Configuring Blue

47 Color Tone

47 Configuring the Color Tone Settings

Table Of Contents

Table Of Contents 4

48 Gamma

48 Configuring Gamma

RESIZING OR

RELOCATING THE

SCREEN

49 H-Position & V-Position

49 Configuring H-Position & V-Position

50 Image Size

50 Changing the Image Size

52 Menu H-Position & Menu V-Position

52 Configuring Menu H-Position & Menu V-

Position

SETUP AND RESET 53 Reset

53 Initializing Settings (Reset)

54 Language

54 Changing the Language

55 Eco Saving

55 Configuring Eco Saving

56 Off Timer On/Off

56 Configuring Off Timer On/Off

57 Off Timer Setting

57 Configuring Off Timer Setting

58 PC/AV Mode

58 Configuring PC/AV Mode

59 Key Repeat Time

59 Configuring Key Repeat Time

60 Customized Key

60 Configuring Customized Key

61 Auto Source

61 Configuring Auto Source

62 Display Time

62 Configuring Display Time

Table Of Contents

Table Of Contents 5

63 Menu Transparency

63 Changing Menu Transparency

INFORMATION MENU AND

OTHERS

64 INFORMATION

64 Displaying INFORMATION

65 Configuring Brightness and Contrast in

the Initial Screen

INSTALLING THE

SOFTWARE

66 Magic Tune

66 What is MagicTune?

66 Installing the Software

67 Removing the Software

68 MultiScreen

68 Installing the Software

69 Removing the Software

70 MagicRotation

70 Installing the Software

72 Removing the Software

TROUBLESHOOTING

GUIDE

73 Requirements Before Contacting

Samsung Customer Service Center

73 Testing the Product

73 Checking the Resolution and Frequency

73 Check the following.

76 Q & A

SPECIFICATIONS 78 General

82 PowerSaver

83 Standard Signal Mode Table

APPENDIX 89 Contact SAMSUNG WORLD WIDE

Table Of Contents

Table Of Contents 6

95 Responsibility for the Pay Service (Cost

to Customers)

95 Not a product defect

95 A Product damage caused by customer's fault

95 Others

96 Correct Disposal

96 Correct Disposal of This Product (Waste

Electrical & Electronic Equipment)

97 Terminology

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is

prohibited.

Microsoft, Windows and Windows NT are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Icons used in this manual

Symbols for safety precautions

An administration fee may be charged if either

(a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

(b) you bring the unit to a repair center and there is no defect in the product

(i.e. where you have failed to read this user manual).

The amount of such administration charge will be advised to you before any work or home visit is

carried out.

The following images are for reference only. Real-life situations may

differ from what is shown in the images.

Warning A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are

not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.

Before Using the Product

Cleaning

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

Take the following steps when cleaning.

1. Power off the monitor and computer.

2. Disconnect the power cord from the monitor.

Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

3. Wipe the monitor screen using a clean, soft and dry cloth.

Do not apply a cleaning agent that contains alcohol,

solvent, or surfactant to the monitor.

Do not spray water or detergent directly on the product.

4. Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the monitor.

5. Connect the power cord to the product after cleaning the product.

6. Power on the monitor and computer.

Before Using the Product

Securing the Installation Space

Ensure some space around the product for ventilation. An internal temperature rise may cause fire

and damage the product. Be sure to allow the amount of space as shown below or greater when

installing the product.

The exterior may differ depending on the product.

Precautions for storage

Be sure to contact Samsung Customer Service Center (page 89) if the inside of the monitor needs

cleaning. (Service fee will be charged.)

10 cm(3.93 inches)

10 cm

(3.93

inches)

10 cm

(3.93

inches)

Before Using the Product

Safety Precautions

Electricity and Safety

The following images are for reference only. Real-life situations may differ from what is shown in the

images.

Warning

Do not use a damaged power cord or plug, or a loose power socket.

An electric shock or fire may result.

Do not plug many products into the same power socket.

Otherwise, the socket may overheat and cause a fire.

Do not touch the power plug with wet hands.

Otherwise, an electric shock may result.

Insert the power plug all the way in so it is not loose.

An unstable connection may cause a fire.

Ensure you connect the power plug to a grounded power socket. (type 1

insulated devices only).

An electric shock or injury may result.

Do not bend or pull the power cord with force. Do not weigh the power cord

down with a heavy object.

A damaged power cord may cause an electric shock or fire.

Do not place the power cord or product near heat sources.

An electric shock or fire may result.

Remove foreign substances such as dust around the plug pins and power socket

with a dry cloth.

Otherwise, a fire may result.
